EPSON EMP-8150 Specifications
Model EMP-8150
Projection System RGB Liquid Crystal Shutter Projection
System
Projection Method Front / Rear / Ceiling Mount
Specification of Main Parts
LCD
Size
Driving Method
Pixel Number
Native Resolution
Aspect Ratio
Pixel Arrangement
Projection Lens
Type
F-number
Focal Length
Zoom Ratio
Lens cover
Lamp Type
Optical System
1.3 inches (x3)
Poly-Silicon TFT Active Matrix
786,432 dots
(1024x768)x3
XGA
4:3
Stripe
Manual : zoom / focus / lens shift
1.7 to 2.3
49 to 63 mm
1:1.3
It’s attached by the string
230W UHE
Dichroic Mirror Separation & Prism Combine
Method
Screen Size
(Projected Distance) 21 to 300 inch (0.9 to 14.6m)
Keystone Correction Ratio 10:0 to 5:5
Brightness 3200 ANSI
Lumens
Contrast Ratio 400:1
Brightness Uniformity 90%
Color Reproduction Full Color (1,677 Million Colors)
Sound Output 3W + 3W SRS *1
Effective Scanning Frequency Range
Pixel Clock
Horizontal
Vertical
14Mhz to 230Mhz
15KHz to 107KHz
43Hz to 120Hz
Adjustment Function
Projector / Remote Control
Tilt Angle
Keystone correction
Keystone / Brightness / Contrast/ Tint /
Sound / Input signal etc.
0 to 15 Degrees
-30 to +30 Degrees
Analog RGB I/O
Display Performance
Native
Resize
Input Signal
Signal Type
Video Signal
1024 x 768 dots
1600x1200 / 1280x1024 / 800x600 /
640x480 dots
Separate Signal
Analog (0.7Vp-p, 75Ω/ Mac0.714Vp-p, 75Ω)

Sync Signal
Audio Signal
Input Terminal
Video
Audio
Output Signal
Video Signal
Sync. signal
Output terminal
Video
Separation (positive & negative 1-5Vp-p) /
Composite (positive & negative 1-5Vp-p) /
Sync. on green (negative, 0.2-0.4Vp-p)
500m Vrms / 47kΩ
Mini D-sub 15 pin x1 (Select with manual
switch) / 5-BNC x1
Stereo Mini Jack (for Mini D-sub 15) / RCA x2
(for 5-BNC)
Analog (0.7Vp-p, 75Ω/ Mac0.714p-p, 75Ω)
Separation (positive & negative TTL) /
Composite (positive & negative TTL) / Sync-
on-green (negative, 0.2-0.4Vp-p)
Mini D-sub 15 pin x1
Digital RGB Input
Display Performance
Native
Resize
Input Signal
Video Signal
Audio Signal
Input Terminal
Video
Audio
1024 x 768 dots
1280x1024 / 800x600 / 640x480 dots
Digital
500m Vrms / 47kΩ
DVI Type D x1
(Select with manual switch / Exclusive to D-
sub 15)
Stereo mini jack
Video I/O
Input Signal
Video Standard
Video Signal
Audio Signal
Input Terminal
Video
Audio
Output Signal
Video Signal
NTSC / NTSC4.43 / PAL / M-PAL / N-PAL /
PAL60 / SECAM
Composite Video (1.0Vpp / Sync. negative,
75Ω) / S-video (Luminous 0.714Vpp,
Chrominous 0.286Vpp, 75Ω) / Component
Video (Analog Y level 0.7V 75Ω/ CrCb level+
/ -0.35V 75Ω/ sync. negative 0.3V or 3-
state+ / -0.3V on Y) / Video-RGB (0.7Vp-p,
75Ω/ MA)
500m Vrms / 47kΩ
Composite Video: RCA x1 / S-video: Mini Din
/ Composite Video: BNC x3 / Video RGB:
Mini Din-sub 15 pin
RCAx2 (for composite Video / S-video /
component Video) / Stereo mini jack (for
Video-RGB)
Analog RGB (Composite Video, S-Video,
Component Video, Video-RGB are
converted) / Separate HV(TTL)

Output Terminal
Video Mini D-sub 15 pin x1 (Common Analog RGB)
Control I/O
I/O Terminal
Mouse / Serial I/O
Mouse compatibility
Input terminal
Remote Control
Output
Stack out
Din 13 pin x1
PS/2, ADB, Serial, USB
Stereo mini jack
Din 13 pin x1
Operating Temperature 5°C to 40°C (41°F to 104°F)
Power Supply Voltage 100-120V / 200-240V AC ±10%, 50 / 60Hz
AC
Dimension
Exclude Projection Lens & Feet
Maximum Dimensions 303 (W) x 179 (H) x 389 (D) mm 305 (W) x 189 (H) x 448 (D) mm
Weight Approx. 20.0lbs / 9.1 kg
Fan Noise 42dB
Accessories Power cable (3m), Computer Cable (1.8m
x2), Audio Cable, RCA Cable, Remote
Control Unit, Macintosh adaptor set,
Communication cable set, User’s Manual, AA
Battery, Link V
EasyMP.net


Graphic
Audio
Network
Interface
LAN
PCMCIA
USB
Accessories
XGA (1024x768), Full color
SoundBlaster 16 Compatible
10 Base-T / 100 Base-TX
RJ45 x1
Type I / II / III x1
Compact Flash Card and CF Card Adapter
are mounted.
Supported Device : ATA Flash Card, ATA
HDD Card, Compact Flash, Smart Media,
MicroDrive
4 ports
Supported Device : US 101 Keyboard,
Mouse, Tablet(Support Wacom Graphire or
Wacom Favo only)
EasyMP.net Software CD-ROM x1
(Windows),
EasyMP.net owner’s manual (Japanese,
English, German, French)
