Walker Edison D44VETHUT User manual

P.1
Please visit our websitefor the most current instructions, assemblytips, report damage,
or request parts. www.walkeredison.com Revised 19/10/2020 (L)
Walker Edison
TM
Item#:D44VETHUT
AssemblyInstructions
Copyright
2020
b
y
Walker Edison Furniture Co., LLC. All rightsreserved.

Parts List
P.3
Copyright
2020
b
y
Walker Edison Furniture Co., LLC. All rightsreserved.
1
2
3
56
4
89
7
10
11
12
13
14
15
16
17
18
19
20
x2

P.4
HardwareList
The hardware quantities listed above are required for proper assembly.
Someextrahardware may also have been included.
8x30mm Woodendowel 15 pcs
Philipsheadscrewdriverrequiredforassembly
(notincluded)
A
15x11mm Camlock 20 pcs B
6x35mm Cambolt 20 pcs
C
D
E
F
6x35mm 2 pcs
G
H
J
M4mm HexKey 1 pc
K
L
Plasticwedge 12 pcs
Screw 12 pcs
Sticker 20 pcs
3x17mm
30mm
Screw 20 pcs 4x38mm
Gluetube 1 pc
Copyright
©
2020
b
y
Walker Edison Furniture Co., LLC. All rightsreserved.
Screw
2
Drawerslider sets
*Note:Thispiece comes preassembled for
shippingpurposesand must bedisassembled
tocompletethe deskassembly.
M
6x30mm 8 pcs
Screw
N
Screw 24 pcs 3x12mm
P
Q
Handle 2 pcs
Bolt 4 pcs 4x22mm

P.5
Step 1
Copyright
2020
b
y
Walker Edison Furniture Co., LLC. All rightsreserved.
Sliderbracket
Sliderarm Sliderbracket
Sliderarm
Q
Q
Pick up the slider arm (Q) and separate the slide runner for the following Steps. Extend
the slide runner all the way forward,press the plastic release lever of the slider arm up
and pull the slide runner complete out .

P.6
Step 2
Copyright
2020
b
y
Walker Edison Furniture Co., LLC. All rightsreserved.
16
17
Q
Q
M
M
M
M
M
M
x2
Using screw (M) attach drawer slider (Q) to parts (16,17) with Philips head screwdriver
as per diagram.

Secure cam bolt (C) into parts (1,2) with Philips head screwdriver as per diagram.

Insert wooden dowel (A) into parts (4,5,6,7,8,9) as per diagram.

P.9
Step 5
Copyright
2020
b
y
Walker Edison Furniture Co., LLC. All rightsreserved.
QQ
88
7 9
QQ
M
M
M
M
M
M
M
M
MM
M
M
Using screw (M) attach drawer slider (Q) to parts (7,8,9) with Philips head screwdriver
as per diagram.

Using Cam lock (B) secure parts (4,5,6) to part (1) with Philips head screwdriver as per diagram.

Put part (12) as per diagram.

Using screw (K) attach part (2) to parts (4,5,6) with Philips head screwdriver as per diagram.

Step 9
P.13
Copyright
2020
b
y
Walker Edison Furniture Co., LLC. All rightsreserved.
21 3
2
7
8
9
B
B
B
B
B
B
Using Cam lock(B) secure parts (7,8,9) to part (2) with Philips head screwdriver as per diagram.

Step 10
P.14
Copyright
2020
b
y
Walker Edison Furniture Co., LLC. All rightsreserved.
7
9
13
2
Put part (13) as per diagram.

Step 11
P.15
Copyright
2020
b
y
Walker Edison Furniture Co., LLC. All rightsreserved.
7
8
9
3
K
KK
KK
K
Using screw (K) attach part (3) to parts (7,8,9) with Philips head screwdriver as per diagram.

Using Bolt (E) attach parts (10,11) into part (15), then using bolt (F) attach part (14) to
parts (10,11) with Hex key (G) as per diagram.

Using Bolt (F) attach parts (10,11) into part (3) with Hex key (G) as per diagram.

Using screw (J) secure plastic wedge (H) to parts (12,13) with Philips head screwdriver
as per diagram.

Secure cam bolt (C) into part (19) ,then using handle bolt ( P) secure handle (N) to part (19)
with Philips head screwdriver as per diagram.

Step 16
P.20
Copyright
2020
b
y
Walker Edison Furniture Co., LLC. All rightsreserved.
x2
17
16
20
K
K
17
16
18
18
Using screw (K) attach parts (16,17) to part (18) with Philips head screwdriver ,then insert part (20)
as per diagram.
