Introduction Page 9
Introduction
Your EPSON Stylus®COLOR 900 printer is the ideal output device for
business graphics, digital photographs, newsletters, and more. With
resolutions up to 1440 by 720 dpi and EPSON’s unique variable micro
droplet technology, you get amazingly realistic photographic images, vivid
color graphics, and sharp black text—all at unprecedented speeds.
The printer software for Microsoft®Windows®and Apple®Macintosh®
provides advanced color management with adjustable levels of
brightness, contrast, sharpness, and other settings. You get even more
precise color matching with ColorSync™2.01 and two Windows color
management systems.
EPSON’s specially formulated ink cartridges and wide variety of ink jet
papers offer the most flexibility for getting the results you want. With
standard parallel, serial, and high-speed USB (Universal Serial Bus)
ports, setting up your printer is fast and easy.
This chapter gives general printer information in these sections:
◗Windows System Requirements
◗Macintosh System Requirements
◗How To Use Your Manuals
◗ENERGY STAR Compliance
◗Year 2000 Ready
◗Important Safety Instructions
