Epson SC-F3000 Series User manual

How to Replace the Print
Head
CMP0270-01 EN

Copyrights and Trademarks
No part of this publication may be reproduced, stored in a retrieval system, or transmitted in any form or by any means, electronic, mechanical,
photocopying, recording, or otherwise, without the prior written permission of Seiko Epson Corporation. The information contained herein is designed
only for use with this Epson printer. Epson is not responsible for any use of this information as applied to other printers.
Neither Seiko Epson Corporation nor its affiliates shall be liable to the purchaser of this product or third parties for damages, losses, costs, or expenses
incurred by the purchaser or third parties as a result of accident, misuse, or abuse of this product or unauthorized modifications, repairs, or alterations to
this product, or (excluding the U.S.) failure to strictly comply with Seiko Epson Corporation’s operating and maintenance instructions.
Seiko Epson Corporation shall not be liable for any damages or problems arising from the use of any options or any consumable products other than those
designated as Original Epson Products or Epson Approved Products by Seiko Epson Corporation.
Seiko Epson Corporation shall not be held liable forany damage resulting from electromagnetic interference that occurs from the use of any interface cables
other than those designated as Epson Approved Products by Seiko Epson Corporation.
EPSON, EPSON EXCEED YOUR VISION, EXCEED YOUR VISION and their logos are registered trademarks or trademarks of Seiko Epson.
YouTube
®
and the YouTube logo are registered trademarks or trademarks of YouTube, LLC.
General Notice:Other product names used herein are for identification purposes only and may be trademarks of their respective owners. Epson disclaims any
and all rights in those marks.
© 2020 Seiko Epson Corporation.
SC-F3000 Series How to Replace the Print Head
Copyrights and Trademarks
2

Contents
Copyrights and Trademarks
Introduction
MeaningofSymbols........................4
Illustrations..............................4
About Doing User Self Repair Work
Notes on Safety
Work Flow
WhenaPrintHeadNeedstoBeReplaced........7
OverviewofWork.........................8
How to Start in User Self Repair Mode
How to Do Diagnosis
DiagnosisProcedure.......................11
How to Do Cleaning(Heavy).................11
Changing the Settings for Nozzle Compensation
......................................11
Replacement Procedure
Preparation..............................13
NotesonHandling........................13
NotesonStorage........................13
NotesonOpening.......................13
CorrectlyHoldingthePrintHead...........14
DoNotTouchTheseAreas................14
HowtoRemove..........................14
HowtoInstall............................19
ProcessafterReplacement...................21
AboutUsedPrintHeads....................22
Adjustment Work
Preparation..............................23
Execute Print Head Alignment...............23
Executing Head Interval X Uni-D Adjustment
......................................24
Executing Head Interval Y Adjustment.........25
ConfirmtheAdjustmentResults..............26
Problem Solver
WhattoDoWhenaMessageIsDisplayed.......27
WhenaPrinterErrorOccurs.................28
SC-F3000 Series How to Replace the Print Head
Contents
3

Introduction
Meaning of Symbols
Warning: Warnings must be followed
to avoid serious bodily
injury.
Caution: Cautions must be followed to
avoid bodily injury.
c
Important: Important must be followed
to avoid damage to this
product.
Note: Notes contain useful or
additional information on
the operation of this product.
UIndicates related content.
Illustrations
The illustrations (including photos) may differ slightly
from the model you are using. Please be aware of this
when using the manual.
SC-F3000 Series How to Replace the Print Head
Introduction
4

About Doing User Self Repair Work
What is User Self Repair Work
Work that you do, such as when you start the printer in Self Repair mode and replace User Self Repair parts (Print
Head), is called "User Self Repair Work" in this manual.
Notes on Doing User Self Repair Work
Use the replacement Print Head and User Self Repair Mode for the following purposes only.
❏When the part has reached the end of its service life and needs to be replaced
❏When print results are not correct and clogged nozzles cannot be cleared
SC-F3000 Series How to Replace the Print Head
About Doing User Self Repair Work
5

Notes on Safety
This section lists precautions that must be taken to use the product safely and prevent damage to property or injury to
operators or others.
North American and Latin American users:
In addition, be sure to read the safety instructions in the online Notices.
Other regions:
In addition, be sure to read the "Safety Instructions" in the Setup Guide (booklet) or the Safety Instructions (booklet),
which is a separate manual.
Notes on Handling
Warning
Do not replace a Print Head without having been trained for User Self Repair.
An electric shock or injury could occur.
SC-F3000 Series How to Replace the Print Head
Notes on Safety
6

Work Flow
When a Print Head Needs to Be Replaced
A Print Head needs to be replaced in the following situations. The work is different for both situations.
When the part has reached the end of its service life:
A Print Head has reached the end of its service life if any of the following 16 digit numbers appears in the enclosure
shown on screen.
“0000020000000000”/“0000040000000000”/“0000060000000000”
Make a note of the number, then press Replace Parts to turn off the printer. Next, start the printer in User Self Repair
Mode, and then replace the Print Head with the replacement one.
If a number other than those above is displayed, contact your dealer or Epson Support and tell them the 16 digit code.
When print results are not correct:
If the print results are not improved after doing the following measures, start the printer in User Self Repair Mode and
do a Diagnosis.
❏Execute Head Cleaning - Cleaning(Heavy)
If the clogs are not cleared after doing this once, then execute Cleaning(Heavy) again one more time.
❏Clean around the Print Heads and the edges of the metal
❏Clean the Suction Cap
❏Replace the Anti-Drying Caps
For the procedures to clean and replace the various parts, see the User's Guide (Online Manual).
Only replace a Print Head with a replacement one if the Diagnosis determines that a Print Head needs to be replaced.
SC-F3000 Series How to Replace the Print Head
Work Flow
7

Overview of Work
1. Start the printer in User Self Repair Mode
U“How to Start in User Self Repair Mode” on page 9
If the print results are not correct, do a Diagnosis, and take measures according to the diagnosis results.
The Print Head may not need to be replaced if you just change the settings or do Cleaning(Heavy).
U“How to Do Diagnosis” on page 11
2. Replacing a Print Head
U“Replacement Procedure” on page 13
3. Adjusting a Print Head
U“Adjustment Work” on page 23
SC-F3000 Series How to Replace the Print Head
Work Flow
8

How to Start in User
Self Repair Mode
You can check the procedure in a video on YouTube.
Epson Video Manuals
A
Check that the printer's power is off.
B
Place right thumb or an approximately 25 mm
(0.98 in.) diameter coin on the area shown
in the illustration of the printer screen below, so it
is not exposed to light.
C
While maintaining the conditions from step 2,
press and hold the power button until the screen
in the illustration appears. (about 20 seconds)
If the screen in the illustration does not appear,
and the power just comes on as normal, turn off
the power and redo the procedure from step 2.
D
Input the "32998" passcode.
❏Press the right side of the screen to change the
numbers from 0 to 9.
❏Press the left side of the screen to confirm the
selected number and advance to the next digit
for input.
E
Press the center of the screen 2 times to confirm
the passcode.
The printer starts in User Self Repair Mode.
F
Check the on-screen messages, and then press
OK.
Starting is successful if User Self Repair Mode
appears in the upper left of the screen, as in the
illustration.
SC-F3000 Series How to Replace the Print Head
How to Start in User Self Repair Mode
9

If it does not appear, turn off the power and redo
the procedure from step 2.
