EnGenius EAP300 User manual

1

1
Table of Contents
1Introduction ....................................................................................................................................................................... 5
1.1 Features and Benefits .....................................................................................................................................................................................5
1.2 Package Contents............................................................................................................................................................................................6
1.3 System Requirements.....................................................................................................................................................................................7
1. Applications .......................................................................................................................................................................................................7
2Before you Begin............................................................................................................................................................... 9
2.1 Considerations for Wireless Installation ..................................................................................................................................................9
2.2 Computer Settings (in Windows XP/Windows 7)..............................................................................................................................10
2.3 Computer Settings in Apple Mac OS X.................................................................................................................................................13
2. Hardware Installation...................................................................................................................................................................................1
3Configuring Your Access Point ...................................................................................................................................... 17
3.1 Default Settings.............................................................................................................................................................................................17
3.2 Web Configuration.......................................................................................................................................................................................18
Building a Wireless Network ......................................................................................................................................... 20
.1 Access Point Mode.......................................................................................................................................................................................20
.2 WDS AP Mode ...............................................................................................................................................................................................21
.3 WDS Bridge Mode........................................................................................................................................................................................22
. Repeater mode ..............................................................................................................................................................................................23
5Status ................................................................................................................................................................................ 2
5.1 Save/Reload....................................................................................................................................................................................................2
5.2 Main...................................................................................................................................................................................................................25
5.3 Wireless Client List........................................................................................................................................................................................28
5. Connection Status.........................................................................................................................................................................................29
5.5 WDS Link List..................................................................................................................................................................................................30

2
5.6 System Log......................................................................................................................................................................................................31
6System .............................................................................................................................................................................. 32
6.1 Operation Mode............................................................................................................................................................................................32
6.2 IP Settings........................................................................................................................................................................................................33
6.3 Spanning Tree Setting.................................................................................................................................................................................35
7Wireless ............................................................................................................................................................................ 37
7.1 Wireless Network..........................................................................................................................................................................................37
7.2 Wireless Security ........................................................................................................................................................................................... 1
7.3 Site Survey....................................................................................................................................................................................................... 5
7. Wireless MAC Filter ...................................................................................................................................................................................... 9
7.5 Wireless Advanced .......................................................................................................................................................................................50
7.6 WPS (Wi-Fi Protected Setup)....................................................................................................................................................................52
7.7 WDS Link Settings.........................................................................................................................................................................................5
8Management.................................................................................................................................................................... 56
8.1 Administration................................................................................................................................................................................................56
8.2 Management VLAN......................................................................................................................................................................................57
8.3 SNMP.................................................................................................................................................................................................................65
8. Backup/Restore..............................................................................................................................................................................................67
8.5 Auto Reboot ...................................................................................................................................................................................................68
8.6 Firmware Upgrade........................................................................................................................................................................................69
8.7 Time Setting....................................................................................................................................................................................................70
8.8 CLI Setting .......................................................................................................................................................................................................71
8.9 Log......................................................................................................................................................................................................................72
8.10 Diagnosis..........................................................................................................................................................................................................73
8.11 Device Discovery ...........................................................................................................................................................................................75
8.12 LED Control.....................................................................................................................................................................................................76
8.13 Logout...............................................................................................................................................................................................................77

3
8.1 Reset..................................................................................................................................................................................................................78
Appendix A – FCC Interference Statement .......................................................................................................................... 79
Appendix B – Industry Canada Statement........................................................................................................................... 80
Appendix C – CE Interference Statement............................................................................................................................. 81

Revision History
Version Date Notes
1.0 2013/0 /22 First Release

5
1Introduction
The EAP300 is a high-powered, long-range 802.11b/g/n Wireless Indoor Access Point with multiple operation modes. It
can be deployed in a number of different businesses from a small office to large hotels and multi-story office, hospital or
university buildings.
The EAP300 can also be used in large homes to extend the range of an existing network and help to eliminate wireless
dead zones caused by certain architectural materials.
To protect data during wireless transmissions, the EAP300 supports industry-standard WPA/WPA2 encryption and MAC
address filtering to authorize only specific devices to access the network.
1.1 Features and Benefits
Features Benefits
High Speed Data Rate Up to 300Mbps Capable of handling heavy data payloads including video
multimedia streaming.
10/100 Fast Ethernet Supports up to 100 Mbps wired networking speed.
IEEE 802.11n Co pliant and Backwards
Co patible with 802.11 b/g devices
Fully compatible with EEE 802.11b/g/n devices.
Multiple Operation Modes Allows users to configure the device in any one of the following
modes: Access Point, WDS AP, WDS Bridge and Repeater.
Point-to-point, Point-to-Multipoint Wireless
Connectivity
Allows transfer of data to and from other access points or wireless
bridges.
Support VLAN Tagging of Multiple SSIDs in
Access Point ode (up to 8)
Allows clients in specified VLANs to access different portions of
the networks based on their specific authorization policies.

6
WPA/WPA2/IEEE 802.1x Support Supports industry-standard wireless encryption and RAD US
authentication.
MAC Address Filtering in Access Point ode Can be configured to grant access to only known devices based
on their MAC addresses.
User Isolation Support (Access Point ode) O Offers an additional layer of protection within the network by
isolating specific clients.
Power-over-Ethernet (IEEE802.3af) Enables the EAP300 to be powered via Ethernet cable so it can be
deployed on ceilings or in crawlspaces where electrical outlets
may not be available.
Save User Settings Enables network administrators to save their device settings so
firmware upgrades do not permanently delete previous device
settings.
SNMP Re ote Configuration Manage ent Allows remote connection to configure or manage the EAP300
easily.
QoS (WMM) support Prioritizes bandwidth-intensive and sensitive data traffic.
IPv6 Supports Pv6 addresses.
1.2 Package Contents
The EAP300 package contains the following items (Resellers and dealers require that all items must be in the package to
issue a refund):
•EAP300
•12V/1A 100V~2 0V Power Adapter
•RJ- 5 Ethernet Cable
•CD with User Manual

7
•Quick Installation Guide
•Wall Mount Screw kit
1.3 System Requirements
The following are the Minimum System Requirements in order configure the device:
•Computer with an Ethernet interface or wireless network capability.
•Windows OS (XP, Vista, 7), Mac OS X, or Linux-based operating systems.
•Web-Browsing Application (i.e.: Internet Explorer, Firefox, Safari, or other similar browser application).
1.4 pplications
Wireless LAN (WLAN) products are easy to install and highly efficient. The following list describes the benefits of
deploying a wireless access point:
a) Difficult-to-Wire Environments
There are many situations where wires cannot be installed, deployed easily or cannot be hidden from view. Many
older buildings sites, or areas within a building may make the installation of an Ethernet-based LAN impossible,
impractical or expensive.
b) Temporary Workgroups
A deployed wireless access point or several access points, gives businesses the flexibility to create temporary
workgroups/networks in more open areas within a building – auditoriums, amphitheater classrooms, ballrooms,
arenas, exhibition centers, and temporary offices.
c) The Ability to Access Real-Time Information

8
Doctors/Nurses, Point-of-Sale Employees, and/or Warehouse Workers can access real-time information on their
network via the access point while dealing with patients, serving customers, and/or processing information.
d) Frequently Changing Environments
Setting up an access point, like the EAP300, to provide access to a company network or its Internet connection is
quick and easy which also makes it ideal for establishing network access in temporary venues like exhibits, special
events, or show rooms.
e) Small Office and Home Office (SOHO) Networks
A wireless access point, like the EAP300, is ideal for SOHO users who need a cost-effective way to expand their
existing network to provide more access for more devices, easy and quick installation of a small network.
f) Wireless Extensions to Existing Ethernet-based Networks
Wireless access points, like the EAP300, enable network administrators, installers and end-users to extend the range
and reach of an existing Ethernet-based network.
g) Training/Educational Facilities
Training sites at corporations and universities deploy wireless access points to provide connectivity their networks
and the Internet connection for their employees and students.

9
2Before you Begin
This section will guide you through the installation process. Placement of the EnGenius EAP300 is essential to maximize the
access point’s performance. Avoid placing the EAP300 in an enclosed space such as a closet, cabinet, or stairwell.
2.1 Considerations for Wireless Installation
Generally, the exact operating distance of a wireless device, like the EAP300, cannot be pre-determined due to a number of
unknown variables or obstacles in the environment in which the device will be deployed. These could be the number,
thickness, and location of walls, ceilings, elevator shafts, stairwells, or other objects that the device's wireless signals must
pass through. Here are some key guidelines to allow the EAP300 to have optimal wireless range.
•Keep the number of walls and/or ceilings between the EAP300 and other network devices to a minimum. Each wall
and/or ceiling can reduce the signal strength, resulting in lower signal strength.
•Building materials make a difference. A solid metal door and/or aluminum studs may have a significant negative effect
on the signal strength of the EAP300. Locate your wireless devices carefully so the signal can pass through drywall
and/or open doorways. Materials such as glass, steel, metal, concrete, water (example: fish tanks), mirrors, file cabinets
and/or brick can also diminish wireless signal strength.
•Interference from other electrical devices and/or appliances that generate RF noise can also diminish the EAP300’s
signal strength. The most common types of devices are microwaves or cordless phones.

10
2.2 Computer Settings (in Windows XP/Windows 7)
In order to use the EAP300, you must first configure the TCP/IPv connection of your Windows OS computer system.
•Click Start button and open Control Panel.
Windows XP Windows 7

11
•In Windows XP, click Network Connection
•In Windows 7, click View Network Status and Tasks in the Network and Internet section and then select Change
adapter settings.
•Right click on Local Area Connection and select Properties.

12
•Select Internet Protocol Version (TCP/IPv ) and then select
Properties.
•Select Use the following IP address and enter an IP address that is
different from the EAP300 and subnet mask then click OK.
Note: Ensure that the IP address and subnet mask are on the same subnet as
the device.
For example: Device IP address: 192.168.1.1
PC IP address: 192.168.1.2 – 192.168.1.255
PC subnet mask: 255.255.255.0

13
2.3 Computer Settings in pple Mac OS X
•Go to System Preferences (can be opened in the Applications folder or selecting it in the Apple Menu).
•Select Network in the Internet & Network section.
•Highlight Ethernet.
•In Configure IPv , select Manually.
•Enter an IP address that is different from the EAP300 and subnet mask then press OK.
Note: Ensure that the IP address and subnet mask are on the same subnet as the device.
For example: Device IP address: 192.168.1.1
PC IP address: 192.168.1.2 – 192.168.1.255
PC subnet mask: 255.255.255.0
•Click Apply when done.

1
2.4 Hardware Installation
1. Ensure that the computer in use has an available Ethernet (RJ- 5) Port. For more information, verify with your
computer’s user manual.
2. Connect one end of the Category 5e Ethernet cable into the RJ- 5 port of the EAP300 and the other end to the RJ- 5
port of the computer. Ensure that the cable is securely connected to both the EAP300 and the computer.
3. Connect the Power Adapter DC connector to the DC-IN port of the EAP300 and the Power Adapter to an available
electrical outlet. Once both connections are secure, verify the following:
a) Ensure that the POWER light is on (it will be blue).
b) Ensure that the WLAN light is on (they will be blue).
c) Ensure that the LAN (Computer/EAP300 Connection) light is on (it will be blue).
d) Once all lights are on, proceed to set up the EAP300 using the computer.

15
This diagram depicts the hardware configuration.

16
Front Panel Rear Panel
Front Panel
Reset Button One click for reset the device. Press over 10 seconds for reset to factory default.
LED Lights LED lights for Wireless, Ethernet port and Power.
Rear Panel
DC N DC IN for Power.
Ethernet Port Ethernet port for RJ-45 cable.

17
3Configuring Your Access Point
This section will show you how to configure the device using the web-based configuration interface.
3.1 Default Settings
Please use your Ethernet port or wireless network adapter to connect the EAP300.
Default Settings
IP Address 192.168.1.1
Username / Password admin / admin
Operation Mode Access Point
Wireless SSID EnGeniusxxxxxx
Wireless Security None
Note: xxxxxx represented in the wireless SSID above is the last 6 characters of your device MAC Address. This can be found on the device body
label and is unique for each device.

18
3.2 Web Configuration
•Open a web browser (Internet Explorer/Chrome/Firefox/Safari) and enter the IP Address http://192.168.1.1
Note: If you have changed the default AN IP Address of the Access Point, ensure you enter the correct IP Address.
•The default username and password are admin. Once you have entered the correct username and password, click the
Login button to open the web-base configuration page.

19
•You will see the following webpage if login successfully.
