Epson PowerLite 76c User manual

Projection System Epson 3LCD technology
Projection Method Front/rear/ceiling mount
LCD
Driving method Epson Poly-silicon TFT Active Matrix
Pixel number 786,432 dots x 3 (1024 x 768) LCDs
Native resolution XGA
Aspect ratio 4:3 (supports 16:9)
Pixel arrangement Stripe
Projection Lens
Type Manual focus
F-number 1.6
Focal length 18.4mm — 22.12mm
Zoom ratio Optical zoom 1.0 — 1.2
Lamp
Type 170W UHE
Life 2000H (High Brightness), 3000H (Low Brightness)
Lamp life results will vary depending
upon mode selecter, environmental
condition and usage.
Screen Size (Projected Distance) 30" to 300" (2.9' to 39.7')
Keystone Correction Vertical: ±30 degrees
Brightness (Typical) 2000 ANSI lumens
Contrast Ratio Up to 400:1
Brightness Uniformity (Typical) 85%
Color Reproduction 24 bit; 16.7 mil
Audio Output 1W Monaural
Operating Temperature 41ºF to 95ºF (5ºC to 35ºC)
Power Supply Voltage 100-240 V ±10%, 50/60 Hz AC
Power Consumption 250 W, 4 W standby
Dimensions (includes lens and feet) 9.7" x 12.9" x 3.9"
Dimensions (excludes lens and feet) 9.7" x 12.9" x 3.4"
Weight 5.7 lb/2.6kg
Fan Noise 36 db, 30 db
Effective Scanning Frequency Range
Pixel clock 13.5 MHz to 162 MHz
Horizontal 15 KHz to 92 KHz
Vertical 50 Hz to 85 Hz
Remote Control
Features Source selection, power, resize, color, mode,
volume, e-zoom, a/v mute, freeze, menu,
page up and down, mouse functions, help, auto
Operating angle Right/Left ±30 degrees
Upper/Lower ±15 degrees
Operating distance 19.7 ft (6m)
RGB
Analog RGB I/O
Display performance
Native 1024 x 768
Resize 640 x 480
800 x 600
1280 x 1024
Input terminal
Video Mini D-sub 15 pin x 1
Audio RCA x 2 (White/Red)
Output terminal
Video Mini D-sub 15pin
(monitor out) x 1
Video I/O
Display performance NTSC: 560 line
PAL: 560 line
(depends on observation of the
multi burst pattern)
Input signal NTSC/NTSC4.43/PAL/M-PAL/
N-PAL/PAL60/SECAM
HDTV: 480i, 480p, 720p, 1080i
Input terminal
Video Composite video: RCA (Yellow) x 1
S-Video: Mini DIN
Component video: Mini D-sub 15pin
(in common with Analog RGB connector)
Video-RGB: Mini D-sub 15pin (in common
with Analog RGB connector)
Audio RCA (White/Red) x 2 (in common with Analog
RGB Audio terminal)
Audio signal 500m Vrms/47Kohm
Control I/O
I/O terminal USB 1.1 Connector Type B x 1
(for mouse/keyboard control)
Security Kensington®-style lock provision
Warranty
Two-year limited warranty, 90-day lamp warranty, Epson Road Service
Program and Epson PrivateLine dedicated toll-free support
(U.S. and Canada only)
Contents
Power cable, computer cable, projector remote control, batteries, soft
carrying case, CD-ROM, Quick Setup Sheet.
Product/Accessory Part Numbers
Epson PowerLite 76c projector V11H177020
Replacement lamp V13H010L34
Air filter set V13H134A08
Universal ceiling mount ELPMBUNI
Suspension adapter ELPMBAPL
False ceiling plate ELPMBFCP
Adjustable ceiling channel (ceiling plate not included or required) ELPMBACC
Security bracket/cabling
for gyro lock mounts (not compatible with ELPMBAPL) ELPMBSEC
Distribution amplifier ELPDA01
Component video cable ELPKC19
S-Video cable ELPSV01
Samsonite wheeled soft case ELPKS35-S
Samsonite soft shoulder case for projector and laptop ELPKS43
ATA molded hardshell case ELPKS54
50" portable screen ELPSC06
60" portable pop-up screen ELPSC07
80" portable pop-up screen ELPSC08
83.6" classroom style pull-down screen ELPSC09
Image Presentation Camera ELPDC05
Kensington security lock ELPSL01
Support–The Epson ConnectionSM
Pre-Sales Support U.S. and Canada 800-463-7766
Automated Technical Support 800-922-8911
Internet Web Site www.epson.com
presentersonline.com
The Epson PowerLite®76c offers brilliant XGA resolution from a light,
bright ultraportable — all at a remarkable value! With 2000 ANSI
lumens and fast, easy operation, this 5.7 lb projector always delivers
astounding performance. Thirty degree keystone correction and
flexible connectivity ensure perfect presentations virtually anywhere,
Epson exclusive and Instant Off™ feature means fast shutdown, with
no cool down necessary
Ultra bright 2000 ANSI lumens in under 6 lb
• Incredible brightness from a sleek, travel friendly projector
• Fills your home or office with larger than life images
Exceptional image quality and performance
•Epson 3LCD technology for natural color and bright,
vibrant images
• Solid state technology works without a moving color wheel
• Accurate color registration
- Rainbow free for crisp, detailed video and date images
• XGA (1024 x 768) resolution for projected images with precision
color and detail
Easy setup and operation
• Power on and off beeps let users know the projector has received
the command
• Epson exclusive Instant Off for immediate shut down capabilty.
No cool downtime required
• 4-second startup for fast, easy setup
• Source search function automatically displays the connected input
source(s) and switches instantly between various sources
• +/- 30 degrees vertical keystone correction and 1.2x optical zoom
for great positioning flexibility
• Monitor out capability to display images on a monitor and screen
simultaneously
• Password protected security feature, plus operation lock, to
protect against unauthorized users
• Full-featured remote control, including mouse emulation
functions and an electronic pointer for complete presentation
control
• Brightness control function for various settings to extend the
lamp life and provide more cost effective operation (up to 3000
hours in Low Brightness mode, up to 2000 hours in High
Brightness mode)
• Soft carrying case included
State-of-the-art video performance
• Video inputs for Composite, Component and S-video
compatibility (optional cables required)
• HDTV ready; supports 480i, 480p, 720p, and 1080i formats
Quiet and unobtrusive
• Whisper-quiet operation to eliminate excessive sound so the
presentation is the center of attention (36 db/30 db)
• Cooling fan located in front for a comfortable viewing experience
• Conveniently placed lamp and air filter access, designed for easy
changes, even when the projector is ceiling mounted (using
Epson mounts)
Outstanding Epson service and support
(two-year limited warranty)
• 90-day lamp warranty for added dependability
- Epson Road Service program provides a replacement projector,
typically within 24 hours
- Epson PrivateLineSM dedicated toll-free support line available
from 6 a.m. to 6 p.m. PST Monday - Friday
(Calls are answered live, typically in about a minute)
• International warranty in over 45 countries
SM
Epson PowerLite 76c Specifications
Epson PowerLite®76c
Bright XGA performance at a truly brilliant value
Specifications and terms are subject to change without notice. Epson is a registered trademark and Instant Off and Exceed your Vision are trademarks of Seiko Epson Corporation.
PowerLite is a registered trademark, and Epson Connection, PrivateLine and Presenters Online are service marks of Epson America, Inc. All other product and brand names are
trademarks and/or registered trademarks of their respective companies. Epson disclaims any and all rights in these marks. © Copyright 2005 Epson America, Inc. CPD-20238 15K 8/05
Epson America, Inc.
3840 Kilroy Airport Way, Long Beach, CA 90806
Epson Canada, Ltd.
3771 Victoria Park Avenue, Toronto, Ontario M1W 3Z5
Printed on Recycled Paper
Front View zoom lens
composite video RCA
high
performance,
low profile
audio in
Back View
stylish metallic
silver finish
full-featured
IR remote control
focus ring
computer/component video
