Epson SureColor SC-S70600 User manual

User's Guide
NPD4674-00 EN

Copyrights and Trademarks
No part of this publication may be reproduced, stored in a retrieval system, or transmitted in any form or by any means, electronic, mechanical,
photocopying, recording, or otherwise, without the prior written permission of Seiko Epson Corporation. The information contained herein is designed
only for use with this Epson printer. Epson is not responsible for any use of this information as applied to other printers.
Neither Seiko Epson Corporation nor its affiliates shall be liable to the purchaser of this product or third parties for damages, losses, costs, or expenses
incurred by the purchaser or third parties as a result of accident, misuse, or abuse of this product or unauthorized modifications, repairs, or alterations to
this product, or (excluding the U.S.) failure to strictly comply with Seiko Epson Corporation's operating and maintenance instructions.
Seiko Epson Corporation shall not be liable for any damages or problems arising from the use of any options or any consumable products other than those
designated as Original Epson Products or Epson Approved Products by Seiko Epson Corporation.
Seiko Epson Corporation shall not be held liable forany damage resulting from electromagnetic interference that occurs from the use of any interface cables
other than those designated as Epson Approved Products by Seiko Epson Corporation.
EPSON
®
is registered trademark, and EPSON EXCEED YOUR VISION or EXCEED YOUR VISION is a trademark of Seiko Epson Corporation.
Microsoft
®
, Windows
®
, and Windows Vista
®
are registered trademarks of Microsoft Corporation.
Apple
®
, Macintosh
®
, Mac OS
®
, and OS X
®
are registered trademarks of Apple Inc.
Intel
®
is a registered trademark of Intel Corporation.
PowerPC
®
is a registered trademark of International Business Machines Corporation.
General Notice: Other product names used herein are for identification purposes only and may be trademarks of their respective owners. Epson disclaims any
and all rights in those marks.
© 2012 Seiko Epson Corporation. All rights reserved.
EPSON SC-S70600 series/SC-S50600 series/SC-S30600 series User's Guide
Copyrights and Trademarks
2

Contents
Copyrights and Trademarks
Introduction
ImportantSafetyInstructions.................5
When choosing a place for this product. . . . . . . . 5
Whensettingupthisproduct...............5
Whenusingthisproduct...................5
Whenhandlingtheinkcartridges............6
NotesonThisGuide........................6
MeaningofSymbols......................6
Illustrations............................6
PrinterParts..............................7
Front section (SC-S70600 series, SC-S50600
series)................................7
Front section (SC-S30600 series)............10
Inside (SC-S70600 series, SC-S50600 series). . . . 13
Inside (SC-S30600 series). . ...............15
Back.................................16
LANport.............................17
Controlpanel..........................19
UnderstandingtheDisplay................20
Features................................22
RealizingHighProductivity................22
HighPrintQuality......................23
SuperiorEaseofUse.....................23
NotesonUsageandStorage..................24
Installationspace.......................24
Noteswhenusingtheprinter...............24
Noteswhennotusingtheprinter............25
Notesonhandlinginkcartridges............25
HandlingMedia........................27
SpecialtyInks............................28
Cautions..............................28
Maintenance...........................28
UsingtheSuppliedSoftware.................29
ContentsoftheSoftwareDisc..............29
StartingEPSONLFPRemotePanel2.........30
ExitingEPSONLFPRemotePanel2.........30
UninstallingSoftware......................30
Basic Operations
LoadingandExchangingMedia...............32
Loading Media (SC-S70600 series/SC-S50600
series)................................32
Loading Media (SC-S30600 series)...........43
ViewingandChangingMediaSettings........52
ExchangingMedia......................53
UsingtheAutoTake-upReelUnit.............55
MediaLoadingandTakeUp...............55
RemovingtheTake-upRoll................59
BeforePrinting...........................60
Saving Optimal Settings for the Current Media
(PrintMediaSettings)......................61
Parameters Stored in Media Setting Banks. . . . . 61
SavingSettings.........................61
ChangingHeaterandFanSettings.............65
Correcting Print Misalignment (Head
Alignment)..............................66
FeedAdjustment(ManualFeedAdjustment).....67
UsingaTestPattern.....................68
Performing Feed Adjustment During Printing
....................................69
Printablearea............................70
SC-S70600 series/SC-S50600 series. .........70
SC-S30600 series. . . . . . . . . . . . . . . . . . . . . . . . 72
Maintenance
DailyMaintenance........................74
Cleaning the Platen Heater, Pressure Rollers,
andMediaHoldingPlates.................74
Checkingforcloggednozzles...............75
Maintenance Procedures for Specialty Inks. . . . . 77
HeadCleaning.........................77
RegularMaintenance......................79
Regular Part Cleaning: Preparation and Notes
....................................79
RegularPartCleaning....................80
DisposingofWasteInk...................85
Replacing the Wiper and Wiper Cleaner. . . . . . 86
ReplacingtheFlushingPad................88
RegularPartCleaningCheckSheet............90
RegularReplacementCheckSheet.............91
ReplacingInkCartridges....................92
Howtoreplace.........................92
PartsThatArePeriodicallyReplaced...........93
Using the Control Panel Menu
MenuOperations.........................94
MenuList...............................95
EPSON SC-S70600 series/SC-S50600 series/SC-S30600 series User's Guide
Contents
3

DetailsoftheMenu.......................100
TheMediaSetupMenu.................. 100
PrinterSetupMenu.....................104
TheMaintenanceMenu..................106
TheInkLevelMenu.................... 108
ThePrintLogsMenu....................108
ThePrinterStatusMenu................. 108
TheNetworkSetupMenu................ 109
ThePreferenceMenu................... 109
TheResetAllSettingsMenu..............110
Problem Solver
WhenaMessageisDisplayed................111
When a Maintenance Call/Service Call Occurs. . . 113
Troubleshooting......................... 114
You cannot print (because the printer does not
work)............................... 114
The printer sounds like it is printing, but
nothingprints.........................114
Theprintsarenotwhatyouexpected........115
Media...............................117
Others.............................. 118
Appendix
OptionsandConsumableProducts........... 120
SupportedMedia.........................124
MovingandTransportingthePrinter..........124
MovingthePrinter..................... 124
Transport............................ 125
SystemRequirements..................... 126
SpecificationsTable.......................126
StandardsandApprovals.................127
Where To Get Help
TechnicalSupportWebSite.................128
ContactingEpsonSupport..................128
BeforeContactingEpson.................128
HelpforUsersinNorthAmerica...........129
HelpforUsersinEurope.................129
HelpforUsersinAustralia............... 129
HelpforUsersinSingapore...............130
HelpforUsersinThailand................130
HelpforUsersinVietnam................130
HelpforUsersinIndonesia...............130
HelpforUsersinHongKong..............131
HelpforUsersinMalaysia................131
HelpforUsersinIndia.................. 131
HelpforUsersinthePhilippines........... 132
Software License Terms
OpenSourceSoftwareLicenses.............. 133
Bonjour............................. 133
OtherSoftwareLicenses................... 138
Info-ZIPcopyrightandlicense.............138
EPSON SC-S70600 series/SC-S50600 series/SC-S30600 series User's Guide
Contents
4

Introduction
Important Safety
Instructions
Read all of these instructions before using the printer.
Also be sure to follow all warnings and instructions
marked on the printer.
When choosing a place for this
product
❏Place this product on a flat, stable surface that is
larger than this product. This product will not
operate properly if it is tilted or at an angle.
❏Avoid places subject to rapid changes in
temperature and humidity. Also keep it away from
direct sunlight, strong light, or heat sources.
❏Avoid places subject to shocks and vibrations.
❏Keep this product away from dusty areas.
❏Place this product near a wall outlet where the plug
can be easily unplugged.
When setting up this product
❏This product’s power cord is for use with this
product only. Use with other equipment may result
in fire or electric shock.
❏Connect all equipment to properly grounded
power outlets. Avoid using outlets on the same
circuit as copiers or air control systems that
regularly switch on and off.
❏Avoid electrical outlets controlled by wall switches
or automatic timers.
❏Keep the entire computer system away from
potential sources of electromagnetic interference,
such as loudspeakers or the base units of cordless
telephones.
❏Use only the type of power source indicated on the
product’s label.
❏Use only the power cord that comes with this
product. Use of another cord may result in fire or
electric shock.
❏Do not use a damaged or frayed power cord.
❏If you use an extension cord with this product,
make sure the total ampere rating of the devices
plugged into the extension cord does not exceed the
cord’s ampere rating. Also, make sure the total
ampere rating of all devices plugged into the wall
outlet does not exceed the wall outlet’s ampere
rating.
❏If you plan to use the printer in Germany, observe
the following:
To provide adequate short-circuit protection and
over-current protection for this printer, the
building installation must be protected by a 10 or 16
amp circuit breaker.
❏If damage occurs to the plug, replace the cord set or
consult a qualified electrician. If there are fuses in
the plug, make sure you replace them with fuses of
the correct size and rating.
When using this product
❏Do not block or cover the openings in this product’s
cabinet.
❏Do not insert objects through the slots. Take care
not to spill liquid on this product.
❏Do not attempt to service this product yourself.
❏Unplug this product and refer servicing to qualified
service personnel under the following conditions:
The power cord or plug is damaged; liquid has
entered the product; the product has been dropped
or the cabinet damaged; the product does not
operate normally or exhibits a distinct change in
performance.
❏Do not move the print heads by hand; otherwise
you may damage this product.
❏Always turn the product off using the Power button
on the control panel. When this button is pressed,
the Power light flashes briefly then goes off. Do not
unplug the power cord or turn off the product until
the Power light stops flashing.
EPSON SC-S70600 series/SC-S50600 series/SC-S30600 series User's Guide
Introduction
5

❏This device has two power systems. There is a risk of
electric shock unless the two power cables are
unplugged during the maintenance.
When handling the ink
cartridges
❏Keep ink cartridges out of the reach of children and
do not drink.
❏Do not touch the green IC chip on the side of the
cartridge. This may affect normal operation and
printing.
❏The IC chip on this ink cartridge retains a variety of
cartridge-related information, such as the ink
cartridge status, so that the cartridge may be
removed and reinserted freely.
❏If you remove an ink cartridge for later use, protect
the ink supply area from dirt and dust, and store it in
the same environment as this product. Note that
there is a valve in the ink supply port, making covers
or plugs unnecessary, but care is needed to prevent
the ink from staining items that the cartridge
touches. Do not touch the ink supply port or
surrounding area.
Notes on This Guide
Meaning of Symbols
!
Warning: Warnings must be followed to
avoid serious bodily injury.
!
Caution: Cautions must be followed to
avoid bodily injury.
c
Important: Important must be followed to
avoid damage to this product.
Note: Notes contain useful or
additional information on the
operation of this product.
Illustrations
Unless otherwise noted, the illustrations in this manual
show the SC-S30600 series.
EPSON SC-S70600 series/SC-S50600 series/SC-S30600 series User's Guide
Introduction
6

Printer Parts
Front section (SC-S70600 series, SC-S50600 series)
The illustration shows the SC-S50600 series.
AMaintenance cover (left)
Open this cover to clean the area around the print head. Normally closed when using the printer.
U“Cleaning Around the Print Head” on page 81
BAdditional print drying system
The additional print drying system can be used to rapidly dry ink after printing. Available separately for the
SC-S70600 series.
UAdditional Print Drying System Setup Guide
CAfter heater
The heater can be used to rapidly dry ink after printing.
U“Heating & Drying” on page 64
DRoll support
Rest media temporarily on these supports when removing the take-up roll. There are two supports: one on the left
and one on the right.
U“Media Loading and Take Up” on page 55
EPSON SC-S70600 series/SC-S50600 series/SC-S30600 series User's Guide
Introduction
7

ETensioner
The tensioner maintains tension to prevent the media sagging as it is taken up.
FRoll core holder locking screw
The locking screws keep the roll core holders in place once they have been attached to the roll core. There are two lift
levers: one on the left and one on the right.
GRoll support
Place the used roll core for media take-up on these holders. There are two supports: one on the left and one on the
right.
HAuto switch
Use this switch to select the auto take-up direction. Choose Off to disable auto take-up.
IManual switch
Use this switch to select the manual take-up direction.AutoThe selected option takes effect when the Auto switch is
in the Off position.
JCasters
There are two casters on each leg. Once installation is complete, the front casters should be kept locked while the
printer is in use.
KAirflow vents
These vents vent air from inside the printer. Do not obstruct these vents.
LWaste ink bottle holder
Place the waste ink bottle in this holder.
MAdjuster
The adjusters keep the printer in place. After installing the printer, keep it securely in place during use.
NWaste ink bottle
Waste ink collects in this bottle.
Replace with a new waste ink bottle when the level approaches the line.
OWaste ink tube
Waste ink is discharged from this tube. Be sure the end of this tube is in the waste ink bottle while the printer is in
use.
PInk cartridge/replacement cartridge
The number of each type of cartridge installed varies with the option selected for color mode.
SC-S70600 series: 8 colors/10 colors
SC-S50600 series: 4 colors/5 colors
In 8 or 4 color mode, use replacement cartridges as well to fill all slots.
QLock levers
Raise the levers to unlock the ink cartridges prior to removal. Lower the levers to lock the cartridges in place after
insertion.
RCartridge check lamp
This lamp lights when an ink cartridge error occurs.
EPSON SC-S70600 series/SC-S50600 series/SC-S30600 series User's Guide
Introduction
8

On : An error occurred. Check the contents of the error on the control panel's screen.
Off : No error.
SAC inlet #1/AC inlet #2
Connects the power cable. Be sure to connect both cables.
TLAN port
U“LAN port” on page 17
UUSB port
Connects the USB cable.
VMaintenance cover (right)
Open this cover when performing regular maintenance. Normally closed when using the printer.
U“Regular Maintenance” on page 79
WMedia loading lever
After loading media, lower the media loading lever to keep the media in place. Raise the lever to release the media
prior to removal.
XAlert lamp
This lamp lights or flashes when an error occurs.
On
Flashing
: An error occurred; the type of error is indicated by how the lamp lights or flashes. Check the
contents of the error on the control panel's screen.
Off : No error.
YControl panel
U“Control panel” on page 19
ZFront cover
Open when loading media, cleaning the inside of the printer, or removing jammed media. Normally closed when
using the printer.
EPSON SC-S70600 series/SC-S50600 series/SC-S30600 series User's Guide
Introduction
9

Front section (SC-S30600 series)
AMaintenance cover (left)
Open this cover to clean the area around the print head. Normally closed when using the printer.
U“Cleaning Around the Print Head” on page 81
BAfter heater
The heater can be used to rapidly dry ink after printing.
U“Heating & Drying” on page 64
CRoll support
Rest media temporarily on these supports when removing the take-up roll. There are two lift levers: one on the left
and one on the right.
U“Media Loading and Take Up” on page 55
DTensioner
The tensioner maintains tension to prevent the media sagging as it is taken up.
ERoll core holder locking screw
The locking screws keep the roll core holders in place once they have been attached to the roll core. There are two lift
levers: one on the left and one on the right.
FRoll support
Place the used roll core for media take-up on these holders. There are two supports: one on the left and one on the
right.
EPSON SC-S70600 series/SC-S50600 series/SC-S30600 series User's Guide
Introduction
10

GAuto switch
Use this switch to select the auto take-up direction.Off Choose Off to disable auto take-up.
HManual switch
Use this switch to select the manual take-up direction.Auto The selected option takes effect when the Auto switch is
in the Off position.
ICasters
There are two casters on each leg. Once installation is complete, the front casters should be kept locked while the
printer is in use.
JAirflow vents
These vents vent air from inside the printer. Do not obstruct these vents.
KWaste ink bottle holder
Place the waste ink bottle in this holder.
LAdjuster
The adjusters keep the printer in place. After installing the printer, keep it securely in place during use.
MWaste ink bottle
Waste ink collects in this bottle.
Replace with a new waste ink bottle when the level approaches the line.
NWaste ink tube
Waste ink is discharged from this tube. Be sure the end of this tube is in the waste ink bottle while the printer is in
use.
OInk cartridges
Install all ink cartridges into each slot.
PLock levers
Raise the levers to unlock the ink cartridges prior to removal. Lower the levers to lock the cartridges in place after
insertion.
QCartridge check lamp
This lamp lights when an ink cartridge error occurs.
On : An error occurred. Check the contents of the error on the control panel's screen.
Off : No error.
RAC inlet #1/AC inlet #2
Connects the power cable. Be sure to connect both cables.
SLAN port
U“LAN port” on page 17
TUSB port
Connects the USB cable.
EPSON SC-S70600 series/SC-S50600 series/SC-S30600 series User's Guide
Introduction
11

UMaintenance cover (right)
Open this cover when performing regular maintenance. Normally closed when using the printer.
U“Regular Maintenance” on page 79
VMedia loading lever
After loading media, lower the media loading lever to keep the media in place. Raise the lever to release the media
prior to removal.
WAlert lamp
This lamp lights or flashes when an error occurs.
On
Flashing
: An error occurred. the type of error is indicated by how the lamp lights or flashes. Check the
contents of the error on the control panel's screen.
Off : No error.
XControl panel
U“Control panel” on page 19
YFront cover
Open when loading media, cleaning the inside of the printer, or removing jammed media. Normally closed when
using the printer.
EPSON SC-S70600 series/SC-S50600 series/SC-S30600 series User's Guide
Introduction
12

Inside (SC-S70600 series, SC-S50600 series)
Dirt on any of the following parts may reduce print quality. Regularly clean or exchange these parts as described in the
chapters listed in the reference sections below. The illustration shows the SC-S70600 series.
APrint head
The print head prints by moving left and right while emitting ink. The print head on the left is Head 1, the print head
on the right Head 2. We recommend that you clean the area around this unit once a week.
U“Cleaning Around the Print Head” on page 81
BMedia holding plate
The media holding plates prevent the media riding up and keeps fuzz on the cut edge of the media from touching
the print head. Position the plates at either side of the media before printing.
U“Loading Media (SC-S70600 series/SC-S50600 series)” on page 32
CCutter groove
Pass the blade of a cutter (available in the market) down this groove to cut media.
DPressure rollers (high)
There are ten rollers in total; the high pressure rollers are the two on the outside edges. They press down on the
edges of the media during ink layering.
U“Cleaning the Platen Heater, Pressure Rollers, and Media Holding Plates” on page 74
Ink layering U“High Print Quality” on page 23
EPressure rollers (low)
There are ten rollers intotal; all of which are low pressure rollers apart from the two on the outside edges. They press
down on the media during normal (non-layer) printing. The number used varies with the width of the media.
U“Cleaning the Platen Heater, Pressure Rollers, and Media Holding Plates” on page 74
EPSON SC-S70600 series/SC-S50600 series/SC-S30600 series User's Guide
Introduction
13

FPlaten heater
The platen heater ensures that the ink adheres evenly.
U“Heating & Drying” on page 64
U“Cleaning the Platen Heater, Pressure Rollers, and Media Holding Plates” on page 74
GWiper cleaner
The wiper cleaner removes ink from the wiper. It is a consumable; replace about once every six months.
U“Replacing the Wiper and Wiper Cleaner” on page 86
HCaps
Except during printing, these caps cover the print head nozzles to prevent them drying out. We recommend that
this unit be cleaned once a week.
U“Regular Part Cleaning” on page 80
IWiper
The wiper removes ink from the print head nozzles. We recommend that this unit be cleaned once a week. It is a
consumable; replace about once every six months.
U“Regular Part Cleaning” on page 80
U“Replacing the Wiper and Wiper Cleaner” on page 86
JFlushing pad
Ink is discharged onto this pad during flushing. It is a consumable; replace about once every six months.
U“Replacing the Flushing Pad” on page 88
EPSON SC-S70600 series/SC-S50600 series/SC-S30600 series User's Guide
Introduction
14

Inside (SC-S30600 series)
Dirt on any of the following parts may reduce print quality. Regularly clean or exchange these parts as described in the
chapters listed in the reference sections below.
APrint head
The print head prints by moving left and right while emitting ink. We recommend that you clean the area around
this unit once a week.
U“Cleaning Around the Print Head” on page 81
BMedia holding plate
The media holding plates prevent the media riding up and keeps fuzz on the cut edge of the media from touching
the print head. Position the plates at either side of the media before printing.
U“Loading Media (SC-S30600 series)” on page 43
CCutter groove
Pass the blade of a cutter (available in the market) down this groove to cut media.
DPressure rollers
These rollers press down on the media during printing.
U“Cleaning the Platen Heater, Pressure Rollers, and Media Holding Plates” on page 74
EPlaten heater
The platen heater ensures that the ink adheres evenly.
U“Heating & Drying” on page 64
U“Cleaning the Platen Heater, Pressure Rollers, and Media Holding Plates” on page 74
EPSON SC-S70600 series/SC-S50600 series/SC-S30600 series User's Guide
Introduction
15

FWiper cleaner
The wiper cleaner removes ink from the wiper. It is a consumable; replace about once every six months.
U“Replacing the Wiper and Wiper Cleaner” on page 86
GCaps
Except during printing, these caps cover the print head nozzles to prevent them drying out. We recommend that
this unit be cleaned once a week.
U“Regular Part Cleaning” on page 80
HWiper
The wiper removes ink from the print head nozzles. We recommend that this unit be cleaned once a week. It is a
consumable; replace about once every six months.
U“Regular Part Cleaning” on page 80
U“Replacing the Wiper and Wiper Cleaner” on page 86
IFlushing pad
Ink is discharged onto this pad during flushing. It is a consumable; replace about once every six months.
U“Replacing the Flushing Pad” on page 88
Back
ADrive switch
The drive switch is used to feed the media during loading and to rewind the media for replacement.
BRoll holder
Place media on these holders. There are two lift levers: one on the left and one on the right.
EPSON SC-S70600 series/SC-S50600 series/SC-S30600 series User's Guide
Introduction
16

CRoll holder fixing screw
These screws fix the roll holders in place once the media has been installed. There are two lift levers: one on the left
and one on the right.
DLift lever
If the media to be mounted on the roll holders seems heavy, use these levers to raise the media effortlessly to the
level of the roll holders. There are two lift levers: one on the left and one on the right.
EPre-heater
Heats the media before printing so that the print area is not subject to sudden changes in temperature.
FRoll support
Rest media on these supports before placing it on the roll holders. There are two lift levers: one on the left and one
on the right.
GHandle
After placing media on the right roll holder, rotate the handle to press the holder and apply pressure to the roll
core.
LAN port
ARJ-45 connector
Connects the LAN cable. Use a shielded twisted pair cable (category 5 or higher).
BData lamp
The data lamp shows connection status and indicates whether the printer is receiving data.
CStatus lamp (green/red)
The status lamp indicates network connection speed.
EPSON SC-S70600 series/SC-S50600 series/SC-S30600 series User's Guide
Introduction
17

Data lamp Status lamp (green/red) Status
On On (green) The printer is connected using a
1000base-T connection.
Flashing The printer is receiving data over a
1000base-T connection.
On On (red) The printer is connected using a
100base-TX connection.
Flashing The printer is receiving data over a
100base-TX connection.
EPSON SC-S70600 series/SC-S50600 series/SC-S30600 series User's Guide
Introduction
18

Control panel
APbutton (power button)
Turns the power on and off.
BPlight (power light)
The printer's operational status is indicated by a lit or
flashing light.
On : The power is on.
Flashing : The printer is receiving data or
performing head cleaning or other
operations during shut-down.
Off : The power is off.
CMbutton (media setup button)
Press this button to display the Media Setup menu,
which contains such items as Media Remaining,
Select Media, Customize Settings, and Print Media
List. This button is disabled during printing.
U“The Media Setup Menu” on page 100
DDisplay
Displays the printer's status, menus, error messages,
and so on. U“Understanding the Display” on
page 20
EMenu button
Press this button to display menus. U“Using the
Control Panel Menu” on page 94
Fybutton (back button)
Press this button to exit to the previous menu when
options are displayed. U“Menu Operations” on
page 94
Gl/rbuttons (left and right arrow buttons)
Use to position the cursor when performing such
tasks as entering a Setting Name or IP Address in
the setup menu.
Hu/dbuttons (media feed buttons)
❏When media is loaded, you can press the dto feed the
media and uto rewind. Keep the dbutton pressed to
feed the media up to 103 cm. Keep the ubutton
pressed to rewind the media up to 25 cm.
Note that when the ubutton is used to rewind, the
media will stop when its edge reaches the starting
print position. Rewind can be resumed by releasing
the button and then pressing it again.
❏When the menus are displayed, these buttons can be
used to select menu items and options. U“Menu
Operations” on page 94
IZbutton
❏Pressing this button when a menu item is highlighted
displays options for the selected item.
❏Pressing this button when an option is highlighted
selects the highlighted item or performs the selected
operation.
Jbutton (heating and drying button)
EPSON SC-S70600 series/SC-S50600 series/SC-S30600 series User's Guide
Introduction
19

Pressing this button displays the Heating & Drying
menu, where you can adjust the Heater
Temperature. If the additional print drying system
(supplied with the SC-S50600 series; optional with
other models) is attached, you can also adjust
Additional Dryer settings. These options can be
adjusted during printing.
U“The Media Setup Menu” on page 100
K#button (maintenance button)
Pressing this button displays the Maintenance
menu, which contains such items as Nozzle Check,
Cleaning, Head Washing, Head Maintenance, and
Waste Ink Counter. This button is disabled during
printing.
U“The Maintenance Menu” on page 106
LWbutton (pause/cancel button)
❏The printer enters pause status if this is pressed while
printing. To release the pause status, press the W
button again, or select Pause Cancel on the screen
and then press the Zbutton. To cancel print jobs
being processed, select Job Cancel on the screen and
then press the Zbutton.
❏Pressing this button when menus are displayed closes
the menus and returns the printer to ready status.
Mbutton (media feed button)
❏When the printer is in the ready state, you can feed the
media to the cut position by pressing this button and
then Z.
U“Cutting Media” on page 54
❏When printing is in progress, you can use this button
to adjust media feed.
U“Feed Adjustment (Manual Feed Adjustment)” on
page 67
Understanding the Display
The illustration shows the display for the SC-S50600
series.
AMessages
Displays the printer's status, operation, and error
messages.
U“When a Message is Displayed” on page 111
BHeater temperature
From left to right, this display shows the temperature
settings for the pre-heater, platen heater, and after
heater. The thermometer icons give a rough indica-
tion of the current temperatures of the heaters.
: The heater has reached the selected
temperature.
: The heater has not reached the selected
temperature.
CMedia info
❏From left to right, this display shows the selected
media, platen gap, media width, and media
remaining.
❏If a media setting bank number created with this
printer is selected as the print media, the number
(from 1 to 30) will be displayed. When RIP Settings is
selected, 0 will be displayed.
❏The selected platen gap is shown as follows.
:1.5
:2.0
:2.5
EPSON SC-S70600 series/SC-S50600 series/SC-S30600 series User's Guide
Introduction
