Epson ET-4700 Series User manual

User's Guide
NPD6002-02 EN

Contents
About This Manual
IntroductiontotheManuals...................7
Using the Manual to Search for Information. . . . . . . 7
MarksandSymbols.........................9
DescriptionsUsedinthisManual...............9
OperatingSystemReferences..................9
Important Instructions
SafetyInstructions.........................11
SafetyInstructionsforInk................. 11
PrinterAdvisoriesandWarnings.............. 12
Advisories and Warnings for Setting Up the
Printer................................12
Advisories and Warnings for Using the Printer. . 12
Advisories and Warnings for Transporting or
StoringthePrinter.......................13
Advisories and Warnings for Using the
PrinterwithaWirelessConnection...........13
Advisories and Warnings for Using the LCD
Screen................................13
ProtectingYourPersonalInformation...........13
Printer Basics
PartNamesandFunctions...................14
ControlPanel............................ 16
GuidetotheLCDScreen....................17
GuidetotheHomeScreen.................17
EnteringCharacters......................18
Network Settings
NetworkConnectionTypes.................. 20
EthernetConnection.....................20
Wi-FiConnection....................... 20
Wi-FiDirect(SimpleAP)Connection.........21
ConnectingtoaComputer...................21
ConnectingtoaSmartDevice................ 22
Connecting to a smart device over a wireless
router................................22
Connecting to an iPhone or iPad (iOS
devices)usingWi-FiDirect.................22
Connecting to Android Devices using Wi-Fi
Direct................................26
Connecting to Devices other than iOS and
AndroidusingWi-FiDirect................ 28
MakingWi-FiSettingsfromthePrinter..........31
Making Wi-Fi Settings by Entering the SSID
andPassword...........................32
Making Wi-Fi Settings by Push Button Setup. . . . 33
Making Wi-Fi Settings by PIN Code Setup
(WPS)................................34
CheckingtheNetworkConnectionStatus........34
NetworkIcon...........................35
PrintingaNetworkConnectionReport........35
PrintingaNetworkStatusSheet...............41
ReplacingorAddingNewWirelessRouters.......42
Changing the Connection Method to a Computer. . 42
Changing the Network Connection to Ethernet
fromtheControlPanel......................43
EnablingEnergyEcientEthernet.............43
Changing the Wi-Fi Direct (Simple AP) Settings. . . 43
DisablingWi-FifromtheControlPanel..........44
Disconnecting Wi-Fi Direct (Simple AP)
ConnectionfromtheControlPanel............ 45
Restoring the Network Settings from the
ControlPanel............................ 45
Preparing the Printer
LoadingPapers...........................46
AvailablePaperandCapacities..............46
LoadingPaperintheRearPaperFeed.........49
LoadingEnvelopesandPrecautions.......... 51
LoadingLongPapers.....................51
ListofPaperType....................... 52
PlacingOriginals..........................52
AvailableOriginalsfortheADF............. 52
PlacingOriginalsontheADF...............53
Placing Originals on the Scanner Glass. . . . . . . . 54
ManagingContacts........................56
RegisteringorEditingContacts............. 56
Registering or Editing Grouped Contacts. . . . . . 56
RegisterContactsonaComputer............57
MenuOptionsforSettings...................58
MenuOptionsforMaintenance............. 58
MenuOptionsforPrinterSetup.............59
MenuOptionsforNetworkSettings..........61
Menu Options for Epson Connect Services. . . . . 62
Menu Options for Google Cloud Print Services. . 62
MenuOptionsforContactsManager......... 63
FaxSettings............................63
User's Guide
Contents
2

MenuOptionsforPrintStatusSheet..........63
MenuOptionsforPrintCounter.............64
MenuOptionsforRestoreDefaultSettings.....64
MenuOptionsforFirmwareUpdate..........64
SavingPower.............................64
SavingPower-ControlPanel...............65
Fax Settings
BeforeUsingFaxFeatures....................66
ConnectingtoaPhoneLine..................66
CompatibleTelephoneLines................66
ConnectingthePrintertoaPhoneLine........67
Connecting Your Phone Device to the Printer. . . 68
Making the Printer Ready to Send and Receive
Faxes(UsingFaxSettingWizard).............. 69
Making Settings Individually for Printer's Fax
Features.................................71
SettingReceiveMode.....................71
Making Settings When You Connect an
ExternalPhoneDevice....................73
MakingSettingsforBlockingJunkFaxes.......74
Making Settings to Send and Receive Faxes
onaComputer..........................74
MenuOptionsforFaxSettings................75
CheckFaxConnection....................75
FaxSettingWizard.......................76
BasicSettingsMenu......................76
ReceiveSettingsMenu....................77
ReportSettingsMenu.....................78
SecuritySettingsMenu....................78
MenuOptionsforUserDefaultSettings....... 79
Printing
Printing from the Printer Driver on Windows. . . . . 80
AccessingthePrinterDriver................80
PrintingBasics..........................80
Printingon2-Sides.......................82
PrintingSeveralPagesonOneSheet..........83
Printing and Stacking in Page Order (Reverse
OrderPrinting).........................83
Printing a Reduced or Enlarged Document. . . . . 84
Printing One Image on Multiple Sheets for
Enlargement(CreatingaPoster).............85
PrintingwithaHeaderandFooter........... 91
PrintingaWatermark.....................92
PrintingMultipleFilesTogether.............92
Printing Using the Color Universal Print
Feature...............................93
AdjustingthePrintColor..................94
PrintingtoEmphasizeinLines............94
PrintingClearBarCodes..................95
CancelingPrinting.......................95
MenuOptionsforthePrinterDriver..........95
PrintingfromthePrinterDriveronMacOS......98
PrintingBasics..........................98
PrintingSeveralPagesonOneSheet..........99
Printing and Stacking in Page Order (Reverse
OrderPrinting)........................100
Printing a Reduced or Enlarged Document. . . . 100
AdjustingthePrintColor.................101
CancelingPrinting......................101
MenuOptionsforthePrinterDriver.........102
Making Operation Settings for the Mac OS
PrinterDriver......................... 103
PrintingfromSmartDevices.................104
UsingEpsoniPrint......................104
UsingEpsonPrintEnabler................105
UsingAirPrint.........................106
CancelingtheOngoingJob..................107
Copying
Copying................................108
Copying Multiple Originals onto One Sheet. . . . . .109
MenuOptionsforCopying..................109
Scanning
ScanningUsingtheControlPanel.............111
ScanningtoaComputer..................111
ScanningtoaComputer(WSD)............115
ScanningfromaComputer..................117
ScanningUsingEpsonScan2..............117
ScanningfromSmartDevices................120
InstallingEpsoniPrint...................120
ScanningUsingEpsoniPrint...............120
Faxing
BeforeUsingFaxFeatures...................122
SendingFaxesUsingthePrinter..............122
SendingFaxesUsingtheControlPanel.......122
VariousWaysofSendingFaxes.............124
ReceivingFaxesonthePrinter............... 127
ReceivingIncomingFaxes.................127
ReceivingFaxesbyMakingaPhoneCall......128
MenuOptionsforFaxing...................129
Fax.................................129
ScanSettings..........................130
User's Guide
Contents
3

FaxSendSettings.......................130
More................................131
ContactsManager......................132
SendingaFaxfromaComputer..............132
Sending Documents Created Using an
Application(Windows)...................132
Sending Documents Created Using an
Application(MacOS)....................135
ReceivingFaxesonaComputer...............136
SavingIncomingFaxesonaComputer.......136
Canceling the Feature that Saves Incoming
FaxestotheComputer...................137
CheckingforNewFaxes(Windows)......... 137
CheckingforNewFaxes(MacOS).......... 138
UsingOtherFaxingFeatures.................139
PrintingFaxReportManually..............139
Relling Ink
CheckingtheInkLevels....................140
CheckingtheInkLevels-Windows..........140
CheckingtheInkLevels-MacOS...........140
InkBottleCodes......................... 140
InkBottleHandlingPrecautions..............141
RellingtheInkTanks.....................142
Maintaining the Printer
Preventing the Print Head from Drying....... 147
CheckingandCleaningthePrintHead.........147
Checking and Cleaning the Print Head -
ControlPanel..........................147
Checking and Cleaning the Print Head -
Windows.............................148
Checking and Cleaning the Print Head - Mac
OS..................................148
RunningPowerCleaning...................149
Running Power Cleaning - Control Panel. . . . . 149
RunningPowerCleaning-Windows.........150
RunningPowerCleaning-MacOS..........150
AligningthePrintHead....................150
Aligning the Print Head - Control Panel. . . . . . 151
CleaningthePaperPathforInkSmears.........151
CleaningtheADF........................ 151
CleaningtheScannerGlass..................153
Checking the Total Number of Pages Fed
roughthePrinter.......................154
Checking the Total Number of Pages Fed
roughthePrinter-ControlPanel.........154
Checking the Total Number of Pages Fed
rough thePrinter-Windows.............155
Checking the Total Number of Pages Fed
roughthePrinter-MacOS..............155
Network Service and Software
Information
Application for Conguring Printer Operations
(WebCong)............................156
Running Web Cong on a Web Browser. . . . . . 156
RunningWebCongonWindows.......... 157
Running Web Cong onMacOS............157
Application for Scanning Documents and
Images(EpsonScan2).....................157
AddingtheNetworkScanner..............158
Application for Conguring Scanning
Operations from the Control Panel (Epson
EventManager)..........................158
Application for Conguring Fax Operations and
SendingFaxes(FAXUtility).................159
Application for Sending Faxes (PC-FAX Driver). . 160
Application for Printing Images (Epson Photo+). . 160
Application for Printing Web Pages (E-Web Print) 161
Application for Scanning and Transferring
Images(EasyPhotoScan)...................161
Soware Update Tools (EPSON Soware
Updater)...............................162
Application for Conguring Multiple Devices
(EpsonNet Cong)........................162
InstallingtheLatestApplications..............163
Updating the Printer's Firmware using the
ControlPanel............................164
UninstallingApplications...................164
UninstallingApplications-Windows.........165
UninstallingApplications-MacOS..........165
PrintingUsingaNetworkService.............166
Solving Problems
CheckingthePrinterStatus..................167
Checking Error Codes on the LCD Screen. . . . . 167
CheckingthePrinterStatus-Windows.......168
CheckingthePrinterStatus-MacOS........168
Checking the Soware Status. . . . . . . . . . . . . . . . 169
RemovingJammedPaper...................169
Removing Jammed Paper from the Rear
PaperFeed............................169
Removing Jammed Paper from Inside the
Printer...............................170
User's Guide
Contents
4

RemovingJammedPaperfromtheADF......172
Paper Does Not Feed Correctly. . . . . . . . . . . . . . . 173
PaperJams............................173
PaperFeedsataSlant....................174
Several Sheets of Paper are Fed at a Time. . . . . . 174
PaperOutErrorOccurs..................174
Original Does Not Feed in the ADF. . . . . . . . . .174
PowerandControlPanelProblems............175
PowerDoesNotTurnOn.................175
PowerDoesNotTurnO.................175
Power Turns O Automatically.............175
LCDScreenGetsDark...................175
CannotPrintfromaComputer...............175
CheckingtheConnection(USB)............175
CheckingtheConnection(Network).........176
Checking the Soware and Data. . . . . . . . . . . . 177
Checking the Printer Status from the
Computer(Windows)....................179
Checking the Printer Status from the
Computer(MacOS).....................179
WhenYouCannotMakeNetworkSettings...... 180
Cannot Connect from Devices Even ough
NetworkSettingsareNoProblems.......... 180
Checking the SSID Connected to the Printer. . . 182
CheckingtheSSIDfortheComputer.........182
Ethernet Connection Becomes Unstable. . . . . . 183
CannotPrintfromaniPhoneoriPad.......... 184
PrintoutProblems........................184
PrintoutisScuedorColorisMissing........184
BandingorUnexpectedColorsAppear.......185
Colored Banding Appears at Intervals of
Approximately2.5cm....................185
Blurry Prints, Vertical Banding, or
Misalignment..........................185
PrintQualityisPoor.....................186
PaperIsSmearedorScued...............187
PrintedPhotosareSticky................. 187
Images or Photos are Printed in Unexpected
Colors...............................188
CannotPrintWithoutMargins.............188
Edges of the Image are Cropped During
BorderlessPrinting......................188
e Position, Size, or Margins of the Printout
AreIncorrect..........................188
Printed Characters Are Incorrect or Garbled. . . 189
ePrintedImageIsInverted..............189
Mosaic-LikePatternsinthePrints...........189
Uneven Colors, Smears, Dots, or Straight
LinesAppearintheCopiedImage...........189
Moiré (Cross-Hatch) Patterns Appear in the
CopiedImage......................... 190
An Image of the Reverse Side of the Original
AppearsintheCopiedImage.............. 190
Banding Appears when Copying from the ADF 190
e Printout Problem Could Not be Cleared. . . 190
OtherPrintingProblems................... 190
PrintingIsTooSlow.....................190
Printing or Copying Slows Down
Dramatically During Continuous Operation. . . 191
CannotStartScanning.....................191
Cannot Start Scanning when Using the
ControlPanel..........................192
ScannedImageProblems...................192
Uneven Colors, Dirt, Spots, and so on Appear
whenScanningfromtheScannerGlass.......192
Straight Lines Appear when Scanning from
ADF................................193
eImageQualityIsRough...............193
Oset Appears in the Background of Images. . . 193
TextisBlurred.........................193
Moiré Patterns (Web-Like Shadows) Appear. . . 193
Cannot Scan the Correct Area on the
ScannerGlass..........................194
Text is Not Recognized Correctly when
SavingasaSearchablePDF................194
Cannot Solve Problems in the Scanned Image. . 195
OtherScanningProblems...................195
ScanningIsTooSlow....................195
Scanning Slows Down Dramatically During
ContinuousScanning....................195
Scanning Stops when Scanning to PDF/
Multi-TIFF........................... 196
Problems when Sending and Receiving Faxes. . . . .196
CannotSendorReceiveFaxes..............196
CannotSendFaxes......................197
Cannot Send Faxes to a Specic Recipient.....198
Cannot Send Faxes at a Specied Time....... 198
CannotReceiveFaxes....................198
SentFaxQualityIsPoor..................199
FaxesAreSentattheWrongSize............199
ReceivedFaxQualityIsPoor...............199
ReceivedFaxesAreNotPrinted............ 199
Pages are Blank or only a Small Amount of
Text is Printed on the Second Page in
ReceivedFaxes.........................200
OtherFaxingProblems.....................200
Cannot Make Calls on the Connected
Telephone............................200
Answering Machine Cannot Answer Voice
Calls................................200
Sender's Fax Number Not Displayed on
Received Faxes or the Number Is Wrong. . . . . . 200
User's Guide
Contents
5

OtherProblems..........................200
Slight Electric Shock when Touching the
Printer...............................200
OperationSoundsAreLoud...............201
eDateandTimeAreIncorrect........... 201
Application Is Blocked by a Firewall (for
WindowsOnly)........................201
A Message Prompting You to Reset the Ink
LevelsisDisplayed......................201
InkSpilled............................201
Appendix
TechnicalSpecications....................202
PrinterSpecications....................202
Scanner Specications................... 203
Interface Specications...................203
FaxSpecications.......................203
NetworkFunctionList...................204
Wi - Fi Specications.....................205
Ethernet Specications...................205
SecurityProtocol.......................206
SupportedirdPartyServices.............206
Dimensions...........................206
Electrical Specications.................. 206
EnvironmentalSpecications..............207
SystemRequirements....................207
RegulatoryInformation....................208
StandardsandApprovals................. 208
RestrictionsonCopying..................209
TransportingandStoringthePrinter...........210
Copyright.............................. 213
Trademarks.............................213
WheretoGetHelp........................214
TechnicalSupportWebSite................214
ContactingEpsonSupport................215
User's Guide
Contents
6

About This Manual
Introduction to the Manuals
e following manuals are supplied with your Epson printer. As well as the manuals, check the various types of
help information available from the printer itself or from the Epson soware applications.
❏Important Safety Instructions (paper manual)
Provides you with instructions to ensure the safe use of this printer.
❏Start Here (paper manual)
Provides you with information on setting up the printer, installing the soware, using the printer, and so on.
❏User's Guide (digital manual)
is manual. Provides overall information and instructions on using the printer, on network settings when
using the printer on a network, and on solving problems.
You can obtain the latest versions of the above manuals with the following methods.
❏Paper manual
Visit the Epson Europe support website at http://www.epson.eu/Support, or the Epson worldwide support
website at http://support.epson.net/.
❏Digital manual
Start EPSON Soware Updater on your computer. EPSON Soware Updater checks for available updates of
Epson soware applications and the digital manuals, and allows you to download the latest ones.
Related Information
&“Soware Update Tools (EPSON Soware Updater)” on page 162
Using the Manual to Search for Information
e PDF manual allows you to search for information you are looking for by keyword, or jump directly to specic
sections using the bookmarks. You can also print only the pages you need. is section explains how to use a PDF
manual that has been opened in Adobe Reader X on your computer.
User's Guide
About This Manual
7

Searching by keyword
Click Edit > Advanced Search. Enter the keyword (text) for information you want to nd in the search window,
and then click Search. Hits are displayed as a list. Click one of the displayed hits to jump to that page.
Jumping directly from bookmarks
Click a title to jump to that page. Click + or > to view the lower level titles in that section. To return to the previous
page, perform the following operation on your keyboard.
❏Wi n d o w s : H o l d d o w n Alt, and then press ←.
❏Mac OS: Hold down the command key, and then press ←.
Printing only the pages you need
You can extract and print only the pages you need. Click Print in the File menu, and then specify the pages you
want to print in Pages in Pages to Print.
❏To specify a series of pages, enter a hyphen between the start page and the end page.
Example: 20-25
❏To specify pages that are not in series, divide the pages with commas.
Example: 5, 10, 15
User's Guide
About This Manual
8

Marks and Symbols
!
Caution:
Instructions that must be followed carefully to avoid bodily injury.
c
Important:
Instructions that must be observed to avoid damage to your equipment.
Note:
Provides complementary and reference information.
Related Information
&Links to related sections.
Descriptions Used in this Manual
❏Screenshots of the printer driver and the Epson Scan 2 (scanner driver) screens are from Windows 10 or macOS
High Sierra. e content displayed on the screens varies depending on the model and situation.
❏Illustrations used in this manual are examples only. Although there may be slight dierences depending on the
model, the method of operation is the same.
❏Some of the menu items on the LCD screen vary depending on the model and settings.
❏You can read the QR code using dedicated app.
Operating System References
Windows
In this manual, terms such as "Windows 10", "Windows 8.1", "Windows 8", "Windows 7", "Windows Vista",
"Windows XP", "Windows Server 2016", "Windows Server 2012 R2", "Windows Server 2012", "Windows Server 2008
R2", "Windows Server 2008", "Windows Server 2003 R2", and "Windows Server 2003" refer to the following
operating systems. Additionally, "Windows" is used to refer to all versions.
❏Microso
®
Wi n d o w s
®
10 operating system
❏Microso
®
Wi n d o w s
®
8.1 operating system
❏Microso
®
Wi n d o w s
®
8 operating system
❏Microso
®
Wi n d o w s
®
7 operating system
❏Microso
®
Wi n d o w s Vi s t a
®
operating system
❏Microso
®
Wi n d o w s
®
XP operating system
❏Microso
®
Wi n d o w s
®
XP Professional x64 Edition operating system
❏Microso
®
Wi n d ow s S e r v e r
®
2016 operating system
❏Microso
®
Wi n d ow s S e r v e r
®
2012 R2 operating system
User's Guide
About This Manual
9

❏Microso
®
Wi n d ow s S e r v e r
®
2012 operating system
❏Microso
®
Wi n d ow s S e r v e r
®
2008 R2 operating system
❏Microso
®
Wi n d ow s S e r v e r
®
2008 operating system
❏Microso
®
Wi n d ow s S e r v e r
®
2003 R2 operating system
❏Microso
®
Wi n d ow s S e r v e r
®
2003 operating system
Mac OS
In this manual, "Mac OS" is used to refer to macOS High Sierra, macOS Sierra, OS X El Capitan, OS X Yosemite,
OS X Mavericks, OS X Mountain Lion, Mac OS X v10.7.x, and Mac OS X v10.6.8.
User's Guide
About This Manual
10

Important Instructions
Safety Instructions
Read and follow these instructions to ensure safe use of this printer. Make sure you keep this manual for future
reference. Also, be sure to follow all warnings and instructions marked on the printer.
❏Some of the symbols used on your printer are to ensure safety and proper use of the printer. Visit the following
Web site to learn the meaning of the symbols.
http://support.epson.net/symbols
❏Use only the power cord supplied with the printer and do not use the cord with any other equipment. Use of
other cords with this printer or the use of the supplied power cord with other equipment may result in re or
electric shock.
❏Be sure your AC power cord meets the relevant local safety standard.
❏Never disassemble, modify, or attempt to repair the power cord, plug, printer unit, or options by yourself, except
as specically explained in the printer's manuals.
❏Unplug the printer and refer servicing to qualied service personnel under the following conditions:
e power cord or plug is damaged; liquid has entered the printer; the printer has been dropped or the casing
damaged; the printer does not operate normally or exhibits a distinct change in performance. Do not adjust
controls that are not covered by the operating instructions.
❏Place the printer near a wall outlet where the plug can be easily unplugged.
❏Do not place or store the printer outdoors, near excessive dirt or dust, water, heat sources, or in locations
subject to shocks, vibrations, high temperature or humidity.
❏Take care not to spill liquid on the printer and not to handle the printer with wet hands.
❏Keep the printer at least 22 cm away from cardiac pacemakers. Radio waves from this printer may adversely
aect the operation of cardiac pacemakers.
❏If the LCD screen is damaged, contact your dealer. If the liquid crystal solution gets on your hands, wash them
thoroughly with soap and water. If the liquid crystal solution gets into your eyes, ush them immediately with
water. If discomfort or vision problems remain aer a thorough ushing, see a doctor immediately.
❏Avoid using a telephone during an electrical storm. ere may be a remote risk of electric shock from lightning.
❏Do not use a telephone to report a gas leak in the vicinity of the leak.
Safety Instructions for Ink
❏Be careful not to touch any ink when you handle the ink tanks, ink tank caps, and opened ink bottles or ink
bottle caps.
❏If ink gets on your skin, wash the area thoroughly with soap and water.
❏If ink gets into your eyes, ush them immediately with water. If discomfort or vision problems continue aer
a thorough ushing, see a doctor immediately.
❏If ink gets into your mouth, see a doctor right away.
❏Do not shake an ink bottle too vigorously or subject it to strong impacts as this can cause ink to leak.
User's Guide
Important Instructions
11

❏Keep ink bottles and the ink tank unit out of the reach of children. Do not allow children to drink from or
handle the ink bottles and ink bottle cap.
Printer Advisories and Warnings
Read and follow these instructions to avoid damaging the printer or your property. Make sure you keep this
manual for future reference.
Advisories and Warnings for Setting Up the Printer
❏Do not block or cover the vents and openings in the printer.
❏Use only the type of power source indicated on the printer's label.
❏Avoid using outlets on the same circuit as photocopiers or air control systems that regularly switch on and o.
❏Avoid electrical outlets controlled by wall switches or automatic timers.
❏Keep the entire computer system away from potential sources of electromagnetic interference, such as
loudspeakers or the base units of cordless telephones.
❏e power-supply cords should be placed to avoid abrasions, cuts, fraying, crimping, and kinking. Do not place
objects on top of the power-supply cords and do not allow the power-supply cords to be stepped on or run over.
Be particularly careful to keep all the power-supply cords straight at the ends and the points where they enter
and leave the transformer.
❏If you use an extension cord with the printer, make sure that the total ampere rating of the devices plugged into
the extension cord does not exceed the cord's ampere rating. Also, make sure that the total ampere rating of all
devices plugged into the wall outlet does not exceed the wall outlet's ampere rating.
❏If you plan to use the printer in Germany, the building installation must be protected by a 10 or 16 amp circuit
breaker to provide adequate short-circuit protection and over-current protection for the printer.
❏When connecting the printer to a computer or other device with a cable, ensure the correct orientation of the
connectors. Each connector has only one correct orientation. Inserting a connector in the wrong orientation
may damage both devices connected by the cable.
❏Place the printer on a at, stable surface that extends beyond the base of the printer in all directions. e printer
will not operate properly if it is tilted at an angle.
❏Allow space above the printer so that you can fully raise the document cover.
❏Leave enough space in front of the printer for the paper to be fully ejected.
❏Avoid places subject to rapid changes in temperature and humidity. Also, keep the printer away from direct
sunlight, strong light, or heat sources.
Advisories and Warnings for Using the Printer
❏Do not insert objects through the slots in the printer.
❏Do not put your hand inside the printer during printing.
❏Do not touch the white at cable and ink tubes inside the printer.
❏Do not use aerosol products that contain ammable gases inside or around the printer. Doing so may cause re.
❏Do not move the print head by hand; otherwise, you may damage the printer.
User's Guide
Important Instructions
12

❏Be careful not to trap your ngers when closing the document cover.
❏Do not press too hard on the scanner glass when placing the originals.
❏If any of the ink tanks are not lled up to the lower line, rell the ink soon. Prolonged use of the printer when
the ink level is below the lower line could damage the printer.
❏Always turn the printer o using the
P button. Do not unplug the printer or turn o the power at the outlet
until the
P light stops ashing.
❏If you are not going to use the printer for a long period, be sure to unplug the power cord from the electrical
outlet.
Advisories and Warnings for Transporting or Storing the Printer
❏When storing or transporting the printer, avoid tilting it, placing it vertically, or turning it upside down;
otherwise ink may leak.
❏Before transporting the printer, make sure that the print head is in the home (far right) position.
Advisories and Warnings for Using the Printer with a Wireless
Connection
❏Radio waves from this printer may negatively aect the operation of medical electronic equipment, causing
them to malfunction. When using this printer inside medical facilities or near medical equipment, follow
directions from the authorized personnel representing the medical facilities, and follow all posted warnings and
directions on the medical equipment.
❏Radio waves from this printer may negatively aect the operation of automatically controlled devices such as
automatic doors or re alarms, and could lead to accidents due to malfunction. When using this printer near
automatically controlled devices, follow all posted warnings and directions on these devices.
Advisories and Warnings for Using the LCD Screen
❏e LCD screen may contain a few small bright or dark spots, and because of its features it may have an uneven
brightness. ese are normal and do not indicate that it is damaged in any way.
❏Only use a dry, so cloth for cleaning. Do not use liquid or chemical cleaners.
❏e exterior cover of the LCD screen could break if it receives a heavy impact. Contact your dealer if the
screen's surface chips or cracks, and do not touch or attempt to remove the broken pieces.
Protecting Your Personal Information
When you give the printer to someone else or dispose of it, erase all the personal information stored in the printer's
memory by selecting Settings > Restore Default Settings > Clear All Data and Settings on the control panel.
User's Guide
Important Instructions
13

Printer Basics
Part Names and Functions
AADF (Automatic Document
Feeder) cover
Open when removing jammed originals in the ADF.
BADF input tray Feeds originals automatically.
CADF edge guide Feeds originals straight into the printer. Slide to the edge of the originals.
DADF output tray Holds originals ejected from the ADF.
ARear paper feed Loads paper.
BPaper support Supports loaded paper.
CEdge guides Feeds the paper straight into the printer. Slide to the edges of the paper.
DOutput tray Holds the ejected paper.
User's Guide
Printer Basics
14

ADocument cover Blocks external light while scanning.
BScanner glass Place the originals.
CControl panel Indicates the printer's status and allows you to make print settings.
AInner cover Open when removing jammed paper inside the printer.
BInk tank unit Contains the ink tanks.
CInk reservoir tank (Ink tank) Supplies ink to the print head.
DInk tank cover Open to rell the ink tank.
EPrint head Ink is ejected from the print head nozzles underneath.
User's Guide
Printer Basics
15

ALAN port Connects a LAN cable.
BUSB port Connects a USB cable to connect with a computer.
CAC inlet Connects the power cord.
DEXT. port Connects external phone devices.
ELINE port Connects a phone line.
Related Information
&“Control Panel” on page 16
Control Panel
ATurns the printer on or o.
Unplug the power cord after checking that the power light is o.
BDisplays menus and messages. Use buttons on the control panel to select a menu or to make settings.
User's Guide
Printer Basics
16

CDisplays the solutions when you are in trouble.
DUse the
u d l r buttons to select a menu, and then ppress the OK button to enter the selected menu.
EStops the current operation.
FEnters numbers, characters, and symbols.
GClears number settings such as the number of copies.
HStarts an operation such as printing or copying.
IApplies to a variety of functions depending on the situation.
JReturns to the previous screen.
KTurns on when received documents that have not yet been printed or saved are stored in the printer's memory.
LDisplays the home screen.
Guide to the LCD Screen
Menus and messages are displayed on the LCD screen. Select a menu or setting by pressing the u d l r buttons.
Guide to the Home Screen
e following icons and menus are displayed on the home screen.
User's Guide
Printer Basics
17

AIcons that show the network status are displayed.
The printer is not connected to a wired (Ethernet) network or unset it.
The printer is connected to a wired (Ethernet) network.
Indicates that a wireless (Wi-Fi) network is disabled, or that the printer is processing a wireless
network connection.
Indicates a problem with the printer's wireless (Wi-Fi) network connection, or that the printer is
searching for a wireless (Wi-Fi) network connection.
Indicates that the printer is connected to a wireless (Wi-Fi) network.
The number of bars indicates the signal strength of the connection. The more bars there are,
the stronger the connection.
Indicates that Wi-Fi Direct (Simple AP) is enabled.
Indicates that Wi-Fi Direct (Simple AP) is disabled.
BWhen
l and r are displayed, you can scroll right or left by pressing the l or r button.
CFunction icons and names are displayed as menu icons.
Copy Enters Copy menu that allows you to copy a document.
Scan Enters Scan menu that allows you to scan a document or a photo.
Fax Enters Fax menu that allows you to send faxes.
Quiet Mode Displays Quiet Mode setting that allows you to reduce the noise the printer makes. However,
enabling this may reduce print speed. Depending on the paper type and print quality settings
you selected, there may be no dierence in the printer's noise level.
This is a shortcut to the following menu.
Settings > Printer Setup > Quiet Mode
Settings Displays Settings menu that allows you to make settings related to maintenance, printer
setup, and network settings.
Maintenance Displays the menus recommended to improve the quality of your printouts such as un-
clogging nozzles by printing a nozzle check pattern and performing head cleaning, and
improving blurring or banding in your printouts by aligning the print head. This is a shortcut to
the following menu.
Settings > Maintenance
Wi-Fi Setup Displays menus that allow you to set up the printer for use on a wireless network. This is a
shortcut to the following menu.
Settings > Network Settings > Wi-Fi Setup
DAvailable buttons are displayed. In this example, you can proceed to the selected menu by pressing the OK button.
Entering Characters
To enter characters and symbols for network settings and register contacts from the control panel, use the 12-key
numeric keypad. To clear all characters, press the Cbutton.
User's Guide
Printer Basics
18

e following is the screen for entering the password for your Wi-Fi network. e displayed screen varies
depending on the setting items.
Butoons Descriptions
Switches the character type.
ABC: Uppercase characters
abc: Lowercase characters
123: Numbers and symbols
Deletes a character to the left (backspace).
OK Enters the selected characters.
Note:
❏Pressing the
l r buttons moves the cursor to the le or right.
❏Pressing the button returns to the previous screen.
User's Guide
Printer Basics
19

Network Settings
Network Connection Types
You can use the following connection methods.
Ethernet Connection
Connect the printer to a hub with an Ethernet cable.
Wi-Fi Connection
Connect the printer and the computer or smart device to the wireless router. is is the typical connection method
for home or oce networks where computers are connected by Wi-Fi through the wireless router.
Related Information
&“Connecting to a Computer” on page 21
User's Guide
Network Settings
20
