EnGenius EAP350 User manual

1
High Powered Gigabit Wired 802.11 b/g/n
Multi-Function Access Point
EAP350
11N Multi-Function Access Point
V1.0

1
Table of Contents
1Introduction ....................................................................................................................................................................... 4
1.1 Features and Benefits .....................................................................................................................................................................................4
1.2 Package Contents ............................................................................................................................................................................................5
1.3 System Requirements.....................................................................................................................................................................................6
1.4 Applications .......................................................................................................................................................................................................6
2Before you Begin............................................................................................................................................................... 8
2.1 Considerations for Wireless Installation ..................................................................................................................................................8
2.2 Computer Settings (Windows XP/Windows 7)......................................................................................................................................9
2.3 Apple Mac X OS................................................................................................................................... Error! Bookmark not defined.
2.4 Hardware Installation......................................................................................................................... Error! Bookmark not defined.
3Configuring Your Access Point ...................................................................................................................................... 15
3.1 Default Settings ................................................................................................................................... Error! Bookmark not defined.
3.2 Web Configuration............................................................................................................................. Error! Bookmark not defined.
4Status ................................................................................................................................................................................ 18
4.1 Save/Reload .................................................................................................................................................................................................... 18
4.2 Main................................................................................................................................................................................................................... 19
4.3 Wireless Client List........................................................................................................................................................................................ 21
4.4 System Log ...................................................................................................................................................................................................... 22
5System .............................................................................................................................................................................. 23
5.1 Operation Mode............................................................................................................................................................................................ 23
5.2 IP Settings........................................................................................................................................................................................................ 25
5.3 Spanning Tree Setting................................................................................................................................................................................. 26
6Wireless ............................................................................................................................................................................ 28

2
6.1 Wireless Network .......................................................................................................................................................................................... 28
6.2 Wireless Security ........................................................................................................................................................................................... 31
6.3 Wireless MAC Filter ...................................................................................................................................................................................... 35
6.4 Wireless Advanced ....................................................................................................................................................................................... 36
6.5 WPS (Wi-Fi Protected Setup).................................................................................................................................................................... 38
6.6 WDS Link Settings......................................................................................................................................................................................... 40
7Management.................................................................................................................................................................... 42
7.1 Administration................................................................................................................................................................................................ 42
7.2 Management VLAN...................................................................................................................................................................................... 43
7.3 SNMP................................................................................................................................................................................................................. 44
7.4 Backup/Restore.............................................................................................................................................................................................. 46
7.5 Firmware Upgrade........................................................................................................................................................................................ 47
7.6 Time Setting.................................................................................................................................................................................................... 48
7.7 Log...................................................................................................................................................................................................................... 49
7.8 Diagnosis.......................................................................................................................................................................................................... 50
7.9 LED Control ..................................................................................................................................................................................................... 51
7.10 Logout............................................................................................................................................................................................................... 52
7.11 Reset .................................................................................................................................................................................................................. 53
8Building a Wireless Network ......................................................................................................................................... 54
8.1 Access Point Mode....................................................................................................................................................................................... 54
8.2 Access Point Mode with WDS Function (WDS AP mode).............................................................................................................. 55
8.3 WDS Bridge Mode........................................................................................................................................................................................ 56
Appendix A – FCC Interference Statement .......................................................................................................................... 57

3
Revision History
Version
Date
1.0
Dec 01, 2011

4
1Introduction
The EAP350 is a Gigabit wired multi-functioned 802.11b/g/n product with 3 major functions. It is designed to operate
in every working environment for enterprises.
The EAP350 is a Wireless Network device that delivers up to 6x faster speeds and 7x extended coverage than 802.11b/g
devices. The EAP350 supports use in the home/office network with superior throughput, performance, and unparalleled
wireless range.
To protect data during wireless transmissions, the EAP350 encrypts all wireless transmissions through WEP data
encryption and supports WPA/WPA2 encryption. Its MAC address filter allows users to select stations to access the
network. The EAP350 is an ideal product to ensure network safety for both home and SMB environments.
1.1 Features and Benefits
Features
Benefits
High Speed Data Rate Up to 300Mbps Capable of handling heavy data payloads such as MPEG video
streaming.
10/100/1000 Fast Ethernet Support up to 1Gbps networking speed.
IEEE 802.11n draft Compliant and backward
compatible with 802.11b/g
Fully compatible with IEEE 802.11b/g/n devices.
Multi-Function, 3 functions Allowing users to select AP, WDS AP or WDS Bridge mode in
various applications.
Point-to-point, Point-to-multipoint Wireless
Connectivity
Allow transferring data from building to building.

5
Support Multi-SSID function (4 SSID) in AP
mode
Allows clients to access different networks through a single access
point and assign different policies and functions for each SSID
through the built in software.
WPA2/WPA/ IEEE 802.1x support Powerful data security.
MAC address filtering in AP mode Ensuring secure network connection.
User isolation support (AP mode) Protecting the private network between client users.
Power-over-Ethernet (IEEE802.3af) Flexible Access Point locations and saving cost.
Save User Settings Firmware upgrade does not delete user settings.
SNMP Remote Configuration Management Allows remote connection to configure or manage the EAP350
easily.
QoS (WMM) support Enhancing user performance and density.
1.2 Package Contents
The package contains the following items. In case of return, please keep the original box set, and the complete box set
must be included for full refund.
•EAP350
•12V/1A 100V~240V Power Adapter
•RJ-45 Ethernet LAN Cable
•CD-ROM with User's Manual
•Quick Guide

6
1.3 System Requirements
The following are the minimum system requirements in order configure the device.
•Computer with an Ethernet interface or Wireless Network.
•Windows, Mac OS, or Linux based operating systems.
•Web-Browsing Application (example: Internet Explorer, FireFox, Safari, or other similar software)
1.4 Applications
Access Point products are easy to install and highly efficient. The following list describes some of the many applications
made possible through the power and flexibility of the use of Wireless Access Points:
a) Difficult-to-Wire Environments
There are many situations where wires cannot be laid easily. Historic buildings, older buildings, multiple
buildings, and/or open areas make the installation of a Wired LAN impossible, impractical, and/or expensive.
b) Temporary Workgroups
Consider situations in open areas such as parks, athletic arenas, exhibition centers, temporary offices, and
construction sites where one wants a temporary Wireless LAN established and easily removed.
c) The Ability to Access Real-Time Information
Doctors/Nurses, Point-of-Sale Employees, and/or Warehouse Workers can access real-time information while
dealing with patients, serving customers, and/or processing information.
d) Frequently changed environments
Show rooms, meeting rooms, retail stores, and manufacturing sites where the network connection needs to
frequently be taken down.

7
e) Small Office and Home Office (SOHO) Networks
SOHO users need a cost-effective, easy and quick installation of a small network.
f) Wireless Extensions to Ethernet networks
Network managers in dynamic environments can minimize the overhead caused by moves, extensions to
networks, and other changes with wireless LANs.
g) Wired LAN backup
Network managers implement wireless LANs to provide backup for mission-critical applications running on
wired networks.
h) Training/Educational facilities
Training sites at corporations and students at universities use wireless connectivity to ease access to
information, information exchanges, and learning.

8
2Before you Begin
This section will guide you through the installation process. Placement of the ENGENIUS EAP350 is very important to
maximize the EAP350’s performance. Avoid placing the EAP350 in an enclosed space such as a closet, cabinet, or
wardrobe.
2.1 Considerations for Wireless Installation
The operating distance of all wireless devices cannot be pre-determined due to a number of unknown obstacles in the
environment that the device is deployed in. These could be the number, thickness, and location of walls, ceilings, or
other objects that the wireless signals must pass through. Here are some key guidelines to ensure that you have the
most optimal wireless range.
•Keep the number of walls and/or ceilings between the EAP350 and other network devices to a minimum. Each wall
and/or ceiling can reduce the signal strength, resulting in lower signal strength.
•Building materials makes a difference. A solid metal door and/or aluminium stubs may have a significant negative
effect on the signal strength of the EAP350. Locate your wireless devices carefully so the signal can pass through a
drywall and/or open doorways. Materials such as glass, steel, metal, concrete, water (example: fish tanks), mirrors, file
cabinets, and/or brick can also lower your wireless signal strength.
•Interferences can also come from other electrical devices and/or appliances that generate RF noise. The most usual
types are microwaves and cordless phones.

9
2.2 Computer Settings (Windows XP/Windows 7)
In order to use the EAP350, you must first configure the TCP/IPv4 connection of your computer system.
•Click Start button and select Control Panel.
Windows XP Windows Vista/Windows 7

10
•In Windows XP, click Network Connections
•In Windows 7, click View Network Status and Tasks in the Network and Internet section, then select Change
Adapter Settings
•Right click on Local Area Connection and select Properties

11
•Highlight Internet Protocol Version 4 (TCP/IPv4) and select
Properties
•Select Use the following IP address and enter IP address and subnet
mask then press OK.
Note: Ensure that the IP address and subnet mask are on the same
subnet as the device.
For example: Device IP address: 192.168.1.1
PC IP address: 192.168.1.2 - 192.168.1.999
PC subnet mask: 255.255.255.0

12
2.3 Apple Mac X OS
•Open the System Preferences (can be opened in the Applications folder or selecting it in the Apple Menu)
•Select Network in the Internet & Network section
•Highlight Ethernet
•In Configure IPv4, select Manually
•Enter IP address and subnet mask then press OK.
Note: Ensure that the IP address and subnet mask are on the same subnet as the device.
For example: Device IP address: 192.168.1.1
PC IP address: 192.168.1.2 - 192.168.1.999
PC subnet mask: 255.255.255.0
•Click Apply when done.

13
2.4 Hardware Installation
1) Ensure that the computer in use has an Ethernet Card (RJ-45 Ethernet Port). For more information, verify with our
computer user manual.
2) Connect one end of the Category 5 Ethernet cable into RJ-45 port of the EAP350 and the other end to the RJ-45
port on the computer that will use the EAP350. Ensure that the cable is securely connected to both the EAP350 and
the Computer.
3) Connect the Power Adaptor DC Inlet to the DC-IN port of the EAP350 and the Power Adaptor to the electrical out.
Once both connections are secure, verify the following:
a) Ensure that the Power light is on (it will be blue).
b) Ensure that the Wireless light is on (it will be blue).
c) Ensure that the LAN (Computer/EAP350 Connection) light is on (it will be blue).
d) Once all three lights are on, proceed to setting up the computer.
This diagram depicts the hardware configuration.

14
Front Panel Rear Panel
Front Panel
Reset Button
Press and hold the “Reset” button over 10 seconds to reset EAP350 to factory default.
LED Lights
LED lights for Wireless, Ethernet LAN port, and Power.
Rear Panel
DC IN
DC IN for Power.
Ethernet Port
Ethernet port for RJ-45 cable.

15
3Configuring Your Access Point
This section will show you how to configure the device using the web-based configuration interface.
3.1 Default Settings
Please use your Ethernet port or wireless network adapter to connect the Access Point.
Default Settings
IP Address
192.168.1.1
Username / Password
admin / admin
Operation Mode
Access Point
Wireless SSID
EnGeniusxxxxxx
Wireless Security
None
Note: xxxxxx represented in the wireless SSID above is the last 6 characters of your device MAC Address. This can be found on the device body
label and is unique for each device.

16
3.2 Web Configuration
•Open a web browser (Internet Explorer/Firefox/Safari) and enter the IP Address: http://192.168.1.1
Note: If you have changed the default LAN IP Address of the Access Point, ensure you enter the correct IP Address.
•The default username and password are admin. Once you have entered the correct username and password, click the
Login button to open the web-base configuration page.

17
•If successful, you will see the EAP350 User Menu

18
4Status
The Status section contains the following options: Save/Reload, Main, Wireless Client List, and System Log.
The following sections describe these options.
4.1 Save/Reload
This page let you save and apply settings shown under Unsaved changes list, or allow you to cancel unsaved changes
and revert to the previous settings that were in effect.

19
4.2 Main
Clicking the Main link under the Status menu or clicking Home at the top-right of the Web Configurator shows status
information about the current operating mode.
- The System Information section shows general system information such as device name, MAC address, current time,
firmware version and management VLAN ID.
- The LAN Settings section shows Local Area Network setting such as the LAN IP address, subnet mask, and DNS
address.
