enware TFC714700 Installation and operating instructions

Call 1300 369 273
www.enware.com.au
Enware Australia Pty Limited
9 Endeavour Rd Caringbah NSW 2229 Australia
Ph: [phone] Fax: [phone]
I00278_Oct 17
ENWARE-DELABIE TIME FLOW
SPORTING SHOWER MODULE
Installation & Maintenance Instructions
TFC714700

www.enware.com.au Call 1300 369 273 2
compliance
Enware products are to be installed in
accordance with the Plumbing Code of Australia
(PCA), AS/NZS3500 and the manufacturer’s
instrucons.
Installaons not complying with PCA, AS/NZS
3500 or the manufacturer’s instrucons may
void the product and performance warranty
provisions.
This product must be installed and commissioned
by a qualied plumber.
please note
Enware Australia advises due to ongoing Research
and Development, specicaons may change
without noce.
Component specicaons may change on some
export models.
before installation
Before Proceeding With Installaon
• Ensure all operang and dimensional
specicaons are suitable for the intended
installaon.
• Ensure all supply lines are ushed thoroughly
to remove debris prior to the installaon of
this product as per AS/NZS 3500.1. Strainers
(40 mesh) are recommended if debris is an
ongoing problem.
• A Pressure reducon valve may be required
to comply with the recommended maximum
supply pressure and balanced pressure
requirements.
As the product is a single inlet – single outlet
valve, it is necessary that water temperature and
ow are pre-set to the unit. It is recommended
that an Aquablend Thermostac Mixing valve is
used to provide pre-mixed water to the valve..
technical data
ENWARE-DELABIE TIME FLOW
SPORTING SHOWER MODULE
Installation & Maintenance Instructions
Inlet Connecon 15mm (1/2” BSP) Male
Working Pressure Range 150-500 kPa
Recommended Pressure for
Opmum Performance 250-350 kPa
Maximum Tesng Pressure 1000 kPa
Maximum Water Temperature 60°C**
Recommended Maximum Water
Temperature 41°C**
Operang Force 22N @ 300 kPa
Flow Time 30 seconds +5 /-10 ^
Flow Rate 6 Lpm (Adjustable)
Finish Anodized Aluminium / San Chrome
** As the product is a single inlet –
single outlet valve, it is necessary that
water temperature and ow are pre-set
to the unit. It is recommended that an
Aquablend Thermostac Mixing valve is
used to provide pre-mixed water to the
valve.
^ Times are indicave only and may
vary depending on the water supply
pressure and ow condions.

www.enware.com.au Call 1300 369 273 3
*Recommended shower installaon height
Floor Level
2100*
2220*
1/2” BSP Male
TOP INLET
1030
Floor Level
2100*
2170*
1/2” BSP Male
BACK
INLET
1015
985
57.5
10
100
26
130
200
180
110
85
22
33
16 55
10
5TYP
DEPTH)
SPACE FOR
CIRCUIT BOARD
(REQUIRES 30mm
COVER PLATE
OUTLINE
57.5
10
100
26
130
200
180
110
85
22
33
16 55
10
5TYP
DEPTH)
SPACE FOR
CIRCUIT BOARD
(REQUIRES 30mm
COVER PLATE
OUTLINE
TOP INLET SETOUTBACK INLET SETOUT
DIMENSIONS

www.enware.com.au Call 1300 369 273 4
SPORTING SHOWER PANEL WITH TOP INLET
1. Posion the panel so that the shower nozzle is 2.10m
from the oor. (See Dimensions on Page 2)
2. Using the removal tool [31] (supplied) or a pair of
circlip pliers, unscrew the outer locking ring [3] and
remove the top cover [7] IMAGE 1
3. From the boom of the shower, unscrew the two
screws [4] using a Phillips head screwdriver and
remove the end-cap [2] IMAGE 1
4. Mark and drill the four holes for panel xing near top
and boom of the panel frame [at 6 and 6’]
5. Six the panel in place using the four screws supplied
(Use wall plugs that are suitable for the wall
material.)
6. Install the lter [8] and connect to the mixed water
supply. A thermostac mixing valve is recommended
to be installed upstream of the water supply.
7. Using a 3mm Allen key check that the stopcock [32]
is fully open (an-clockwise) IMAGE 3
8. Turn on water supply and check for leaks
9. Replace the top cover and ghten up the outlet
locking ring using the removal tool
10. Replace the end cap and ghten the two screws
SPORTING SHOWER PANEL WITH BACK INLET
ROUGH-IN
11. Posion the panel so that the shower nozzle [5] is
2.10m from the oor (or the water supply is 2.17m
above the ground) (See dimensions on page 2)
12. A thermostac mixing valve is recommended to be
installed upstream for the water supply
13. Supply a 1/2” BSP Female ng in wall. Length of
male threaded screw [37] IMAGE 4 is approx. 23mm
deep from nished wall
8
6’
7
1
6
2
32
5
3
4
2220
2100
6’
40
3
5
6
1
4
2
2100
2170
32
57.5
10
100
26
130
200
180
110
85
22
33
16 55
10
5TYP
DEPTH)
SPACE FOR
CIRCUIT BOARD
(REQUIRES 30mm
COVER PLATE
OUTLINE
57.5
10
100
26
130
200
180
110
85
22
33
16 55
10
5TYP
DEPTH)
SPACE FOR
CIRCUIT BOARD
(REQUIRES 30mm
COVER PLATE
OUTLINE
IMAGE 1
IMAGE 4
31
32
57.5
10
100
26
130
200
180
110
85
22
33
16 55
10
5TYP
DEPTH)
SPACE FOR
CIRCUIT BOARD
(REQUIRES 30mm
COVER PLATE
OUTLINE
IMAGE 2 IMAGE 3
INSTALLATION PROCEDURE

5 Call 1300 369 273 www.enware.com.au
FIT OFF
14. Using the removal tool [31] (supplied) or a pair of
circlip pliers, unscrew the outlet locking ring [3]
and remove the top cover [7]
SEE IMAGE 2 &3 on page 4
15. Remove the inlet assembly [33] by unscrewing nut
[34] using a 19mm spanner (not supplied) IMAGE 3
on previous page. Do not lose the washer [36]
16. Close the stopcock [32] (clockwise) using a 3mm
Allen key. IMAGE 3 on page 4
17. Fully unscrew hinge nut [35] with a 14mm spanner
(not supplied) IMAGE 5
18. Turn the threaded screw [37] around and screw
hinge nut [35] back up IMAGE 5 (Note: If the
threaded screw is not turned around the blank cap
on top cover will not t in Step 16)
19. Connect inlet assembly to the mixed water supply
by screwing the 1/2” BSP threaded screw [37] into
the wall ng, making sure that the threaded
connecon has a waterproof seal. Tighten so that
the groove on the inlet assembly [38] is in line with
the mounng nished wall surface [39] IMAGE 6
20. Using a 3mm Allen key, check that the stopcock
[32] is closed (turn clockwise). Turn on the water
supply and check the threaded joint for leaks.
IMAGE 3 on page 4
21. From the boom of the shower, unscrew the two
screws [4] using a Phillips screwdriver and remove
the end-cap [2] IMAGE 5
22. Posion the panel, insert sealing washer [36] and
ghten the nut back up [34] IMAGE 3 on page 4
23. Mark and drill the four holes for panel xing near
top and boom of the panel frame [at 6 and 6’]
IMAGE 5
24. Fix the panel in place using the four screws
supplied. (Use wall plugs that are suitable for the
wall material)
25. Turn on water supply and check the threaded
joint for leaks
26. Open the stopcock [32] (an-clockwise) using
a 3mm Allen key. IMAGE 5
27. Slide the blank cap [40] into the slot on the
top cover [7] IMAGE 5
28. Replace the top cover and ghten up the outer
locking ring using the removal tool
29. Replace the end-cap, ghten the two screws
6’
40
3
5
6
1
4
2
2100
2170
32
57.5
10
100
26
130
200
180
110
85
22
33
16 55
10
5TYP
DEPTH)
SPACE FOR
CIRCUIT BOARD
(REQUIRES 30mm
COVER PLATE
OUTLINE
IMAGE 5
37
35
32
39
2170
38
57.5
10
100
26
130
200
180
110
85
22
33
16 55
10
5TYP
DEPTH)
SPACE FOR
CIRCUIT BOARD
(REQUIRES 30mm
COVER PLATE
OUTLINE
IMAGE 5
57.5
10
100
26
130
200
180
110
85
22
33
16 55
10
5TYP
DEPTH)
SPACE FOR
CIRCUIT BOARD
(REQUIRES 30mm
COVER PLATE
OUTLINE
IMAGE 6

www.enware.com.au Call 1300 369 273 6
COMMISSIONING
Press the starter [1] IMAGE 1 &2 repeatedly to purge
the air unl the automac shut-o stabilises (~ 30 sec.
+5/ -10). The rst cycles can last 5-7 minutes. Pressing
on the starter [1] releases a jet of water.
This causes the shower to open hydraulically. Releasing
the starter will stop the jet of water aer the set delay
me.
OPERATION
1. Press the push-buon starter [1] to open the valve
IMAGE 1 &4
2. Automac shut-o aer ~30 seconds (+5/-10 – ow
me may vary depending on water supply pressure
and ow condions).
SETTINGS
Adjusng Direcon of Water Jet from Nozzle
The water jet from the nozzle [5] can be rotated
through 20°. Apply pressure with your thumb on the
nozzle [5] and adjust to desired posion. IMAGE 7
Locking the Positon of the Nozzle
The rotaonal posion can be locked in place.
To do this:
1. Remove the nozzle [5] using the removal tool [31]
IMAGE 7
2. Using a 19mm spanner, carefully ghten the nut
3. Replace the nozzle [5], taking care not to block it
PROBLEM CAUSE RECTIFICATION
Time ow tap does not shut o
Dripping / trickling constantly
Debris fouling cartridge Clean the cartridge or replace if dam-
aged. See Maintenance secon following
Automac shut-o takes too
long. Run me is longer than
specied Time ow tap does
not shut o
Debris fouling cartridge Clean the cartridge or replace if damaged.
See Maintenance secon following
5
31
41
57.5
10
100
26
130
200
180
110
85
22
33
16 55
10
5TYP
DEPTH)
SPACE FOR
CIRCUIT BOARD
(REQUIRES 30mm
COVER PLATE
OUTLINE
IMAGE 7
COMMISSIONING & OPERATION
TROUBLESHOOTING

7 Call 1300 369 273 www.enware.com.au
FROST PROTECTION
To protect SPORTING shower from damage due to
freezing, it is recommended to remove the shower
unit from wall and store it in a frost-free area.
The pipework, stopcocks, mixers and all sanitary ware
must be checked regularly, and at least once a year.
DIRT OR ABRASIONS ON THE O-RINGS ON STARTER
Using the removal tool [31] unscrew the outer locking ring
[3] and remove the top cover [7]
SEE IMAGE 1 & 3 or 2 & 3 on page 4
1. Turn o the water supply by closing the stopcock [32]
(clockwise) IMAGE 1 &4 on page 4
2. Unscrew the two screws [4] and remove the end cap
[2] IMAGE 1 &4 on page 4
3. Remove the starter, parally loosening the holding
screw [20] with a screwdriver IMAGE 8
4. Remove the ring using a at screwdriver, applying
pressure to eject the starter assembly IMAGE 8
5. Check/clean the O-rings [21] and [22] IMAGE 8
6. Replace starter and the ring: press fully on starter then
release; ghten the screw [20] IMAGE 8
7. Open the water supply by opening the stopcock [32]
(an-clockwise)
8. Replace the top cover and ghten the outer locking
ring using the removal tool
9. Replace the end cap and ghten the two screws
DIRT OR ABRASIONS ON THE O-RINGS ON SHOWER HEAD
MECHANISM
1. Using the removal tool [31], unscrew the outer locking
ring [3] and remove the top cover [7]
SEE IMAGE 1 &3 or 2 &3 on page 4
2. Turn o the water supply by closing the stopcock [32]
(clockwise)
3. Using a 30mm spanner, unscrew the mechanism body
[42] IMAGE 9
4. Remove the delay case [25], the spring [26] and the
piston [27], taking care not to lose the washer [24].
IMAGE 10B
5. Clean the inside of the delay case [25] with
a cloth, and the ming groove [30] with a
non-metallic point, and check/clean the seals [28] and
[29] IMAGE 10A &10B
6. Replace the mechanism assembly not forgeng the
washer [24] IMAGE 10B
7. Restore the water supply by opening the stopcock
(an-clockwise)
8. Replace top cover and ghten outer locking ring
CLEANING THE FILTER
1. Using the removal tool [31], unscrew the outer locking
ring [3] and remove the top cover [7]
SEE IMAGE 1 & 3 or 2 & 3 on page 4
2. Turn o the water supply by closing the stopcock [32]
(clockwise) using a 3mm Allen key
3. With the same Allen key, unscrew the lter holder [43]
and clean the lter [44] IMAGE 11
4. Replace the lter [44] and the lter holder [43]
5. Restore the water supply by opening the stopcock
(an-clockwise)
6. Replace the top cover and ghten the outer locking
ring using the removal tool
1
1
2
4
22
21
20
32
24
25
26
2
2
2
42
57.5
10
100
26
130
200
180
110
85
22
33
16 55
10
5TYP
DEPTH)
SPACE FOR
CIRCUIT BOARD
(REQUIRES 30mm
COVER PLATE
OUTLINE
57.5
10
100
26
130
200
180
110
85
22
33
16 55
10
5TYP
DEPTH)
SPACE FOR
CIRCUIT BOARD
(REQUIRES 30mm
COVER PLATE
OUTLINE
IMAGE 8 IMAGE 9
44
32
43
B
24
25
26
27
28
29
A
25
30
B
24
25
26
27
28
29
A
25
30
57.5
10
100
26
130
200
180
110
85
22
33
16 55
10
5TYP
DEPTH)
SPACE FOR
CIRCUIT BOARD
(REQUIRES 30mm
COVER PLATE
OUTLINE
IMAGE 10A IMAGE 10B
57.5
10
100
26
130
200
180
110
85
22
33
16 55
10
5TYP
DEPTH)
SPACE FOR
CIRCUIT BOARD
(REQUIRES 30mm
COVER PLATE
OUTLINE
IMAGE 11
MAINTENANCE

PRODUCT WARRANTY FOR AUSTRALIA Eecve 1 September 2014
Enware Australia Pty Limited (ACN 003 988 314)
(“we” or “us”) warrants that this product (also referred
to as “our goods”) will be free from all defects in
materials and workmanship for 24 months* from the
date of purchase. Our liability under this warranty is
limited at our opon to the repair or replacement of
the defecve product or part, the cost of repair of the
defecve product or part or the supply of an equivalent
product or part, in each case if we are sased the
loss or damage was due to a defect in the materials or
workmanship of the product or part. All products must
be installed in accordance with the manufacturer’s
instrucons, the PCA, and AS/NZS3500 including any
other applicable regulatory requirements.
exceptions
This warranty does not apply in respect of any damage or
loss due to or arising from:
a) Failure by you or any other person to follow any
instrucons for use (including instrucons and direcons
relang to the handling, storage, installaon, ng,
connecon, adjustment or repair of the product)
published or provided by us;
b) Failure by you or any other person responsible for the
ng, installaon or other work on the product to follow
or conform to applicable laws, standards and codes
(including the AS/NZ 3500 set of Standards, all applicable
State and Territory Plumbing Codes, the Plumbing Code
of Australia and direcons and requirements of local and
other statutory authories); or
c) Any act or circumstance beyond our control including
faulty installaon or connecon, accident, abnormal use,
acts of God, damage to buildings, other structures or
infrastructure and loss or damage during product transit
or transportaon.
making a claim
To make a claim under this warranty you must
nofy us in wring within 7 days of any alleged defect
in the product coming to your aenon and provide us
with proof of your purchase of the product together with
a completed Product ServiceRequest form (ENF091),
which is available on request from our oce or website
(see contact details below). All nocaons and
accompanying forms must be sent to us marked for the
aenon
of the Enware Australia Pty Limited, 9 Endeavour Road,
Caringbah NSW 2229. We can also be contacted by
telephone [phone]) or by
email (inf[email protected]om.au). Your costs in making a
claim under this warranty, including all freight, collecon
and delivery costs, are to be borne and paid by you. We
also reserve the right at our cost
to inspect any alleged defect in the product wherever it
is located or installed or on our premises.
*Condional warranty: Jumper Valve Tapware - 2 Years: 1
year parts and labour on the complete assembly then
a further 1 year parts only warranty is applicable
Ceramic Disc Cartridge Tapware - 10 Years: 10 Year
ceramic disc cartridges – parts only; 1 Year parts and
labour on complete assembly
Outlets - 1 Year parts and labour on the complete
assembly
other conditions
Except as provided or referred to in this document, we
accept no other or further liability for any damages
or loss (including indirect, consequenal or economic
loss) and whether arising in contract, tort or otherwise.
Any benets available to you under this warranty are in
addion to any non-excludable rights or remedies you
may have under applicable legislaon, including as a
“consumer” under the Australian Consumer Law. To that
extent you need to be aware that: Our goods come with
guarantees that cannot be excluded under the Australian
Consumer Law. You are entled to a replacement or
refund for a major failure and for compensaon for any
other reasonably foreseeable loss or damage. You are
also entled to have the goods repaired or replaced if
the goods fail to be of acceptable quality and the failure
does not amount to a major failure.
