Enerpac REB-5 User manual

Repair Parts Sheets for this product are available from the Enerpac
web site at www.enerpac.com, or from your nearest Authorized
Enerpac Service Center or Enerpac Sales office.
1.0 IMPORTANT RECEIVING INSTRUCTIONS
Visually inspect all components for shipping damage. Shipping
damage is not covered by warranty. If shipping damage is found,
notify carrier at once. The carrier is responsible for all repair and
replacement costs resulting from damage in shipment.
SAFETY FIRST
2.0 SAFETY ISSUES
Read all instructions, warnings and cautions carefully.
Follow all safety precautions to avoid personal injury
or property damage during system operation. Enerpac
cannot be responsible for damage or injury resulting from unsafe
product use, lack of maintenance or incorrect product and/or
system operation. Contact Enerpac when in doubt as to the safety
precautions and operations. If you have never been trained on high-
pressure hydraulic safety, consult your distribution or service center
for a free Enerpac Hydraulic safety course.
Failure to comply with the following cautions and warnings could
cause equipment damage and personal injury.
A CAUTION is used to indicate correct operating or maintenance
procedures and practices to prevent damage to, or destruction of
equipment or other property.
A WARNING indicates a potential danger that requires correct
procedures or practices to avoid personal injury.
A DANGER is only used when your action or lack of action may
cause serious injury or even death.
WARNING: Wear proper personal protective gear when
operating hydraulic equipment.
WARNING: Stay clear of loads supported by hydraulics.
A cylinder, when used as a load lifting device, should never
be used as a load holding device. After the load has been
raised or lowered, it must always be blocked mechanically.
WARNING: USE ONLY RIGID PIECES TO HOLD LOADS.
Carefully select steel or wood blocks that are capable of
supporting the load. Never use a hydraulic cylinder as a
shim or spacer in any lifting or pressing application.
DANGER: To avoid personal injury keep hands and
feet away from cylinder and workpiece during
operation.
WARNING: Do not exceed equipment ratings. Never
attempt to lift a load weighing more than the capacity of the
cylinder. Overloading causes equipment failure and
possible personal injury. The cylinders are designed for a max.
pressure of 700 bar [10,000 psi]. Do not connect a jack or cylinder
to a pump with a higher pressure rating.
Never set the relief valve to a higher pressure than the
maximum rated pressure of the pump. Higher settings may
result in equipment damage and/or personal injury.
WARNING: The system operating pressure must not
exceed the pressure rating of the lowest rated component
in the system. Install pressure gauges in the system to
monitor operating pressure. It is your window to what is happening
in the system.
CAUTION: Avoid damaging hydraulic hose. Avoid sharp
bends and kinks when routing hydraulic hoses. Using a
bent or kinked hose will cause severe back-pressure.
Sharp bends and kinks will internally damage the hose leading to
premature hose failure.
Do not drop heavy objects on hose. A sharp impact may
cause internal damage to hose wire strands. Applying
pressure to a damaged hose may cause it to rupture.
IMPORTANT: Do not lift hydraulic equipment by the hoses
or swivel couplers. Use the carrying handle or other means
of safe transport.
CAUTION: Keep hydraulic equipment away from
flames and heat. Excessive heat will soften packings
and seals, resulting in fluid leaks. Heat also weakens
hose materials and packings. For optimum performance do not
expose equipment to temperatures of 65°C [150°F] or higher.
Protect hoses and cylinders from weld spatter.
DANGER: Do not handle pressurized hoses. Escaping oil
under pressure can penetrate the skin, causing serious
injury. If oil is injected under the skin, see a doctor
immediately.
WARNING: Only use hydraulic cylinders in a coupled
system. Never use a cylinder with unconnected couplers. If
the cylinder becomes extremely overloaded, components
can fail catastrophically causing severe personal injury.
WARNING: BE SURE SETUP IS STABLE BEFORE
LIFTING LOAD. Cylinders should be placed on a flat
surface that can support the load. Where applicable, use a
cylinder base for added stability. Do not weld or otherwise
modify the cylinder to attach a base or other support.
Avoid situations where loads are not directly centered on
the cylinder plunger. Off-center loads produce
considerable strain on cylinders and plungers. In addition,
the load may slip or fall, causing potentially dangerous results.
Distribute the load evenly across the entire saddle surface.
Always use a saddle to protect the plunger.
IMPORTANT: Hydraulic equipment must only be serviced
by a qualified hydraulic technician. For repair service,
contact the Authorized ENERPAC Service Center in your
area. To protect your warranty, use only ENERPAC oil.
WARNING: Immediately replace worn or damaged parts
by genuine ENERPAC parts. Standard grade parts will
break causing personal injury and property damage.
ENERPAC parts are designed to fit properly and withstand high
loads.
®
®
®
®
®
Instruction Sheet
BASE CLEVIS ATTACHMENTS
L1326 Rev. O 07/89

CAUTION: Always provide clearance for hoses and
couplers to avoid moving objects, abrasion or sharp
objects.
3.0 Purpose
1. Base clevis attachments fit ENERPAC RE single-acting
cylinders using socket head capscrews. Cylinder capacities
are 5 through 25 ton. (See Data Chart.)
2. Clevis attachments provide a method of attaching cylinders
to custom fixtures or set-ups for a pushing operation only.
CAUTION: Do not use clevis attachment for pulling
operations. When used properly the clevis is capable of
withstanding full rated cylinder capacity.
4.0 INSTALLATION
1. Place the clevis over the cylinder base. Align the two
mounting holes. Install two socket head capscrews. See
below for recommended sizes. Torque capscrews tovalues
shown below.
Clevis Capscrew Torque Values Dry
Model Sizes Lubricated
REB-5 1/4 - 20 x 5/8" long 8 - 10 ft-lbs. 11 - 13 ft-lbs.
REB-10 5/16 - 18 x 5/8" long 16 - 20 ft-lbs. 22 - 27 ft-lbs.
REB-15 3/8 - 16 x 3/4" long 27 - 35 ft-lbs. 39 - 47 ft-lbs.
REB-20 1/2 - 13 x 3/4" long 73 - 89 ft-lbs. 98 - 118 ft-lbs
Clevis Model Pin Size Yield Strength
REB-5 5/8" diameter 50,000 PSI
REB-10 7/8" diameter 60,000 PSI
REB-15 7/8" diameter 60,000 PSI
REB-20 1-1/4" diameter 60,000 PSI
Figure 1
2. Install the cylinder and clevis into fixture by inserting cold
drawn steel pins through the clevis and fixture. See figure 1
for pin sizes and the recommeded fixture mounting condition.
View "A" is correct and provides a stable condition. View "B"
and "C" are incorrect.
CORRECT
View
AView
C
INCORRECT INCORRECT
View
B
Cylinder
Base
Clevis
Pin
Fixture
DATA CHART
C
B
D
E
H
GF
A
J
M
I
L
Cyl. Dimensions — In Inches Order
Cap. ABC DE F GH I J LM Model
(tons) No.
5* 11⁄21⁄41⁄221⁄85⁄811⁄89⁄16 5⁄819⁄16 1⁄413⁄4REB-5
10 21⁄41⁄41⁄227⁄811
11⁄16 17⁄819⁄16 15⁄16 21⁄2REB-10
15 23⁄41⁄41⁄227⁄811
11⁄16 17⁄817⁄813⁄83REB-15
20 33⁄81⁄41⁄233⁄811⁄421⁄411⁄211⁄425⁄16 11⁄29⁄16 33⁄4REB-25
*Not usable with RC and JSS-50 cylinders.
BASE CLEVIS
Attached to cylinder base with capscrews.
See torque table in installation procedure.
