thermal line printer
TM-T85/T85P
Operator’s Manual
400471502

Printer parts
TM-T85P
TM-T85
(1) Printer cover
(2) Power connector
(3) Interface connector
(4) Drawer kick-out connector
(5) DIP switches
(6) POWER light
(7) ERROR light
(8) PAPER light
(9) POWER button
(10) PAPER FEED button
Control Panel
(1)
(2) (3) (4)
(5)
DIP Switch 1 DIP Switch 2
(2) (3) (4)
(5)
DIP Switch 1
(6) (7)
(9) (8) (10)
