TM-U375/TM-U375 P
Using this online information guid e
The words on the left side of this screen are bookmark s for all the
topics in this guide .
Use the scroll ba r next to the bookmarks to find any topic you
want. Click a bookmark to instantly jump to its topic. (If you wish,
you can increase the size of the bookmark area by dragging the
dividing bar to the right. )
Use the zoo m tools to magnify or reduce the page display .
Click the Fin d button if you want to search for a particular term.
(However, using the bookmarks is usually quicker. )
Complete online documentation for Acrobat Reader is located in the Help directory for Acrobat Reader .

EPSON
Guide to
TM-U375/U375P
SEIKO EPSON CORPORATION
®
400609200

The programming examples in this manual are provided for the sole purpose of illustrating the
functions of the products. Seiko Epson Corporation makes no warranty, either expressed or implied,
as to their reliability and appropriateness for other uses.
All rights reserved. No part of this publication may be reproduced, stored in a retrieval system, or
transmitted in any form or by any means, mechanical, photocopying, recording, or otherwise,
without the prior written permission of Seiko Epson Corporation. No patent liability is assumed with
respect to the use of the information contained herein. While every precaution has been taken in the
preparation of this book, Seiko Epson Corporation assumes no responsibility for errors or omissions.
Neither is any liability assumed for damages resulting from the use of the information contained
herein.
Neither Seiko Epson Corporation nor its affiliates shall be liable to the purchaser of this product or
third parties for damages, losses, costs, or expenses incurred by purchaser or third parties as a result
of: accident, misuse, or abuse of this product or unauthorized modifications, repairs, or alterations to
this product, or (excluding the U.S.) failure to strictly comply with Seiko Epson Corporation’s
operating and maintenance instructions.
Seiko Epson Corporation shall not be liable against any damages or problems arising from the use of
any options or any consumable products other than those designated as Original Epson Products or
Epson Approved Products by Seiko Epson Corporation.
EPSON is a registered trademark of Seiko Epson Corporation.
ESC/POS is a trademark of Seiko Epson Corporation.
NOTICE: The contents of this manual are subject to change without notice.
Copyright© 1996 by Seiko Epson Corporation, Nagano, Japan.
ESC/POS™ Information Manual
Guide to TM–U375/U375P
9603-01
SEIKO EPSON CORPORATION
SYSTEM DEVICE DIVISION
2070 Kotobuki Koaka, Matsumoto-shi, Nagano-ken 399, Japan

Rev. A i
Introduction
ESC/POS
The market for store automation equipment is changing rapidly with the widespread
introduction of POS (point of sale) terminals. These terminals are now appearing even in small
retail stores and specialty shops. They occupy a secure position in the range of applications
available for personal computers.
As more personal computers come to be used as POS terminals, the demand for matching
standardized peripheral devices is expected to rise. At present, however, many of the competing
POS terminal printer displays on the market employ mutually incompatible command sets. This
imposes limits on the expandability and range of applications possible with PC-based systems.
There is a need for a new command set designed to provide the expandability and universal
applicability demanded by the market.
To meet this need, Seiko Epson Corporation proposes the adoption of a newly developed
command set to standardize POS terminal peripheral devices: ESC/POS (Epson Standard Code
for Point of Sale).
The aim when developing ESC/POS was to create a set of control codes that could be used to
operate any output device connected to a POS terminal. These new codes are intended to replace
the mutually incompatible command sets previously in use.
TM/DM series models already support ESC/POS, and they have been evaluated highly in the
marketplace.
Seiko Epson Corporation plans to produce new models in the TM/DM series offering ESC/POS
support and to continue to work for the standardization of the entire POS environment to
promote the dissemination of ESC/POS.
About This Manual
❏Chapter 1 contains a table of supported commands, descriptions of all the commands
arranged by function with program examples and print samples, and character code tables.
❏Chapter 2 contains an example showing procedures and a program for combining system
processes with the TM-U375, DM-D202II, and a drawer.
❏Chapter 3 contains a table of the commands listed by function type and a table showing
which commands are supported by various EPSON printers.

ii Rev. A
Features
The TM-U375 and TM-U375P are high-performance POS printers that can print on slip,
validation, and journal paper. The printers have the following features:
❏World’s smallest multi-function 1.5 station printer.
❏High-speed printing using logic seeking.
❏Easy problem handling (e.g., paper jams or objects dropped into the printer) via a clamshell
mechanism.
❏Two cut-sheet entrances: from above for validation paper and from the front for slip paper.
❏Both journal and receipt printing with pressure-sensitive paper.
❏Free-format printing in page mode.
❏Various check printing patterns.
❏Logic seeking and page mode for check printing.
❏Movable platen for easy paper insertion.
❏Paper load switch for easy paper roll loading.
❏Control capability for two drawers.
❏Selectable character size (7 ×9 or 5 ×9 font).
❏Command protocol based on the ESC/POS
TM
standard.
❏Automatic Status Back (ASB) function that automatically transmits changes in printer status.
❏EPSON intelligent module connection (TM-U375 only).
❏EPSON customer display series connection (TM-U375 only).
Options and Accessories
❏EPSON power supply unit, PS-150 (not required when the TM-U375 (only) is connected to
an intelligent module).
❏Direct connection display modules, DM-D102 and DM-D203 (for use with TM-U375 only).
❏Pass-through customer display modules, DM-D101II and DM-D202II (for use with TM-U375
only).
❏EPSON ribbon cassette, ERC-38.

Rev. A iii
Specifications
❏Printing specifications
Printing method: 9-pin, serial impact dot matrix
Printing speed: Approximately 3.5 LPS
(40 columns, 16 CPI, continuous printing)
Approximately 5.4 LPS
(20 columns, 16 CPI, continuous printing)
Number of printable columns: 40/33
❏Character specifications
Character fonts: 7 ×9/5 ×9
Character pitch: 16/13.3 CPI
Character size: 1.24(W) ×3.1(H) mm/1.56(W) ×3.1(H) mm
Character sets: ASCII: 95 characters
International: 32 characters
Extended graphics: 128 characters ×6 pages
❏Paper specifications
Paper size: Paper roll: 75.5-76.5(W) mm × 83.0 mm diameter
Slip paper: 70(W) ×160(L) mm – 182(W) ×257(L) mm
Validation paper: 135(W) ×70(L) mm – 182(W) ×257(L) mm
Thickness: Paper roll: 0.06 mm – 0.085 mm
Slip paper: 0.09 mm – 0.31 mm
❏Interface: RS-232 (serial interface)
or
IEEE-1284 (parallel interface)
❏Data buffer: 4K or 40 bytes (selectable by DIP switch)

iv Rev. A
Contents
Chapter 1 Command Descriptions
Using Bit Value Tables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3
Print Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-4
Line Spacing Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-7
Character Commands. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-8
Panel Button Command . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-18
Paper Sensor Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-19
Printing Paper Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-21
Print Position Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-24
Bit-Image Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-30
Status Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-32
Mechanism Control Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-40
Miscellaneous Function Commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-42
Character Code Tables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-48
Chapter 2 Application
Chapter 3 Command Reference
Command Classification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-1
Reference Table . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-6

Rev. A Command Descriptions 1-1
TM–U375/U375P Information Manual
Chapter 1
Command Descriptions
Following this table are all the commands organized by function and described with program
examples and print samples. The print samples are images of the printing results of the program
examples; they do not represent actual printing.
Supported Commands
Command Name Function Type Page
Number
HT Horizontal tab Print position 1-27
LF Print and line feed Print 1-4
FF
Print and eject cut sheet (in standard mode)
Print and return to standard mode (in page
mode)
Print 1-5
CR Print and carriage return Print 1-4
CAN Cancel print data in page mode Character 1-17
DLE EOT Real-time status transmission Status 1-36
DLE ENQ Real-time request to printer Miscellaneous function 1-46
ESC SP Set right-side character spacing Character 1-9
ESC ! Select print mode(s) Character 1-13
ESC $ Set absolute print position Print position 1-24
ESC % Select/cancel user-defined character set Character 1-10
ESC & Define user-defined characters Character 1-10
ESC ✻Select bit-image mode Bit image 1-30
ESC – Turn underline mode on/off Character 1-14
ESC 2 Select default line spacing Line spacing 1-7
ESC 3 Set line spacing Line spacing 1-7
ESC < Return home Mechanism control 1-40
ESC = Select peripheral device Miscellaneous function 1-45
ESC ? Cancel user-defined characters Character 1-10
ESC @ Initialize printer Miscellaneous function 1-43
ESC C Set cut sheet eject length Line spacing 1-8
ESC D Set horizontal tab positions Print position 1-27
ESC E Turn emphasized mode on/off Character 1-15
ESC G Turn double-strike mode on/off Character 1-15
ESC J Print and feed paper Print 1-6
ESC L Select page mode Miscellaneous function 1-46
ESC R Select an international character set Character 1-11
1
2

1-2 Command Descriptions Rev. A
ESC T Select print direction in page mode Print position 1-29
ESC U Turn unidirectional printing mode on/off Mechanism control 1-41
ESC V Turn 90°clockwise rotation mode on/off Character 1-17
ESC W Set printing area in page mode Print position 1-28
ESC \ Set relative print position Print position 1-24
ESC a Select justification Print position 1-25
ESC c 0 Select paper type(s) for printing Printing paper 1-21
ESC c 1 Select paper type(s) for command settings Printing paper 1-22
ESC c 3 Select paper sensor(s) to output paper-end
signals Paper sensor 1-20
ESC c 4 Select paper sensor(s) to stop printing Paper sensor 1-19
ESC c 5 Enable/disable panel buttons Panel button 1-18
ESC d Print and feed
n lines Print 1-6
ESC f Set cut sheet wait time Printing paper 1-23
ESC p Generate pulse Miscellaneous function 1-45
ESC q Paper release Mechanism control 1-41
ESC t Select character code table Character 1-12
ESC u Transmit peripheral device status Status 1-39
ESC v Transmit paper sensor status Status 1-40
ESC { Turn upside-down printing mode on/off Character 1-16
GS ✻Define downloaded bit image Bit image 1-31
GS / Print downloaded bit image Bit image 1-31
GS E Select head control method Miscellaneous function 1-43
GS I Transmit printer ID Miscellaneous function 1-44
GS L Set left margin Print position 1-26
GS P Set horizontal and vertical motion units Miscellaneous function 1-42
GS W Set printing area width Print position 1-26
GS a Enable/disable Automatic Status Back (ASB) Status 1-33
GS r Transmit status Status 1-35
Command Name Function Type Page
Number

Rev. A Command Descriptions 1-3
TM–U375/U375P Information Manual
Using Bit Value Tables
For each command that has a complex method of determining the variable n, there is a table showing
how to calculate the variable in three numbering systems: binary, hexadecimal, and decimal.
When you look at the table, first find the value of each component of the variable. Then add the
values of the components together to determine the value of the variable n.
For example, here is how you would use the table below, which selects the print mode, to combine
double height, double width, and underline. In the table, you see that bit 4 on (or hex 10 or decimal
16) turns on double height, bit 5 on (or hex 20 or decimal 32) turns on double width, and bit 7 on (or
hex 80 or decimal 128) turns on underline mode.
To combine all three, turn on bits 4, 5, and 7, which is 10110000 in binary. Or you can add the hex
values 10, 20, and 80 for the hex sum of B0, or you can add the decimal values 16, 32, and 128 for the
decimal value of 176.
Therefore, you send the following to turn on double height, double width, and underline, depending
on the numbering system used:
ASCII ESC ! n
Hex 1B 21 B0
Decimal 28 33 176
Note that the program examples throughout this chapter use decimal numbers, but binary, decimal,
and hexadecimal numbers all have the same printing results.
Bit Off/On Hex Decimal Function
0Off 00 0 Character font 5 x 9 selected.
On 01 1 Character font 7 x 9 selected.
1, 2 — — — Undefined.
3Off 00 0 Emphasized mode not selected.
On 08 8 Emphasized mode selected.
4Off 00 0 Double-height mode not selected.
On 10 16 Double-height mode selected.
5Off 00 0 Double-width mode not selected.
On 20 32 Double-width mode selected.
6 — — — Undefined.
7Off 00 0 Underline mode not selected.
On 80 128 Underline mode selected.

1-4 Command Descriptions Rev. A
Print Commands
The TM-U375/U375P supports the following commands for printing characters and advancing
paper:
Command Name
LF Print and line feed
CR Print and carriage return
FF Print and eject cut sheet (in standard mode)
Print and return to standard mode (in page mode)
ESC J Print and feed paper
ESC d Print and feed nlines
LF
[Name] Print and line feed
[Format] ASCII LF
Hex 0A
Decimal 10
LF prints the data in the print buffer and feeds one line. The amount of paper fed per line is based on
the value set using the line spacing command. The default setting is 1/6 inch.
CR
[Name] Print and carriage return
[Format] ASCII CR
Hex 0D
Decimal 13
CR prints one line of data from the print buffer and does not feed the paper. This command sets the
print starting position to the beginning of the line.
Program Example Print Sample
PRINT #1, "AAAAA"; CHR$(&HA); AAAAA
PRINT #1, "BBBBB"; CHR$(&HA); BBBBB
Program Example Print Sample
PRINT #1, "AAAAA"; CHR$(&HD); AAAAABBBBB
PRINT #1, " BBBBB"; CHR$(&HA);
1
2

Rev. A Command Descriptions 1-5
TM–U375/U375P Information Manual
FF
[Name] Print and eject cut sheet (in standard mode)
Print and return to standard mode (in page mode)
[Format] ASCII FF
Hex 0C
Decimal 12
In standard mode, FF prints the data in the print buffer and ejects the cut sheet (slip or validation
paper). This command is enabled only when a cut sheet is selected for printing. When the eject
length has been set by ESC C, the printer ejects the cut sheet based on the current eject length
regardless of the cut-sheet paper sensor state. Otherwise, the printer ejects the cut sheet completely.
Paper from the paper roll is not ejected, even if it is also selected.
After cut-sheet ejection, the paper roll is selected for printing. The cut sheet is ejected in the forward
direction only.
In page mode, FF prints the data in the print buffer collectively and returns to standard mode. The
buffer data is deleted after being printed, but the paper is not ejected.
Program Example <standard mode> Print Sample <standard mode>
PRINT #1, CHR$(&H1B);"c0";CHR$(4);← Select slip
PRINT #1, "AAAAA"; CHR$(&HA);
PRINT #1, "BBBBB"; CHR$(&HC);
AAAAA
BBBBB
The paper is completely ejected.
Program Example <page mode> Print Sample <page mode>
PRINT #1, CHR$(&H1B);"L";←Select page mode
PRINT #1, CHR$(&H1B);"W";CHR$(0);CHR$(0);CHR$(0);
CHR$(0);CHR$(30);CHR$(0);CHR$(30);CHR$(0);
PRINT #1, CHR$(&H1B);"T";CHR$(0);
PRINT #1, "AAAAA"; CHR$(&HA);←Store characters for printing
PRINT #1, "BBBBB"; CHR$(&HA);←Store characters for printing
PRINT #1, "CCCCC"; CHR$(&HC);←Batch print
1
2
AAAAA
BBBBB
CCCCC

1-6 Command Descriptions Rev. A
ESC J n
[Name] Print and feed paper
[Format] ASCII ESC J n
Hex 1B 4A n
Decimal 27 74 n
[Range] 0 ≤ n ≤ 255
ESC J n prints the data in the print buffer and feeds the paper [n×(vertical or horizontal motion unit)]
inches. This command is used to temporarily feed a specific length without changing the line spacing
set by other commands. The maximum paper feed amount is 40 inches. When standard mode is
selected, the vertical motion unit set by GS P is used. When page mode is selected, the vertical or
horizontal motion unit set by GS P is used for the print direction set by ESC T.
ESC d n
[Name] Print and feed nlines
[Format] ASCII ESC d n
Hex 1B 64 n
Decimal 27 100 n
[Range] 0 ≤ n ≤ 255
ESC d n prints the data in the print buffer and feeds nlines. The amount of paper fed per line is based
on the value set using the line spacing command. The maximum paper feed amount is 40 inches. The
default setting of the paper feed amount is 1/6 inch.
Program Example Print Sample
PRINT #1, CHR$(&H1D);"P";CHR$(160);CHR$(144);
PRINT #1, "AAAAA"; CHR$(&HA);
PRINT #1, "BBBBB"; CHR$(&H1B);"J";CHR$(72);
PRINT #1, "CCCCC"; CHR$(&HA);
PRINT #1, "DDDDD"; CHR$(&HA);
Program Example Print Sample
PRINT #1, "AAAAA"; CHR$(&HA);
PRINT #1, "BBBBB"; CHR$(&H1B);"d";CHR$(6);
PRINT #1, "CCCCC"; CHR$(&HA);
AAAAA
BBBBB
CCCCC
ESC d used to print one line and
advance the paper by six lines
AAAAA
BBBBB
CCCCC
DDDDD
ESC J used to print one line and advance
the paper by 72/144 inch

Rev. A Command Descriptions 1-7
TM–U375/U375P Information Manual
Line Spacing Commands
The TM-U375/U375P supports the following commands for setting line spacing. These commands
only set the line spacing; they do not actually advance the paper. The line spacing can be set
independently in standard mode and in page mode. The line spacing set using these commands
effects the results of the LF and ESC d commands. The paper is advanced using the PAPER FEED
button.
Command Name
ESC 2 Select default line spacing
ESC 3 Set line spacing
ESC C Set cut sheet eject length
ESC 2
[Name] Select default line spacing
[Format] ASCII ESC 2
Hex 1B 32
Decimal 27 50
ESC 3 n
[Name] Set line spacing
[Format] ASCII ESC 3 n
Hex 1B 33 n
Decimal 27 51 n
[Range] 0 ≤ n ≤ 255
ESC 2 sets the line spacing to 1/6 inch. This is equivalent to 12 dots.
ESC 3 n sets the line spacing to [n×(vertical or horizontal motion unit)] inches. The default setting of
the paper feed amount is 1/6 inch (n=24). The maximum line spacing amount is 40 inches. When
standard mode is selected, the vertical motion unit set by GS P is used. When page mode is selected,
the vertical or horizontal motion unit set by GS P is used for the print direction set by ESC T.
Program Example Print Sample
PRINT #1, CHR$(&H1D);"P";CHR$(160);CHR$(144);
PRINT #1, CHR$(&H1B);"c1";CHR$(1);← Select paper roll
FOR n=10 TO 60 STEP 10
PRINT #1, CHR$(&H1B);"3";CHR$(n);
PRINT #1, "AAAAA"; CHR$(&HA);
NEXT n
PRINT #1, CHR$(&H1B);"2";
PRINT #1, "BBBBB"; CHR$(&HA);
PRINT #1, "CCCCC"; CHR$(&HA); CCCCC
AAAAA
AAAAA
AAAAA
AAAAA
AAAAA
AAAAA
BBBBB
10/144-inch (5-dot) line spacing
20/144-inch (10-dot) line spacing
30/144-inch (15-dot) line spacing
40/144-inch (20-dot) line spacing
50/144-inch (25-dot) line spacing
60/144-inch (30-dot) line spacing
1/6-inch (12-dot) line spacing

1-8 Command Descriptions Rev. A
ESC C n
[Name] Set cut sheet eject length
[Format] ASCII ESC C n
Hex 1B 43 n
Decimal 27 67 n
[Range] 0 ≤ n ≤ 255
ESC C n sets the eject length for cut sheet (slip or validation paper) to nlines. The maximum eject
length is 40 inches. The default setting for the eject length is n=0. This length is calculated by [n×line
spacing setting]. No eject length is set if n=0. When n=0, the paper is ejected continuously until it is
completely out of the printer. The eject length set by this command is used by the FF command. This
command sets the eject length for the paper specified by ESC c 1.
Character Commands
The TM-U375/U375P supports the following commands for setting character font and size:
Command Name
ESC SP Set right-side character spacing
ESC % Select/cancel user-defined character set
ESC & Define user-defined characters
ESC ? Cancel user-defined characters
ESC R Select an international character set
ESC t Select character code table
ESC ! Select print mode(s)
ESC – Turn underline mode on/off
ESC E Turn emphasized mode on/off
ESC G Turn double-strike mode on/off
ESC { Turn upside-down printing mode on/off
ESC V Turn 90° clockwise rotation mode on/off
CAN Cancel print data in page mode
Program Example Print Sample
PRINT #1, CHR$(&H1B);"c1";CHR$(4);←Select slip
PRINT #1, CHR$(&H1B);"C";CHR$(8);←Set eject length
PRINT #1, CHR$(&H1B);"c0";CHR$(4);←Select slip
PRINT #1, "AAAAA"; CHR$(&HA);
PRINT #1, "BBBBB"; CHR$(&HC);
AAAAA
BBBBB
Eject length set to 8 lines using
ESC C

Rev. A Command Descriptions 1-9
TM–U375/U375P Information Manual
ESC SP n
[Name] Set right-side character spacing
[Format] ASCII ESC SP n
Hex 1B 20 n
Decimal 27 32 n
[Range] 0 ≤ n ≤ 255
ESC SP n sets the right-side character spacing to [n×(horizontal or vertical motion unit)] inches. It is
used to change the spacing between characters. The default setting is n=0. When standard mode is
selected, the horizontal motion unit set by GS P is used. When page mode is selected, the vertical or
horizontal motion unit set by GS P is used for the print direction set by ESC T.
The right-side character spacing can be set independently in standard mode and in page mode.
Program Example Print Sample
PRINT #1, CHR$(&H1D);"P";CHR$(160);CHR$(144);
PRINT #1, CHR$(&H1B);" ";CHR$(0);← Character spacing set to 0
PRINT #1, "AAAAA"; CHR$(&HA);
PRINT #1, CHR$(&H1B);" ";CHR$(6);← Character spacing set to 6
PRINT #1, "BBBBB"; CHR$(&HA);
PRINT #1, CHR$(&H1B);" ";CHR$(12);← Character spacing set to 12
PRINT #1, "CCCCC"; CHR$(&HA);
AAAAA ←0-inch right-side character spacing
BBBBB ←6/160-inch right-side character spacing
CCCCC ←12/160-inch right-side character spacing

1-10 Command Descriptions Rev. A
ESC % n
[Name] Select/cancel user-defined character set
[Format] ASCII ESC % n
Hex 1B 25 n
Decimal 27 37 n
[Range] 0 ≤ n ≤ 255
ESC & y c1 c2 [x1 d1 ... d(y ×x1)] ... [xk d1 ... d(y ×xk)]
[Name] Define user-defined characters
[Format] ASCII ESC & y c1 c2 [x1 d1 ... d(y ×x1)] ... [xk d1 ... d(y ×xk)]
Hex 1B 26 y c1 c2 [x1 d1 ... d(y ×x1)] ... [xk d1 ... d(y ×xk)]
Decimal 27 38 y c1 c2 [x1 d1 ... d(y ×x1)] ... [xk d1 ... d(y ×xk)]
[Range] y= 2
32 ≤c1 ≤c2 ≤126
0 ≤x≤6 (5 ×9 font)
0 ≤x≤10 (7 ×9 font)
0 ≤d1 ... d(y ×xk) ≤ 255
k= c2-c1+1
ESC ? n
[Name] Cancel user-defined characters
[Format] ASCII ESC ? n
Hex 1B 3F n
Decimal 27 63 n
[Range] 32 ≤ n ≤ 126
ESC % n selects or cancels the user-defined character set. When the LSB (least significant bit) of nis 1,
the user-defined character set is selected. When it is 0, the internal character set is selected; this is the
default setting.
ESC & y c1 c2 [x1 d1 ... d(y ×x1)] ... [xk d1 ... d(y ×xk)] defines user-defined characters from character
code c1 to c2. yand xare the configuration of a user-defined character. yspecifies the number of
bytes in the vertical direction. xspecifies the number of dots in the horizontal direction. Character
codes from the alphanumeric characters (20H (decimal 32) to 7EH (decimal 126)) can be defined by c1
and c2. Data (d) specifies a bit printed to 1 and not printed to 0. As the default, user-defined
characters are not defined and the internal character set is printed. Once the user-defined characters
have been defined, they are available until ESC @, ESC ?, or GS ✻is executed; the user-defined
characters are redefined; the power is turned off; or the printer is reset. When this command is
executed, the downloaded bit image is canceled.

Rev. A Command Descriptions 1-11
TM–U375/U375P Information Manual
ESC ? n cancels the user-defined characters defined for the character code n. After the user-defined
characters are canceled, the internal character set is printed.
ESC R n
[Name] Select an international character set
[Format] ASCII ESC R n
Hex 1B 52 n
Decimal 27 82 n
[Range] 0 ≤ n ≤ 10
Program Example Program Example (continued)
y=2
PRINT #1, CHR$(&H1B);"&";CHR$(y);"AC";
x=7: PRINT #1, CHR$(x);
FOR i=1 TO y*x
READ d: PRINT #1, CHR$(d);
NEXT i
x=9: PRINT #1, CHR$(x);
FOR i=1 TO y*x
READ d: PRINT #1, CHR$(d);
NEXT i
x=9: PRINT #1, CHR$(x);
FOR i=1 TO y*x
READ d: PRINT #1, CHR$(d);
NEXT i
PRINT #1, CHR$(&H1B);"%";CHR$(0); ←Select the internal character
PRINT #1, "A B C D E"; CHR$(&HA);
PRINT #1, CHR$(&H1B);"%";CHR$(1); ← Select the user-defined
PRINT #1, "A B C D E"; CHR$(&HA):
PRINT #1, CHR$(&H1B);"?";"A"; ←Cancel the user-defined character
PRINT #1, "A B C D E"; CHR$(&HA);
DATA &H30,&H00,&H78,&H00,&HFC,&H00,&H78,&H00
DATA &H30,&H00,&H00,&H00,&H00,&H00
DATA &H18,&H00,&H24,&H00,&H42,&H00,&H81,&H00
DATA &H42,&H00,&H24,&H00,$H18,&H00,&H00,&H00
DATA &H00,&H00
DATA &H18,&H00,&H28,&H00,&H4F,&H80,&H80,&H80
DATA &H4F,&H80,&H28,&H00,&H18,&H00,&H00,&H00
DATA &H00,&H00
Print Sample
ABCDE ←Characters from internal character set
+◊↑DE ← Characters from user-defined character set
A◊↑DE ←Characters from user-defined character set
(cancel one character)
Defines the
user-defined
characters as
"A", "B", and "C"
character set
set

1-12 Command Descriptions Rev. A
ESC R n selects an international character set nas follows. The default value is U.S.A. (n=0).
ESC t n
[Name] Select character code table
[Format] ASCII ESC t n
Hex 1B 74 n
Decimal 27 116 n
[Range] 0 ≤ n ≤ 5
254 ≤ n ≤255
n Country
0U.S.A.
1 France
2 Germany
3U.K.
4 Denmark I
5 Sweden
6Italy
7Spain
8 Japan
9 Norway
10 Denmark lI
Program Example Print Sample
FOR n=0 TO 10
PRINT #1, CHR$(&H1B);"R";CHR$(n);
PRINT #1, "# $ @[ \ ] ^ ` { ¦ } ~"; CHR$(&HA);
NEXT n
# $@[\]^`{¦}~← n =0 (Default setting)
# $à°ç§^`éùè¨← n =1
# $§ÄÖÜ^`äöüß← n =2
£ $@[\]^`{¦}~← n =3
# $@ÆØÅ^`æøå~← n =4
# ¤ÉÄÖÅÜéäöåü← n =5
# $@°\é^ùàòèì← n =6
Pt $@¡Ñ¿^`¨ñ}~← n =7
# $@[¥]^`{¦}~← n =8
# ¤ÉÆØÅÜéæøåü← n =9
# $ÉÆØÅÜéæøåü← n =10

Rev. A Command Descriptions 1-13
TM–U375/U375P Information Manual
ESC t n selects a page n from the character code table as follows. The alphanumeric characters (20H
(decimal 32) to 7FH (decimal 127)) are the same for each page. The graphic characters (80H (decimal
128) to FFH (decimal 255)) are different for each page. The default setting is page 0.
ESC ! n
[Name] Select print mode(s)
[Format] ASCII ESC ! n
Hex 1B 21 n
Decimal 27 33 n
[Range] 0 ≤ n ≤ 255
n Character Code Table
0 Page 0 [PC437 (U.S.A. , Standard Europe)]
1 Page 1 [Katakana]
2 Page 2 [PC850 (Multilingual)]
3 Page 3 [PC860 (Portuguese)]
4 Page 4 [PC863 (Canadian-French)]
5 Page 5 [PC865 (Nordic)]
254 Page 254 [space page]
255 Page 255 [space page]
Program Example Print Sample
PRINT #1, CHR$(&H1B);"!";CHR$(0);
PRINT #1, CHR$(&H1B);"t";CHR$(0); ←Select page 0
GOSUB printing
PRINT #1, CHR$(&H1B);"t";CHR$(1); ←Select page 1
GOSUB printing
END
printing:
FOR i=&H20 TO &H7F
PRINT #1, CHR$(i);
NEXT i
PRINT #1, CHR$(&HA);
FOR i=&H80 TO &HFF
PRINT #1, CHR$(i);
NEXT i
PRINT #1, CHR$(&HA);
RETURN
Page 0
Page 1
