ergoline Prestige 1600 Technical manual

Planning Manual Prestige 1600
Prestige 1600 – 1
Prestige 1600
The Prestige 1600 is setting new standards in tanning 
technology with its improved Hybrid Performance and Beauty
Light LED. This unique combination of UV and red light delivers
a particularly attractive and long-lasting tan with simultaneous
skin care. Another totally new feature is Personal Sunstyle.
Every customer can have their personally select their tan at the
touch of a button. All the feel-good features including really 
easy-to-use Bluetooth® Connect provide luxury at the highest
level.Intelligent Performance Technologie combines face tan-
ning units with UV-B optimized Spaghetti lamps. This ensures
maximum, standardized tanning intensity as well as producing
a tanning effect that stays with you far longer than normal.
The new Control Center offers the user and the studio operator
comfortable setting. 
Depending on studio philosophy devices can be operated as
more power efficient or optimized tanning power. Simply by
setting software through authorized service partners. All wit-
hout lamp replacement and modifications to the tanner. 
Good to know: Energy-saving mode extends the lamp’s life to
up to 1,000 hours. The Power Setting chosen ensures even
lamp control up to the maximum power level selected 
throughout each lamp’s lifespan.
Aqua / Aroma System as well as the air conditioning unit 
provide continuous freshness. The enclosed tanning tunnel 
also ensures that the specified temperature setting is reached
quickly and remains constant afterwards.
PRESTIGE 1600
HYBRID PERFORMANCE LED
Contents
Device descripition. . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Technical data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Maximum exhaust pipe lengths. . . . . . . . . . . . . . . . . 5
Equipment cooling . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Surround cooling . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Exhaust air accessories. . . . . . . . . . . . . . . . . . . . . . . 7
Electrical connections . . . . . . . . . . . . . . . . . . . . . . . . 8
Sound system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Air conditioner . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Aqua / Aroma System. . . . . . . . . . . . . . . . . . . . . . . . . 8
Control Center with NFC and Bluetooth Connect . . 8
EN 60335-2-27:2003+A1:2009

Prestige 1600 Planning Manual
2 – Prestige 1600
Prestige 1600
1. Adjustable air nozzles – Facial cooling
2. Face tanner (UV high pressure lamps +
UV low pressure lamps)
3. Shoulder tanner with sound system
4. Headphones and MP3 connection
5. Acrylic glass panel, base
6. Partition
7. UV low pressure lamps, base
8. Air nozzles body cooling, foot end
9. UV low pressure lamps, side part
10. UV low pressure lamps, canopy
11. Interior lighting (LEDs)
12. Nozzles Aqua / Aroma System
13. Air nozzles body cooling
14. Operating handle
15. Display unit
16. Control Center
17. Decorative lighting, canopy (LEDs)
18. Decorative lighting, front panel (LEDs)
19. Enclosed tanning tunnel (optional)
20. Beauty Light LED
21. Service Light 
(only with opened bed base)
Device Description

Planning Manual Prestige 1600
Prestige 1600 – 3
Prestige 1600
Technical data
Electrical data
Nominal power consumption with 
climatronic: 17800 W
Nominal voltage: 400 – 415 V 3N~
Nominal frequency: 50 Hz
Rated fusing: 3 x 35 A (time delay)
Mains supply line 
(scope of delivery): H05VV-F 5G 4 mm²
or
Nominal voltage: 230 – 240 V ~3
Nominal frequency: 50 Hz
Rated fusing: 3 x 50 A (time delay)
Mains supply line: H05VV-F 4G 10 mm²
Max. allowed network impedance: 0,095 
Performance:
Canopy:
UV low pressure lamps 18 x 160 W1)
1) Electronically controlled
Low pressure lamps SMART SUN 6 x 160 W
Low pressure lamps SMART SUN 3 x 8 W
UV low pressure lamps 3 x 520 W2)
2) Broad-band radiators
Lower part:
UV low pressure lamps 14 x 160 W1)
Low pressure lamps SMART SUN 6 x 160 W
Side part:
UV low pressure lamps 6 x 160 W1)
Low pressure lamps SMART SUN 2 x 160 W
UV high pressure lamps 1 x 520 W2)
Shoulder tanner:
UV high pressure lamps 2 x 250 W
Noise emission
Acoustic pressure level: 62,9 db (A)
Inlet and exhaust air
Temperature difference, supply/
exhaust air: 16 °C
Max. air requirement: 2900 m3/h
Opt. ambient temperature: 25 °C – 30 °C
Max. ambient temperature: 15 °C – 32 °C
Max. inlet air temperature: 32 °C
Exhaust cross section w/o exhaust
system: 588 cm2
Cabin inlet air cross section 
at 1.5 m/s: 5370 cm2
Exhaust cross section with exhaust
system: 710 cm2
Warm air return: possible

Prestige 1600 Planning Manual
4 – Prestige 1600
Prestige 1600
Dimensions
B 1521 mm
B1 953 mm
B2 205 mm
B+ 1545 mm
B– 1516 mm
L 2380 mm
L1 2200 mm
L2 1756 mm
L3 235 mm
L4 243 mm
L5 867 mm
L7 1120 mm
H 1491 mm
H1 1955 mm
H2 1106 mm
H4 450 mm
H5 56 mm
H6 1879 mm
H7 2002 mm
H8 2215 mm
H9 2360 mm
X 1277 mm
Y 712 mm
Z 2240 mm
300 mm
BK 2500 mm
TK 2300 mm

Planning Manual Prestige 1600
Prestige 1600 – 5
Prestige 1600
Maximum exhaust pipe lengths
Calculation base (without additional ventilator):
Back pressure 100 Pascal
Air pressure 100.000 Pascal
Exhaust air temperature 40 °C
Density 1,112 kg/m3
Dynamic inertia of the air 1,92E-05 Pa x s
Corrugated pipe

Roughness
(at centre)
kabsolut
Flow volume Loss coefficient 90° bend in line
(metal)
Permissible
length of
straight line
mm mm m³/h of pipe of blend pieces m
300 8 2550 0,1821)
1) zeta Value ()
0,211)
010
19
28
37
Smooth pipe

Roughness
(at centre)
kabsolut
Flow volume Loss coefficient 90° bend in line
(metal)
Permissible
length of
straight line
mm mm m³/h of pipe of blend pieces m
300 0,1 2550 0,0611) 0,211)
030
126
222
318

Prestige 1600 Planning Manual
6 – Prestige 1600
Prestige 1600
Cabin or studio air is drawn in beneath the front panel (1) of the lower part of the sunbed
and over the filter mats in the canopy (2) (inlet air) in order to cool the equipment.
The inlet air is first cleaned in a filter, then fed past the hot UV low pressure and high
pressure lamps and finally expelled as warm exhaust air via the central exhaust air
bracket (3) at the rear of the sunbed.
Surround air ventilation for the user is provided automatically. The intensity is adjusta-
ble in 9 steps. Cabin or studio air is drawn in and used for cooling.
The air is fed through several nozzles in the middle of the canopy. In the head area
there are two air nozzles that can be switched on separately.
Studio air is also supplied via the air inlet slots beneath the front panel of the sunbed
base and fed to two nozzles at feet level at the lying surface height, thus surrounding
the body with cooling air.
The user can have a pleasant cooling mist (Aqua System) sprayed from the outer noz-
zles in the body area.
The user can preselect the temperature of the air conditioner (Climatronic Plus) provid-
ed as standard equipment, and therefore adjust the temperature of the bed surface and
body air in accordance with his/her wishes.
With the Climatronic Plus with acrylic glass panels at the head and foot end, the desired
temperature is reached even more quickly and stays constant even at extreme room
temperatures due to the closed tanning tunnel.
Equipment cooling
Surround cooling

Planning Manual Prestige 1600
Prestige 1600 – 7
Prestige 1600
Connection to a central exhaust system is possible upwards, upwards right, upwards
left and to the rear.
The apertures intended for this purpose are located above the central exhaust air
bracket.
Corrugated pipe
Suitable device exhaust is possible with an exhaust pipe up to 10 metres in length (with-
out 90° bend). An auxiliary fan is required for exhaust pipes longer than 10 metres.
Smooth pipe
Suitable device exhaust is possible with an exhaust pipe up to 30 metres in length (with-
out 90° bend). An auxiliary fan is required for exhaust pipes longer than 30 metres.
Warm air recycling
Warm air recycling is a technically advanced, secure device which feeds part of the hot
cooling air back to the studio via a motor-controlled air choke. A thermostat provides
fully automatic control of the studio temperature, between 15 °C and 25 °C as required.
The exhaust air bracket and warm air recycling can also be retrofitted.
Exhaust air accessories
Item Accessory parts Article No. Notes
1 Central exhaust air bracket, 
with warm air recycling, thermostatically con-
trolled including connector piece, see Item 4
500000872 with connection possible for exhaust air pipes
(300 mm) on the top, top right, top left and to the rear
Central exhaust air bracket, 
but without warm air recycling
500000873
2 90° Pipe bend in Brilliant Silver 100001292 for inlet and exhaust air ducting to right, left or to rear,
plus tube adapter for direct connection to central
exhaust air bracket [possible with tube (300 mm)]
3 Corrugated pipe (300 mm, 6 m length,
flexible, grey) including 2 pipe clamps
34502800 –
4 Corrugated pipe connector piece (300
mm)
34502700 for connecting two corrugated pipes
5 Connector bracket for corrugated pipe (
300 mm)
34503600 connection of the corrugated pipe, e.g. to a canal
6 Exhaust air adapter in black (not shown) 34526600 for double rear wall

Prestige 1600 Planning Manual
8 – Prestige 1600
Prestige 1600
Standard equipment: Climatronic Plus for bed surface and Surround Cooling with fully integrated climate control of body cooling; with
acrylic glass panels at the head and foot ends; Cabin climate control via body cooling run-on (temperature-controlled).
Standard equipment: Aroma and atomized essences for the user.
The Control Center allows for a particular comfortable operation from the outside of the Ergoline sunbed. Your customers are offered
a new kind of convenience, for all comfort settings are done in a few seconds before the tanning session even starts. Thus your cus-
tomers may enjoy a relaxing tanning session. With the integrated Professional Setup Manager the salon owner can view all informa-
tion about the sunbed and deal with all settings. The big outside display makes operation comfortable and simple.
NFC Connect
Via NFC Connect your customers may save all comfort settings on a Customer Card – during the next session the sunbed is at once
set up according to the preferences of your customer. As operator, you can use NFC Connect to transfer the sunbed configuration to
other sunbeds. This works for all your sunbeds that are equipped with NFC Connect by Ergoline. In the Ergoline price list you may
find cards and stickers with NFC chip.
Bluetooth Connect
Using Bluetooth Connect, the customer can wirelessly transfer their favourite music from their own smartphone to the sunbed. It is
really easy to use during the tanning session using the control panel.
Electrical connections
Mains supply line included
Electr. control line none
Line for external music and channel selection none
Sound system
Description: Article No. Notes
3D-sound unit1) with shoulder tanner
1) includes Voice Guide, MP3-dock-in and SD card slot
100003160 standard equipment
Audio wiring set 50000060 with channel selection
Audio wiring set 50000061 w/o channel selection
Controls
Control Article No. Notes
MCS III plus hand-held remote control 500000456 with chip card terminal
Air conditioner
Aqua / Aroma System
Control Center with NFC and Bluetooth Connect

Planning Manual Prestige 1600
Prestige 1600 – 9
Prestige 1600
Personal Sunstyle
Each user simply selects their customised tanning experience from three tanning programme options. Regardless of whether your
customer is looking for a lightly tanned complexion or a directly visible, long-lasting tan: the Prestige 1600 with Personal Sunstyle is
always the perfect sunbed. As always, the intensity of the facial tanners can be changed at any time during the session or turned off
completely. This also makes UV-free use of the Beauty Light possible in the facial area.
INTENSIVE: 100% power of UV- and SMART SUN lamps and facial tanner
MEDIUM: 85% power of UV- and SMART SUN lamps, facial tanner level 2
SENSITIVE: 65% power of UV- and SMART SUN lamps, facial tanner level 2
18132 / 0

Prestige 1600 Planning Manual
10 – Prestige 1600
Prestige 1600
