EMERGENCY TANK SHOWER
AND EYE WASH
Assembly | Commissioning | Maintenance
INSTALLATION COMPLIANCE
Installaon of emergency showers, eye and eye/face wash equipment shall be in accordance with
AS4775 or ANSI Standard Z358.1 whichever is applicable to the installaon.
Tank Shower frame is not Cyclone Rated when mounted on FRP Grid Base. Tank Shower frame with privacy panels is Category B
Cyclone Rated when bolted to the specied concrete slab and when tank is at least half full of water.
Note: Tank shower must be installed as per manufacturer’s drawings and installaon instrucons.
ET1400F ET1400FP
ET1400FB
(with powder coang opon)
ET1400FBP

2 Call 1300 369 273 www.enware.com.au
1. Remove the tank lid.
Lid is secured with M12 bolts. Use a 19mm socket (or
equivalent) to unscrew the bolts.
2. The `oat’ has been xed in place with a carabiner onto
the eyelet loop so that it is secure during transportaon.
When removing the carabiner for assembly, please be
careful to lower the oat slowly unl oat and chain come
to a stop; if it is dropped quickly it can cause damage to
the ow controller and/or the oat (SEE IMAGE 1).
Check that the chain has not become entangled during
transportaon.
prior to installation
FLOAT
IMAGE 1
ASSEMBLING THE FRAME
The Flat Pack frame* is a frame that comes in 6 parts, and will
need to be assembled on site before commencing (SEE IMAGE 2).
The Flat Pack frame is located inside the tank for transportaon,
ready to be lied out of the tank via the slings aached to the
frames, by using a forkli or a crane.
Each frame component is secured by the xing bolts supplied.
Use 120mm long bolts for vercal xings and 70mm long bolts for
horizontal xings, with smaller M12 washers and nuts.
An-Seize is pre-applied on bolt threads. Apply more An-Seize if
required. Tighten all bolts rmly but do not over-ghten.
*Enware Tank Shower Sales Codes:
ET1400F - Tank, at pack frame
ET1400FP - Tank, at pack frame, side panels
ET1400FB - Tank, at pack frame, foot base
ET1400FBP - Tank, at pack frame, foot base, side panels
assembly
IMAGE 2
Float connected
to ow controller
by chain

www.enware.com.au Call 1300 369 273 3
ASSEMBLING RELOCATABLE FOOT BASE (ET1400FB, ET1400FBP)
1. The Foot Base is supplied as shown, with four FRP Grang
Mats, and ve Clamping Plate Sets. SEE IMAGE 3
IMAGE 4
2. Posion the Grang Mats as shown, taking note of the
orientaon of the pre-installed Mounng Plates.
SEE IMAGE 4
IMAGE 6IMAGE 5
IMAGE 3
3. Join the Grang Mats by using Clamping Plate Sets as shown.
SEE IMAGE 5 & 6

www.enware.com.au Call 1300 369 273 4
TANK INSTALLATION
4. Find the coil of eyewash hose supplied inside the tank.
Uncoil the hose and feed the hose through the top back
frame as shown (SEE IMAGE 9), with the free end loose,
ready for connecon to the tank.
Insert the other end of hose into the push-t connector on
the eyewash, and push unl it booms out.
IMAGE 9
IMAGE 8
MOUNTING PLAT E
INSTALLING ONTO GROUND SURFACE
Secure the tank shower frame onto the ground, a relocatable
foot base or concrete foong. Use appropriate xing bolts or
anchors through the Mounng Plates to x the shower frame
securely to the ground.
For installaon requiring cyclone wind category rang, see
page 7.
Important: Ensure the frame is installed on a at, level
surface.
INSTALLING ONTO GROUND WITH RELOCATABLE FOOT BASE
Place the Foot Base onto a at, level surface.
The ground surface must be well compacted and have a
maximum slope of 1% when installed on subgrade.
All four corners of the Frame have Mounng Plates to allow
the Frame to be bolted to the Foot Base.
Aach the Bolts and Washers into the corresponding
Mounng Plates already on the Foot Base, and x the Frame
onto Foot Base assembly. Use An-Seize compound on all
bolts to allow for any disassembly and relocaon of the
shower unit in future.
Install ramps up to the Foot Base on all sides, to reduce the
risk of trip hazard.
IMAGE 7
installation

5 Call 1300 369 273 www.enware.com.au
5. Check that the tank is not lled with water before installing
tank to the frame.
Li the tank onto the frame using a forkli or a crane. When
liing using a sling, use the four liing lugs located on the top
corners of the tank.
Take care to align the bolt mounng holes on the frame
with the matching threaded holes on the boom of the tank
assembly (SEE IMAGE 10).
Tank is ONLY to be lied when completely empty of water.
6. Use 80mm bolts (x10) and two larger washers (Acetyl and
stainless steel supplied) for each bolt, to x the tank in place.
Acetyl (plasc) washer should be placed closest to the frame,
so that the Acetyl washer is sandwiched between the frame
and stainless steel washer (SEE IMAGE 11).
Apply An-Seize onto bolt thread before ghtening.
Tighten bolts rmly but do not over-ghten.
7. Insert the eyewash hose into the bulk head ng, and push
unl it booms out (SEE IMAGE 12). (The ng is a push-t
connector and does not require further ghtening.)
IMAGE 10
IMAGE 11
IMAGE 12

6 Call 1300 369 273 www.enware.com.au
8. Locate the inlet ll assembly and t to the Inlet connecon of
the tank (SEE IMAGE 13).
The union connecon will have to be disassembled to screw
the top elbow in. Use appropriate thread sealing tape, to seal
the inlet connecon.
NOTE:
Inlet connecon for inlet ll assembly is noted by an arrow
directed into tank.
Overow outlet is noted by an arrow out of tank.
Assemble union connecons for inlet ll assembly, then
secure the inlet ll assembly onto tank frame using brackets
supplied. The frame has pre-drilled holes to accomodate
the 2x bracket xing screws (M6 head cap screws). Place
rubber clamps around the plasc pipe to secure the inlet ll
assembly onto bracket.
9. Reach inside boom access of tank, and pull the acvaon
valve arm down. Use appropriate step ladder to do so.
Aach shower acvaon pull handle to the acvaon valve
arm using the nut and bolt supplied (SEE IMAGE 14).
INSTALLATION IS NOW COMPLETED AND THE TANK SHOWER IS
READY TO BE COMMISSIONED.
SEE PAGE 6 FOR COMMISSIONING.
IMAGE 13
IMAGE 14

7 Call 1300 369 273 www.enware.com.au
Note: Tank Shower frame is not Cyclone Rated when
mounted on FRP Grid Base.
Tank Shower frame with privacy panels is Category B Cyclone
Rated when bolted to the specied concrete slab and when
tank is at least half full of water.
MOUNTING ANCHORS
The frame is to be anchored to the reinforced concrete
foong specied below, using the 6 mounng plates on the
frame (SEE FIGURE 1).
Each mounng plate has provision for 4 or 2 anchor bolts/rods
(NOT SUPPLIED), for a total of 20 to fully anchor the frame.
The 20 anchors must be of an M12 Stainless Steel Epoxy type
with 150mm embedment into the reinforced concrete foong
to meet Cercaon Requirements.
FOUNDATION: The foong is to be founded upon a minimum
150kPa material.
CONCRETE SPECIFICATIONS
ELEMENT SLUMP AGGREGATE
SIZE
CEMENT
TYPE F’C - MPA
FOOTING
SLAB
80mm 20mm max. GP 32
REINFORCED CONCRETE FOOTING SPECIFICATIONS
Reinforced concrete foong is to be a minimum
2000 x 2000 x 200mm (SEE FIGURE 2) with 16mm Diameter
Bars (with a Tensile Stress Capacity of 500 MPa) running at
200mm each way both top and boom (SEE FIGURE 3).
Foong must have a 50mm top and edge cover
and a 65mm boom cover.
CONCRETE NOTES
1. All workmanship and materials shall be in accordance
with AS3600-2001 concrete structures code.
2. Concrete quality and clear concrete cover are to be as
specied.
3. Concrete element sizes do not include thickness of any
applied nishes.
4. All concrete shall be mechanically vibrated. The vibrator
shall not be used to spread concrete.
5. Reinforcement is shown diagramacally, not necessarily
shown in true projecon.
6. All reinforcement shall be rmly supported on plasc
or MS plasc pped or galvanised chairs placed at not
greater than 800mm centres both ways.
cyclone wind catergory B requirements
200
2000
2000
FIGURE 2
FIGURE 1
FIGURE 3
Cross Secon showing reinforcement bars in one direcon
200

8 Call 1300 369 273 www.enware.com.au
1. Aach water source to the 40mm inlet camlock ng
(SEE IMAGE 15).
Use only clean water to ll the tank.
2. Turn on water supply and commence lling.
3. Take note of the water level indicator (SEE IMAGE 16).
When it reaches the yellow level, acvate the shower and
eye wash to ush the line and to test operaon.
When acvang the eye wash for the rst me, take the
aerators out of eye wash outlet to clear the line of any
debris.
Check for any leaks in joints and connecons.
4. Turn shower and eye wash o, and connue to ll.
Replace aerators onto the eye wash outlet.
5. Once water starts to ow out from the internal overow,
turn o the infeed water and disconnect from the 40mm
camlock ng. (SEE IMAGE 15)
COMMISSIONING COMPLETE
Shower and eyewash are now commissioned and tank shower
and eyewash are ready for use.
commissioning
IMAGE 15
IMAGE 16
FULL
EMPTY

9 Call 1300 369 273 www.enware.com.au
Descripon Part Number Image
FIXINGS-FLATPACK FRAME TO PALLET ET14SP002
10 X BOLTS
M16X80
10 X ACETAL WASHERS
10 X SS316
WASHERS M16
WATER LEVEL ASSEMBLY ET14SP003
TEMPERATURE GAUGE ET14SP004
SIGNAGE SHOWER - EYEWASH STAINLESS STEEL ET14SP005
FLOW CONTROLLER - ORIFICE PLATES ET14SP006
SHOWER ROSE ASSEMBLY ET14SP007
spare parts

10 Call 1300 369 273 www.enware.com.au
Descripon Part Number Image
PULL HANDLE ASSEMBLY ET14SP008
EYEWASH CONNECTOR KIT ET14SP009
EYEWASH OUTLET KIT ET14SP010
ASSEMBLED
FOOT BASE CLAMP KIT ET14SP011
ASSEMBLED
FOOT BASE CENTRE CLAMP KIT ET14SP012
ASSEMBLED
FOOT BASE CLAMP M10X25 SCREW - SET OF 6 ET14SP013
FOOT BASE PANEL - 1 PANEL ET14SP014

11 Call 1300 369 273 www.enware.com.au
cleaning
Enware product should be cleaned with a so damp cloth using only mild liquid detergent or soap and water.
Do not use cleaning agents containing a corrosive acid, sourcing agent or solvent chemicals. Do not use cream
cleaners, as they are abrasive. Damage caused this way will not be covered by warranty.
Descripon Part Number Image
FOOT BASE ANCHOR PLATE KIT - LEFT ET14SP015L
ASSEMBLED
FOOT BASE ANCHOR PLATE KIT - RIGHT ET14SP015R
ASSEMBLED
INFILL KIT ET14SP016

WEEKLY UNIT ACTIVATION
In accordance with ANSI Z358.1 or AS 4775
(whichever is applicable).
The unit should be acvated every week for a period
long enough to verify operaon and ensure the ushing
uid is available. The tank must then be relled to the
correct height.
Note: the intent is to ensure that there is a ushing uid
supply at the head of the device and to clear the supply
line of any sediment build up that could prevent uid
from being delivered to the head of the device and to
minimise microbial contaminaon due to sing water.
Internal eye wash strainer should also be removed and
cleaned during this process or when required.
ANNUAL INSPECTION
In accordance with ANSI Z358.1 or AS4775
(whichever is applicable).
Shower units and eye wash shall be inspected annually
by a qualied technician to ensure ongoing performance.
INSPECTION TAGS
Inspecon tags are available (if not already supplied) to
record weekly and annual inspecons. If you need to
purchase inspecon tags contact Enware.
FILTER MAINTENANCE
Filters to be checked and cleaned once a month or in
accordance with usage. Filters are located at Y-Strainer
on the inlet ll assembly, and at the lter strainer in the
eye wash tee piece.
WATER QUALITY CHECK
Enware recommends that water quality is checked for
suitability of use in an emergency. These checks should
be done periodically (at intervals based on the specic
site risk assessment) to determine if the ushing uid
needs to be replaced.
CLEANING THE TANK
It is recommended to empty the tank periodically to
ensure good water quality. The interval will depend on
the specic site risk assessment.
maintenance schedule
Eye Wash Filter Strainer
AS4775
Lic SMKP21998
SAI Global
Australian
Standard
ANSI Z358.1
Lic SMKP20545
SAI Global
Global-Mark.com.au®
O
H
&
S
M
a
n
a
g
e
m
e
n
t
S
y
s
t
e
m
s
.
A
S
/
N
Z
S
4
8
0
1
