Installation Guide

Using the Product Safely
1
Safety Instructions
For your safety, read all the instructionsin this guide before using this product. Incorrect handling that ignores
instructions in this guide could damage this product or could result in personal injury or property damage.
Keep this installation guide at hand for future reference.
Read the User'sGuide and SafetyInstructions for your projector and follow the instructions in these documents.
Safety indications
The documentation and this product use graphical symbols to show how to use this product safely.
The indications and their meaning are as follows. Make sure you understand them properly before reading
the guide.
Symbol Explanation
Warning This symbol indicates information that, if ignored, could possibly result in personal injury or
even death due to incorrect handling.
Caution This symbol indicates information that, if ignored, could possibly result in personal injury or
physical damage due to incorrect handling.
Explanation of Symbols
Symbols Explanation
Symbol indicating an action that must not be done
Symbol indicating an action that should be done
c
Symbol indicating related or useful information
Safety Precautions for Installation
Warning
The setting plate is exclusively for mounting the projector on a wall. If anything other than
a projector is mounted, the weight may result in damage.
If this product falls, it could cause death or personal injury.
The installation work (wall mounting) should be performed by specialists who have tech-
nical knowledge and ability. Incomplete or incorrect installation could cause the product
to fall and cause personal injury or property damage.
Follow the instructions in this guide when installing this product.
If the instructions are not followed, this product may fall, resulting in personal injury or an accident.

Using the Product Safely
2
Warning
Handle the power cord carefully.
Incorrect handling may cause fire or electric shock. Observe the following precautions when han-
dling:
•
Do not handle the power plug with wet hands.
•
Do not use a power cord that is damaged or modified.
•
Do not pull the power cord with too much force when routing the cable through the setting plate.
Do not install the setting plate in a place where it might be subjected to vibration or shock.
This could cause damage to the projector or mounting surface. If this product falls, it could cause
death or personal injury.
Install the setting plate so that it can sufficiently support the mass of the projector and
setting plate, and resist any horizontal vibration. Use M10 nuts and bolts.
Nuts and bolts smaller than M10 could cause the setting plate to fall. Epson acceptsno responsibility
for any damage or injury caused by lack of wall strength or inadequate installation.
The installation work should be performed by at least two qualified service personnel. If
you need to loosen any screws during installation, be careful not to drop this product.
If this product falls, it could cause death or personal injury.
When mounting this product on a wall, the wall requires enough strength to hold the
projector and the setting plate.
This product should be installed on a concrete wall. The maximum combined weight of the pro-
jector and the setting plate is approximately 20 kg (not including cables). Ensure the strength of
the wall before mounting this product on the wall. If the wall is not strong enough, reinforce the
wall before installation.
Inspect the setting plate on a regular basis to ensure there are no broken parts or loose
screws.
If any parts are damaged, stop using the setting plate immediately. If this product falls, it could
cause death or personal injury.
Do not disassemble or remodel this product.
There are numerous high-voltage sections inside the product that could cause a fire, electric shock,
or an accident.
Do not hang on this product or hang a heavy object on this product.
If this product falls, it could cause death or personal injury.
Do not use adhesives, lubricants, or oils to install or adjust the setting plate.
If you use adhesives to prevent the screws from loosening or things such as lubricants or oils on
the slide plate fixing part of the projector, the case may crack and cause the projector to fall,
resulting in personal injury or property damage.
Tighten all screws firmly after adjustment.
Otherwise, the product may fall and cause personal injury or property damage.
Never loosen the bolts and nuts after installation.
Confirm that the screws have not become loose on a regular basis. If you find any loose screws,
tighten them firmly. Otherwise, the product may falland cause personal injury or property damage.
Route the cables so that they are not interfered with the nuts and bolts.
Incorrect handling of the cables may cause fire or electric shock.

Using the Product Safely
3
Warning
When turning on the projector, do not look into the projection window.
This could cause damage to eyesight due to the powerful light emitted. Take particular care when
there are children present. When turning on the projector at a distance using the remote control,
make sure there is no one looking into the projection window.
When using the projector, do not place any objects or put your hand near the projection
window.
This area is dangerous as it reaches a high temperature due to the concentrated projection light.
Do not cover the projector's air intake vent or air exhaust vent. If either of the vents are
covered, the internal temperature could rise and cause a fire.
Avoid locations subject to high temperatures, such as close to heaters, and leave a gap of at least
50 cm between the wall and the air exhaust vent.
Do not use the projector in a location subject to combustible or explosive gas.
The projector may catch fire because of the high temperature inside the projector.
If any abnormalities occur with this product, immediately disconnect the cables from the
product, and then contact your local dealer or the nearest Epson service call center.
Continuing to use the product in an abnormal condition could cause a fire, electric shock, or visual
impairment.
Laser warning labels are attached to the inside and the outside of the projector.
Inside
Outside
As with any bright source, do not stare into the beam, RG2 IEC/EN 62471-5:2015.
Never open any cases on the projector.
Electrical voltages inside the projector can cause severe injury.

Using the Product Safely
4
Warning
Do not look at operating light source.
Possibly hazardous optical radiation emitted from this product. Eye injury may result.
Caution
Do not install this product in a location where the operating temperature for your projector
model may be exceeded.
Such an environment may damage the projector.
Install this product in a place free from excessive dust and humidity to prevent the lens or
optical components from becoming dirty.
Do not use excessive force when adjusting this product.
This product may break, resulting in personal injury.
This projector is a Class 1 laser product that complies with the IEC/EN60825-1: 2014
international standard for lasers.
Do not disassemble the projector when disposing of it.
Dispose according to your local or national laws and regulations.
Notes on handling the Touch Unit
Warning
Do not disassemble or remodel the Touch Unit.
The Touch Unit contains a high power laser product that could cause a fire, electric shock, or an
accident.
Only connect the Touch Unit to the EB-1470Ui. Do not connect it to any other projectors
or devices.
The device could malfunction, or laser light that is higher than normal intensity could be emitted.
Do not go near the Touch Unit if you are using medical equipment such as a pace maker.
Furthermore, when using the Touch Unit, make sure there is no one using medical equip-
ment such as a pace maker, in the surrounding area.
A powerful magnet within the unit generates electromagnetic interference which may cause med-
ical equipment to malfunction.
Caution
Do not go near the Touch Unit with magnetic storage media such as magnetic cards, or
precision electronic devices such as computers, digital watches, or mobile phones.
A powerful magnet within the unit could corrupt data or cause a malfunction.
Do not disassemble the touch unit when disposing of it.
Dispose according to your local or national laws and regulations.
About This Installation Guide
This guide describes how to mount the ultra short-throw projector EB-1470Ui on a wall.

Using the Product Safely
5
It also describes how to install the Touch Unit, Control Pad, and Pen Stand after mounting the projector on
a wall.

Using the Product Safely
6
Choosing an Installation Location
Projector installation location
•Carry out power supply wiring work for the installation location of the setting plate in advance.
•Install the projector away from other electric devices such as fluorescent lights or air conditioners. Some kinds of
fluorescent lights could interfere with the remote control of the projector.
•When installing the projector, make sure there is a gap of at least 50 cm from the wall to the projector's air exhaust
and intake vents on the left and right.
•When installing two or more projectors in parallel, make sure the temperature of the surrounding environment is
less than 35°C.
If the environment is too hot, the projector may overheat and the power may turn off without warning. When using
the projector in an environment of 35°C or more, install a partition to block the heat vented from the projector's air
exhaust vent. Make sure the partition is slightly larger than the exhaust vent (approx. 2 cm wider and taller), and then
install the partition 30 cm from the exhaust vent.
•It is recommended to keep connection cable length less than 20 meters to reduce external noise.
•We recommend using stick-on screens or board screens.
•Install the projector so that it is tilted at an angle of no more than ±3° vertically and horizontally in relation to the screen.
•When using the interactive function (Easy Interactive Function), install so that the projected image is within reach.
•Do not install the projector or the screen in a location subject to direct sunlight. If the projector or the screen are
subject to direct sunlight, the interactive function may not operate correctly.

Using the Product Safely
7
Touch Unit installation location
•When using the Touch Unit, install the projector using one of the following methods. The Touch Unit cannot be used
if another installation method is used.
•Mount the projector on a wall or suspend it from a ceiling and project images from in front of the screen.
•Install vertically on a table and project from the front of the desk. (When installing vertically on a table, you need
the optional Interactive Table Mount (ELPMB29).)
•Before installing the Touch Unit, make sure that the installation surface is not warped or distorted, and that any
unevenness on the screen surface is less than 5 mm.
•When installing the Touch Unit on a whiteboard, secure the Touch Unit with magnets or screws.
•When installing the Touch Unit outside the whiteboard, you need the supplied Touch Unit Bracket.

Using the Product Safely
8
•If the distance from the wall to the surface of the screen (f) is more than 50 mm, you cannot install the Touch Unit
outside the whiteboard.
•If there is a frame around the screen, make sure that the thickness of the top of the frame (e) is less than 3 mm. If
the thickness of the top of the screen exceeds 3 mm, the Touch Unit will not operate correctly.

Contents
9
Using the Product Safely
SafetyInstructions .................... 1
Safetyindications .......................1
ExplanationofSymbols ................... 1
SafetyPrecautionsforInstallation ............ 1
NotesonhandlingtheTouchUnit ............ 4
AboutThisInstallationGuide ............... 4
ChoosinganInstallationLocation ...... 6
Projectorinstallationlocation ............... 6
TouchUnitinstallationlocation.............7
Installation Guide
InstallationWorkFlow ............... 11
Installingoneprojector ..................11
When two or more projectors are installed in
parallel .............................. 12
PackageContents .................... 13
Settingplate .......................... 13
ControlPad ........................... 14
TouchUnit ........................... 15
TouchUnitBracket .................... 15
Specifications ....................... 16
Settingplate .......................... 16
Wallplatecover ...................... 16
Wallplate .......................... 17
Verticalslideadjustmentrange ........... 17
Horizontalslideadjustmentrange ......... 18
Forward/backward slide adjustment range
.................................. 18
Positionforinstallingaccessories.........18
ControlPad/PenStand ................... 19
Control Pad (external dimensions/weight)
.................................. 19
Cableroutingholes ................... 20
PenStand(externaldimensions/weight)....20
TouchUnit ........................... 21
Touch Unit (external dimensions/weight)
.................................. 21
Touch Unit Bracket (external dimensions/
adjustmentrange/weight)..............21
Attachedlabels ...................... 22
Laserdiffusionport ...................23
ProjectionDistanceTable ............ 24
FiguresofInstallationDimensions ........... 24
WheninstallingtheTouchUnit ........... 25
When installing the Control Pad and the Pen
Stand ............................. 28
When Projected Image is Smaller than 85 Inches
.................................... 29
16:10projectedimage ................. 30
When Projected Image is 85 inches or more . . . . 31
16:10projectedimage ................. 32
InstallingtheSettingPlate ........... 33
ConnectingDevices ..................... 33
Necessarycables ..................... 33
InstallationProcedure ................... 36
Assembletheparts ...................36
Installthewallplateonthewall..........38
Determine the projection distance, and then
pass the cables through the setting plate . . . . 40
Attaching the setting plate to the wall plate
.................................. 42
Securing the projector to the setting plate
.................................. 44
AdjustingthePositionoftheProjector.......46
Stickingtheinfrareddeflectors ........... 52
ArcCorrection ....................... 54
Calibratingthepen .....................55
AttachingtheCovers .................... 59
Installing the Control Pad and the Pen
Stand ............................... 62
InstallingtheControlPad ................. 62
InstallingthePenStand .................. 63
InstallingtheTouchUnit ............. 65
When installing the Touch Unit outside the
whiteboard (using the Touch Unit Bracket) . . . . 65
InstallationProcedure .................65
AngleAdjustment .................... 71
TouchCalibration ....................85
When installing the Touch Unit on the
whiteboard (without using the Touch Unit
Bracket) .............................. 88
InstallationProcedure .................88

Contents
10
AngleAdjustment .................... 92
Appendix
Installing Multiple Projectors in
Parallel(Multi-Projection) ............ 96
Multi-Projectionsettings................. 96
SettingtheProjectorID ................96
Adjusting the Image in Multi-Projection . . . . . 99
When two projectors are installed in parallel
and you are using the interactive function . . . . 100
Settingtheprojectorsinsync ........... 100
SettingMulti-ProjectionInteractive ....... 102
BatchSetupFunction ............... 109
SetupUsingaUSBflashdrive ............. 110
SavingsettingstotheUSBflashdrive..... 110
Copying saved settings to other projectors
.................................. 112
WhenSetupFails ...................... 112
AttachingaSecurityCable ........... 114

Installation Guide
11
Installation Work Flow
Installing one projector
Follow the procedures below to mount the projector on a wall.
a
Installing the Setting Plate and the Projector (sp.33)
b
Adjusting the Position of the Projector (sp.46)
c
Calibrating the Interactive Pen (sp.55)
d
Installing the Control Pad and the Pen Stand (sp.62)
When installing the Touch Unit, finish installing the projector first, and then follow the procedures below.
The procedure differs depending on where the Touch Unit is to be installed.
When installing the Touch Unit outside the whiteboard (using the Touch Unit Bracket)
a
Installing the Touch Unit (sp.65)
b
Adjusting the Angle of Laser Diffusion (sp.71)
c
Performing Touch Calibration (sp.85)

Installation Guide
12
When installing the Touch Unit on the whiteboard (without using the Touch Unit Bracket)
a
Installing the Touch Unit (sp.88)
b
Adjusting the Angle of Laser Diffusion (sp.92)
c
Performing Touch Calibration (sp.85)
When two or more projectors are installed in parallel
When using the multi-projection function (when multiple projectors are installed in parallel to project one,
large screen), follow the steps below.
a
Installing the Setting Plate and the Projector (sp.33)
b
Adjusting the Position of the Projector (sp.46)
c
Setting the Projector ID (sp.96)
d
Adjusting the Image in Multi-Projection (sp.99)
When two projectors are installed in parallel and you want to use the interactive function, make the following
settings. Make the settings for each projector.
a
Setting Projector Synchronization (sp.100)
b
Setting Multi-Projection Interactive (sp.102)

Installation Guide
13
Package Contents
Setting plate
The following supplied items are necessary to mount the projector on a wall. Confirm that you have all items
before beginning. Depending on the area in which you purchased the product, the Setting Plate is not
supplied. In this situation, purchase the optional Setting Plate ELPMB53.
Setting plate Hexagonal axis Wall plate
Wall plate cover 3-axis adjustment unit
*The slide plate ( ) is secured dur-
ing shipping.
Template sheet
(for installing the wall plate)
End cap Masking sticker Hexagon wrench (for M4) Open-ended spanner
13 mm (for M8 and M6),
6 mm (for hexagonal axis)
Shape Name Quan-
tity
Application
M4 x 12 mm hexagon socket head cap bolt
with washer/spring washer
5Forwallplateassembly
4 For 3-axis adjustment unit/arm installation
4 For slide plate/projector installation
M6 x 20 mm hexagon shoulder head bolt
with washer/spring washer
1 For setting plate/wall plate installation
M6 x 20 mm cross recessed head shoulder
screws with plastic washers
3
•Use the bolts or screws supplied with this product to install it as directed in this guide. Do not substitute these bolts
with any other types.
•You need to use commercially available M10 x 60 mm anchors (at least 4) and one M10 screw to attach the wall plate
to the wall.
•Gather the tools and parts you need before you begin installation.

Installation Guide
14
Control Pad
The following supplied products are necessary when attaching the Control Pad. Confirm that you have all
items before beginning.
Control Pad Pen Stand
Stereo mini cable
(for connecting the Control Pad (approx. 5m))
Port protection stickers
When installing the Control Pad on a wall and so on, prepare commercially available M4 screws (20 mm x4).
When installing the Pen Stand on a wall and so on, prepare commercially available M4 screws (20 mm x2).

Installation Guide
15
Touch Unit
The following supplied products are necessary when attaching the Touch Unit. Confirm that you have all
items before beginning. When installing the Touch Unit outside the whiteboard, use the supplied Touch Unit
Bracket.
Touch Unit Touch Unit connection cable (approx. 2.8 m)
Markers x2 Infrared deflectors
(approx. 28.5 cm) x8
Spacer for screw hole x3 Label x4 Tape for securing the markers
(approx. 6 cm) x12
When installing the Touch Unit on a non-magnetic whiteboard, prepare three commercially available M4
screws.
Touch Unit Bracket
Installation plate Securing plate
M4 x 10 mm hexagon socket head
cap bolts x2
M4 x 25 mm hexagon socket head
cap bolts x2
M4 x 55 mm hexagon socket head cap
bolt x1
M4 x 70 mm hexagon socket head cap
bolt x1
For the installation plate, you also need three commercially available 4 mm diameter wood screws, or three
M4 anchor bolts.

Installation Guide
16
Specifications
Setting plate
Item Specification Remark Reference
Page
Setting plate weight Approx. 7.9 kg Setting plate, 3-axis adjustment unit, slide
plate, wall plate, wall plate covers/end
caps
Maximum load capacity 13.0 kg
Forward/backward slide ad-
justment range
0 to 320 mm Adjustment for 3-axis adjustment unit in-
stallation position: 87 mm
See the fig-
ure below
Vertical slide adjustment range ±38 mm See the fig-
ure below
Horizontal roll adjustment
range
±3° Fine adjustments possible with adjust-
ment dial
sp.46
Horizontal rotation adjustment
range
±8° Fine adjustments possible with adjust-
ment dial
sp.46
Vertical tilt adjustment range ±3° Fine adjustments possible with adjust-
ment dial
sp.46
Horizontal slide adjustment
range
±45 mm See the fig-
ure below
Wall plate cover
The following dimensions apply when attaching the wall plate cover.
[Unit: mm]
505.7
255.7 277.1
When installing the wall plate cover, you need a space of approximately 263 mm from the center of the wall
plate to the left side, and approximately 253 mm to the right side.

Installation Guide
17
Wall plate
The following figure shows two frames connected to one plate (separate when shipped).
[Unit: mm]
186.4
130.2 107.3
28.3
4545 24
24
131131 99 99
79
192.3
234.4
24
60
24
496
5.1
5.1
R10
*The offset value for the position of the center of the projected image and the center of the wall plate is 27 mm.
Cable routing holes
When routing cables to connect to the projector through a wall, use positions ( ) and ( ) in the following
figure as the cable routing holes.
Vertical slide adjustment range
[Unit: mm]

Installation Guide
18
Horizontal slide adjustment range
[Unit: mm]
Forward/backward slide adjustment range
Arm slide adjustment range
[Unit: mm]
Adjustment range for 3-axis adjustment unit installation position
[Unit: mm]
Position for installing accessories
These screw holes allow you to secure peripheral devices and accessories such as external tuners. Use
commercially available M4 screws.
[Unit: mm]

Installation Guide
19
2 x M4
30.5
49.7
60.8
35
Control Pad/Pen Stand
Control Pad (external dimensions/weight)
[Unit: mm]
140
178
34.5
30.5
60
16.6
51.5
63.350.1
10915.5
4 x M4
•Weight: approx. 262 g
•Operating temperature: 0 to +50°C (no condensation)
•Operating temperature: -20 to +60°C (no condensation)
