Introduction
About Your Network Interface
The EpsonNet 802.11g Wireless Ext. Print Server is a wireless
network interface that connects to the USB port of an Epson device
(such as printer or all-in-one). With this network interface, you
can create a wireless connection between the Epson device and a
local area network using the IEEE 802.11b/g communication
standard.
A radio signal is transmitted over the wireless network when you
send a job to the device. Then the device prints or scans the file
when the network interface receives the radio signal directly from
a computer or from an access point.
This network interface is Wi-Fi certified for interoperability with
other 802.11-compliant products.
Because the network interface supports multiple protocols and
automatically detects protocols on your network, you can print
from Microsoft®Windows®, Apple®Macintosh®, UNIX®, and
IBM®OS/2 applications.
Use EpsonNet EasyInstall to easily configure the network
interface for use on a TCP/IP network. If you are using an
all-in-one, EpsonNet EasyInstall installs the drivers on your
computer. You can use the device on the TCP/IP network at once.
For protocols such as TCP/IP, NetWare, NetBEUI, AppleTalk®,
IPP, and SNMP, you can use EpsonNet Config, the configuration
utility provided with your product, to quickly and easily
configure the network interface to use these protocols.

2
R4CB860
html.bk Rev. F
INTRO.FM A5 size
10/19/04
LProof Sign-off:
KOW N.Mizuno H.Tomizawa
T.Takahashi
NOC K. Lee
Note:
The EpsonNet Config utility configures the network interface to work
only with protocols that exist on your network. This does not imply that
you can use all of the above-mentioned protocols on your network or
operating system. The protocols that the network interface can use may
vary depending on the operating system and the network configuration.
About This Guide
This Reference Guide contains information about using the
network interface on a network. It includes how to set up the
network interface, install the configuration software, and modify
network settings of your device and computer.
For information about your device, see the manual shipped with
the device.
Note:
❏To read the online guide, you must have Microsoft Internet Explorer
4.0 (or later) or Netscape Navigator 4.0 (or later) installed on your
computer.
❏This guide is written for network administrators, and many of the
steps included here require detailed network knowledge and
administrator rights.
❏The term “network administrator” refers to the person responsible
for maintaining the network. “Administrator” is synonymous with
“Supervisor” in this guide.
❏The term “network interface” refers to the EpsonNet 802.11g
Wireless Ext. Print Server in this guide.
❏The term “device” refers to the printer or all-in-one that is supported
by the network interface.

3
R4CB860
html.bk Rev. F
INTRO.FM A5 size
10/19/04
R
Proof Sign-off:
KOW N.Mizuno H.Tomizawa
T.Takahashi
NOC K. Lee
❏Some screen shots in this guide may list a device name other than
your device. This difference does not alter the instructions.
Instructions on Using the Network Interface
Notes on powering on and off
❏Do not turn off the device and the network interface when
changing the settings. This may damage the device and the
network interface.
❏Do not turn off the device and the network interface while
printing is in progress. This may cause operational trouble to
the computer sending the print data and suspend the printing
process.
❏Do not turn off the network interface during a firmware
update. Otherwise, the update cannot be completed correctly
and the network interface may not turn on (may not work)
after the update.
Notes on USB connection
❏Only supported devices can connect to a USB downstream
connector of the network interface. Do not use a USB hub.
❏Only IBM compatible computer or Macintosh equipped with
USB can connect to a USB upstream connector of the network
interface.
Notes on security
❏WEP Key
Set a WEP Key or WPA-PSK to prevent wireless interception
by unauthorized persons. The wireless transmission speed is
reduced when WEP or WPA-PSK is enabled because time is
required for encryption and decryption.

4
R4CB860
html.bk Rev. F
INTRO.FM A5 size
10/19/04
LProof Sign-off:
KOW N.Mizuno H.Tomizawa
T.Takahashi
NOC K. Lee
❏Security lock
Insert a commercially available theft-prevention cable
through the security lock, which is located on the back panel
of the network interface, to secure the device to a table or
pillar. This network interface is compatible with the
Microsaver Security System manufactured by Kensington.
Notes on radio waves
❏Radio wave interference may occur when there are devices
that use radio waves within the 2.4 GHz ISM band near the
network interface. Therefore, separate the network interface
from these devices as much as possible to prevent radio wave
interference.
❏When using the network interface in the Ad Hoc mode, radio
wave interference may occur if the channel of the network
interface and the other devices are close to each other.
Therefore, separate a few channels from the channel used near
the network interface.
❏Shorten the distance of the network interface and devices that
communicate with the network interface.
Where to locate the network interface
❏The location of the network interface must be considered to
improve the wireless communication. The rotary stand can
provide a good position. The condition of radio wave can be
checked using EpsonNet Config, lights of the network
interface, and the status sheet.
Package Contents
Your network interface package includes the following items.

5
R4CB860
html.bk Rev. F
INTRO.FM A5 size
10/19/04
R
Proof Sign-off:
KOW N.Mizuno H.Tomizawa
T.Takahashi
NOC K. Lee
❏Wireless network interface (The Web-based EpsonNet Config
is pre-installed.)
❏AC adapter and power cord
cCaution:
Only use the AC adapter shipped with this package to supply
power to the network interface.
❏USB cable
❏Software CD-ROM containing:
-- EpsonNet Config (for Windows)
-- EpsonNet Config (for Macintosh)
-- EpsonNet Print
-- EpsonNet Internet Print
-- EpsonNet WebManager
-- EpsonNet SetupManager
-- Reference Guide
-- Drivers and utilities for the following Epson devices:
EPSON STYLUS PHOTO RX500
EPSON STYLUS PHOTO RX600
EPSON STYLUS CX4600
EPSON STYLUS CX6400
EPSON STYLUS CX6600
❏Setup sheet
❏AC Adapter sheet
Note:
You need to supply items such as a computer with an 802.11b/g WLAN
compliant network interface card installed, an Epson device with a USB
port, a USB cable, and an access point (required for infrastructure mode
only).

6
R4CB860
html.bk Rev. F
INTRO.FM A5 size
10/19/04
LProof Sign-off:
KOW N.Mizuno H.Tomizawa
T.Takahashi
NOC K. Lee
Operating Environment
Supported operating systems
The network interface supports the following operating systems.
Printing environments
The network interface receives print jobs in the following
environments.
Supported operating systems Windows XP
Windows Me
Windows 98 Second Edition
Windows Server 2003
Windows 2000
Mac OS X 10.2 or later
Mac OS 9.1 or later
Operating systems Version Protocol
Windows XP
(Home,
Professional)
- TCP/IP (using LPR, Standard
TCP/IP Port, or EpsonNet Print)
IPP
Windows Me - TCP/IP (using EpsonNet Print)
IPP
NetBEUI
Windows 98
Second Edition
- TCP/IP (using EpsonNet Print)
IPP (using EpsonNet Internet
Print)
NetBEUI

7
R4CB860
html.bk Rev. F
INTRO.FM A5 size
10/19/04
R
Proof Sign-off:
KOW N.Mizuno H.Tomizawa
T.Takahashi
NOC K. Lee
Windows Server
2003
Windows 2000
(Professional,
Server)
- TCP/IP (using LPR, Standard
TCP/IP Port, or EpsonNet Print)
IPP
Macintosh Mac OS X 10.2.4
or later
AppleTalk
TCP/IP
Rendezvous
Mac OS X 10.2 or
later
AppleTalk
TCP/IP
Mac 9.1 or later AppleTalk
NetWare 3.x Bindery mode
4.x/IntranetWare NDS mode
Bindery emulation mode
5.x/6.0 NDS Queue-based print
system
NDPS
OS/2 (OS/2 Warp
Connect, OS/2
Warp Server)
V3
V4
TCP/IP (lprportd)
NetBEUI
UNIX Sun OS 4.1.4 or
later: SPARC
lpr, ftp
SunSoft Solaris 2.4
or later: SPARC
and x86
SCO UNIX 4.2 or
later
SCO UnixWare
2.01 or later
HP/UX 9.05 or
later
IBM AIX 3.2.5 or
later and 4.1.3 or
later
Operating systems Version Protocol

8
R4CB860
html.bk Rev. F
INTRO.FM A5 size
10/19/04
LProof Sign-off:
KOW N.Mizuno H.Tomizawa
T.Takahashi
NOC K. Lee
Note:
❏The multi-user environment of Mac OS 9 is not supported.
❏If you use the device in a dial-up router environment, you must set
an IP address for the device. Make sure the IP address is suitable for
the segment; incorrect IP address may generate unexpected dial-up.
❏See the manual shipped with your device for information on the
supported operating system of the device.
Scanning environments
The network interface supports EPSON Scan via TCP/IP and
allows network scanning when it is connected to the all-in-one.
The supported operating systems are Windows XP/Me/98/2000
and Mac OS X/9.
Network Storage environments
The network interface supports sharing memory via SMB when
it is connected to the all-in-one. The supported operating systems
are Windows XP/2000.
Supported Epson Devices
The network interface can be installed for the following Epson
devices (as of May, 2004).
❏Ink Jet Printer:
Stylus C64/C84
Stylus Photo 1280/2200
Stylus Photo R200/R300/R800

9
R4CB860
html.bk Rev. F
INTRO.FM A5 size
10/19/04
R
Proof Sign-off:
KOW N.Mizuno H.Tomizawa
T.Takahashi
NOC K. Lee
❏All-in-one:
Stylus Photo RX500/RX600
Stylus CX3600/CX4600/CX6400/CX6600
❏Laser Printer:
EPL-6200
EPL-N2500/N3000/N7000
AL-C1900/C4000/C4100
❏Impact Dot Matrix Printer:
FX-880+/890/1180+/2190
DLQ-3500
PLQ-20
LQ-590/630/2090
Features of the Network Interface
❏Meets the IEEE 802.11b/g (2.4 GHz) communication
standard.
❏Prints or scans via wireless network.
❏Supports the network storage function.
❏Supports both the Infrastructure mode and the Ad Hoc mode.
❏Supports the roaming function.
❏Supports 64-bit/128-bit WEP Key and WPA-PSK(TKIP).
❏Communicates with up to 11 or 13 channels.
❏Communicates with any Wi-Fi certified products.
❏Uses communication speeds at 11/5.5/2/1 Mbps for 802.11b,
54/48/36/24/18/12/9/6 Mbps for 802.11g, or automatically
changes the speed according to the radio waves.

10
R4CB860
html.bk Rev. F
INTRO.FM A5 size
10/19/04
LProof Sign-off:
KOW N.Mizuno H.Tomizawa
T.Takahashi
NOC K. Lee
❏Supports multiple protocols, such as TCP/IP, NetWare,
NetBEUI, AppleTalk, and IPP.
❏Supports DHCP.
❏Supports Automatic Private IP Addressing (APIPA) that
assigns an IP address automatically to the network interface
even if there is no DHCP server on your network.
❏Supports the Dynamic DNS function.
❏Supports Rendezvous on Mac OS X 2.4 or higher.
❏Supports SNMP and MIB.
❏Supports NTP (Network Time Protocol).

11
R4CB860
html.bk Rev. F
INTRO.FM A5 size
10/19/04
R
Proof Sign-off:
KOW N.Mizuno H.Tomizawa
T.Takahashi
NOC K. Lee
Network Interface Operation
The status lights and status sheet can provide you with important
information about the operation and configurationof the network
interface.
1. NETWORK light
2. DATA light
3. USB light
4. Status sheet button
5. USB upstream connector
6. USB downstream connector
7. DC-IN connector
8. Security lock
NETWORK light
DATA light
USB upstream connector
Status sheet button
USB downstream connector
DC-IN connector
Security lock
Back panel Front panel
USB light

12
R4CB860
html.bk Rev. F
INTRO.FM A5 size
10/19/04
LProof Sign-off:
KOW N.Mizuno H.Tomizawa
T.Takahashi
NOC K. Lee
Status lights
The network interface has three lights (NETWORK, DATA, and
USB), which indicates the current operating status of the network
interface when you first turn on the device, during normal
operation, and when errors occur. The NETWORK and USB lights
have three colors (red, green, and yellow). The DATA light is
green.
The status lights indicate the network interface status, as follows:
NETWORK DATA USB Network interface status
Off Off Green
flashing
Initializing
Off Off Red flashing Error status
Off Off Red and
green lights
flashing
alternately
Firmware update mode
Off Off Red on Printer communication is
disabled.
Off Off Green
flashing
when
receiving
data
Printer communication is
enabled.
Red NETWORK light and green USB light flashing
simultaneously
Wireless LAN and the IP
address are not set.
Red on Off Off Network
communication is
disabled.
Yellow on Flashing
when
receiving
data
Off High speed link
Green on Flashing
when
receiving
data
Off Low speed link

13
R4CB860
html.bk Rev. F
INTRO.FM A5 size
10/19/04
R
Proof Sign-off:
KOW N.Mizuno H.Tomizawa
T.Takahashi
NOC K. Lee
Status sheet button
The first time you use the network interface after installing or
reinstalling it, plug the power cord of the network interface into
a wall outlet while holding down the status sheet button for about
twenty seconds to initialize the network interface. The length of
time necessary to hold down the status sheet button varies
depending on the device model.
Before you start configuring the network interface, be sure to
press and hold down the status sheet button on the network
interface to print a status sheet. A status sheet provides important
information about the network interface, such as MAC address,
SSID, device settings, and device’s current status. Press the status
sheet button once to print a simple status sheet, or twice to print
a full status sheet. You cannot print a status sheet when the device
has already started printing, or when it is offline or not ready to
print.
Note:
If the device does not print a status sheet, make sure the device is online
and no print jobs are being processed, then wait a minute. If it still does
not print a status sheet, turn the device off, wait until the DATA light
goes out while the red USB light is on, and then turn it back on again.
The status sheet can be printed one minute after the device finishes
warming up.
cCaution:
After turning off the device, wait until the DATA light goes out
before turning it back on; otherwise the network interface may not
work correctly.
USB upstream connector
This connector is used to connect a USB cable to a computer, so
that the default network interface settings can be modified by
using the configuration utility.

14
R4CB860
html.bk Rev. F
INTRO.FM A5 size
10/19/04
LProof Sign-off:
KOW N.Mizuno H.Tomizawa
T.Takahashi
NOC K. Lee
USB downstream connector
This connector is used to connect a USB cable to the device to
enable communication with the device.
DC-IN connector
This is an external power supply connector for the AC adapter
shipped with the network interface. Plug or unplug the power
cord of the network interface from a wall outlet to turn the
network interface on or off.
Security lock
You can pass a commercially available theft-prevention cable
through the security lock hole to secure the network interface to
a table or pillar. This network interface is compatible with the
Microsaver Security System manufactured by Kensington.
Rotary stand
The rotary stand is located at the bottom of the network interface.
Rotate the rotary stand counterclockwise by 90 degrees to provide
an auxiliary stand for stability. The stand can be screwed to a
location or on the wall for hanging.
The IEEE 802.11g Communication Standard
The network interface supports the IEEE 802.11b/g
communication standard. It is compatible with other IEEE
802.11b/g compliant products.

15
R4CB860
html.bk Rev. F
INTRO.FM A5 size
10/19/04
R
Proof Sign-off:
KOW N.Mizuno H.Tomizawa
T.Takahashi
NOC K. Lee
An IEEE 802.11b/g WLAN (wireless local area network) operates
within the 2.4 GHz ISM band. It divides the 2.4 GHz into 11 or 13
channels using Direct-Sequence Spread Spectrum (DSSS), and
uses Carrier Sense Multiple Access with Collision Avoidance
(CSMA/CA) to avoid packet collision. Both CSMA/CA with
ACK and CSMA/CA with RTS/CTS are supported.
Wi-Fi certification
This wireless network interface is
Wi-Fi certified by the Wi-Fi Alliance
(WFA). The WFA certification ensures
full product interoperability with
other Wi-Fi certified products. For
more information on other Wi-Fi
certified products, go to
http://www.wi-fi.org.
Wireless Environment
Operating modes
You can configure the network interface for the Infrastructure
mode or the Ad Hoc mode.

16
R4CB860
html.bk Rev. F
INTRO.FM A5 size
10/19/04
LProof Sign-off:
KOW N.Mizuno H.Tomizawa
T.Takahashi
NOC K. Lee
In the Infrastructure mode, both wireless and wired computers
can communicate through an access point to send data to the
network interface.
Note:
Some access points or routers support only the TCP/IP protocol. If you
use this product with a protocol other than TCP/IP, make sure the
protocols are supported by the access point or router.
In the Ad Hoc mode, a network interface and computers
wirelessly communicate directly with each other, without using
an access point.
HUB

17
R4CB860
html.bk Rev. F
INTRO.FM A5 size
10/19/04
R
Proof Sign-off:
KOW N.Mizuno H.Tomizawa
T.Takahashi
NOC K. Lee
Security
WEP (Wired Equivalent Privacy) is a security protocol for
wireless network. Data is encrypted using the WEP Key
providing the security of your wireless network. You must set the
same WEP Key to the network interface and the access point.
The network interface supports a 64-bit or 128-bit encryption key,
and you can use either hexadecimal or ASCII characters.
WPA-PSK(TKIP) is a Wi-Fi security with a strong encryption
algorithm as well as user authentication. It provides a high
security that user data remains protected and that only authorized
users may access the network.
Note:
The wireless transmission speed is reduced when WEP or
WPA-PSK(TKIP) is enabled because time is required for encryption and
decryption.
SSID is a unique identifier to specify a wireless LAN. All devices
and access points connected to a specific wireless LAN must use
the same SSID to communicate with devices on the wireless LAN.
Radio signal range
The data transfer rate of the network interface depends on the
environment where the network interface is located.
Note:
The wireless transmission speed decreases as the distance between the
network interface and the computer or the access point increases.

18
R4CB860
html.bk Rev. F
INTRO.FM A5 size
10/19/04
LProof Sign-off:
KOW N.Mizuno H.Tomizawa
T.Takahashi
NOC K. Lee
About the Software
❏EpsonNet Config for Windows is a Windows-based
configuration utility for administrators that allows you to
configure the network interface for various protocols such as
TCP/IP, NetWare, MS Network, AppleTalk, IPP, and SNMP.
See “About EpsonNet Config”.
❏EpsonNet Config for Macintosh is a Macintosh-based
configuration utility for administrators that allows you to
configure the network interface for TCP/IP, AppleTalk, and
IPP. See “About EpsonNet Config”.
❏EpsonNet Config with Web Browser is a Web-based
configuration utility that allows you to configure the network
interface for TCP/IP, NetWare, MS Network, AppleTalk, IPP,
and SNMP. See “About EpsonNet Config”.
❏EpsonNet Print is a utility that enables TCP/IP printing for
Windows. (Windows XP/Server 2003/2000/NT 4.0 also
support OS standard LPR printing.) See “About EpsonNet
Print”.
❏EpsonNet Internet Print is a utility that supports printing
across the Internet using Internet Printing Protocol for
Windows 98/95/NT 4.0. See “About EpsonNet Internet
Print”.
❏EpsonNet WebManager is a Web-based utility that helps
network administrators to easily manage network devices.
See “About EpsonNet WebManager”.
❏EpsonNet SetupManager is a utility that provides a simple
printer installation and configuration tool for network
administrators, and an easy network printer installation
process for clients. See “About EpsonNet SetupManager”.

19
R4CB860
html.bk Rev. F
INTRO.FM A5 size
10/19/04
R
Proof Sign-off:
KOW N.Mizuno H.Tomizawa
T.Takahashi
NOC K. Lee
Terms and Concepts
2.4 GHz range -- the frequency spectrum assigned by the
organization such as FCC or IC to WLAN systems
Access point -- a device that acts as a communication hub linking
a wireless LAN to a wired LAN
Ad Hoc mode -- a wireless network mode. It allows devices to
communicate directly without being wired to a network.
Configuration -- a prepared set of conditions for proper operation
of a device. Configuring the network interface is to prepare it to
work with protocols available on a network.
DHCP -- a dynamic host configuration protocol. It is a protocol
that assigns dynamic IP addresses to devices on a network.
EtherTalk --the communication protocol of AppleTalk governing
Ethernet transmissions
ftp -- a TCP/IP application protocol for file transfer
IEEE 802.11g -- an IEEE standard for the 2.4 GHz range of WLANs
Infrastructure mode -- a wireless network mode. It allows both
wireless and wired computers to send print jobs to the device
through an access point.
lpd -- a TCP/IP remote printing protocol application
Print queue -- a location where a print job is stored as a file, until
the network interface sends the job to the assigned device
Protocol -- a rule that controls how data or information is
exchanged through a network. Computers and software cannot
communicate with each other using different protocols.

20
R4CB860
html.bk Rev. F
INTRO.FM A5 size
10/19/04
LProof Sign-off:
KOW N.Mizuno H.Tomizawa
T.Takahashi
NOC K. Lee
Remote printer -- a shared device connected elsewhere on the
network, but under the control of a NetWare print server
Roaming -- the ability to move the wireless station from oneaccess
point to another without losing the connection or interrupting the
service
SSID (or ESSID) -- Service Set Identifier (or Extended Service Set
Identifier), a unique identifier to specify a WLAN
TCP/IP -- Transmission Control Protocol/Internet Protocol, a
layer of protocols that provides communications between nodes
on a network
WEP -- Wired Equivalent Privacy, a security protocol for WLANs
defined in the IEEE 802.11b/g standard. WEP provides security
by encrypting data over radio waves.
WEP key -- a shared key algorithm for encrypting data
WLAN -- Wireless Local Area Network
WPA-PSK(TKIP) -- a Wi-Fi security with a strong encryption
algorithm as well as user authentication
