ESAB Caddy Tig 1500i User manual

GB
Valid for serial no. 803--xxx--xxxx0460 443 001 GB 080129
Tig 1500i/2200i
Caddy t
Instruction manual

-- 2 --
TOCe
Rights reserved to alter specifications without notice.
1 DIRECTIVE 3........................................................
2SAFETY 3...........................................................
3 INTRODUCTION 5...................................................
3.1 Equipment 5................................................................
3.2 Control panels 5............................................................
4 TECHNICAL DATA 5.................................................
5 INSTALLATION 6....................................................
5.1 Location 6..................................................................
5.2 Mains power supply 7........................................................
6 OPERATION 8.......................................................
6.1 Connections and control devices 8............................................
6.2 Key to symbols 8............................................................
6.3 Water connection 8..........................................................
6.4 TIG--welding 9..............................................................
6.5 MMA--svetsning 9...........................................................
6.6 Overheating protection 9.....................................................
6.7 Connection to cooling unit
(only valid for Caddyt Tig 2200i) 9.............................................
6.8 Turning on the power source 9................................................
7 MAINTENANCE 10....................................................
7.1 Inspection and cleaning 10....................................................
8 FAULT--TRACING 10..................................................
9 ORDERING SPARE PARTS 11..........................................
10 DISMANTLING AND SCRAPPING 11...................................
DIAGRAM 12............................................................
ORDERING NUMBER 18.................................................
ACCESSORIES 19.......................................................
NOTES 22......................................................

-- 3 --
bt34d1ea
1DIRECTIVE
DECLARATION OF CONFORMITY
ESAB AB, Welding Equipment, SE--695 81 Laxå, Sweden, gives its unreserved guarantee that weld-
ing power source Tig 1500i, 2200i, 2200iw from serial number 803 are constructed and tested in
compliance with the standard EN 60974--1 /--3 and EN 60974--10 (Class A) in accordance with the
requirements of directive (2006/95/EC) and (2004/108/EEC).
-- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- -- --------
Kent Eimbrodt
Global Director
Equipment and Automation
Laxå 2008--01--25
2SAFETY
Users of ESAB welding equipment have the ultimate responsibility for ensuring that anyone who
works on or near the equipment observes all the relevant safety precautions. Safety precautions
must meet the requirements that apply to this type of welding equipment. The following recommen-
dations should be observed in addition to the standard regulations that apply to the workplace.
All work must be carried out by trained personnel well--acquainted with the operation of the welding
equipment. Incorrect operation of the equipment may lead to hazardous situations which can result
in injury to the operator and damage to the equipment.
1. Anyone who uses the welding equipment must be familiar with:
Sits operation
Slocation of emergency stops
Sits function
Srelevant safety precautions
Swelding
2. The operator must ensure that:
Sno unauthorized person is stationed within the working area of the equipment when it is
started up.
Sno--one is unprotected when the arc is struck
3. The workplace must:
Sbe suitable for the purpose
Sbe free from drafts
4. Personal safety equipment
SAlways wear recommended personal safety equipment, such as safety glasses, flame--proof
clothing, safety gloves.
SDo not wear loose--fitting items, such as scarves, bracelets, rings, etc., which could become
trapped or cause burns.
5. General precautions
SMake sure the return cable is connected securely.
SWork on high voltage equipment may only be carried out by a qualified electrician.
SAppropriate fire extinquishing equipment must be clearly marked and close at hand.
SLubrication and maintenance must not be carried out on the equipment during operation.
GB

-- 4 --
bt34d1ea
WARNING
Read and understand the instruction manual before installing or operating.
Arc welding and cutting can be injurious to yourself and others. Take precausions when welding.
Ask for your employer’s safety practices which should be based on manufacturers’ hazard data.
ELECTRIC SHOCK - Can kill
SInstall and earth the welding unit in accordance with applicable standards.
SDo not touch live electrical parts or electrodes with bare skin, wet gloves or wet clothing.
SInsulate yourself from earth and the workpiece.
SEnsure your working stance is safe.
FUMES AND GASES - Can be dangerous to health
SKeep your head out of the fumes.
SUse ventilation, extraction at the arc, or both, to take fumes and gases away from your breathing zone
and the general area.
ARC RAYS - Can injure eyes and burn skin.
SProtect your eyes and body. Use the correct welding screen and filter lens and wear protective
clothing.
SProtect bystanders with suitable screens or curtains.
FIRE HAZARD
SSparks (spatter) can cause fire. Make sure therefore that there are no inflammable materials nearby.
NOISE - Excessive noise can damage hearing
SProtect your ears. Use earmuffs or other hearing protection.
SWarn bystanders of the risk.
MALFUNCTION - Call for expert assistance in the event of malfunction.
PROTECT YOURSELF AND OTHERS!
ESAB can provide you with all necessary welding protection and accessories.
WARNING!
Do not use the power source for thawing frozen pipes.
CAUTION!
Read and understand the instruction manual before
installing or operating.
CAUTION!
This product is solely intended for arc welding.
CAUTION!
Class A equipment is not intended for use in residential locations where
the electrical power is provided by the public low--voltage supply
system. There may be potential difficulties in ensuring electromagnic
compatibility of class A equipment in those locations, due to conducted
as well as radiated disturbances.
GB

-- 5 --
bt34d1ea
3 INTRODUCTION
The Tig 1500i / 2200i is a TIG welding power source, which can also be used for
MMA welding. It can be used direct current (DC).
ESAB’s accessories for the product can be found on page 19.
3.1 Equipment
Thepowersourceissuppliedwitha3mweldingcablecompletewithaTIG--torch,
3 m return cable, 3 m mains cable, instruction manual for power source and control
panel, see Ordering information on page 18.
3.2 Control panels
STA33 STA34
See the separate instruction manual for a detailed description of the control panels.
4 TECHNICAL DATA
Tig 1500i Tig 2200i/2200iw
Mains voltage 230V, ±10%, 1∼50/60 Hz 230V, ±10%, 1∼50/60 Hz
Primary current
Imax TIG
Imax MMA
13.8 A
21.3 A
24.1 A
24.9 A
Mains supply Zmax 0.35 ohm Zmax 0.30 ohm
No--load power 30 W 30 W
Setting range
TIG
MMA
3 -- 150 A
4 -- 150 A
3 -- 220 A
4 -- 170 A
Permissible load at TIG
20% duty cycle
25% duty cycle
60% duty cycle
100% duty cycle
150 A / 16.0 V
120 A / 14.8 V
110A/14.4V
220 A / 18.8 V
150 A / 16.0 V
110A/14.4V
Permissible load at MMA
30% duty cycle
60% duty cycle
100% duty cycle
150 A / 26.0 V
100 A / 24.0 V
90 A / 23.6 V
170 A / 26.8 V
130 A / 25.2 V
110A/24.4V
Power factor at maximum current
TIG
MMA
0.99
0.99
0.99
0.99
GB

-- 6 --
bt34d1ea
Tig 2200i/2200iwTig 1500i
Efficiency at maximum current
TIG
MMA
76 %
80 %
78 %
81 %
Open--circuit voltage MMA 72 V 72 V
Operating temperature -- 1 0 t o + 4 0 ˚C-- 1 0 t o + 4 0 ˚C
Transportation temperature -- 2 0 t o + 5 5 ˚C-- 2 0 t o + 5 5 ˚C
Constant sound pressure in
open--circuit <70dB(A) <70dB(A)
Dimensions, l x b x h 418 x 188 x 208 mm 418 x 188 x 208 mm
including the cooling unit -- 418 x 188 x 345 mm
Weight
cooling unit with/without cooling water
9.2 kg
--
9.4 kg
6.7 / 4.5 kg
Shielding gas
max pressure
All types intended for TIG
welding
5 bar
All types intended for TIG
welding
5 bar
Insulation class transformer H H
Enclosure class IP 23 IP 23
Application class
Duty cycle
The duty cycle refers to the time as a percentage of a ten--minute period that you can weld at a cer-
tain load without overloading.
The duty cycle is valid for 40˚C ambient temperature.
Enclosure class
The IP code indicates the enclosure class, i. e. the degree of protection against penetration by solid
objects or water. Equipment marked IP23 is designed for indoor and outdoor use.
Application class
The symbol indicates that the power source is designed for use in areas with increased
electrical hazard.
Mains supply, Zmax
Maximum permissible line on the network impedance in accordance with IEC 61000--3--11.
5 INSTALLATION
The installation must be executed by a professional.
Note!
Mains supply requirements
High power equipment may, due to the primary current drawn from the mains supply, influence the
power quality of the grid. Therefore connection restrictions or requirements regarding the
maximum permissible mains impedance or the required minimum supply capacity at the interface
point to the public grid may apply for some types of equipment (see technical data). In this case it
is the responsibility of the installer or user of the equipment to ensure, by consultation with the
distrubution network operator if necessary, that the equipment may be connected.
5.1 Location
Position the welding power source such that its cooling air inlets and outlets are not
obstructed.
GB

-- 7 --
bt34d1ea
5.2 Mains power supply
Check that the welding power source is connected to the
correct mains power supply voltage, and that it is
protected by the correct fuse size.
A protective earth connection must be made in
accordance with regulations.
Rating plate with supply connection data
Recommended fuse sizes and minimum cable area
Tig 1500i Tig 2200i/2200iw
TIG MMA TIG MMA
Mains voltage 230 V ¦10 %,
1μ
230 V ¦10 %,
1μ
230 V ¦10 %,
1μ
230 V ¦10 %,
1μ
Mains frequency 50/60 Hz 50/60 Hz 50/60 Hz 50/60 Hz
Mains cable area mm23G2.5 3G2.5 3G2.5 3G2.5
Phase current I1eff 9.1 A 11.5 A 11.5 A 13.4 A
Fuse
anti--surge
type C MCB
16 A
13 A
16 A
13 A
16 A
16 A
16 A
16 A
NOTE! The mains cable areas and fuse sizes as shown above are in accordance with Swedish
regulations. Use the welding power source in accordance with the relevant national regulations.
GB

-- 8 --
bt34d1ea
6 OPERATION
General safety regulations for the handling of the equipment can be found on
page 3. Read through before you start using the equipment!
6.1 Connections and control devices
1Connection (+) for the return cable for
TIG.
MMA: for the return cable or the welding
cable.
7Mains switch
2Connection for the remote control unit 8Mains cable
3Control panel (see separate instruction
manual)
9Connection for shiedling gas
4Connection for the TIG--torch 10 Connection BLUE, with ELP* for cooling
water from the cooling unit
5Connection for gas to the TIG--torch 11 Connection RED for cooling water to the
cooling unit.
6Connection (--) for the TIG--torch
MMA: return cable or welding cable
12 Refilling of cooling water
* ESAB Logic Pump, see under 6.3
6.2 Key to symbols
MMA TIG
6.3 Water connection
The cooling unit is equipped with a detection system ELP (ESAB Logic Pump) which
checks that the water hoses are connected. When connecting a water--cooled TIG
torchcoolingstarts.
GB

-- 9 --
bt34d1ea
6.4 TIG--welding
Before using the Arc 1500i/2200i for TIG welding it must be equipped with:
Sa TIG torch
Sa cylinder of suitable welding gas
Sa welding gas regulator (suitable gas regulator)
Stungsten electrodes
Ssuitable filler metal, if necessary
6.5 MMA--svetsning
Connection of welding and return cable
The welding power source has two terminals, one plus and one minus pole, for the con-
nection of the welding and the return cable. Connect the welding cable to the pole indi-
cated on the package of the electrode to be used.
Connect the return cable to the other terminal. Fit the earth clamp of the return cable
to the work--piece and make sure there is good contact between the work--piece and
the return cable terminal on the welding power source.
6.6 Overheating protection
The power source has two thermal overload trips which operate if the internal
temperature becomes too high. A fault code is shown in the panel. They reset
automatically when the temperature has fallen.
6.7 Connection to cooling unit
(only valid for CaddytTig 2200i)
Only those persons who have appropriate electrical
knowledge (authorized personnel) may remove the
safety plates to connect or carry out service,
maintenance or repair work on welding equipment.
See installation instructions in the instruction manual
for the cooling unit.
6.8 Turning on the power source
Turn on the mains power by turning the mains switch to the ”1” position.
Turn the unit off by turning the switch to the ”0” position.
Whether the mains power supply is interrupted or the power unit is switched off in
the normal manner, welding data will be stored and is available next time the unit is
started.
GB

-- 1 0 --
bt34d1ea
7 MAINTENANCE
Regular maintenance is important for safe, reliable operation.
Only those persons who have appropriate electrical knowledge (authorized
personnel) may remove the safety plates to connect or carry out service,
maintenance or repair work on welding equipment.
Note!
All guarantee undertakings from the supplier cease to apply if the customer himself
attempts any work in the product during the guarantee period in order to rectify any
faults.
7.1 Inspection and cleaning
Power source
Check regularly that the welding power source is not clogged with dirt.
How often and which cleaning methods apply depend on: the welding process, arc
times, placement, and the surrounding environment. It is normally sufficient to blow
down the power source with dry compressed air (reduced pressure) once a year.
Clogged or blocked air inlets and outlets otherwise result in overheating.
Welding torch
The welding torch’s wear parts should be cleaned and replaced at regular intervals in
order to achieve trouble--free welding.
8 FAULT--TRACING
Try these recommended checks and inspections before sending for an authorised
service technician.
Type of fault Corrective action
No arc. SCheck that the mains power supply switch is turned on.
SCheck that the welding current supply and return cables are
correctly connected.
SCheck that the correct current value is set.
SCheck the mains power supply.
The welding current is
interrupted during welding.
SCheck to see whether the thermal cut--outs have tripped.
SCheck the mains power supply fuses.
The thermal cut--out trips
frequently.
SMake sure that you are not exceeding the rated data for the
welding power source (i.e. that the unit is not being
overloaded).
SMake sure that the power source is clean.
Poor welding performance. SCheck that the welding current supply and return cables are
correctly connected.
SCheck that the correct current value is set.
SCheck that the correct electrodes are being used.
SCheck the gas flow.
GB

-- 1 1 --
bt34d1ea
9 ORDERING SPARE PARTS
Repair and electrical work should be performed by an authorized ESAB serviceman.
Use only ESAB original spare and wear parts.
Tig 1500i, 2200i, 2200iw is designed and tested in accordance with the international
and European standards IEC/EN 60974--1, IEC/EN 60974--3 and IEC/EN 60974--10. It is
the obligation of the service unit which has carried out the service or repair work to
make sure that the product still conforms to the said standard.
Spare parts may be ordered through your nearest ESAB dealer, see the last page of
this publication.
10 DISMANTLING AND SCRAPPING
Welding equipment primarily consists of steel, plastic and non--ferrous metals, and must
be handled according to local environmental regulations.
Coolant must also be handled according to local environmental regulations.
Do not dispose of electrical equipment together with normal waste!
In observance of European Directive 2002/96/EC on Waste Electrical and Electronic
Equipment and its implementation in accordance with national law, electrical equipment
that has reached the end of its life must be collected separately and returned to an
environmentally compatible recycling facility. As the owner of the equipment, you should
get information on approved collection systems from our local representative.
By applying this European Directive you will improve the environment and human
health!
GB

Edition 080129
Diagram
-- 1 2 --
bt34e
Tig 1500i TA34

Edition 080129
-- 1 3 --
bt34e

Edition 080129
-- 1 4 --
bt34e
Tig 1500i TA33

Edition 080129
-- 1 5 --
bt34e

Edition 080129
-- 1 6 --
bt34e
Tig 2200i TA33/TA34

Edition 080129
-- 1 7 --
bt34e

Tig 1500i, 2200i, 2200iw
Edition 080129
Ordering number
-- 1 8 --
bt34o
Ordering no. Denomination Type
0460 450 880 Welding power source CaddytTig 1500i, TA33 incl. 3 m MMA cable kit complete
and Tig torch TXH 150, 4 m
0460 450 881 Welding power source CaddytTig 2200i, TA33 incl. 3 MM cable kit complete and
Tig torch TXH 200, 4 m
0460 450 882 Welding power source CaddytTig 1500i, TA34 incl. 3 m MMA cable kit complete
and Tig torch TXH 150, 4 m
0460 450 883 Welding power source CaddytTig 2200i, TA34 incl. 3 m MMA cable kit complete
and Tig torch TXH 200, 4 m
0460 450 884 Welding power source CaddytTig 2200iw, TA33 incl. water cooler, 3 m MMA cable
kit complete and Tig torch TXH 250w, 4 m
0460 450 885 Welding power source CaddytTig 2200iw, TA34 incl. 3 m MMA cable kit complete
and Tig torch TXH 250w, 4 m
0460 447 074 Instruction manual Control panel, CaddytTA33, TA34
0459 839 025 Spare parts list Welding power source, Tig 1500i, Tig 2200i, Tig 2200iw
0459 839 028 Spare parts list Control panel, CaddytTA33
0459 839 028 Spare parts list Control panel, CaddytTA34
Instruction manuals and the spare parts list are available on the Internet at www.esab.com

R0460 443 /E080129/P24
Tig 1500i, 2200i, 2200iw
Accessories
-- 1 9 --
bt34a11a
Strap ................................... 0460 265 001
Cable holder ............................ 0460 265 002
Shoulder strap .......................... 0460 265 003
Trolley
for5--10litregasbottle .................... 0459 366 885
Trolley
for20--50litregasbottle ................... 0459 366 886
Trolley
for20--50litregasbottle .................. 0460 330 880

R0460 443 /E080129/P24
Tig 1500i, 2200i, 2200iw
-- 2 0 --
bt34a11a
Tig torch
TXH150 4m............................
TXH150 8m............................
TXH200 4m............................
TXH200 8m............................
TXH 250w 4 m ...........................
TXH 250w 8 m ...........................
0460 011 842
0460 011 882
0460 012 840
0460 012 880
0460 013 840
0460 013 880
Tig torch
TXH 150r 4 m ...........................
TXH 150r 8 m ...........................
TXH 200r 4 m ...........................
TXH 200r 8 m ...........................
TXH 250wr 4 m ..........................
TXH 250wr 8 m ..........................
0462 011 842
0462 011 882
0462 012 840
0462 012 880
0462 013 840
0462 013 880
Remote control adapter RA12 12pole ....
For analogue remote controls to CAN based
equipment.
0459 491 910
RemotecontrolunitMTA1CAN ..........
MIG/MAG: wire feed speed and voltage
MMA: current and arc force
TIG: current, pulse and background current
0459 491 880
RemotecontrolunitM110ProgCAN......
Choice of on of 10 programs
MIG/MAG: voltage deviation
TIG and MMA: current deviation
0459 491 882
RemotecontrolunitAT1CAN ............
MMA and TIG: current
0459 491 883
RemotecontrolunitAT1CFCAN .........
MMA and TIG: rough and fine setting of
current.
0459 491 884
