Enlighten Glass board User manual

Balt 4' x 6' Black

Enlighten Glass Dry-

Erase Whiteboard

Instruction Manual

1234567890123456789012345678901212345678901234567890123456789012123456789012

Enlighten Boards

Assembly Instructions

Part Drawing Description Qty

Hardware List

P-1 Glass Board 1 EA

EEnlighten Board

A Outer Cap Chart

B Brass Mount Chart

C PlasticAnchor Chart

D CS Screw Chart

Part Drawing Description Qty

Hardware Chart by Board Size

2’X3’ GBoard - 4 pcs. (A), (B)

4pcs. (C),(D),(E)

3’X4’ GBoard - 4 pcs. (A), (B)

4 pcs. (C), (D), (E)

4’X6’ GBoard - 6 pcs. (A), (B)

6 pcs. (C), (D), (E)

1’ X1’ GBoard- 4 pcs. (A),(B)

4 pcs. (C), (D), (E)

1.5” X 2’ GBoard- 4 pcs. (A), (B)

4 pcs. (C), (D), (E)

20” X 30” GBoard-4 pcs. (A),(B)

4 pcs. (C), (D), (E)

See

E DrywallAnchor See

Chart

F Plastic Washer See

Chart

4 pcs. (F)

6 pcs. (F)

4 pcs. (F)

SpecialNote:

Yournew glass boardrequiresa flatwallfor mounting. Make surethe

areabehind the glass board is free of any highspots.

Measurethelength andwidthofyour newboard. Determinethewall centerlineandheight

offthe floorthatyou wantyournew boardtobe located. Holdyourboard upinposition and

drawaline underthebottom of theboardand parallel withthefloor. Ifyourwall has studs,

determine the centerline of thestuds. It is recommendedthat you tieinto as manystuds

as possible when mounting your board. .

aring to InstallPreparing to Install Your New Enlighten Board

NOTE: The proper installation of your board will require at least two people.

Tools required: Tape measure, chalkline, electric drill / screwdriver, drill and

screwdriver bits, stud finder and level. .

1.)

Illustration#1

2.) Whenyou have yourglass boardpositioned,

markthewallthroughthemountholes that are

in theboard.

Illustration#2

Afteryouhave followedtheguidelines from Page3,install the correctnumberof wallanchorsfor

thesizeboardyou aremountingtothewall. Install the anchorsasshowninIllustration #3A and

#3B.

Illustration # 3A

3.)

3A.) For all walls except sheet rock: .

Predrilla 5/16” diameterhole inthe centerof eachof yourmarked mount holes. Pushin aPlastic

Anchor(C) intoeachpredrilled hole.Repeat this Step for eachanchor thatisrequired foryour size

board. .

3B.) For sheet rock walls: .

Predrilla 1/4”diameter holein thecenter ofeach of yourmarked holes. Screwin aDrywal lAnchor

(E)in thecenterof eachofthe marked mountholes. Repeat thisStepfor eachanchorthat is

required foryoursize board.

Illustration # 3B

Installing the Glass Board

5/16”

Predrilled Hole

1/4””

Predrilled Hole

Illustration#5

Screwan OuterCap(A) ontoeach BrassMount(B) asshown in illustration# 5. Repeat

thisStepforeach mountonyourboard.

Toattachyour GlassBoard (P1) tothe wall,usea Screw(D)through aBrass Mount (B), a

PlasticWasher(F) ,throughtheholein theboardandinto thewallanchoras shownin

illustration# 4. Repeat thisStepfor each mountingholein yourboard.

Illustration#4

Enlighten_07-30-15

5.)

4.)

WallAnchor

WWW.MYBINDING.COM
