Ordering Information
PowerLite®1825
Multimedia Projector
PRODUCT SPECIFICATIONS
Product Name Product Code UPC
PowerLite 1825 V11H274020 0 10343 86734 5
Replacement lamp V13H010L40 0 10343 86282 1
Replacement air filter V13H134A08 0 10343 85123 8
Features/Benefits
• Deliver brilliant presentations, even in well-lit rooms, with 3500 lumens
• Project video wirelessly with 802.11a/b/g via Windows Vista® or included
EasyMP® software
• Monitor and control installed projectors, or make a presentation over the
LAN, with included software
• Set up in six seconds with Quick Setup’s automatic image adjustments
• Get amazing color, detail and reliability with 3-chip 3LCD technology
• Send video and audio wirelessly in MovieSending Mode
• Enjoy added positioning exibility with 1.6x zoom ratio
• Use remote-free power control on installed units with direct
power on/off
• Easily access and replace the lamp and air lter, even if the projector
is ceiling mounted
• Display most image les without a computer via CompactFlash®
or USB memory device
Epson. The world leader in projectors.
Powerful wireless
performance.
A better way to see.

PowerLite 1825
Dimensions 14.4" x 19.8" x 9.0" (W x D x H)
Weight 13.9 lb
Replacement Lamp
Dimensions 5.5" x 6.3" x 5.6" (W x D x H)
Weight 0.8 lb (approx.)
Master Carton
Dimensions 13.1" x 28.4" x 6.8" (W x D x H)
Weight 10.1 lb (approx.)
Units Per Master Carton 10
Replacement Air Filter
Dimensions 4.1" x 11.4" x 1.9" (W x D x H)
Weight 0.35 lb
Master Carton
Dimensions 11.8" x 18.9" x 4.7" (W x D x H)
Weight 4.4 lb
Units Per Master Carton 10
Packaging Specifications
Projection System
Epson 3-chip 3LCD technology
Projection Method
Front/rear/ceiling mount
LCD
Driving Method
Epson Poly-silicon TFT Active Matrix
Pixel Number
786,432 dots x 3 (1024 x 768) LCDs
Native Resolution
XGA
Aspect Ratio
4:3 (supports 16:9)
Pixel Arrangement
Cross-stripe
Projection Lens
Type
Manual focus/zoom
F-number
1.75 – 2.42
Focal Length
24 – 38.2 mm
Zoom Ratio
Optical zoom 1.0 – 1.6
Lamp
Type
210 W UHE
Life*
2500 hours (High Brightness Mode)
3000 hours (Low Brightness Mode)
Screen
Throw Ratio Range
1.46" – 2.39"
Size (projected distance)
30” – 300” (2.7' – 48.2')
Keystone Correction
Automatic: Vertical: ± 45 degrees
Manual: Vertical: ± 45 degrees
Horizontal: ± 30 degrees
Brightness (High Brightness Mode)
Up to 3500 lumens (IS0 21118 Standard)
Contrast Ratio (High Brightness, Game Mode)
Up to 500:1
Brightness Uniformity (typical)
90%
Color Reproduction
16.7 million colors
Dimensions (W x D x H)
Including Feet
13.6” x 10.1” x 3.7”
Excluding Feet
13.6” x 10.1” x 3.4”
Weight
6.9 lb/3.1 kg
Effective Scanning Frequency Range
Pixel Clock
13.5 MHz – 162 MHz
Horizontal
15 KHz – 99 KHz
Vertical
50 Hz – 120 Hz
Remote Control
Features
Source search selection, power, aspect resize, color
mode, volume, e-zoom, A/V mute, freeze, menu,
page up and down, help, auto, enter, esc and pointer
functions
Operating Angle
Right/left ± 30 degrees
Upper/lower ± 15 degrees
Operating Distance
19.7 ft (6 m)
Display Performance
Native
1024 x 768
Resize
640 x 480
800 x 600
1280 x 1024
1400 x 1050
1600 x 1200
Video I/O
Display Performance
NTSC: 560 line
PAL: 560 line
(depends on observation of the multi burst pattern)
Input Signal
NTSC/NTSC4.43/PAL/M-PAL/N-PAL/PAL60/
SECAM
SDTV: 480i, 480p; HDTV: 720p, 1080i
Interfaces
Computer/component video: Mini D-sub HD 15 pin x 2
S-video: Mini DIN x 1
Composite video RCA x 1
Audio in x 3 (RCA (L & R) x 1, mini stereo x 2)
Variable audio out: mini stereo x 1
USB connector Type B x 1 (for mouse/keyboard
control, USB display)
USB connector Type A x 1 (for USB memory device)
CompactFlash x 1 (3.3v)
LAN networking: RJ-45 x 1
Serial: RS-232c x 1
Monitor out: Mini D-sub 15 pin x 1
Other Features
Audio Output
5 W monaural
Audio Signal
500 m Vrms/47K ohm
Operating Temperature
41 ˚ to 95 ˚F (5 ˚ to 35 ˚C)
Power Supply Voltage
100 – 240 V ±10%, 50/60 Hz AC
Power Consumption
306 W, 12 W standby (network on),
2.6 W standby (network off)
Fan Noise
37 dB (High Brightness Mode
32 dB (Low Brightness Mode)
Security
Kensington®-style lock provision, anchor (metal) bar
for security lock or cable
Support — The Epson ConnectionSM
Pre-sales Support
U.S. and Canada 800-463-7766
Internet Web Site www.epson.com
Projector resources available at presentersonline.com
Service Programs
Two-year limited warranty, 90-day lamp warranty,
Epson Road Service Program and Epson PrivateLine®
dedicated toll-free support (U.S. and Canada only)
Contents
Wireless LAN module, power cable, computer cable,
projector remote control, soft carrying case, batteries,
user manual CD, EasyMP software CD, Quick Setup
Sheet, PrivateLine support card, password protection
sticker and security screw
Accessory Part Numbers
Replacement remote control 1452589
Universal projector ceiling mount ELPMBPJF
Advanced projector ceiling mount
with precision gear ELPMBPRG
High security projector ceiling mount ELPMBATA
Adjustable suspended ceiling
channel kit ELPMBP01
False ceiling plate kit ELPMBP02
Structural round ceiling plate ELPMBP03
Adjustable extension column
(pipe) 6"–9" ELPMBC01
Security ex foot kit ELPMBF01
Distribution amplier ELPDA01
Component to VGA video cable ELPKC19
S-video cable ELPSV01
Wheeled soft case ELPKS62
Soft shoulder case for projector
and laptop ELPKS61
Molded hardshell case ELPKS58
50” portable screen ELPSC06
60” portable pop-up screen ELPSC07
80” portable pop-up screen ELPSC08
Duet™ screen ELPSC80
Image presentation camera (ELPDC05)
V12H162020
Kensington security lock ELPSL01
Epson PowerLite 1825 Specifications
Specications and terms are subject to change without notice. Epson and EasyMP are registered trademarks and Epson Exceed Your Vision is a trademark of Seiko Epson Corporation. PowerLite and PrivateLine are
registered trademarks, Duet is a trademark, and Epson Connection and Epson PresentersOnline are service marks of Epson America, Inc. All other product and brand names are trademarks and/or registered trademarks
of their respective companies. Epson disclaims any and all rights in these marks. Copyright 2008 Epson America, Inc. CPD-24888R1 3/08 PDF
Epson America, Inc.
3840 Kilroy Airport Way, Long Beach, CA 90806
Epson Canada, Ltd.
3771 Victoria Park Avenue, Toronto, Ontario M1W 3Z5
www.epson.com
www.epson.ca
* Lamp life results will vary depending upon mode selected, environmental conditions and usage. Lamp brightness decreases over time.
