Equinox Systems SuperSerial PM16-RJ/422 Installation and operating instructions

e
Hardware Manual Addendum
PN302078/A
July1996
PM16-RJ/422
(RS-422)
Port Module

2 Equinox SST PM16-RJ/422 ( RS-422) Port Module
PM16-RJ/422 Port Module
The PM16-RJ/422 (RS-422) port module is installed into a
system in the same manner as described in PN560075. Refer
to PN560075 for information on installing port modules.
Figures 1 and 2 below show the PM16-RJ/422 port module
pinouts.
Figure 2. RS-422 Port Pinouts
Figure 1. RJ/422 Port Connector Orientation

EquinoxSSTHardwareManualAddendum 3

Equinox Systems Inc.
One Equinox Way
Sunrise, Florida 33351
Tel. [phone]
FAX [phone]
BBS 954-746-0282
E-mail [email protected]
FTP site ftp.equinox.com
