enware ECE030 Assembly instructions

Call 1300 369 273
www.enware.com.au
Enware Australia Pty Limited
9 Endeavour Rd Caringbah NSW 2229 Australia
Ph: [phone] Fax: [phone]
I00067_Dec 17
EMERGENCY SHOWER,
EYE & EYE/FACE WASH
Installation, Operating & Maintenance Instructions
ECE030
ECE060
ECE090
ECE240
ECE270
ENBE060
ENBE090
ENBE240
ENBE270
NOTE: THIS DOCUMENT IS TO BE LEFT ONSITE WITH FACILITY MANAGER AFTER INSTALLATION

2 Call 1300 369 273 www.enware.com.au
product descriptions
ECE030
EMERGENCY STAINLESS STEEL SHOWER
ECE090
EMERGENCY STAINLESS STEEL
COMBINATION SHOWER WITH HAND/
FOOT OPERATED EYEWASH
ECE060
EMERGENCY STAINLESS STEEL
COMBINATION SHOWER WITH
HAND OPERATED EYEWASH
ECE240
EMERGENCY STAINLESS STEEL
COMBINATION SHOWER WITH HAND
OPERATED EYE/FACE WASH
ECE270
EMERGENCY STAINLESS STEEL
SHOWER WITH HAND/FOOT
OPERATED EYE/FACE WASH
ENBE060
EMERGENCY STAINLESS STEEL
COMBINATION SHOWER WITH HAND
OPERATED NO-BOWL EYEWASH
ENBE090
EMERGENCY STAINLESS STEEL
COMBINATION SHOWER WITH HAND/
FOOT OPERATED NO-BOWL EYEWASH
ENBE270
EMERGENCY STAINLESS STEEL
COMBINATION SHOWER WITH HAND/FOOT
OPERATED NO-BOWL EYE/FACE WASH
ENBE240
EMERGENCY EMERGENCY STAINLESS STEEL
COMBINATION SHOWER WITH HAND
OPERATED NO-BOWL EYE/FACE WASH

www.enware.com.au Call 1300 369 27 3
technical information
installation compliance
Inlet Connecon 25mm (1” BSP)
Water Supply Line Size Supply piping shall be adequately sized to meet ow requirements
Minimum Requirements to achieve
ANSI Z358.1-2009 and AS/NZS 4775
2007 compliance
Min Working Pressure: 210 kPa (30 psi)
Cauon should be taken when pressure exceeds 550 kPa (80 psi)
Shower Minimum Flow 75.7 lpm (20 US gpm)
Eye Wash Minimum Flow 1.5 lpm (0.4 US gpm)
Eye/Face Wash Minimum Flow 11.4 lpm (3 US gpm)
Enware Performance
At Working Pressure: 210 kPa (30 psi)
Shower Flow 76 lpm (20 US gpm)
Eye Wash Flow 17 lpm (4.5 US gpm)
Eye/Face Wash Flow 26 lpm (6.9 US gpm)
Waste Water Outlet Size 38.1 mm (1½”) OD
Mounng Base Plate Size 150 x 150 mm (5 9/10 “ x 5 9/10”) with 4 bolts 11 mm (7/16”)
Shipping Approximate Weight: 9.5 - 13.5 kilograms
Dimensions: 1150 x 287.5 x 200 mm
Supply Lines
Installaon procedures shall be in accordance with proper
plumbing pracces. Supply piping shall be adequately sized
to meet ow requirements. If shut o valves are installed
for maintenance purposes, provisions shall be made to
prevent unauthorised shut o.
Placement of Emergency Equipment
Emergency eyewash and shower equipment shall be
available for immediate use. It shall take no longer than
10 seconds for an individual to reach the nearest facility.
Factors that inuence the locaon of emergency facilies
include workplace lighng, obstrucons to the path of
travel and the work environment. It should be noted that
some situaons may warrant the placement of equipment
signicantly closer to the hazard. In these situaons, such
as exposure to highly corrosive chemicals, the proper
distances should be selected based on the advice from
appropriate consultants. For situaons such as exposure to
strong acids or alkalis, due consideraon needs to be given
to possible reacon between the ushing uid and the
chemical if the ushing uid enters a bulk container of the
chemical.
Flushing Fluid Temperature
Connuous and mely irrigaon of aected ssues for
the recommended irrigaon period are the principal factors
in providing rst aid treatment. Providing ushing uid
at temperatures conducive to use for the recommended
irrigaon period is considered an integral part of providing
suitable facilies. Medical recommendaons suggest a
ushing uid at tepid temperature be delivered to aected
chemically-injured ssue. Temperatures in excess of 38ºC
have proven to be harmful to the eyes and can enhance
chemical interacon with the eyes and skin. During design
and installaon, the eects of exposure of pipe to sun,
radiant heat or other heat sources should be considered,
and suitable control measures should be introduced
to avoid any risk of scalding. While cold ushing uid
temperature provide immediate cooling aer chemical
contact, prolonged exposure to cold uids aects the ability
to maintain adequate body temperature and can result
in the premature cessaon of rst aid treatment. Before
emergency eyewash and shower equipment is selected,
a risk assessment shall be carried out to determine the
most appropriate delivery temperature for the applicaon.
Means to ensure a constantly suitable delivery temperature
shall also be idened during selecon, so that equipment
can perform as desired once installed.
Installaon of emergency showers, eye and eye/face wash equipment shall be in accordance with AS/NZS4775-2007
or ANSI Standard Z358.1-2009 - whichever is applicable to the installaon. REFER to checksheet on pages 10 and 11.

4 Call 1300 369 273 www.enware.com.au
components
ECE030 ECE060 ECE090 ECE240 ECE270
2
3
4
1
#Descripon
1 Base Frame Complete with Inspection Tag
2 Shower Arm & Rose
3 Pull Handle
4 Upper frame with ball valve
2
1
4
7
3
6
5
8
G
G
G
ITEM NO. PART NUMBER DESCRIPTION QTY.
1 794224 SUB ASS ECE TOP COMPLETE 1
2 794225
SUB ASS ECE PULL HANDLE 1
3 794553
SUB ASSY SHOWER ARM AND ROSE ECE SHOWER 1
4 891097
BOWL NEW STYLE 304 SS 0.9MM ECE 1
5 790486
SUB ASS FOOT PEDAL W/CABLE ECE SHOWER 1
6 794592
SUB ASS EYE/FACE WASH OUTLET ECE CAST 1
7 794250
SUB ASS ECE BOTTOM W/EYEWASH CTRL CAST 1
8 794591
SUB ASS PUSH HANDLE W/ STICKER ECE CAST 1
REVISION
REV. DATE ECN DESCRIPTION
MODIFIED
BY
D 24/05/12 960 WAS 965
KN
E 20/09/13 INSTALL DETAILS ADDED
KN
F 4/12/14 2639 PULL HANDLE POSITION CHANGED
YK
G 30/03/15 4852
794250 WAS 794230; 794592 WAS 790481; 794591 ADDED; 995 WAS
960; 1015 WAS 990
YK
DRAWN
CHECKED
APPROVED
GENERAL NOTES:
- REMOVE ALL BURRS AND SHARP
EDGES UNLESS OTHERWISE STATED
- ALL THREADS TO BE CHAMFERED
- DIMENSIONS ARE IN mm's
- DO NOT SCALE OFF DIMENSIONS
TOLERANCE EXCEPT WHERE STATED:
NO DECIMAL POINT
+
-
2
ONE DECIMAL PLACE
+
-
1
ANGLES
+
-
1
ENWARE RESERVES THE RIGHT TO
AMMEND PRODUCT SPECIFICATIONS
AND DESIGNS WITHOUT NOTICE
FINISH:
SHEET: 2 OF 2
TITLE
S/S COMB D/SHWR E/F WSH
HND/FT
This drawing is the
property of Enware
Australia Pty Ltd and
may not be reproduced
in full or part without the
written consent of
Enware Australia.
9 Endeavour Rd,
Caringbah, NSW, 2229
Ph. 61-2-9525-9511
Fax. [phone]
LR
AC
KN
A
B C D
D
C B
A
1
2
3
44
3
2
1
SIZE: A4
SCALE: 1:16
DRAWING
NUMBER:
Quality Endorsed
Company
AS/NZS ISO 9001
LIC No. 1213
Standards Australia
ECE270
#Descripon
1 Upper Frame with Ball Valve
2 Pull Handle
3 Shower Arm and Rose
4 New Style Bowl - 304 SS
5 Foot Pedal with Cable*
6A Eye Wash Outlet Assembly
6B Eye/Face Wash Outlet Assembly
7 Base Frame with Eyewash Control & Waste
8 Inspection Tag
* ECE090 and ECE270 only
2
1
4
6
3
5
7
F
F
F
ITEM NO. PART NUMBER DESCRIPTION QTY.
1 794224 SUB ASS ECE TOP COMPLETE 1
2 794225
SUB ASS ECE PULL HANDLE 1
3 794553
SUB ASSY SHOWER ARM AND ROSE ECE SHOWER 1
4 891097
BOWL NEW STYLE 304 SS 0.9MM ECE 1
5 794589
SUB ASS EYEWASH OUTLET ECE CAST SHOWER 1
6 794250
SUB ASS ECE BOTTOM W/EYEWASH CTRL CAST 1
7 794591
SUB ASS PUSH HANDLE W/ STICKER ECE CAST 1
REVISION
REV. DATE ECN DESCRIPTION
MODIFIED
BY
C 27/01/12 BOM CHANGED
KN
D 7/03/12 TOLERANCES ADDED
KN
E 4/12/14 2639 PULL HANDLE POSITION CHANGED
YK
F 31/03/15 4852
794250 WAS 794230; 794589 WAS 794368; 794591 ADDED; 995 WAS
960; 1005 WAS 985
YK
DRAWN
CHECKED
APPROVED
GENERAL NOTES:
- REMOVE ALL BURRS AND SHARP
EDGES UNLESS OTHERWISE STATED
- ALL THREADS TO BE CHAMFERED
- DIMENSIONS ARE IN mm's
- DO NOT SCALE OFF DIMENSIONS
TOLERANCE EXCEPT WHERE STATED:
NO DECIMAL POINT
+
-
2
ONE DECIMAL PLACE
+
-
1
ANGLES
+
-
1
ENWARE RESERVES THE RIGHT TO
AMMEND PRODUCT SPECIFICATIONS
AND DESIGNS WITHOUT NOTICE
FINISH:
SHEET: 2 OF 2
TITLE
SS DELUGE SHOWER HAND
OPERATED
This drawing is the
property of Enware
Australia Pty Ltd and
may not be reproduced
in full or part without the
written consent of
Enware Australia.
9 Endeavour Rd,
Caringbah, NSW, 2229
Ph. 61-2-9525-9511
Fax. [phone]
LR
AC
KN
A
B C D
D
C B
A
1
2
3
44
3
2
1
SIZE: A4
SCALE: 1:15
DRAWING
NUMBER:
Quality Endorsed
Company
AS/NZS ISO 9001
LIC No. 1213
Standards Australia
ECE060
6A6B

5 Call 1300 369 273 www.enware.com.au
ENBE060 ENBE090 ENBE240 ENBE270
#Descripon
1A Eye Wash Outlet Assembly
1B Eye/Face Wash Outlet Assembly
2 Upper Frame with Ball Valve
3 Base Frame with Eye Wash Control
4 Pull Handle
5 Shower Arm and Rose
6 Foot Pedal with Cable*
7 Inspection Tag
* ENBE090 and ENBE270 only
6
2
7
1B
3
1A
4
5

www.enware.com.au Call 1300 369 27 6
assembly/installation procedure
1. Place the unit so there is enough space for any addional
plumbing xtures being used (drain, taps, strainers,
shut-o valves). Bolt base of Lower Shower Assembly to a level
oor using 4 corrosion resistant anchors (see AS/NZS 2982.1,
ANSI Z358.1-2009 and AS/NZS4775-2007).
Base Plate is 150mm square with mounng holes at 100mm
centres. SEE IMAGE 1.
2. Apply sealing tape or Locte 577 to threaded end of shower rose
assembly and screw it into the ball valve of the Upper Shower
Assembly. SEE IMAGE 2. Tighten to an aligned posion where
the shower head is parallel to the oor.
3. Aach the pull arm to the Upper Ball Valve using the nut already
on the ball valve. SEE IMAGE 3. The valve arm should point up at
45 degrees when in the o posion.
4. Connect Upper Shower Assembly to Lower Shower
Assembly using the integral Stainless Steel Union.
SEE IMAGE 4. No tools are required.
Be sure the rubber O-ring is in place on the tapered secon of
the union and ghten by hand. For combinaon showers, make
sure the arm of the shower is centered over the Eye (Eye/Face)
wash.
100 TYP
100 TYP
11.1 TYP - CLIENT
TO SUPPLY BOLTS
TO SUIT
150mm
25
25
IMAGE 1
Upper Frame
Shower Arm and Rose
IMAGE 2
Upper Frame
Base Frame
Stainless Steel
Union
Place upper part onto
lower part vertically align,
then tighten the union.
IMAGE 4
IMAGE 3

7 Call 1300 369 273 www.enware.com.au
assembly/installation procedure
Eye (Eye/Face) Wash Installaon Procedure
5. Aach the Eye or Eye/Face wash push handle
to the Acvaon Ball Valve using the spring
washer & hexagonal nut already on the ball valve.
SEE IMAGE 5.
6. If a bowl is to be included with the Eye (Eye/Face)
wash, place the Bowl on top of the Waste Adaptor.
Using the Washer and the Waste – screw in to the
Waste Adaptor to secure the bowl. Turn as ght
as you can with ngers, then turn Waste and Bowl
together using the outside edge of the bowl for extra
leverage. SEE IMAGE 6
7. Remove the grub screw from the front of the waste
adaptor.
Push the eye (eye/face) wash assembly into the
centre of the waste adaptor making sure the
direconal arrow is facing the front.
Re-t the grub screw and ghten unl it locates
within the eye wash frame.
8. Connect the water supply line to the 1” thread
located on the Upper Shower Assembly. Use thread
tape or Locte 577 on all threads.
9. Connect the drain line (if applicable) for the Eye
(Eye/Face) Wash Sink using the 1½” OD outlet located
on the Lower Shower Assembly. There should be
sucient clearance for the addion of a drain trap
if required.
Waste
Washer
Bowl
Waste
A
daptor
IMAGE 6
DRAWN
CHECKED
APPROVED
GENERAL NOTES:
- REMOVE ALL BURRS AND SHARP
EDGES UNLESS OTHERWISE STATED
- ALL THREADS TO BE CHAMFERED
- DIMENSIONS ARE IN mm's
- DO NOT SCALE OFF DIMENSIONS
TOLERANCE EXCEPT WHERE STATED:
NO DECIMAL POINT
+
-
2
ONE DECIMAL PLACE
+
-
1
ANGLES
+
-
1
ENWARE RESERVES THE RIGHT TO
AMMEND PRODUCT SPECIFICATIONS
AND DESIGNS WITHOUT NOTICE
FINISH:
SHEET: 2 OF 2
TITLE
S/S F/STND EYE WSH HAND
OPERATE
This drawing is the
property of Enware
Australia Pty Ltd and
may not be reproduced
in full or part without the
written consent of
Enware Australia.
9 Endeavour Rd,
Caringbah, NSW, 2229
Ph. 61-2-9525-9511
Fax. [phone]
LR
CL
KN
A
B C D
D
C B
A
1
2
3
44
3
2
1
SIZE: A4
SCALE: 1:10
DRAWING
NUMBER:
Quality Endorsed
Company
AS/NZS ISO 9001
LIC No. 1213
Standards Australia
EEE180
IMAGE 7
Waste Adaptor
Eye Wash
Push Handle
Activation
Ball Valve
Spring Washer
Hex Nut
2x Washers
IMAGE 5

www.enware.com.au Call 1300 369 27 8
10. (For Foot-Operated Models Only) Back o the two
rear shower mounng bolts. Slide the bracket under
the washers of the shower mounng bolts and
reghten. Reaach foot pedal plate to bracket using
bolts supplied. Do not over ghten. SEE IMAGE 8
Aach cable to push handle and set the cable length.
To do this, turn the push handle to the full on posion
and lower the foot pedal to approximately 3mm
from the ground. Loosen the locking nut using the
4mm Allen key, pull excess cable through and re-
ghten nut. Return push handle to the o posion.
SEE IMAGE 9
11. Before turning on the water supply to the unit make
sure both the shower and Eye (Eye/Face) wash valves
are closed.
Push up the shower pull rod so the valve arm is
poinng back up and pull forward the Eye (Eye/Face)
wash “PUSH” handle back up to ensure the valves are
in the closed posion.
12. Turn water supply on. Check for leaks before
proceeding.
13. Slowly push the Eye (Eye/Face) wash valve handle
forward to start the water ow.
Flush unl the water runs clean then pull back
on the push handle to stop ow. Replace aerator
assemblies.
Remove internal strainer by un screwing the strainer
cap with a at head screw driver.
Clean strainer and re t.
14. With the aerators reinstalled, use a at screwdriver
to turn o the Ball Valve before Eye (Eye/Face) Wash
Acvaon Ball Valve. Turn the push handle to the full
open posion and adjust the second ball valve with
screwdriver unl the correct ow is achieved. SEE
IMAGE 10 and 11.
15. To acvate the shower, pull down on the triangular
pull rod. A large amount of water will ow from the
showerhead on to the oor. The spray paern should
be 508mm in diameter at a height of 1524mm from
the oor. SEE IMAGE 12.
The shower should also deliver at a minimum ow
rate of 75.7 lpm.
16. Once correct operaon has been checked, turn o
the valves by posioning the handles to the fully o
posion.
Note: Water will drain through the 2mm hole near
the shower head/ball valve connecon. This is a self-
draining feature designed to drain water remaining
in shower head to reduce Legionella risk.
Place dust covers over Eye (Eye/Face) wash outlets.
Mount appropriate Shower and Eye (Eye/Face) wash
signage as required - refer to Enware’s Product Guide
or call Customer Service on 1300 369 279.
Foot pedal adjustment
IMAGE 8
Split ring
IMAGE 9
IMAGE 12
2438 max.
2083 min.
1524
ø 508 min.
Fluid Stream
R 406 min. Free from obstructions
IMAGE 11
32
83
38
max
Point of fluid
stream interaction
Fluid stream
Required
coverage widths
Fluid stream
IMAGE 10

9 Call 1300 369 273 www.enware.com.au
operating and training instructions
SHOWER OPERATION
Pulling down on the triangular pull handle acvates
the shower; this handle opens the 1’’ ball valve
allowing water to ow through to showerhead. To
close the shower valve and stop ow the handle is
pushed upwards. The water remaining in shower head
will drain through the self-draining hole aer closing
the valve.
EYE, EYE/FACE WASH OPERATION
The Eye/Face wash is acvated by pushing forward
(away from the user) the at “PUSH” handle. This
opens the ½’’ ball valve allowing water to ow to the
Eye, Eye/Face wash outlets. To close the valve and stop
ow, gently pull the handle back up (towards the user).
FOOT PEDAL OPERATION
(ECE090, ENBE090, ECE270, ENBE270)
The Eye, Eye/Face wash can be acvated by pushing
down the foot pedal where marked. This opens the
½’’ ball valve allowing water to ow to the Eye, Eye/
Face wash outlets. To close the valve and stop ow
gently pull the “PUSH” handle back (towards the user).
Releasing the foot pedal will not stop the ow.
Instrucons for all emergency equipment shall be readily accessible to maintenance and training personnel.
Employees who may be exposed to hazardous materials shall be instructed in the locaon and proper use of
emergency shower equipment. Refer to AS/NZS 4775 or ANSI Z358.1 where applicable.
The unit should be acvated every week for a period long enough to
verify operaon and ensure the ushing uid is available. Note: the intent
is to ensure that there is a ushing uid supply at the head of the device
and to clear the supply line of any sediment buildup that could prevent
uid from being delivered to the head of the device and to minimise
microbial contaminaon due to sing water. Internal eye/face wash
strainer should also be removed and cleaned during this process or when
required.
All shower units shall be inspected annually by a qualied technician
to assure conformance with ANSI Z358.1-2009 or AS/NZS 4775- 2007
whichever is applicable to the installaon.
DRAWN
CHECKED
APPROVED
GENERAL NOTES:
- REMOVE ALL BURRS AND SHARP
EDGES UNLESS OTHERWISE STATED
- ALL THREADS TO BE CHAMFERED
- DIMENSIONS ARE IN mm's
- DO NOT SCALE OFF DIMENSIONS
TOLERANCE EXCEPT WHERE STATED:
NO DECIMAL POINT
+
-
0.2
ONE DECIMAL PLACE
+
-
0.1
TWO DECIMAL PLACES
+
-
0.05
ANGLES
+
-
1
FINISH:
SHEET: 1 OF 1
MATERIAL:
TITLE
SUB ASS EYEWASH OUTLET ECE
CAST SHOWER
This drawing is the
property of Enware
Australia Pty Ltd and
may not be reproduced
in full or part without the
written consent of
Enware Australia.
9 Endeavour Rd,
Caringbah, NSW, 2229
Ph. 61-2-9525-9511
Fax. [phone]
-
-
AM
A
B C D
D
C B
A
1
2
3
44
3
2
1
SIZE: A4
SCALE: 1:2
DRAWING NUMBER
. .
Quality Endorsed
Company
AS/NZS ISO 9001
LIC No. 1213
Standards Australia
maintenance

www.enware.com.au Call 1300 369 27 10
AS4775 – 2007 Safety Equipment Minimum Performance Checklist
Installaon shall be in accordance with proper plumbing pracces.
Supply piping shall be adequately sized to meet ow requirements.
(Sec D1)
All plumbed emergency equipment shall be connected to a connuous
source of ushing uid supply which may be drinking water, preserved
water, preserved buered saline soluon or other medically acceptable
soluon manufactured and labelled in accordance with applicable
government regulaons. (Sec 4.4, 4.10, 6.7 (c)), 7.5 (b), 8.5 (b), 9.5 (b),
11.3.3 (c))
All equipment shall be constructed of corrosion–resistant materials
(Sec 4.2, 5.1) Note: The Plumbing Code of Australia does not allow the
use of galvanised pipes or ngs on drinking water supply lines. AS/
NZS3500.1 Sec 2.4.2(c)
Safety Staon shall be accessible within 10 seconds of hazard. (Sec 6.6,
7.4, 8.4, 9.4)
Safety equipment shall be located on the same level as the hazard and
the path of travel shall be free of obstrucons.
(Sec 6.6, 7.4, 8.4, 9.4)
Emergency equipment locaon shall be well illuminated and be
idened by a highly visible sign complying with AS1319 visible
throughout the area served by the equipment. (Sec 6.6, 7.4, 8.4, 9.4)
Employees who may be exposed to hazardous materials shall be
trained in the locaon and proper use of emergency equipment. (6.8,
7.6, 8.6, 9.6).
Emergency equipment shall be acvated weekly to verify operaon
(6.8, 7.6, 8.6, 9.6)
Emergency equipment shall be inspected annually to ensure
conformance with the requirements of AS4775. (Sec 6.8, 7.6, 8.6, 9.6)
Combinaon unit components shall comply with the individual
performance requirements of the shower, eye wash & eye/face wash
while operang simultaneously & shall be posioned so components
may be used simultaneously by the same user. (Sec 9.3, 9.5 (b), 9.5 (e) (iii))
Drench hoses are considered supplemental equipment to provide
immediate ushing to support plumbed and self-contained equipment
but shall not replace them. (Sec 11.1)
Drench hoses shall be simple to operate and shall go from closed to
fully open in one second or less. The valve shall be corrosion resistant.
(Sec 11.3.2)
Showerhead shall be not less than 2083mm and not more than
2438mm from the surface on which the user stands. (Sec 6.5.1, 9.1
(b)) 
Shower shall deliver a minimum of 75.7 l/min of ushing uid at
210kPa, with the ushing uid being substanally dispersed throughout
the paern which shall be of a minimum diameter of 508mm when
measured at 1524mm above the surface on which the user stands. (Sec
6.2, 6.5, 9.1 (b), 9.3) 
The shower operang control valve shall remain open without the use
of the operator’s hands. The valve shall be simple to operate and shall
go from closed to fully open in one second or less and not be located
more than 1733mm from the surface on which the user stands. The
valve shall be corrosion resistant. (Sec 6.3, 7.2, 8.2, 9) 
Eye wash equipment shall deliver ushing uid to both eyes
simultaneously at a ow rate not less than 1.5 l/min at 210kPa. The
ushing uid streams should rise to approximately equal heights and
should cover the areas between the interior and exterior lines of the
test gauge, and when lowered not more than 38mm below the uids
peak. (Sec 7.1, 9.1 (c), 7.3.1) 





 
Eye / face wash equipment shall deliver ushing uid
to the eyes simultaneously at a ow rate not less than
11.4 l/min at 210kPa. The ushing uid streams should
rise to approximately equal heights and should cover
the areas between the interior and exterior lines of the
test gauge when lowered not more than 38mm below
the uids peak. (Sec 8.1, 8.3, 9.1 (d)) 
The ushing uid nozzles of eye and eye/face wash
units shall be not less than 838mm and no greater than
1143mm from the surface on which the user stands
and 153mm from the wall or nearest obstrucon.
(Sec7.4, 8.4, 9.1 (c), 9.1 (d)) 
The eye and eye/face wash operang control valve
shall remain open without the use of the operator’s
hands. The valve shall be simple to operate and go
from closed to fully open in one second or less. The
valve shall be corrosion resistant. (Sec 7.2, 8.2, 9.1 (c),
9.1 (d)) 

11 Call 1300 369 273 www.enware.com.au
 








RECOMMENDED TESTING FLOW PRESSURE IS
30 psi (+.5 psi -.0 psi)
Safety equipment shall be accessible within 10 seconds of
hazard. (Sec 4.5.2, 5.4.2, 6.4.2, 7.4.2)
Safety station shall be located on the same level as the
hazard and the path of travel shall be free of obstructions.
(Sec 4.5.2, 5.4.2, 6.4.2, 7.4.2)
All employees subject to exposure to hazardous material
should be instructed in the location and proper use of
emergency equipment. (Sec 4.6.4, 5.5.4, 6.5.4, 7.5.4)
Emergency equipment shall be activated weekly.
(Sec. 4.6.2, 5.5.2, 6.5.2, 7.5.2) All shower units shall be
inspected annually to assure conformance with ANSI Z358.1.
(Sec. 4.6.5, 5.5.5, 6.5.5, 7.5.5)
Combination unit components shall be capable of operating
simultaneously and shall be positioned so that components
may be used simultaneously by the same user. (Sec. 7.3,
7.4.4)
All plumbed emergency equipment shall be connected to
a continuous source of ushing uid supply which may be
drinking water, preserved water, preserved buffered saline
solution or other medically acceptable solution manufactured
and labelled in accordance with applicable government
regulations.
Drench hose must deliver a controlled ow of ushing uid
at a velocity low enough to be non-injurious. (Sec. 8.2.1)
A drench hose can only be considered an eyewash –
eye/face wash if it meets performance requirements in
Sec. 5 and/or 6.
Delivery of tepid ushing uid.* (Sec. 4.5.6, 5.4.6, 6.4.6,
7.4.5). *Suggested temperature range – above 60°F (16°C)
and below 100°F (38°C)
Showerhead must be 82 to 96 inches (208.3cm – 243.8cm)
above surface oor of user (Sec. 4.1.3, 7.1) 
Shower must deliver minimum of 20 gallons (75.7L) per
minute and provide a column of water 20 inches (50.5cm)
wide at 60 inches (152.4cm) above the surface oor of the
user. (Sec. 4.1.2, 4.1.4, 7.1) 
Valve shall be designed so that the ushing ow remains on
without the use of the operator’s hands. The valve shall be
simple to operate and go from “off” to “on” in one second or
less and actuator can not be more than 69 inches (173.3cm)
from surface oor of user. (Sec. 4.2, 7.1) 
Emergency equipment location shall be well lit and identied
with a highly visible sign. (Sec. 4.5.3, 5.4.3, 6.4.3, 7.4.3) 
Must provide a means of controlled ow to both eyes
simultaneously at a velocity low enough to be non-injurious.
(Sec. 5.1.1, 6.1.1, 7.1) 
Eye/face wash equipment must deliver minimum of 3 gallons
(11.4L) per minute of water for 15 minutes. (Sec. 6.1.6, 7.1)
Eyewash only must deliver minimum of 0.4 gallon (1.5L) per
minute for 15 minutes. (Sec. 5.1.6, 7.1) 
The ushing uid of an eyewash – eye/face wash shall cover
the areas between the interior and exterior lines of a gauge at
some point less than 8 inches (20.3cm) above the eyewash
nozzle. (Sec. 5.1.8, 6.1.8, 7.1) 
Outlets shall be protected from airborne contaminants.
(Sec. 5.1.3, 6.1.3, 7.1) 
Flushing uid nozzles should be 33 to 45 inches
(83.8cm – 114.3cm) from oor and minimum of 6
inches (15.3cm) from wall. (Sec. 5.4.4, 6.4.4, 7.1)

Valve shall be designed so that the ushing ow
remains on without the use of the operator’s
hands. The valve shall be simple to operate and
go from “off” to “on” in one second or less. (Sec.
5.2, 6.2, 7.2) 
ANSI Z358.1-2009 Safety Equipment Minimum Performance Checklist
