3 of 3
300-5523-00 rev. D • 11/19
3/4" Button Hd PB Screw
Back of Shelf
Tabs
Drawer Tabs
CONGRATULATIONS! YOUR DRAWER ASSEMBLY IS COMPLETE!
© 2016 Ergotron, Inc. All rights reserved.
www.ergotron.com |
USA: 1-800-888-8458
|
Europe: +31 (0)33-45 45 600
|
China: 400-120-3051
|
STEP 2
Install the Drawer Frame
Align the Drawer Frame with the bottom of the
Zido shelf so that the holes on the frame line up
with the holes on the shelf and the tabs on the
frame extend toward the back of the shelf.
Using the Anthro driver, install the Drawer
Frame onto the shelf with six PB screws.
STEP 3
Install the Drawer Body
Slide the drawer body into place on
the drawer frame. Move the drawer
in and out a few times to set the ball
bearings.
STEP 1
Remove the Drawer from the Frame
Pull the drawer all the way out. Locate the
drawer tabs on the glides on each side of the
drawer body. Depress the drawer tabs (one goes up
and one goes down) to release the drawer from the
glides. Slide the drawer o the glides and set aside.
For local customer care phone numbers visit: http://contact.ergotron.com
For Service visit: www.ergotron.com
For Warranty visit: www.ergotron.com/warranty
For the latest User Installation Guide please visit: www.ergotron.com
