Entel HT700 Series User manual

HT700 Series
VHF/UHF submersible transceivers
OWNERS MANUAL
V/01

CE COMPLIANCE STATEMENT
The HT700 series transceiver displays "CE" on the serial number label,
indicating its compliance with the essential requirements of the EEC directive
for Electromagnetic Compatibility.
DECLARATION OF CONFORMITY
We Entel UK Limited,
OF:
4 Elstree Gate, Elstree Way
Borehamwood, Herts
WD6 1JD
United Kingdom
Declare under our sole responsibility that the product:-
HT700 series VHF/UHF handheld transceiver
Serial Number
To which this declaration relates, is in accordance with directive 95/5/EC and
conforms to the following standard or other nominative documents:-
EN 300 086-2 V1.1.1, EN 301 489-1 V1.5.1:2003, EN 60065:2002
Following provisions of the R&TTE directive.
M. Austin.
Quality Manager
2

3
1.1 GENERAL FEATURES
1.2 PACKING LIST
1.3 OPTIONS (ACCESSORIES)
1.3.1 ATTACHING AUDIO ACCESSORIES
1.4 CONTROLS AND INDICATORS
1.5 LCD INDICATORS
1.6 RECEPTION
1.7 TRANSMITTING
1.8 ADDITIONAL FEATURES
1.9 VOX (voice operated transmit)
2.0 BATTERY CHARGING
2.1 OPTIONAL RAPID CHARGER-model CSA640E
2.2 BATTERY INDICATOR
2.3 BATTERY SAFETY
2.4 TROUBLE SHOOTING
2.5 SPECIFICATION (General, receive and transmit)
2.6 NOTES
04
04
05
06
07
10
11
11
12
12
13
13
14
15
16
17
19
TABLE OF CONTENTS

4
Heavy duty, commercial grade construction
Submersible / Fully waterproof to JIS7
128 PC programmable channels
All CTCSS & DCS tones
Scan mode
Four programmable buttons
Lithium-lon battery technology
14 hour duty cycle
VOX (voice operated transmit)
Low battery warning bleep
Battery level indicator
Extensive range of accessories
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
12.
1.1 GENERAL FEATURES
The supplied package:
HT720/780
CNB640E
CBH640
CAT20/80
Owners manual
Transceiver
Rechargeable lithium-lon battery pack
Spring loaded rear clip
High efficiency antenna
1.2 PACKING LIST

5
The HT700 Series is supported by a wide range of useful accessories.
For an up to date list visit our web site at www.entel.co.uk
CSA640E
CSB640E
CMC12
CMC230
CMC110
CNB640E
CMP1/640
CMP640
EA19/640
EA15/640
EA12/640 D shape earpiece microphone with in-line PTT
MSP01/640
CHP1/640
CHP640HS
CHP640HD
CHP640D
CXR5/640
CXR16/640
EHP640
CFC640
CLC940
CLC640
CXW640
CAT20VS
CAT80US
CAT20
CAT80
CBH940
Single pod intelligent rapid charger, 110/230v operation
Six pod rapid charger, 110/230v operation
12v trickle charger
230v trickle charger
110v trickle charger
7.4V 1800mAh rechargeable lithium-Ion battery pack
Small compact speaker microphone with earpiece jack
Submersible, noise cancelling speaker microphone (heavy duty)
Earpiece microphone with PTT button
Covert style ear/microphone with transparent acoustic tube
Crash helmet earpiece microphone with PTT
Light weight single earpiece hardhat with PTT (vox)
Heavy-duty single ear defender for hardhat with PTT (vox)
Heavy duty double ear defender for hardhat with PTT (vox)
Heavy duty double ear defender with headband and PTT (vox)
Skull microphone (vox)
Throat microphone (vox)
Covert style earpiece
Coloured soft pouch with carry strap. (Red, blue, yellow)
Heavy duty leather case with belt loop & carry strap
Heavy duty transparent case with belt loop & carry strap
Antenna adaptor for external aerial connection
Stubby antenna VHF
Stubby antenna UHF
High efficiency antenna, VHF
High efficiency antenna, UHF
Spring loaded rear clip
1.3 OPTIONS (ACCESSORIES)
Accessories suitable for vox operation have been marked (vox)

6
Locate accessory connector cover marked "ACC" Lift cover and
rotate (screw) the connector clockwise.
1.3.1 ATTACHING AUDIO ACCESSORIES
1. Attaching the belt clip; Align the belt clip with the plastic slots of
the battery pack. Slide the belt clip downwards onto the battery
pack, pushing firmly until a click is heard.
2. BATTERY REMOVAL/ATTACHMENT
Preparation prior to use
Note: The accessory socket is waterproof
without the ACC cover in place. However, when
not using an audio accessory we strongly
advise keeping the ACC cover firmly pressed in
its recess to prevent foreign objects from getting
into the socket.
Figure 1.
Attachment of accessory connector
1. Turn the transceiver off.
2. Using a coin, rotate the battery screw anti-clockwise 2 or 3 turns.
**Ensure that you do not hold the battery pack when
unscrewing the release screw!

7
Figure 2.
Battery removal / Attachment
To remove rotate
the screw
anti-clockwise
3. To attach the battery, locate
the bottom section of the
battery and press the battery
against the transceiver, then
rotate the battery screw
clockwise.
1.4 CONTROLS AND INDICATORS
POWER SWITCH/VOLUME CONTROL
Powers the transceiver on and off. Adjusts volume to desired level.
PUSH TO TALK SWITCH
Hold down to transmit, release to receive.
UP/DOWN button
Select the desired channel by pressing the UP/DOWN buttons.
For fast channel selection hold down for more than 1 second.
LAMP/LOCK button
P1, P2, P3, P4 buttons
Dealer programmable.
button
Dealer programmable.
1.
2.
3.
4.
5.
6.

8
MON buttons
Dealer programmable.
ANTENNA CONNECTOR
Connects the supplied flexible antenna or an optional external
aerial adaptor.
BATTERY PACK
Rechargeable lithium-lon battery packs provides power to the transceiver.
ACCESSORY CONNECTOR
To connect any HT700 Series radio to an Entel approved
audio accessory.
7.
8.
9.
10.

Figure 3. Controls and Connectors
POWER SWITCH
PTT
UP/DOWN
MON
LAMP/LOCK
ANTENNA CONNECTOR
BATTERY PACK
ACCESSORY CONNECTOR
DEALER
PROGRAMMABLE
(FUNCTION)
9

10
CHANNEL DISPLAY
The operating channel.
Appears when bleep sound is turned on.
H/L
H indicates high power L indicates low power.
SCAN
Appears when scan is activated.
TX
Indicates transmission in progress.
RX
Indicates reception is in progress.
VOX
Voice operated mode enabled.
The keypad is locked.
BATTERY LIFE INDICATOR
The lithium-lon battery of your transceiver is continually
monitored for your convenience and safety.
MON
Monitor button, to open the squelch.
1.5 LCD INDICATORS
Figure 4. LCD indications

11
1.7 TRANSMISSION
1. Perform steps 1 through 3 of RECEPTION.
2. Before transmitting, monitor the channel and make sure it is clear.
3. When receiving a signal, wait until the signal stops before transmitting.
The transceiver cannot transmit and receive simultaneously.
4. Press the [PTT] (push-to-talk) switch to begin your transmission.
To confirm transmission in progress the LED illuminates RED,
and TX is displayed on the LCD.
5. Holding the transceiver 1 inch from your mouth speak slowly and
clearly into the microphone.
6. When the transmission is finished, release the [PTT] switch.
1. Turn the transceiver on by rotating the volume control in a
clockwise direction. A power on tone is generated after 1
second to indicate the transceiver has passed its
self-diagnostic test. Select the desired audio level by further
rotating the control clockwise. After power on, the transceiver
will always default to the last channel selected.
2. Select the desired channel using the [UP/DOWN] buttons.
3. When receiving a signal the LED indicator illuminates green,
and "RX" is displayed on the LCD.
1.6 RECEPTION

12
1.8 Additional features
The HT700 Series incorporates some additional features that can be
of positive benefit to your organisation. These features can be set-up
and accessed in a number of different ways using any one of the
programmable buttons. Please contact your dealer to discuss your
exact requirements.
1.9 VOX Voice operated transmit
Any one of the programmable buttons can be assigned to access
the VOX feature.
In VOX mode the transceiver will react to your voice and transmit
automatically without you having to press the PTT button.
There is always a slight delay for the electronic switching, and
consideration will need to be given.
To get optimum performance from the VOX feature you should
use a noise cancelling headset or earpiece microphone
(see accessory options marked VOX)

2.0 BATTERY CHARGING
1. Connect the CWC640 AC
adaptor to the CCA640
charger pod. The LED
status light will illuminate
green indicating ready for
charge.
2. Turn the transceiver off.
3. Insert the battery pack
into the CCA640 pod, either with or without the transceiver attached.
The LED status light changes from green to RED and trickle charge
begins.
4. A fully discharged battery pack will take approximately 6 hours to
charge, depending on the remaining power condition.
When charge is complete, the LED status light turns green.
NOTE : The CWC640 AC adaptor can be replaced by the CMC640
12v charger cable. Charge time remains at 6 hours.
Figure 5. CCA640 Charger pod
DC12V
P
1
P
2
P
3
P
4
2.1 OPTIONAL RAPID CHARGER-model CSA640E
1. Connect the CSA640E to a
mains supply(110 to 230V).
When switching on the
LED flashes orange briefly
to confirm self-diagnostic
test complete.
P
1
P
2
P
3
P
4
Figure 5-1. OPTIONAL CSA640E
Rapid charger
110-230VAC
13

14
2. Turn the transceiver off.
3. Insert the battery pack into the CSA640E charger, either with or without
the transceiver attached. The LED will illuminate red to indicate rapid
charge in progress.
4. Charge time for a fully discharged battery pack will take up to
120 minutes. On completion the LED turns green.
2.2 BATTERY INDICATOR
For your safety and convenience your transceiver continually monitors the
battery pack and gives an indication on the LCD:
3 Segments : 14hours
2 Segments : 1hour
1 Segment : 20mins
Figure 6. Battery Indicator

15
Lithium-Ion battery packs must be recycled or disposed of properly.
For requirements in your area, check with the dealer from whom you
purchased your transceiver.
DO NOT INCINERATE
Do not dispose of your CNB640 battery in a fire or incinerator.
The heat of fire may cause battery cells to explode and/or release
dangerous gases.
DO NOT SHORT BATTERY PACK TERMINALS
Shorting the terminals that power the transceiver can cause sparks,
severe over heating, burns, and battery cell damage.
If the short is of sufficient duration, it is possible to melt the battery
components. Do not place a loose battery pack on or near a metal
surface or objects such as paper clips, keys, tools etc.
When the battery pack is installed on the transceiver, the terminals
that transfer current to the transceiver are not exposed.
The terminals that are exposed on the battery pack when it is mounted
on the transceiver are charging terminals only and do not constitute a
hazard.
DISPOSE OF BATTERY PACKS PROPERLY
2.3 BATTERY SAFETY
The battery pack of your transceiver contains lithium-Ion cells.
This type of battery stores a charge powerful enough to be dangerous
if misused or abused, especially when removed from the transceiver.
Please observe the following precautions:

16
TROUBLESHOOTING CHART
SYMPTOM
Transceiver not
switching on
Battery needs charging
Battery is exhausted
Charge the battery pack
Replace the battery pack
The scan key does not
start the scan
No channels
memorised (MEM)
Enter the desired channels
into scan memory
REMEDYPROBABLE CAUSE
2.4 TROUBLE SHOOTING
Cannot change any
function
Key lock is switched on Turn key lock off
LED on CCA640 & CWC640
does not illuminate when
charging
Defective battery,
CCA640, or CWC640
Dirty terminal contact
on CCA640
Contact your dealer
Clean contacts with dry
clean cloth
Receiving calls from other
users outside your radio
system
congestion on channel contact your dealer for new
frequency or sub tone
assignment
Transceiver transmits
without pressing PTT button
Buttons seem to work
intermittently
VOX has been enabled Press assigned vox button to
switch vox off.

128ch
148-174MHz(VHF)/440-470(UHF)MHz
22MHz(VHF)/30MHz(UHF)
25KHz
12.5KHz
5KHz/6.25KHz
59 x 33 x 130mm
296g
7.4V, Nominal
50mA, Max.
160mA, Max.
1,000mA, Max.
1,800mA, Max.
50 ohms
8 ohms
2.5ppm Max.
-20 to +55
2.5 SPECIFICATION(General, receive and transmit)
Performance specifications are nominal, unless otherwise indicated,
and are subject to change without notice.
GENERAL
Number of Channels
Frequency Range
Operational Bandwidth
Channel Spacing - Wide Band
Narrow Band
Channel Increments
Size (WxDxH)
Weight (With Battery and Antenna)
Battery Voltage
Current Drain
Squelched (w/out Power Saver)
Rated Audio
Transmit-1Watt
Transmit-5Watt
Antenna impedance
Speaker impedance
Frequency Stability
Operation Temperature
17

Sensitivity (12dB SINAD)
Squelch Sensitivity
Adjacent Channel Selectivity (ETS)-Wide Band
Narrow Band
Spurious Rejection (ETS)
Intermodulation (ETS)
Hum and Noise Ratio-Wide Band
Narrow Band
Rated Audio Output at 5% T.H.D.(1KHz)
>0.35uV Max.
>10dB SINAD
70dB Min.
-60dB Min
-70dB Min.
-65dB Min.
-45dB Min.
-40dB Min.
500mW Typical
RECEIVER
5W(VHF)/4W(UHF)
1W(VHF)/1W(UHF)
-36dBm<1GHz
-30dBm>1GHz
5KHz
2.5KHz
-40dB Typical
5% Max.
-70dB
-60dB
TRANSMITTER
RF Output Power-Hi Power
Lo Power
Spurious/Harmonic Emissions
Modulation-Wide Band
Narrow Band
FM Hum and Noise
Audio Distortion
Adjacent Channel Power-Wide Band
Lo Power
18

19
2.6 NOTES
Use this page to record important information, such as the
serial number of your HT700 Series transceiver, and any of the
frequencies and sub-tones programmed by your dealer.

NOTES
20
Other manuals for HT700 Series
6
Table of contents
Other Entel Transceiver manuals

Entel
Entel HT700 2.0 Series User manual

Entel
Entel HT446 User manual

Entel
Entel HT446E User manual

Entel
Entel HT9506 User manual

Entel
Entel HT642 User manual

Entel
Entel HT640 User manual

Entel
Entel HT640 User manual

Entel
Entel HT644 Series Setup guide

Entel
Entel HT20 User manual

Entel
Entel HT644 GMDSS User manual
