EPCOM DVR Technical Manual
EV-1004 / EV-1008 / EV-1016 Series DVR
Technical Manual

Desarrollado en base de las últimas tecnologías EV Series combina la
codificación avanzada de de vídeo H.264 y el estándar de decodificación, para
mantener una alto rendimiento y un mayor tiempo de grabación.
EPCOM EV Series puede ser utilizado como un producto de video vigilancia
independiente, así como para construir una red de vigilancia de gran alcance
que es ideal para el hogar o pequeñas aplicaciones de negocio.
Overview

Grabación en D1 en todos sus canales
Saque el máximo a sus cámaras de alta resolución y tenga evidencia confiable.
Salida a 2 Monitores Simultáneos
Utilice un monitor para visualizar puntos críticos y otro para acceder a
grabaciones. O visualice video en tiempo real de diferentes cámaras en 2
monitores con su salida VGA y BNC simultáneo.
Compatibilidad con Celulares
Acceso Web utilizando Internet Explorer con Interface Gráfica Atractiva
y Sencilla.
Extracción rápida de grabaciones
No pierda el tiempo esperando a grabar un CD. Obtenga un respaldo completo
y rápido utilizando una memoria USB de fácil acceso por su panel frontal.
Eficiente y compacta
Bajo consumo de energía con un diseño elegante y robusto
No requiere de IP fija ni servicios de DDNS de costo
Evite molestias y costos adicionales en su instalación, utilice su servidor de
nombres gratuito.
Grabación de audio de alta calidad
Audio perfectamente sincronizado con video para un análisis preciso.
Compatibilidad PTZ
Compatible con cámaras PTZ localmente, por Internet o utilizando su celular.
Administración Centralizada
Administre hasta 250 DVRs en un PC y utilice hasta 4 monitores si lo requiere.
Main Features

Hikvision Technical Manual
©2006 –2011 by HIKVISION. All rights reserved.
Rear Panel of DS-7208HVI-ST/SN
①USB Interface
②VIDEO OUT
③VIDEO IN
④AUDIO IN
⑤AUDIO OUT
⑥VGA Interface
⑦LAN
⑧RS-485 Interface
⑨12VDC Power Supply Interface
⑩POWER
⑪GND
Hikvision Technical Manual
©2006 –2011 by HIKVISION. All rights reserved.
Rear Panel & Interfaces
Rear Panel of DS-7204HVI-ST/SN
①USB Interface
②VIDEO OUT
③VIDEO IN
④AUDIO IN
⑤AUDIO OUT
⑥VGA Interface
⑦LAN
⑧RS-485 Interface
⑨12VDC Power Supply Interface
⑩POWER
⑪GND
1.USB Interface
2. VIDEO OUT
3. VIDEO IN
4. AUDIO IN
1.USB Interface
2. VIDEO OUT
3. VIDEO IN
4. AUDIO IN
1.USB Interface
2. VIDEO OUT
3. VIDEO IN
4. AUDIO IN
Rear Panel & Interfaces
Panel trasero EV-1004
Panel trasero EV-1008
Panel trasero EV-1016
5. AUDIO OUT
6. VGA Interface
7. LAN
8. RS-485 Interface
5. AUDIO OUT
6. VGA Interface
7. LAN
8. RS-485 Interface
5. AUDIO OUT
6. VGA Interface
7. LAN
8. RS-485 Interface
9. 12VDC Power Supply
10. POWER
11. GND
9. 12VDC Power Supply
10. POWER
11. GND
9. 12VDC Power Supply
10. POWER
11. GND
Hikvision Technical Manual
©2006 –2011 by HIKVISION. All rights reserved.
Rear Panel of DS-7216HVI-ST/SN
①USB Interface
②VIDEO OUT
③VIDEO IN
④AUDIO IN
⑤AUDIO OUT
⑥VGA Interface
⑦LAN
⑧RS-485 Interface
⑨12VDC Power Supply Interface
⑩POWER
⑪GND

Specifications - EV1004
Hikvision Technical Manual
©2006 –2011 by HIKVISION. All rights reserved.
Specifications
Model
DS-7204HVI-ST/SN
Video/Audio
input
Video
compression
H.264
Analog video
input
4-ch, BNC connector (1.0 Vp-p, 75 Ω);
PAL / NTSC adaptive
Audio
compression
G.711
Audio input
1-ch, RCA connector (2.0 Vp-p, 1 kΩ)
Voice talk input
1-ch, RCA (2.0 Vp-p, 1 kΩ)
(Using AUDIO IN)
VGA output
1-ch, resolution: 1024 × 768 / 60 Hz
CVBS output
1-ch, BNC connector (1.0 Vp-p, 75 Ω);
Resolution: PAL: 704 × 576, NTSC: 704 ×
480
Audio output
1-ch, RCA connector (Linear, 1 kΩ)
Video/Audio
output
Recording
resolution
4CIF / 2CIF / CIF
Frame rate
Main stream: 4CIF / 2CIF@12 fps, CIF@25
fps (P) / 30 fps (N)
Sub stream: CIF / QCIF@25 fps (P) / 30 fps
(N)
Video bit rate
32 kbps ~ 2048 kbps, or user-defined (Max.
3072 kbps)
Stream type
Video/ Video & Audio
Audio bit rate
64 kbps
Dual stream
Support
Synchronous
playback
4-ch
Hard disk
Type
1 SATA interface
Capacity
Up to 2TB capacity for each interface
External
interface
Network
interface
1, RJ45 10 M / 100 M adaptive Ethernet
interface
Serial interface
1 RS-485 interface, half-duplex
USB interface
2, USB 2.0
Others
Power supply
12 VDC
Consumption
≤10 W (without hard disk or DVD-R/W)
Working
temperature
-10℃~ +55℃
Working
humidity
10% ~ 90%
Dimensions
(W x D x H)
315 × 230 × 45 mm
Weight
≤2 kg (without hard disk or DVD-R/W)

Hikvision Technical Manual
©2006 –2011 by HIKVISION. All rights reserved.
Model
DS-7208HVI-ST/SN
Video/Audio
input
Video
compression
H.264
Analog video
input
8-ch, BNC connector (1.0 Vp-p, 75 Ω);
PAL / NTSC adaptive
Audio
compression
G.711
Audio input
1-ch,RCA connector (2 Vp-p, 1 kΩ)
Voice talk input
1-ch, RCA (2.0 Vp-p, 1 kΩ)
(Using AUDIO IN)
VGA output
1-ch, resolution: 1024 × 768 / 60 Hz
CVBS output
1-ch, BNC connector (1.0 Vp-p, 75 Ω);
Resolution: PAL: 704 × 576, NTSC: 704 ×
480
Audio output
1-ch, RCA connector (Linear, 1 kΩ)
Video/Audio
output
Recording
resolution
4CIF / 2CIF / CIF
Frame rate
Main stream: 4CIF / 2CIF@8 fps, CIF@25
fps (P) / 30 fps (N)
Sub stream: CIF / QCIF@25 fps (P) / 30 fps
(N)
Video bit rate
32 kbps ~ 2048 kbps, or user-defined (Max.
3072 kbps)
Stream type
Video/ Video & Audio
Audio bit rate
64 kbps
Dual stream
Support
Synchronous
playback
8-ch
Hard disk
Type
1 SATA interface
Capacity
Up to 2TB capacity for each interface
External
interface
Network
interface
1, RJ45 10 M / 100 M adaptive Ethernet
interface
Serial interface
1 RS-485 interface, half-duplex
USB interface
2, USB 2.0
Others
Power supply
12 VDC
Consumption
≤10 W (without hard disk or DVD-R/W)
Working
temperature
-10℃~ +55℃
Working
humidity
10% ~ 90%
Dimensions
(W x D x H)
315 × 230 × 45 mm
Weight
≤4 kg (without hard disk or DVD-R/W)
Specifications - EV1008

Hikvision Technical Manual
©2006 –2011 by HIKVISION. All rights reserved.
Model
DS-7216HVI-ST/SN
Video/Audio
input
Video
compression
H.264
Analog video
input
16-ch, BNC connector (1.0 Vp-p, 75 Ω);
PAL / NTSC adaptive
Audio
compression
G.711
Audio input
1-ch,RCA connector (2 Vp-p, 1 kΩ)
Voice talk input
1-ch, RCA (2.0 Vp-p, 1 kΩ)
(Using AUDIO IN)
VGA output
1-ch, resolution: 1024 × 768 / 60 Hz
CVBS output
1-ch, BNC connector (1.0 Vp-p, 75 Ω);
Resolution: PAL: 704 × 576, NTSC: 704 ×
480
Audio output
1-ch, RCA connector (Linear, 1 kΩ)
Video/Audio
output
Recording
resolution
4CIF / 2CIF / CIF
Frame rate
Main stream: 4CIF / 2CIF@6 fps, CIF@25
fps (P) / 30 fps (N)
Sub stream: CIF / QCIF@25 fps (P) / 30 fps
(N)
Video bit rate
32 kbps ~ 2048 kbps, or user-defined (Max.
3072 kbps)
Stream type
Video/ Video & Audio
Audio bit rate
64 kbps
Dual stream
Support
Synchronous
playback
16-ch
Hard disk
Type
1 SATA interface
Capacity
Up to 2TB capacity for each interface
External
interface
Network
interface
1, RJ45 10 M / 100 M adaptive Ethernet
interface
Serial interface
1 RS-485 interface, half-duplex
USB interface
2, USB 2.0
Others
Power supply
12 VDC
Consumption
≤15 W (without hard disk or DVD-R/W)
Working
temperature
-10℃~ +55℃
Working
humidity
10% ~ 90%
Dimensions
(W x D x H)
315 × 230 × 45 mm
Weight
≤4 kg (without hard disk or DVD-R/W)
Specifications - EV1016
