EnGenius EZ Hotspot V3 Manual

EZ Setup V3
EZ Hotspot Extender
EnGenius Europe | Veldzigt 28, 3454 PW Utrecht (NL)
0900-WIFIABC | www.wiabc.com
Disclaimer: Information may be subject to changes without prior notication.
Remove the rear bottom panel.
Connect one end of the Ethernet cable (not supplied) to the LAN
(PoE) port on the EZ Hotspot Extender. The LAN (PoE) port can be
founded on the right-hand side as seen from the back of the device.
Connect the other end of the Ethernet cable to the PoE injector’s
PoE port. Connect the power adapter DC inlet to the 24V DC IN of
the PoE Injector and the power adapter to an electrical outlet. The
device is ready for conguring when the two LEDs (Power and
Wireless) are lit and the green LED stops blinking. This may take
about 30 seconds.
1
2
3

EZ Setup V3
EZ Hotspot Extender
Follow us
https://www.linkedin.com/company/engeniuseurope
https://plus.google.com/+EngeniusEuropeBVDeMeern
https://www.youtube.com/user/engeniuseuropebv
https://twitter.com/engeniuseu
Type ezhotspot.eu in your browser.
Select which option applies at your location.
For an extended installation version see www.engenius-europe.com.
Go to your network center, view the SSIDs (network names) and
select ez@XXXXXX. You can nd this address at the back panel of
your product. Enter your password (this is also on the back panel).
5
6
4
