Epcom X13 Series User manual

User Manual
Warning Light
X13 Series

Introduction
The X13 Series warning light offers high power Gen III LEDs
(Generation III) as light sources, a compact structure, convenient operation
and various flash patterns.
With its novel design, its features are high brightness, low current
consumption, easy installation and long service time.
The equipment is specially designed to be installed in any type of
emergency vehicle. Users can easily define the flash pattern.
Note: Please read the manual before installing.
Dimensions:

Cable configuration
●Cable length: 30 cm
●Red cable: VCC
●Black cable: GND
●White cable: to define flash type (Pulse to GND)
●Blue/Orange cable: Sync with another light
Technical Data
●Voltage: 10 Vdc - 30 Vdc
●Max consumption: 1 A
●Pattern display: 23
●Available colors: Red, Blue, Amber, Clear
●Mounting: Permanent
●Dimensions: 9.85 cm x 3.37 cm x 2.5 cm
Recommendations
● X13 warning light is designed for exterior vehicle use.
● Maintain the equipment ventilated.
Content
● Auxiliar light X13 Series 1 PZ
● User Manual 1 PZ

High intensity equipment. Do not look
directly while the device is on. May
cause momentary blindness and/or
permanent eye damage.
IMPORTANT Please, read the instructions
before installing your equipment
WARNING You must be careful when
positioning this equipment, for
that the light and / or cable do not interfere
with the proper functioning of the
airbag of both the driver and the
passenger. Do not lend
Attention to this warning can cause serious or fatal injuries
