Enitial Lab CM3216SC-2PK User manual

1 / 8
MODEL #
Questions?
GIVE US CALL: 1-888-980-5122
MON-FRI 8:30AM - 5:30PM (PST)
The Assembly Rating is a
5-point system showing the
level of effort needed to
assemble a specific product.
EASY DIFFICULT
2 - People
(Included)
Allen Wrench
Recommended
(Included)
Wrench
CM3216SC-2PK
VERSION # 20-07-15

Thank you for your purchase!
We hope you enjoy this new addition to your home for many years to come.
Our commitment to providing quality products does not simply end when you purchase
our product. We fully stand behind our products from start to finish. Our customer
service department is available Monday – Friday 8:30 AM – 5:30 PM Pacific and can
help with assembly questions as well as, if necessary, replacing damaged or missing
parts. To help expedite our service, please have these assembly instructions readily
available, along with your order receipt.
E-MAIL
[e-mail]
Furniture of America
WEBSITE
www.foagroup.com
FOA Intro
FurnitureOfAmerica
foagroup
Monday to Friday
8:30AM- 5:30PM (PST)
Consumer Hotline
Toll-Free 1-888-980-5122
Prep Time!
Please review the assembly instructions and all
diagrams prior to assembling. Arrange parts as
recommended on Page 7 and group identical
hardware together to make assembling easier.
Check out our Quick Tips!
We recommend reviewing the pre-assembly
handouts. Even experts need a refresher now and
then!
Are you missing anything?
Double-check all parts, hardware and
accessories listed on Page 6 are
accounted for.
Should we send any replacements?
Are there any irregularities or flaws in the
parts? We can send replacements!
CHECK
BEFORE STARTING
2/ XXXXXXX8

PRE ASSEMBLY
INTRODUCTION
Suitable Location
Assembling near the area of the
intended location is highly
recommended.
Avoid Scratches
Use cardboard, blankets or a
carpeted area while assembling
furniture to prevent scratches.
Teamwork
ALWAYS have at least two people
to help with transporting and
assembling the product to avoid
potential injury and/or damage.
Flat Surface
Make sure the furniture rests on
a flat and level surface with each
leg evenly touching the floor.
Sufficient Space
Make sure you have enough
space to move around during the
assembly.
We understand building ready-to-assemble furniture can be a challenging
experience for some. To help avoid confusion, we have provided some helpful
tips that may speed up the process.
3/ XXXXXXX8

4 / XXXXXXX8

CM3216SC-2PK
5 / 8
#1 1pc x2 #2 1pc x2
#B 4pcs x2#A 3pcs x2
Front Leg
#3 2pcs x2
Chair Back Cushion Seat
#C 7pcs x2 #D 7pcs x2
#E 1pc x2
Bolt Ø1/4" x 3-1/4"
Bolt Ø1/4" x 1-1/2" Lock Washer
Ø1/4"x13mm Flat Washer
Ø1/4"x19mm
Allen Wrench M4 Hex Nut (Ø5/16")
#F 4pcs x2 #G 4pcs x2 #H 4pcs x2
Lock Washer
Ø5/16"x13mm Flat Washer
Ø5/16"x19mm
#I 1pc x2
Wrench
SIDE CHAIR

6 / 8
Exploded View
#2
#1
#3 #3 x 2

ASSEMBLY INSTRUCTIONS
1
2
7 / 8
Part #1 x1pc
Part #2 x1pc
Hardware #A x3pcs
Hardware #C x3pcs
Hardware #D x3pcs
Hardware #B x4pcs
Hardware #C x4pcs
Hardware #D x4pcs
1. Prepare 3 bolt assemblies by first
inserting a lock washer (#D) onto
the bolt (#A) then a flat washer
(#C) onto that same bolt (#A).
2. Place the backrest (#1) onto a protected surface, then
align the seat (#2). Insert the bolt assemblies into the
center holes and secure using the Allen wrench (#E).
1. Prepare 4 bolt assemblies by first inserting
a lock washer (#D) onto the bolt (#B) then
a flat washer (#C) onto that same bolt (#B).
2. Insert 2 bolt assemblies into each back corner of the
seat (#2) and secure using the Allen wrench (#E).

ASSEMBLY INSTRUCTIONS
3
4
8 / 8
Part #3 x2pcs
Hardware #F x4pcs
Hardware #G x4pcs
Hardware #H x4pcs
1. Insert the threaded ends of the front legs (#3) into the
front corners of the seat (#2), make sure to insert the leg
supports (#4,5) into the slots as you align the front legs.
2. Apply a flat washer (#G), lock washer (#H),
and hex nut (#F) onto each threaded end
in that order. Secure using the wrench (#I).
