Echo Speed-Feed Universal 400 LH/RH User manual

Speed-Feed® Universal 400 LH/RH Trimmer Head
P/N 99944200907
Installation and Loading Instructions
Package Contents:
1 Speed-Feed® 400 LH/RH Universal Mount Trimmer Head (K)
Bushings
(F) 1 - 8mm x 1.25mm LH Bushing (Red)
(G) 1 - 10mm x 1.0mm LH Bushing (Green)
(E) 1 - 10mm x 1.25mm LH Bushing (Gold)
(J) 1 - 10mm x 1.25 LH Long Bushing (Silver)
(N) 1 - 3/8-24 RH Bushing (Black)
Spacer
(M) 1 - Reversible Nylon Spacer w/20/25/38 mm Recesses
Trimmer Head Installation
1. Insert locking tool (A) into gear case to lock output shaft (B). Remove existing cutting attachment (C) from unit
following manufacturer’s instructions.
IMPORTANT: Your unit must be equipped with a debris shield including a line cutter that will cut line to length
when trimmer line is advanced.
2. Install or reuse unit manufacturer’s gear case base plate (D). Base plate must support trimmer head and allow it
to rotate freely.
3. Select and Install Mounting Hardware
Use the Speed-Feed® Application Chart provided to identify the bushing or bushing and mounting stud
combination needed for your model.
IMPORTANT: For Echo SRM units only. Check debris shield on unit for “R” mark between cutoff blade
screws.
 a. Unitswith“R”mark–Echolineheadwilltonunitasis-gotoStep6.
b. Units without “R” mark – Remove short bushing (E) from Echo line head and replace with long
bushing (J) and use spacer (M).
NOTE: If your brand or model number is not listed, match the existing mounting hardware from your model
with Echo mounting studs and/or bushings to determine the correct parts needed. If you need help, visit www.
echo-usa.com, or call the Consumer Product Support Department at 1-800-432-3246 from 8:30 am to 4:30 pm
(Central Time) Monday through Friday.
NOTE: Gold bushing (E) (used with LH1,LH2,LH6)ispreinstalledintrimmerhead.Blackbushing(N)(used
with RH 1 and RH 2) is preinstalled in white core (P). If required, depress locking tabs (T), and open trimmer
head (K) to install new parts. Reassemble trimmer head in reverse order of disassembly. Make sure “L”
mark is facing away from bushing when replacing spool for LH units. Make sure “R” mark is facing away from
bushing for RH units. Trimmer head halves will snap together tightly only if parts are properly assembled.
4. If required, install new mounting stud into threaded hole in gear case output shaft (B). Turn “LH” studs
counterclockwise to tighten. Turn “RH” stud clockwise to tighten.
5. If required, place reversible spacer (M) on base plate of gearcase, matching spacer recess to pilot diameter of
base plate.
NOTE: When spacer is properly matched and installed, there should be no gap between spacer and base
plate on gearcase.
6. Attach New Trimmer Head (K)
Thread LH trimmer head counterclockwise on to mounting stud or output shaft. Thread RH trimmer head on
clockwise. Hand-tighten only.
Echo SRM Only NOTE: There should be no gap between spacer and line head after tightening.
IMPORTANT:Donotforce,otherwisethreadswillstripandcausepermanentdamage.Unscrewandconrm
correct thread size.
7. Remove locking tool (A) from gear case.
8. If necessary, cut trimmer lines so length does not extend beyond the cut-off blade on debris shield.
Operation
1. To feed trimmer line, bump bottom of trimmer head against ground while running at normal operating speed.
Loading Instructions – See Page 4.
X7672052500
07/13
Mounting Studs
(H) 1 - 7mm x 10mm (LH) Mounting Stud (Gold)
(I) 1 - 8mm x 10mm (LH) Mounting Stud (Silver)
(O) 1 - 8mm x 3/8-24 (RH) Mounting Stud (Black)
Core
(P) 1 - White RH Core
B
C
A
D
I
E
E, F, G, or J T
T
HGF
D
B
K
H,I,O
A
A
Echo SRM Only
“R”
O
N
P
“R”
M
J
“RH”
“LH”
J
“L”
“RH” “LH”

4
Chargement de la ligne du taille-bordures
1. Couper un morceau de ligne de la longueur préconisée.
2.Alignerlesèchesdelapartiesupérieureduboutonaveclestrousdes
œillets.
3. Insérer une extrémité de la ligne de coupe dans un œillet et pousser la
lignejusqu’àmi-longueuràtraverslatêtedecoupe.
4. Maintenir la tête de coupe en tournant le bouton dans pour enrouler la
lignesurlabobinejusqu’àcequ’ilresteunelongueurd’environ13cm(5”)
sortie à chaque extrémité.
La tête de coupe est à présent complètement chargée et prête pour
le fonctionnement.
Longueur totale capacité de ligne de coupe du taille-bordures
Speed-Feed® 400 LH/RH
ENGLISH
FRANCAIS
.080 (2.0 mm) dia. – 20’ (6 m)
.095 (2.4 mm) dia. – 20’ (6 m)
Carga del hilo de la recortadora
1.Corte un pedazo de hilo a la longitud recomendada.
2.Alineelasechasdelapartesuperiordelaperillaconlasaberturas
enlosojales.
3.Inserteunextremodelhilodelarecortadoraenunojal,yempujeel
hilo una misma distancia por la cabeza de la recortadora.
4.Sujetelacabezadelarecortadoramientrasgiralaperillaenelcarrete
hasta que queden al descubierto unos 13 cm (5”) de cada hilo.
La cabeza de la recortadora está ahora completamente cargada y
lista para la operación.
Hilo total capacidad de la cabeza de recortadora
Speed-Feed® 400 LH/RH
ESPAñOL
.080 (2.0 mm) dia. – 20’ (6 m)
.095 (2.4 mm) dia. – 20’ (6 m)
Speed-Feed® 400 LH/RH Trimmer Head Total Line Capacity
Loading Trimmer Line
1. Cut one piece of line to recommended length.
2. Align arrows on top of knob with openings in eyelets.
3. Insert one end of trimmer line into an eyelet, and push line equal distance
through trimmer head.
4. Hold trimmer head while turning knob to wind line onto spool until about 5”
(13 cm) of each line remains exposed.
Trimmer head is now fully loaded and ready for operation.
.080 (2.0 mm) dia. – 20’ (6 m)
.095 (2.4 mm) dia. – 20’ (6 m)
Loading Instructions
Instructions De Chargement
NOTE: Trimmer head is pre-wound with .095" (2.4mm) Crossfire™ trimmer
line.
REMARQUE : Une ligne Crossfire™ de 2,4 mm (0,095”) a été pré-enroulée
sur la tête de coupe du taille-bordures.
NOTA:Lacabezadelarecortadoraestáenrolladadeantemanoconunhilo
de recortadora de 2.4 mm (0.095”) Crossfire™.
Instrucciones De Carga
“RH”
“LH”

5
Wear Indicators
Indicateurs d’usure
Indicadores de desgaste
Wear Indicators
Indicateurs d’usure
Indicadores de desgaste
IMPORTANT! When the wear indicators located at the bottom of the Speed-Feed® head are worn smooth, or if holes appear,
replacement of the cover or the entire Speed-Feed® head is required.
IMPORTANT! Lorsque les indicateurs d’usure placés sous la tête Echo sont complètement usés, il faut remplacer la totalité de
la tête.
¡IMPORTANTE! Cuando los indicadores de desgaste ubicados en la parte inferior de la cabeza Speed-Feed© estén lisos por el
desgaste, o si aparecen agujeros, será necesario reemplazar la cubierta o toda la cabeza Speed-Feed©.
Speed-Feed® LH/RH Trimmer Head Application Chart
Tabella di applicazione LH/RH testina del bordatore
Tabla De Aplicaciones LH/RH De Cabezales
PROMACSERIES:III,IIISUP,IVSUP,PROSCAPER;SERIES:28S,
32H,32HDS,IIIIV,V,IS,II,IIHD,SEBIC,SUPMAC100A;PS1,PS2,
PS3,PS4,PS5,SEBIV;EBSERIES:III,IVSL,3,4,3SX,32BCS,
35L,280,282,285BCS,297BCS,325BC,327BC,2815,28162817,
2818
MAC22/23/30A,SUPERMAC30AV,MS33,DELTA,38AV,MS40,
BP30AV,TD2400/3300/4000
MAC57,MAC90,MAC95,MAC100A,MAC32,MAC37LH3
BC220DL,BC221DL,BC300DL,BC2300DL,BK235FL,BK345FL,
BK435FL,BK530DL,BC17,BC23,BC32,BC240DLLH1
BC260DL,BC261DL,BC262DL,BC340DL,BC341DL,BC342DL,
BC2600DL,BC430DWM,BC440DWM,BK346FL,BK245FLK,
BK436FL,BC245A,BC260DM/DMU,BC340DWM/FW,BC431DWM,
BCD20,BCF01,BC2601S,BC3400DW,BC4400DW,BCX2600DS,
BCZ2500S/SU/SW
BC430DWM,BC440DWM,BC441DWM,BC442DWM,BC531DWM,
BC532DWM,FBC22,FBC26LH3
BC200,BC2000DL,BT2000,BT2001DLLH6
22T,C230,C242,C2510,T195s,T220,T222,T230,T231,T230s,
T242,C242,T242X,T2510,C2510,T2510X
C3410,T3410,C260,T260,T261,T261B/XR/XB,T270,T272,
T272X,T282,C282,T300,T3410,T3410X,T350
BP35,B45,B450,C350LH3
T235,T344,C344,T254,C254 LH6
FS51, FS55, FS60, FS61, FS65, FS80,FS83, FS85, FS86,
FS90,FS91,FS96
FS66,FS74,FS76,FS81,FS83,FS85,FS86,FS100,FS106,FS108,
FS110,FS130,FS250,FS44, FS45, FS46, FS48, FS52, FS56,
FS62,FS66,FS85,FS86,FS88,FS96,FS106,FS108,FS120,FS200,
FS350,FS450,FS550
DOLMAR/SACHS
DOLMAR BC250,BC330,BC400,PRO370,PRO400,SD330,LT250 LH2
STIHL
LH5
LH1
LH2
LH3
LH1
LH2
LH2
LH2
LH6
McCULLOCH
REDMAX
SHINDAIWA
MODELS REF#
ECHO SRMSERIES:140,200,202,210,220,230,250,251,260,261,
265,266,280,300,302,303,311,330,340,343,350,400,402,500,
501,1500,1501,2010,2090,2100,2110,2200,2201,2300,2301,
2400,2410,2450,2500,2501,2502,2510,2530,2601,3000,
3001,3010,3100,3110,3400,3410,3500,3550,3800,4600
HOMELITE HK24(to1/1/’86),HK30(after1/1/86),HK33(to1/1/86) LH2
BCH20,BCH24,BCH32,BCH33,BCH40,BCH48,HBC30,HBC38,
HK15,HK18(after1/1/86),HK28,HK24(after1/1/86),HK25,
HK30(upto1/86),HK33(after1/1/86),HK38,PBC3600,PBC
3800,PBC4000,PBC4000,PLT3400,ST285,ST155,ST175,
ST385,ST485
FK514,NBA524,PMB522,SX040,SXD40,TXD508 LH3
HBC40,PBC3800,PBC4000,PMB52,HBC48 LH6
ST80/385(EURO) LH2
ST100/200/400,SXD20,RK521,TK518 LH4
HONDA UMK422LNA/LTA,UMK431LNA/TA/UNBA,HHT25SLTAT,
HHT35SLTAT,HHT35SUKAT LH6
(UPTO86)16R,22R,24R,25RL LH2
24R(uptoser#603702) LH1
26LC,26RLC,32LC,32RLC,MONDO RH1
122L,125L,225L,225LD,225R,225RD,225RJ,227LD,232L,
232R,322L,322R,324LX,325LX/RX,326LS/LX,335LS
JONSERED BP40,BP40COMBI,BP2040,BR400,BR420,BR450,BR460,
BR480,BR500,Tiger40,GT21L,GT22L,GT24L,GR26COMBI,
GR26D,GR26L,GR32L,GR2026CL,GR2026D,LR200,LR220,
LR260,LR320,LR400,LR420,LR450,LR460
RS38ANCIEN,RS38olderLH5
RS44,GR44,GR41,J40D,KQ20/30(EURO)LH6
BC184,BC184C,BC200,BC201,BC230,BC241,BC260,BC260H,
BC310,BC320,BC320H,BC326,BC340DL,BC402,BC420H,
BC500,BC500H,BC2300,BC2321,BC2600,BC3021,BC3200,
BC4200H,BCL2550,BCGX22,BCGX31,BCL2250,BCL2250C,
BST23,MC5,NC8
BC220DL,BC221DL LH1
BT17,BT220,BC200C,BC260C LH4
BC184C,BC200C,BC260CLH6
BC430DWM,BC440DWM,32,35,BC500 LH3
MAC57,MAC90,MAC95,MAC100ALH3
LH6
LH4
HUSQVARNA
MARUYAMA
LH6
LH2
LH2

6
REF#
