Introduction
The EPSON Expression™ 836XL is a true 800-dpi full-color
flatbed scanner with a US B (12.2 inch ×17.2 inch) or A3 size
scanning area. It has the ability to scan in color or grayscale,
making it ideal for virtually all uses, from simple drawings to
complex full-color illustrations. It achieves extremely high
quality in color by reading and saving 36 bits per pixel.
Your EPSON®scanner offers the following features:
◗Full color scanning of up to 68 billion colors or grayscale
scanning in up to 4,096 shades of gray.
◗Scanning resolution of 800 dpi. You can adjust the output
resolution to match the resolution of your output device.
◗Automatic Area Segmentation (AAS) gives you the ability
to separate text from photographs on a page so grayscale
images are clearer and text recognition is more accurate.
◗Text Enhancement Technology enhances optical
character recognition (OCR) accuracy when scanning text.

Introduction Page 12
◗Three resident interfaces: one bidirectional parallel and
two SCSI. With these interfaces, you can connect multiple
computers to the scanner at the same time.
◗Software control of all scanner functions.

Introduction Page 13
Optional Equipment
The following optional items are available to expand the
versatility of your scanner. For detailed information on using
these options, see Using Optional Equipment.
Auto Document Feeder (B81311*)
The auto document feeder allows you to scan up to 30 pages
automatically.
Transparency Unit (B81310*)
This option allows you to scan transparent materials, primarily
35 mm slides and negatives. It has a maximum reading area
of 11.4 ×16.5 inches (290 ×420 mm), which allows you to
scan transparent materials up to A3 or US B size.
SCSI System Cable (25-pin to 50-pin) (B860081)
This cable allows you to connect a SCSI device to an
Apple®Macintosh®computer or a SCSI adapter card on a
Windows®PC.
SCSI Peripheral Cable (50-pin to 50-pin) (B860091)
This cable allows you to connect two SCSI devices in a daisy
chain.

Introduction Page 14
Bidirectional Parallel Interface Board (B80818*)
This board installs in an IBM-
®compatible computer and
provides parallel connection between the scanner and
computer. Setup and installation of this board are fully
described in the manual that comes with the board. An
interface cable must be purchased separately.
How to Use This Manual
Scanner Basics describes the scanner’s lights and buttons,
and gives instructions for basic scanning and scanning of
oversized documents.
Using Optional Equipment gives instructions for installing and
using the optional transparency unit and auto document
feeder.
Maintaining and Transporting Your Scanner gives tips on
caring for your scanner and preparing it for a move.
Troubleshooting provides solutions to problems you may
encounter.

Introduction Page 15
Specifications provides technical details on your scanner and
its optional equipment.
Warnings, Cautions, and Notes
Warnings must be followed carefully to avoid bodily injury.
Cautions must be observed to avoid loss of data or damage
to your equipment.
Notes contain important information about your scanner.

Introduction Page 16
Important Safety Instructions
Read all of these instructions carefully. Follow all warnings
and instructions marked on the scanner.
◗The scanner must be placed on a sturdy, level surface.
◗Unplug the scanner before cleaning it. Clean it with a
damp cloth only. Do not spill liquid on the scanner.
◗Do not place the scanner near a radiator or heat source.
◗Do not block or cover the openings in the scanner’s
cabinet. Do not insert objects through the slots.
◗Place your scanner close enough to the computer or
workstation for the scanner cable to reach both ends.
Make sure you can easily unplug the power cord.
◗Use only the type of power source indicated on the
scanner’s label.
◗Connect all equipment to properly grounded power outlets.
Avoid using outlets on the same circuit as photocopiers or
air control systems that regularly switch on and off.
◗Do not let the power cord become damaged or frayed.

Introduction Page 17
◗If you use an extension cord with the scanner, make sure
the total ampere rating of the devices plugged into the
extension cord does not exceed the cord’s ampere rating.
Also, make sure the total ampere rating of all devices
plugged into the wall outlet does not exceed the wall
outlet’s ampere rating.
◗Do not attempt to service the scanner yourself.
Unplug the scanner, lock the carriage in place with the
transportation lock screw, and bring it to qualified service
personnel under the following conditions:
◗If the power cord or plug is damaged
◗If liquid has entered the scanner
◗If the scanner has been dropped or the cabinet
damaged
◗If the scanner does not operate normally or exhibits a
distinct change in performance.

Introduction Page 18
Where to Get Help
EPSON provides customer support through the following
services:
Electronic support services
Service Access
World Wide Web From the Internet, you can reach EPSON’s Home Page at
http://www.epson.com.
EPSON Internet FTP
Site If you have Internet FTP capability, use your Web browser (or other software for FTP downloading) to log onto ftp.epson.com with the user
name anonymous and your e-mail address as the password.
EPSON Download
Service You can call the EPSON Download Service at [phone]. Set your communications software to 8 data bits, 1 stop bit, no parity. Modem
speed can be up to 28.8 Kbps.
EPSON Forum on
CompuServe®Members of CompuServe can type GO EPSON at the menu prompt to
reach the Epson America Forum. For a free introductory CompuServe
membership, call (800 848-8199 and ask for representative #529.

Introduction Page 19
Automated telephone services
Service Access
EPSON SoundAdvice™ For pre-recorded answers to commonly asked questions about EPSON
products 24 hours a day, seven days a week, call [phone].
EPSON FaxAdvice™ Access EPSON’s technical information library by calling
[phone]. You must provide a return fax number to use this
service.
EPSON Referral
Service For the location of your nearest Authorized EPSON Reseller or Customer Care Center, call [phone].

Introduction Page 20
EPSON also provides technical support and information on
the installation, configuration, and operation of EPSON
products. Dial [phone] (U.S. and Canada) or
[phone] (U.S. only), 6 A.M. to 6 P.M., Pacific Time,
Monday through Friday.
Before you call, please have the following information ready:
◗Product name
◗Product serial number
◗Computer configuration
◗Description of the problem
You can purchase optional equipment, manuals, accessories,
and parts from EPSON Accessories at [phone] (U.S.
sales only). In Canada, please call [phone] for dealer
referral.
Note:
If you need help
using software with
an EPSON product,
see the
documentation for
that program for
technical support
information.
