entegris NT 4000 Series User manual

NT® PRESSURE TRANSDUCER
4000 Series User Guide

ENTEGRIS, INC. Customer Service Tel. [phone] Customer Service Fax [phone]
NT PRESSURE TRANSDUCER USER GUIDE
Introdu tion ........................ 2
Nonstandard Produ t
Configurations .................... 3
Identifying Nonstandard
Product Configurations ....... 3
Installation ......................... 4
echanical Installation ......... 4
Electrical Installation ........... 5
Power Supply Requirements .... 5
Unit Operation ..................... 7
Operating Environment ......... 7
Process Connections ............. 7
Pressure Transducer
Cover Assembly ................ 7
Pressure and Temperature
Requirements .................. 7
Pressure Limits .................... 8
Pressure Reference
Accuracy ........................ 8
Linear Output Signal ............ 9
Troubleshooting .................. 10
Maintenan e ...................... 10
Zero and Span Adjustment ..... 10
Referen e .......................... 12
Physical Specifications ........ 12
Electrical Specifications ...... 12
Performance Specifications .... 12
Certifi ations ..................... 13
CE Compliance ................... 13
UL Standard 1604 for Class 1,
Division II Hazardous
Environments .................. 13
UL Standard 2279 for Class 1,
Zone 0, 1 and 2
Hazardous Locations ........ 13
Ordering Information ........... 14
odel 4100 Single-port ........ 14
odel 4210 Flow-through ...... 15
odel 4130 Single-Port ........ 16
odel 4230 Flow-through ....... 16
Installation Drawings .......... 17
odel 4100 Single-port ........ 17
odel 4210 Flow-through ...... 19
odel 4130 Single-port ........ 21
odel 4230 Flow-through ....... 22
Repair and Warranty Servi e ... 23
Table of Contents

NT PRESSURE TRANSDUCER USER GUIDE
2Customer Service Tel. [phone] Customer Service Fax [phone] ENTEGRIS, INC.
Introduction
Polypropylene electrical
connector option
Signal conditioning circuit
Electronic pressure sensor
Solid PTFE
Process connection
Cut-away Example:
NT Single-port Pressure Transducer
Polypropylene electrical
connector option
Signal conditioning circuit
Electronic pressure sensor
Solid PTFE
Process connection
Cut-away Example:
NT Flow-through Pressure Transducer
This manual is for use with the
following standard NT Pressure
Transducers 4000 Series odels
4100, 4130, 4210 and 4230. These
instruments have been designed for
use in high purity applications in the
semiconductor industry.
These products feature no moving
parts and no filled cavities, which
reduces the possibility of a contami-
nated process. The wetted parts of
these nonmetallic transducers are
constructed with PTFE, PFA or other
similar high purity inert materials.
WARNING!
Attempting to install or operate
NT standard 4000 Series Pressure
Transducers without reviewing the
instructions contained in this
manual could result in personal
injury or equipment damage.
!

ENTEGRIS, INC. Customer Service Tel. [phone] Customer Service Fax [phone]
NT PRESSURE TRANSDUCER USER GUIDE
Identifying Nonstandard
Product Configurations
This User Guide applies to product
manufactured as standard NT®
Pressure Transducers, odels 4100,
4130, 4210 and 4230. Entegris
also manufactures nonstandard
product to meet the needs of specific
applications. Nonstandard product
may have different materials of con-
struction, accuracy specifications,
performance and other specifications
that differentiate the nonstandard
product from the standard offering.
N TE: Nonstandard pressure
transducers may be identified by
the model number found on the
product label. Specifications for
nonstandard pressure transducers
are available by contacting
Entegris.
Nonstandard single-port pressure
transdu ers, odel 4100 product
line, are identified with a “P” fol-
lowed by a number code.
For example, part number:
4100-030G-F02-B06-A-P04
the “P04” designates the product as a
nonstandard product manufactured
to certain specifications designated
under the “P04” code.
Nonstandard flow-through pressure
transdu ers, odel 4210 product
line, are identified with a “T”
followed by a number code.
For example, part number
4210-030G-F02-B06-A-T02
the “T02” designates the product as a
nonstandard product manufactured
to certain specifications designated
under the “T02” code.
Nonstandard Product Configurations

NT PRESSURE TRANSDUCER USER GUIDE
4Customer Service Tel. [phone] Customer Service Fax [phone] ENTEGRIS, INC.
Installation
CAUTI N!
The pressure transducer has
been factory sealed. Do not
attempt to remove the cover
of the pressure transducer.
Any attempt at removal of the
pressure transducer cover will
void the warranty and damage
the unit.
N TE: NT Pressure Transducers
for DI water applications, odels
4130 and 4230, are built with
a removable grommet to allow
adjustment of the zero and span
potentiometers.
CAUTI N!
Do not tighten the nuts that
protect the process connections
during shipment. Do not tighten
the nuts unless the proper tubing
has been installed. Tightening
these nuts may result in damage
to the pressure transducer process
connections.
echanical Installation
Standard NT Pressure Transducers
utilize flared tube connections and
must be used with the proper tubing
size and coupling nut.
When installing flared tubing to the
pressure transducer, the flared tube
is pushed over the transducer’s
fitting until the fitting reaches the
smaller tube diameter. The amount
of torque required to tighten the
coupling nut is dependent upon
the size of the fitting.
Care should be taken when installing
flared tubing onto the pressure trans-
ducer. Do not use excessive torque or
subject the transducer to high heat
during installation. The transducer
should be firmly mounted to a solid
surface to ensure stability. Verify that
the pressure transducer and the sig-
nal cable are free from mechanical
stress or excessive bending from the
surrounding equipment.
FITTING SIZE 1⁄4”3⁄8”1⁄2”3⁄4” 1”
Torque (in•lbs) 5811 14 30
!
!

Electrical Installation
The pressure transducer provides
an analog (0–5 VDC, 0–10 VDC or
4–20 mA) electrical output propor-
tional to the pressure measured.
N TE: The white wire is not
required for the 4–20 mA output
configuration, please refer to the
wiring diagrams below.
Power Supply Requirements
The pressure transducer requires
a 12–30 volt DC power supply with
less than 2% ripple at 100 or 120 Hz.
The required power supply voltage
varies with the load resistance
(RLoad), please refer to the formulas
on page 6. The power supply must
provide clean power and must be
used only to power similar measure-
ment-type devices. The power supply
must not be used to power inductive
loads, such as motors, relays or sole-
noids. These devices may produce
transients that may affect the pres-
sure transducer measurements when
the inductive device is powered up
or powered down.
N TE: Be sure to ground the
shield of the cable to local ground.
ENTEGRIS, INC. Customer Service Tel. [phone] Customer Service Fax [phone]
NT PRESSURE TRANSDUCER USER GUIDE
Pressure transducer
4–20 mA output version
Pressure Transducer
0–5 VDC, 0–10 VDC output version
+24 VDC GND
RED
RED
WHITE
WHITE
BLACK
BLACK
Voltage pressure signal
4–20 mA pressure signal
No connection
Display
or PLC
Display
or PLC

Load Resistan e: Current Output
(4–20 mA Configuration)
If a load resistor, RLoad, is used in
series with the current output, the
value of RLoad is dependent on the
supply voltage and the meter resis-
tance and is calculated from the
following formula:
RLoad = – Rmeter
where:
RLoad = maximum load
resistance (ohms)
VPS = power supply
voltage (volts)
Rmeter = meter resistance (ohms)
(theoretically = 0)
Load Resistan e: Voltage Output
(0– 5, 0–10 VDC)
The output impedance is 1 kOhm.
The input impedance should be
≥1 megohm for ±0.1% load imped-
ance error.
NT PRESSURE TRANSDUCER USER GUIDE
6Customer Service Tel. [phone] Customer Service Fax [phone] ENTEGRIS, INC.
Operating
region
Power supply voltage
(VPS)
RLoad (Ohms)
12 24 29
850
0
Figure 1. Power Required for a 4–20 mA Loop
VPS – 12 V
20 mA

ENTEGRIS, INC. Customer Service Tel. [phone] Customer Service Fax [phone]
NT PRESSURE TRANSDUCER USER GUIDE
Unit Operation
Operating Environment
The pressure transducer is to be
mounted in a well vented and con-
trolled environment. Refer to the
Reference section on page 12 for
additional specifications.
Process Connections
To avoid possible pressure leaks,
make sure all process connections
have been performed in accordance
with the Mechanical In tallation
guidelines on page 4.
Pressure Transducer Cover
Assembly
Standard NT Pressure Transducer
covers are factory sealed and should
not be tampered with or opened.
Opening the cover shall void the
product warranty. The NT Pressure
Transducers for DI water applica-
tions, odels 4130 and 4230, are
built with a removable grommet to
allow adjustment of the zero and
span potentiometers.
CAUTI N!
Any attempt to remove or
tamper with the transducer
cover will void the warranty
and damage the unit.
Pressure and Temperature
Requirements
The minimum pressure required
is atmospheric pressure. The pres-
sure transducer may be damaged if
subjected to vacuum pressure (pres-
sure that is less than atmospheric
pressure).
The pressure transducer is rated for
use with fluids at process tempera-
tures between 10–65°C (50–149°F)
under normal operating conditions.
CAUTI N!
NT Pressure Transducers, Models
4100, 4130, 4210 and 4230,
may be damaged if the sensor is
subjected to any level of vacuum
pressure (pressure less than
atmospheric pressure).
!
!

NT PRESSURE TRANSDUCER USER GUIDE
8Customer Service Tel. [phone] Customer Service Fax [phone] ENTEGRIS, INC.
Pressure Limits
MAX. PRESSURE LIMIT MAX. PRESSURE LIMIT
TRANSDUCER RANGE @ 23°C(73°F) @ 65°C(149°F)
0–30 PS G 690 kPa (100 PS G)3690 kPa (100 PS G)2, 4
0–60 PS G 1034 kPa (150 PS G)1, 3 690 kPa (100 PS G)2, 4
0–100 PS G 1034 kPa (150 PS G)1, 3 690 kPa (100 PS G)2, 4
0–150 PS G 1310 kPa (190 PS G)1, 3 N/A
1Maximum pressure limit for 3⁄4” Flaretek® fitting connections at 23°C (73°F) is 758 kPa (110 PS G).
2Maximum pressure limit for 3⁄4” Flaretek fitting connections at 65°C (149°F) is 620 kPa (90 PS G).
3Maximum pressure limit for 1” Flaretek fitting connections at 23°C (73°F) is 517 kPa (75 PS G).
4Maximum pressure limit for 1” Flaretek fitting connections at 65°C (149°F) is 372 kPa (54 PS G).
For detailed pressure limit information on Flaretek tube fitting connections, refer to the Maximum
Pressure Capabilities chart in the Flaretek fittings product section on Entegris’ website at
http:// .entegrisfluidhandling.com.
WARNING!
The pressure limits for standard
NT Pressure Transducers (4000
Series) decrease significantly for
temperatures above 65°C
(149°F). Exceeding these limits
may result in personal injury
or equipment damage. Please
consult the factory.
Pressure Reference Accuracy
The accuracy of the pressure trans-
ducer output is ±1% of full scale.
This accuracy includes the effects of
linearity, hysteresis and repeatability,
measured at room temperature. For
accuracy specifications for non-
standard product configurations,
please consult the factory.
!

Linear Output Signal
The output signal of the pressure
transducer is a linear function pro-
portional to the applied pressure.
ENTEGRIS, INC. Customer Service Tel. [phone] Customer Service Fax [phone]
NT PRESSURE TRANSDUCER USER GUIDE
Pressure easurement
Current Output
(mA)
0 PSIG Full scale
20 mA
4 mA
Pressure easurement
Voltage Output
(V)
0 PSIG Full scale
10 V
or 5 V
0 V

NT PRESSURE TRANSDUCER USER GUIDE
10 Customer Service Tel. [phone] Customer Service Fax [phone] ENTEGRIS, INC.
Troubleshooting
Troubleshooting the NT Pressure
Transducers (4000 Series) may be
accomplished by measuring the out-
put signal of the pressure transducer
with a battery powered current/
voltage meter. The meter may be
placed in series with the pressure
transducer to measure the current
output or it may be used to directly
measure the voltage output.
Using the battery powered current/
volt meter is an effective method to
determine whether the device or the
on-site data acquisition system is not
functioning properly.
Diagram A
aintenance: (NT Pressure Transducers for DI
Water Applications, odels 4130 and 4230 Only)
Zero and Span Adjustment
Unit Calibration Steps:
1. Remove pressure transducer
from service.
2. Connect the pressure transducer
to a calibrated pressure source.
3. Connect the pressure transducer
to a power source.
4. Connect the pressure transducer
to a display to monitor the mA or
voltage output.
5. Remove the access grommet
(see Diagram A).
6. Locate the zero and span adjust-
ment screws (see Diagram B).

7. At ambient pressure (no pressure
applied), rotate the zero adjust-
ment screw (see Diagram C)
clockwise or counterclockwise
until the display reads 4.0 mA or
0 Volts.
8. Apply full scale pressure to the
unit, rotate the span adjustment
screw clockwise or counterclock-
wise until the display reads the
full scale value (i.e., depending
upon configuration: 20.0 mA, 10
Volts or 5 Volts).
9. To obtain best accuracy, repeat
steps 7 and 8.
10. The calibration procedure is
complete. Reinstall the access
grommet.
11. Safely vent any applied pressure,
disconnect the display and dis-
connect the power.
12. Return the pressure transducer
to service.
ENTEGRIS, INC. Customer Service Tel. [phone] Customer Service Fax [phone]
NT PRESSURE TRANSDUCER USER GUIDE
Span
Pot
Zero
Pot
Diagram B
Diagram C

NT PRESSURE TRANSDUCER USER GUIDE
12 Customer Service Tel. [phone] Customer Service Fax [phone] ENTEGRIS, INC.
Reference
Physical Specifications
Materials: Wetted parts Body PTFE
Sensor interface CTFE or PFA (Models 4100 and 4210)
PFA (Models 4130 and 4230)
O-ring Kalrez® (Models 4100 and 4210)
EPDM (Models 4130 and 4230)
Nonwetted parts Polypropylene, polyethylene, PVDF (in addition to
materials listed above)
Connection type: Flared tube, NPT
Electrical Specifications
nput power: 24 VDC (12–30 VDC)*
Pressure signal output ranges: 4–20 mA, 0–5 VDC, 0–10 VDC
Electrical connection: 6’, 12’, 30’ FEP-jacketed pigtail or polypropylene 3-pin connector
(Models 4100 and 4210)
12’ FEP-jacketed pigtail (Models 4130 and 4230)A
* Models 4100 and 4210 with 4–20 mA electrical output, operated with 12–28 VDC input are
ETL listed for conformance to UL Standard 2279, Class 1, Zone 0, 1 and 2, Ex ia A T6.
Performance Specifications
Reference accuracy: ±1% of full scale (includes linearity, hysteresis
and repeatability) at 23°C (73°F)
Process temperature: 10–65°C (50–149°F)
The following lists the specifications
for the NT Pressure Transducer
product line. Please consult the
factory for product specifications
manufactured for nonstandard
applications.
N TE: Specifications are subject to
change without notice. Please
consult the factory for the most
current information.

ENTEGRIS, INC. Customer Service Tel. [phone] Customer Service Fax [phone]
NT PRESSURE TRANSDUCER USER GUIDE
Certifications
CE Compliance
Entegris products have been tested
to various test standards required
by the E C 89/336/EEC directive.
The results of this testing are on
file at Entegris and are available
upon request.
Please contact the factory for
the latest information. The most
current specifications may be
found on Entegris’ Web site at:
http://www.entegri fluidhandling.com/
Default.a p?G=1613&1n=en
UL Standard 1604 for
Class 1, Division II Hazardous
Environments
Entegris has tested our standard
products to the UL Standard 1604
for use in Class 1, Division II, Group
A, B, C, D and T6 hazardous environ-
ments. The results of this testing are
on file at Entegris and are available
upon request. The products that are
in compliance to this standard are:
•NT Single-port Pressure
Transducer, odel 4100,
with electrical outputs of
either 0–10 VDC (ordering
information code B)
or 0–5 VDC (ordering
information code C)
•NT Flow-through Pressure
Transducer, odel 4210,
with electrical outputs of
either 0–10 VDC (ordering
information code B)
or 0–5 VDC (ordering
information code C)
UL Standard 2279 for
Class 1, Zone 0, 1 and 2
Hazardous Environments
Entegris has tested our standard
products to the UL Standard 2279
for use in Class 1, Zone 0, 1 and 2
Hazardous (Classified) locations.
The results of this testing are on file
at Entegris and are available upon
request. The products that are in
compliance to this standard are:
•NT Single-port Pressure
Transducer, odel 4100, with
electrical output of 4–20 mA
(ordering information code A)
•NT Flow-through Pressure
Transducer, odel 4210, with
electrical output of 4–20 mA
(ordering information code A)
These products are labeled
“Ex ia IIA T6” and may only be
operated in hazardous locations with
a 12–28 VDC power supply at
ambient to 65°C (149°F) tempera-
tures and installed per applicable
standards.
All specifications are subject to
change. Please contact the factory
for the latest information.

NT PRESSURE TRANSDUCER USER GUIDE
14 Customer Service Tel. [phone] Customer Service Fax [phone] ENTEGRIS, INC.
Ordering Information
Refer to the following for the desired configuration.
Model 4100 Single-port Pressure Transducer
Example model number: 4100-100G-F02-D06-A-P1-U1
C DE PRESSURE RANGE
030G 207 kPa (30 PS G)
060G 414 kPa (60 PS G)
100G 690 kPa (100 PS G)
150G 1034 kPa (150 PS G)
C DE INLET/ UTLET P RT C NNECTI N
F02 1⁄4” Flaretek
F03 3⁄8” Flaretek
F04 1⁄2” Flaretek
N02 1⁄4” FNPT
N04 1⁄2” FNPT
M02 1⁄4” MNPT
C DE ELECTRICAL C NNECT R TYPE
B06 FEP-jacketed 6’ pigtail electrical cable
B12 FEP-jacketed 12’ pigtail electrical cable
B30 FEP-jacketed 30’ pigtail electrical cable
D00 Polypropylene connector (cable not included)
D06 Polypropylene connector and 6’ PVC cable
D12 Polypropylene connector and 12’ PVC cable
D30 Polypropylene connector and 30’ PVC cable
C DE ELECTRICAL UTPUTS
A 4–20 mA (12–30 VDC input)*
B 0–10 VDC (12–30 VDC input)
C 0–5 VDC (12–30 VDC input)
C DE SENS R INTERFACE
P1 CTFE sensor interface (default)
P2 PFA sensor interface
C DE PRIMARY/SEC NDARY SEAL
U1 Kalrez 4079 / Viton® (default)
U2 Kalrez 1050 / Viton
U3 Kalrez 6375 UP / Viton
S1 Kalrez 4079 / Kalrez 4079
S2 Kalrez 1050 / Kalrez 1050
S3 Kalrez 6375 UP / Kalrez 6375 UP
* The 4–20 mA electrical output, operated with 12–28 VDC input, is ETL listed for conformance to
UL Standard 2279, Class 1, Zone 0, 1 and 2, Ex ia A T6.

C DE PRESSURE RANGE
030G 207 kPa (30 PS G)
060G 414 kPa (60 PS G)
100G 690 kPa (100 PS G)
CDE INLET/ UTLET P RT C NNECTI N
F02 1⁄4” Flaretek
F03 3⁄8” Flaretek
F04 1⁄2” Flaretek
F06 3⁄4” Flaretek*
F08 1” Flaretek*
C DE ELECTRICAL C NNECT R TYPE
B06 FEP-jacketed 6’ pigtail electrical cable
B12 FEP-jacketed 12’ pigtail electrical cable
B30 FEP-jacketed 30’ pigtail electrical cable
D00 Polypropylene connector (cable not included)
D06 Polypropylene connector and 6’ PVC cable
D12 Polypropylene connector and 12’ PVC cable
D30 Polypropylene connector and 30’ PVC cable
C DE ELECTRICAL UTPUTS
A 4–20 mA (12–30 VDC input)**
B 0–10 VDC (12–30 VDC input)
C 0–5 VDC (12–30 VDC input)
C DE SENS R INTERFACE
P1 CTFE sensor interface (default)
P2 PFA sensor interface
C DE PRIMARY/SEC NDARY SEAL
U1 Kalrez 4079 / Viton (default)
U2 Kalrez 1050 / Viton
U3 Kalrez 6375 UP / Viton
S1 Kalrez 4079 / Kalrez 4079
S2 Kalrez 1050 / Kalrez 1050
S3 Kalrez 6375 UP / Kalrez 6375 UP
* For detailed pressure limit information on Flaretek tube fitting connections, refer to the Maximum
Pressure Capabilities chart in the Flaretek fittings product section on Entegris’ website at
http:// .entegrisfluidhandling.com.
** The 4–20 mA electrical output, operated with 12–28 VDC input, is ETL listed for conformance to
UL Standard 2279, Class 1, Zone 0, 1 and 2, Ex ia A T6.
ENTEGRIS, INC. Customer Service Tel. [phone] Customer Service Fax [phone]
NT PRESSURE TRANSDUCER USER GUIDE
Model 4210 Flow-through Pressure Transducer
Example model number: 4210-100G-F02-D06-A-P1-U1

NT PRESSURE TRANSDUCER USER GUIDE
16 Customer Service Tel. [phone] Customer Service Fax [phone] ENTEGRIS, INC.
C DE PRESSURE RANGE
030G 207 kPa (30 PS G)
060G 414 kPa (60 PS G)
100G 690 kPa (100 PS G)
150G 1034 kPa (150 PS G)
CDE INLET/ UTLET P RT C NNECTI N
F02 1⁄4” Flaretek
F03 3⁄8” Flaretek
F04 1⁄2” Flaretek
N02 1⁄4” FNPT
N04 1⁄2” FNPT
M02 1⁄4” MNPT
C DE ELECTRICAL UTPUTS
A 4–20 mA (12–30 VDC input)
B 0–10 VDC (12–30 VDC input)
C 0–5 VDC (12–30 VDC input)
Model 4130 Single-port Pressure Transducer
Example model number: 4130-100G-F02-A
C DE PRESSURE RANGE
030G 207 kPa (30 PS G)
060G 416 kPa (60 PS G)
100G 690 kPa (100 PS G)
C DE INLET/ UTLET P RT C NNECTI N
F02 1⁄4” Flaretek
F03 3⁄8” Flaretek
F04 1⁄2” Flaretek
F06 3⁄4” Flaretek*
F08 1” Flaretek*
C DE ELECTRICAL UTPUTS
A 4–20 mA (12–30 VDC input)
B 0–10 VDC (12–30 VDC input)
C 0–5 VDC (12–30 VDC input)
* For detailed pressure limit information on Flaretek tube fitting connections, refer to the Maximum
Pressure Capabilities chart in the Flaretek fittings product section on Entegris’ website at
http:// .entegrisfluidhandling.com.
Model 4230 Flow-through Pressure Transducer
Example model number: 4230-100G-F02-A

ENTEGRIS, INC. Customer Service Tel. [phone] Customer Service Fax [phone]
NT PRESSURE TRANSDUCER USER GUIDE
Installation Drawings
4100 Single-port Pressure Transducer with Flared Connection
3 conductor FEP-jacketed cable,
pigtail connection (BXX)
(Cable length up to 30 feet)
25.4 mm (1.00”)
76.2 mm (3.00”)
B
A
Ø 47.8 mm
(1.88”)
3 conductor connector/cable (DXX)
(Cable length up to 30 feet)
A
Ø 47.8 mm
(1.88”)
B
4–20 mA V LTAGE
UTPUT UTPUT
PIN WIRE VERSI N VERSI N
10 Black Ground Ground
VDC–
11 Red 24 VDC 24 VDC
VDC+ (12–30 VDC) (12–30 VDC)
12 White Not used 0–5 VDC signal or
0–10 VDC signal
INLET/ UTLET
P RT C NNECTI N AB
1⁄4”Flaretek 76.2 mm (3.00”) 25.2 mm (0.99”)
3⁄8”Flaretek 76.2 mm (3.00”) 26.9 mm (1.06”)
1⁄2”Flaretek 76.2 mm (3.00”) 29.0 mm (1.14”)
ELECTRICAL C NNECT R INF RMATI N
INLET/ UTLET
P RT C NNECTI N AB
1⁄4”Flaretek 76.2 mm (3.00”) 25.2 mm (0.99”)
3⁄8”Flaretek 76.2 mm (3.00”) 26.9 mm (1.06”)
1⁄2”Flaretek 76.2 mm (3.00”) 29.0 mm (1.14”)
11.4 mm (0.45”)
4–20 mA V LTAGE
UTPUT UTPUT
WIRE VERSI N VERSI N
Red 24 VDC 24 VDC
VDC+ (12–30 VDC) (12–30 VDC)
Black Ground Ground
VDC–
White Not used 0–5 VDC signal or
0–10 VDC signal
ELECTRICAL C NNECT R INF RMATI N
Receptacle with
plug removed

NT PRESSURE TRANSDUCER USER GUIDE
18 Customer Service Tel. [phone] Customer Service Fax [phone] ENTEGRIS, INC.
4100 Single-port Pressure Transducer with NPT Connection
3 conductor Teflon®-jacketed
cable, pigtail connection (BXX)
(Cable length up to 30 feet)
25.4 mm (1.00”)
76.2 mm (3.00”)
11.4 mm (0.45”)
B
A
Ø 47.8 mm
(1.88”)
3 conductor connector/cable (DXX)
(Cable length up to 30 feet)
Receptacle
with plug
removed
B
A
Ø 47.8 mm
(1.88”)
INLET/ UTLET
P RT C NNECTI N AB
1⁄4” NPT 76.2 mm (3.00”) 15.0 mm (0.59”)
1⁄4” FNPT 82.3 mm (3.24”) —
1⁄2” FNPT 88.9 mm (3.50”) —
INLET/ UTLET
P RT C NNECTI N AB
1⁄4” NPT 76.2 mm (3.00”) 15.0 mm (0.59”)
1⁄4” FNPT 82.3 mm (3.24”) —
1⁄2” FNPT 88.9 mm (3.50”) —
4–20 mA V LTAGE
UTPUT UTPUT
PIN WIRE VERSI N VERSI N
10 Black Ground Ground
VDC–
11 Red 24 VDC 24 VDC
VDC+ (12–30 VDC) (12–30 VDC)
12 White Not used 0–5 VDC signal or
0–10 VDC signal
ELECTRICAL C NNECT R INF RMATI N
4–20 mA V LTAGE
UTPUT UTPUT
WIRE VERSI N VERSI N
Red 24 VDC 24 VDC
VDC+ (12–30 VDC) (12–30 VDC)
Black Ground Ground
VDC–
White Not used 0–5 VDC signal or
0–10 VDC signal
ELECTRICAL C NNECT R INF RMATI N

ENTEGRIS, INC. Customer Service Tel. [phone] Customer Service Fax [phone]
NT PRESSURE TRANSDUCER USER GUIDE
3 conductor FEP-jacketed cable,
pigtail connection (BXX)
(Cable length up to 30 feet)
25.4 mm (1.00”)
B
A
6.4 mm (0.25”)
C
INLET/ UTLET
P RT C NNECTI N ABC
1⁄4” Flaretek 89.7 mm (3.53”) 94.5 mm (3.72”) 18.5 mm (0.73”)
3⁄8” Flaretek 89.7 mm (3.53”) 98.3 mm (3.87”) 17.0 mm (0.67”)
1⁄2” Flaretek 96.0 mm (3.78”) 102.4 mm (4.03”) 21.6 mm (0.85”)
3⁄4” Flaretek 104.4 mm (4.11”) 108.5 mm (4.27”) 25.4 mm (1.00”)
1” Flaretek 112.5 mm (4.43”) 120.7 mm (4.75”) 30.5 mm (1.20”)
4–20 mA V LTAGE
UTPUT UTPUT
WIRE VERSI N VERSI N
Red 24 VDC 24 VDC
VDC+ (12–30 VDC) (12–30 VDC)
Black Ground Ground
VDC–
White Not used 0–5 VDC signal or
0–10 VDC signal
ELECTRICAL C NNECT R INF RMATI N
4210 Flow-through Pressure Transducer with Flared Connection
5.1 mm (0.20”) (2)
59.9 mm (2.36”)
44.5 mm
(1.75”)
47.2 mm
(1.86”)
44.5 mm”
(1.75)
