Enitial Lab Furniture of America CM3310T User manual

MODEL #
CM3310T
Questions?
GIVE US CALL: 1-888-980-5122
MON-FRI 8:30AM - 5:30PM (PST)
The Assembly Rating is a
5-point system showing the
level of effort needed to
assemble a specific product.
EASY DIFFICULT
2 - People
(Included)
Allen Wrench
Recommended
1 / 10
VERSION # 20-06-09

Thank you for your purchase!
We hope you enjoy this new addition to your home for many years to come.
Our commitment to providing quality products does not simply end when you purchase
our product. We fully stand behind our products from start to finish. Our customer
service department is available Monday – Friday 8:30 AM – 5:30 PM Pacific and can
help with assembly questions as well as, if necessary, replacing damaged or missing
parts. To help expedite our service, please have these assembly instructions readily
available, along with your order receipt.
E-MAIL
[e-mail]
Furniture of America
WEBSITE
www.foagroup.com
FOA Intro
FurnitureOfAmerica
foagroup
Monday to Friday
8:30AM- 5:30PM (PST)
Consumer Hotline
Toll-Free 1-888-980-5122
Prep Time!
Please review the assembly instructions and all
diagrams prior to assembling. Arrange parts as
recommended on Page 7 and group identical
hardware together to make assembling easier.
Check out our Quick Tips!
We recommend reviewing the pre-assembly
handouts. Even experts need a refresher now and
then!
Are you missing anything?
Double-check all parts, hardware and
accessories listed on Page 6 are
accounted for.
Should we send any replacements?
Are there any irregularities or flaws in the
parts? We can send replacements!
CHECK
BEFORE STARTING
2/ XXXXXXX10

PRE ASSEMBLY
INTRODUCTION
Suitable Location
Assembling near the area of the
intended location is highly
recommended.
Avoid Scratches
Use cardboard, blankets or a
carpeted area while assembling
furniture to prevent scratches.
Teamwork
ALWAYS have at least two people
to help with transporting and
assembling the product to avoid
potential injury and/or damage.
Flat Surface
Make sure the furniture rests on
a flat and level surface with each
leg evenly touching the floor.
Sufficient Space
Make sure you have enough
space to move around during the
assembly.
We understand building ready-to-assemble furniture can be a challenging
experience for some. To help avoid confusion, we have provided some helpful
tips that may speed up the process.
3/ XXXXXXX10

4/ XXXXXXX10

Bolt Ø5/16" x 2" Allen Key 5mm
Flat Washer Ø5/16"
Lock Washer Ø5/16"
Table Top Cross Bar
#D 1pc
Pedestal Table Base
Table Leaf
Mounting Plate Bar strengthening bottom
Wood dowel Screw #8 x 25mm
#6 2pcs #7 1pc
#A 28pcs #B 28pcs #C 28pcs
#E 1pc #F 10pcs
TABLE
CM3310T
5 / 10
#1 1pc #2 1pc #3 2pcs #4 2pcs #5 1pc

CM3310T is packed in 2 cases
6 / 10
CM3310T-1
#4
#5
#3
#1
#2
CM3310T-2
Table Top
Cross Bar
Table Leaf
#6
Bar strengthening bottom #7
Carton
Disignation Part Hardware
# A x 28pcs
#D x 1pc
#E x 1pc
#B x 28pcs
#C x 28pcs
#
F x 1 0pcs
M ounting Plate
T able Base
P edestal

1
2
ASSEMBLY INSTRUCTIONS
Part #1 x1pc
#A
#B
#C
open
#D
#1
Turn back
Part #6 x2pcs
7 / 10
#6
#6
#4
#7
#1
#2
#5
#3
Detach mounting plates (#6) from the table
top (#1). Turn the lever from the table top
(#1) to open.

3
4
ASSEMBLY INSTRUCTIONS
Hardware #A x8pcs
Part #2 x 1pc
Hardware #B x8pcs
Hardware #C x8pcs
#A
#B
#C
#3
#6
#D
x 2
#2
8 / 10
Part #3 x2pcs
Align mounting plates (#6) to pedestals
(#3), then secure by using bolts (#A)
with washers (#B,C).
Extend table top (#1) and insert leaf (#2)
to table top (#1).

ASSEMBLY INSTRUCTIONS
5
6
Hardware #A x8pcs
Hardware #B x8pcs
Hardware #C x8pcs
Hardware #A x4pcs
Hardware #B x4pcs
Hardware #C x4pcs
#A
#B
#C
Close
#D
#6
#B #C
#A
#D
#5
#4
#4
Part #4 x 2pcs
Part #5 x 1pc
9 / 10
Turn the lever to close on the table top (#1). Align mounting plate
with pedestal to the table top (#1), then secure by using bolts (#A)
with washers (#B,C).
Align table bases (#4) to cross bar (#5), then secure by
using bolts (#A) with washers (#B,C).

7
8
#A
#B
#C
#D
#4
#3
#7
#F
#F
#E
Hardware #A x8pcs
Hardware #B x8pcs
Hardware #C x8pcs
Hardware #E x1pc
Hardware #F x10pcs
Part #7 x 1pc
ASSEMBLY INSTRUCTIONS
10/10
Align table base (#4) to the pedestals (#3),
then secure by using bolts (#A) with
washers (#B,C).
Align stretcher (#7) to the table base,
then secure by using screw (#F)
