Escali E15CB User manual

CBSeries
Battery Powered Counting Scales
E
Es sc ca al li iTM Digital Scales
ELECTRONIC SCALE OPERATING MANUAL

SPECIFICATION
CB Series
MODEL E3CB E6CB E15CB E30CB
g 3,000 6,000 15,000 30,000
Capacity lb 6 12 30 60
g 0.5 1 2/5 5
Resolution(e) lb 0.001 0.002 0.005/0.01 0.01
Tare range 50% of Full Capacity
g 10~3,000 20~6,000 40~15,000
100~30,000
Weighing range lb 0.02~6 0.04~12 0.08~30 0.2~60
Operating Temp., Humidity -10 ~ +40, 85%
Power Requirement DC 1.5V(D size) X 6EA / DC 12V, 300mA(Adapter)
Power Consumption MAX.: 0.31W
Platform Size(mm) 337(W) × 256(L)
Product Size(mm) Non-pole type 348(W) × 382.4(L) × 153(H)
Product Weight Non-pole type 4 kg
Display Two side display: Weight (5 Digits), Quantity (8 Digits), Unit Weight (6 Digits)
Operating hours with battery Manganese battery -  500hrs , Alkaline battery -  1,000hrs (Without Back light)
Direct PLU 20 Direct PLU keys
g 15 30 75 150
Quantity Shortage Range lb 0.03 0.66 0.2 0.3
g 0.33 0.66 1.33 3.33
Unit Weight Shortage Range lb 0.001 0.002 0.003 0.007

CONTENTS
1. Introduction ---------------------------------------------------------------------
2. Installation and Details for Caution Use -------------------------------------------------
3. Name of Each Part ----------------------------------------------------------------
4. Instructions classified by Power Source -------------------------------------------------
5. Keypad and Display Information -------------------------------------------------------
6. Function ----------------------------------------------------------------------
-Procedures to set to Zero
-Procedures to set up and release the Tare
-Procedures to save a preset key (PLU key) with Unit weight
-Procedures to add up
-Procedures to set up time to automatically turn off the power
7. Error Indication and its Information ----------------------------------------------------
1. Introduction
Thank you for purchasing our Escali commercially applicable CB SERIES electronic scale. Before using this product, please read the manual carefully
in order to fully utilize the features.
z The protection provided by this equipment may be impaired if this equipment is used in a manner not specified in this manual.
z Possible modifications could be made to this product in the future for quality and functional improvement purposes.
zInstallation Category  : This instrument is supplied from the fixed installation.
zPollution degree 2 : General environment without restriction for dust and moisture.
z: Grounding, : Caution

2. Installation and Details for Caution Use
* Unless you follow the cautions properly, there may be life damage or material damage.
Correct Installation Procedures
zThis instrument is intended for indoor use only.
zInstall in areas with no influence of heat, such as direct ray of light and heater.
zInstall away from areas with either strong magnetic force or electrical noise.
zInstall on a flat and vibration-free platform.
zInstall in areas with no dusts and moistures.
zInstall in areas with no wind currents and radical thermal alterations.
zThis instrument is not suitable for use at altitude above 2000m.
Details for Caution Use – Make sure to check the power source before use.
zUse a soft cloth with appliance of alcohol when polishing the scale.
zKeep out water or any liquid-type substance from the scale.
zCheck to see if the scale is placed horizontally before use. If the scale is not in a horizontal position, use the horizontal positioning screw in order to adjust its position.
(Have the foam inside of the level gauge be in the center.)
zWhen the scale is turned on, the display will be set to initial scaling condition after indicating RB-XX.
In order to maintain its electrical safeties, warm up the machine for approximately 10 minutes before use.
zMake sure the weight display is set to " 0 g " before use. If the display is not set to " 0 g ", use after setting the display to " 0 g " by pushing the "Zero/Tare" key.
zUse only authorized adapter.
zUse same kinds of batteries when using batteries.
zRemove the battery from the scale if not using the scale for a long time. It may cause damage to the scale from the leak of zinc-air battery.
zWeighing by over maximum capacity may cause damage to the scale.
zThis scale needs periodical inspection every two years.
zNever reorganize, repair or disassemble this scale. Inquire of a manufacturer of a distributor about after service.

3. Name of Each Part
N-type
P-type
4. Instructions classified by Power Source
1. Adapter
-Connect the adapter (DC 12V, 300mA) with the power cord. Connect the jack to the adapter jack in the back side of scale body.
-Use only authorized adapter. Using a different adapter may cause a problem to the scale.
-When connecting adapter while the battery is in the scale, the battery power will be automatically turned off and adapter power will be charged even though the battery is in
the scale.
2. Battery (D-size)
- Open the battery cover. Place 6 units of batteries to polarity at the bottom of the scale. Close the cover properly.
- Exchange the battery when “BAT” is indicated in the display.
- Not available to accurately weigh during “BAT” state.
- Use same kinds of batteries when using batteries. Using different batteries may cause a problem to the scale.
3. Rechargeable battery
- Put the rechargeable battery pack into the bottom of the scale after opening the battery cover.
- Put the 2 pin connector from rechargeable battery pack into the power pack.
- Must connect adapter jack directly from the pack case or connect adapter jack to its power pack to charge.

5. Keypad & Display Information
KEY KEY NAME FUNCTION
[ ] Preset Keys (PLU
keys)
Inputs unit price or calls up the unit price.
[ 0 ]~[ 9 ], [ •] Number Keys Inputs data.
M ] Save Key Saves unit price into a preset key. (Register 20 numbers of
products.)
[ Unit Wt. ] Unit weight Key Sets up the unit weight of the scaled product
[ Q’ty ] Quantity Key Sets up the quantity of the scaled product
[ + ] Add Key Adds up the prices.
= ] Total Key Shows the total add-up price.
[ Tare ] Tare Key Sets up the tare or deletes the tare.
[ C ] Delete Key Deletes inputted data.
[ Zero ] Zero Key Sets the weight to “0g”.
[ ON/OFF ] Power Key Turns the scale on/off.
C
654 ¡Ü
23
1
0
OFF
8
M
9
7
£½
£«
ON
TARE
Uni t
Wt .
Q' t y ZERO

6. Function
■Procedures to set to Zero
zUsed in order to set the weight display to “0 g” when it is not set to “0 g” even though there is noting on the platform.
■Procedures to Set up and Release the Tare: Used when scaling liquid or grain type substances that require a container.
zCases when the container weight is not known.
1. Place the container on the platform.
2. Push the “Tare” key when the weighing is stable.
3. Check the lighting of Tare.
zCases when the container weight is known.
1. Input the container weight using the number keys.
2. Push the “Tare” key.
3. Place the container on the platform.
4. Check the lighting of Tare.
zRelease the Tare
1. Remove the container from the platform.
2. Push the “Tare” key.
3. Look at the light of Tare to check if the light is turned off.
* By setting the tare, weight display will show the scaled product weight excluding the container weight.
* Use after resetting the tare when the container weight has been changed.
Procedures to set to counting
1) procedures to count by setting up the quantity 2) procedures to count by setting up the unit weght
1.Placethecontaineronthe platform 1.Placethecontainerontheplatform
2. Input the quantity of the product using the number keys. 2. Input the unit weight of the product using the number keys.
3.Push the“ Q’ty”key 3.Pushthe“UnitWt.” Key
4. When finished, push the “C” key to set to initial scaling condition. 4. When finished, push the “C” key to set to initial scaling condition.
zIf the “Shortage Unit Wt.” LCD Is turned on, it means that the unit weight of the scaled product is within the “Unit Weight Short” range
zInaccuracy may result when measured in a condition with both “Short Q’ty” and “Short Unit Wt.” LCD turned on. Therefore, scale in a condition when both LCDs are
completely turned off.

■Procedures to save a Preset Key (PLU key) with a Unit weight value
-Use by saving the unit weight of the frequently scaled product into the preset key. (Save up to 20 PLUs.)
-Make sure the display is set to “0g” before inputting unit price.
1. Input the unit weight by using the number keys. (unit weight is “2 g”) Weighing range :40 g ~ 6/15 kg,e = d : 2 g / 5 g
(0.1 lb ~ 15/30 lb,e = d : 0.005 lb/0.01 lb)
lb
Model : CB-15N
WEI GHT
UNI T WEI GHT
QUANTI TY
BAT
Short
Uni t Wt .
TOTAL
TARE
ZERO
Shor t
Q' t y
kg
g/pc
pcs
2. Push the “M” key. Weighing range :40 g ~ 6/15 kg,e = d : 2 g / 5 g
(0.1 lb ~ 15/30 lb,e = d : 0.005 lb/0.01 lb)
lb
Model : CB-15N
WEI GHT
UNI T WEI GHT
QUANTI TY
BAT
Short
Uni t Wt .
TOTAL
TARE
ZERO
Shor t
Q' t y
kg
g/pc
pcs
3. Push the preferred preset key. Weighing range :40 g ~ 6/15 kg,e = d : 2 g / 5 g
(0.1 lb ~ 15/30 lb,e = d : 0.005 lb/0.01 lb)
lb
Model : CB-15N
WEI GHT
UNI T WEI GHT
QUANTI TY
BAT
Short
Uni t Wt .
TOTAL
TARE
ZERO
Shor t
Q' t y
kg
g/pc
pcs
* Reference: Unable to delete the inputted unit weight. therefore inputting the preset key will automatically replace the old unit weight with the new one.
■Procedures to call up the saved Unit Weight
-During use, calling up the inputted unit price will automatically display the corresponding price when a product is placed on the platform.
-Cases when unit weight “2g” is saved into the first preset key.
1. Push the preset key. Weighing range :40 g ~ 6/15 kg, e = d :2 g / 5 g
(0.1 lb ~ 15/30 lb,e = d : 0.005 lb/0.01 lb)
lb
Model : CB-15N
WEI GHT
UNI T WEI GHT
QUANTI TY
BAT
Short
Uni t Wt .
TOTAL
TARE
ZERO
Shor t
Q' t y
kg
g/pc
pcs
2. Place the product on the platform. (In cased : 200 g) Weighing range :40 g ~ 6/15 kg, e = d :2 g / 5 g
(0.1 lb ~ 15/30 lb,e = d : 0.005 lb/0.01 lb)
lb
Model : CB-15N
WEI GHT
UNI T WEI GHT
QUANTI TY
BAT
Short
Uni t Wt .
TOTAL
TARE
ZERO
Shor t
Q' t y
kg
g/pc
pcs

■Procedures to add up the Unit weight
-Although there are many products to be measured, the quantity of the scaled each objects can be added up disregarding their unit weight.
-The number of add-ups can be possible up to 99 times and the total add-up value can be possible up to 99,999.999.
[ex] Cases when adding up the unit weight of the three different products (ex: unit weight 2g, 1. product A weight with 200g,
2. product B with weight 500g, 3. product C with weight 700g)
1. Place the product A on the platform Weighing range :40 g ~ 6/15 kg, e = d : 2 g / 5 g
(0.1 lb ~ 15/30 lb, e = d :0.005 lb/0.01 lb)
lb
Model : CB-15N
WEI GHT
UNI T WEI GHT
QUANTI TY
BAT
Short
Uni t Wt .
TOTAL
TARE
ZERO
Shor t
Q' t y
kg
g/pc
pcs
2. Input the unit weight by using the number keys. (unit weight is “2 g”) Weighing range :40 g ~ 6/15 kg,e = d : 2 g / 5 g
(0.1 lb ~ 15/30 lb,e = d : 0.005 lb/0.01 lb)
lb
Model : CB-15N
WEI GHT
UNI T WEI GHT
QUANTI TY
BAT
Short
Uni t Wt .
TOTAL
TARE
ZERO
Shor t
Q' t y
kg
g/pc
pcs
3. Push the “+” key Weighing range :40 g ~ 6/15 kg, e = d : 2 g / 5 g
(0.1 lb ~ 15/30 lb,e = d : 0.005 lb/0.01 lb)
lb
Model : CB-15N
WEI GHT
UNI T WEI GHT
QUANTI TY
BAT
Short
Uni t Wt .
TOTAL
TARE
ZERO
Shor t
Q' t y
kg
g/pc
pcs
4. Remove the product A, place the product B Weighing range :40 g ~ 6/15 kg, e = d :2 g / 5 g
(0.1 lb ~ 15/30 lb,e = d :0.005 lb/0.01 lb)
lb
Model : CB-15N
WEIGHT
UNIT WEIGHT
QUANTITY
BAT
Short
Uni t Wt .
TOTAL
TARE
ZERO
Shor t
Q' t y
kg
g/pc
pcs
5. Push the “+” key Weighing range :40 g ~ 6/15 kg, e = d : 2 g / 5 g
(0.1 lb ~ 15/30 lb,e = d : 0.005 lb/0.01 lb)
lb
Model : CB-15N
WEI GHT
UNI T WEI GHT
QUANTI TY
BAT
Short
Uni t Wt .
TOTAL
TARE
ZERO
Shor t
Q' t y
kg
g/pc
pcs

6. Remove the product B, place the product C Weighing range :40 g ~ 6/15 kg, e = d : 2 g / 5 g
(0.1 lb ~ 15/30 lb,e = d :0.005 lb/0.01 lb)
lb
Model : CB-15N
WEIGHT
UNIT WEIGHT
QUANTITY
BAT
Short
Uni t Wt .
TOTAL
TARE
ZERO
Shor t
Q' t y
kg
g/pc
pcs
7. Push the “+” key Weighing range :40 g ~ 6/15 kg, e = d : 2 g / 5 g
(0.1 lb ~ 15/30 lb,e = d : 0.005 lb/0.01 lb)
lb
Model : CB-15N
WEI GHT
UNI T WEI GHT
QUANTI TY
BAT
Short
Uni t Wt .
TOTAL
TARE
ZERO
Shor t
Q' t y
kg
g/pc
pcs
8. Push the “=” key after removing the scaled product C, Weighing range :40 g ~ 6/15 kg,e = d : 2 g / 5 g
(0.1 lb ~ 15/30 lb,e = d : 0.005 lb/0.01 lb)
lb
Model : CB-15N
WEI GHT
UNI T WEI GHT
QUANTI TY
BAT
Short
Uni t Wt .
TOTAL
TARE
ZERO
Shor t
Q' t y
kg
g/pc
pcs
9. When finished, Push the “C” key twice. Weighing range :40 g ~ 6/15 kg, e = d : 2 g / 5 g
(0.1 lb ~ 15/30 lb,e = d : 0.005 lb/0.01 lb)
lb
Model : CB-15N
WEI GHT
UNI T WEI GHT
QUANTI TY
BAT
Short
Uni t Wt .
TOTAL
TARE
ZERO
Shor t
Q' t y
kg
g/pc
pcs

■Procedures to set up time to automatically turn off the power
-Push the “C” key for 5 seconds while the weight, quantity, unit weight of the scale are zero state and Tare is released as the picture No. 1. Weighing range :40 g ~ 6/15 kg, e = d : 2 g / 5 g
(0.1 lb ~ 15/30 lb, e = d :0.005 lb/0.01 lb)
lb
Model : CB-15N
WEI GHT
UNI T WEI GHT
QUANTI TY
BAT
Shor t
Uni t Wt .
TOTAL
TARE
ZERO
Shor t
Q' t y
kg
g/pc
pcs
-Set up the preferable time to turn off the power by using the “+” key or “=” key while the display is showing as picture No. 2. Weighing range : 40 g ~ 6/15 kg , e = d :2 g / 5 g
(0.1 lb ~ 15/30 lb, e = d :0.005 lb/0.01 lb)
lb
Model : CB-15N
WEI GHT
UNI T WEI GHT
QUANTI TY
BAT
Shor t
Uni t Wt .
TOTAL
TARE
ZERO
Shor t
Q' t y
kg
g/pc
pcs
-Complete the procedures to set up the time using the “M” key. Not pushing the “M” key does not save this function.
zThe scale is automatically turned off when not being used for selected time without inputting a key or changing the weight.
zUsed in order to prevent unnecessary consumption of the battery.
zSelect time to automatically turn off the power as OFF – 5min.- 10min. – 30min. – 60min. – 120min.
zRelease the time setup by setting up with ‘OFF’.
zWithout inputting a key for 5 seconds will automatically set back to the scale mode in the picture No. 2.
zThe scale is dispatched with ‘5 minutes automatic turning off the power’ mode. (The scale is automatically turned off when not being used for 5 minutes.)
7. Error Indication and its Information
Error Information Solution Error Information Solution
Err-01 Memory reading error A/S Err-02 Zero range error (Test mode) A/S
Err-03 Problems in Weighing range (Test mode) A/S Err-d0 Exceed maximum weight Check the platform, A/S
Err-d1 Below minimum weight Check the platform Err-d2 Problems in AD converter A/S
Err-d3 Tare range error: Unstable condition, Exceed
tare range, Setting up the Tare during “-
(minus)“ weighing
Check the scale Err-d4 Exceed maximum data range of AD
converter
Check to see if there is anything
on the platform, A/S
Err-d5 Below minimum data range of AD converter Check the platform, A/S Err-d6 Weighing range error A/S
Err-d7 Problems in Zero / Exceed the range A/S Err-d8 Not in a stabilized condition The scale is experiencing
vibrations or wind currents : Place
the scale in a stabilized condition
- When the scale stops operating or ON/OFF key does not operate
- Reset the battery or adapter jack. When they do not operate after resetting the battery or adapter jack, claim the after service.

Warranty Regulations
1. Warranty information and term of its validity.
The scale's breakdown under normal operating condition is guaranteed for a repair with no charge for 1 year from the date of its purchase.
2. Exception for guaranteed repair.
Data of visit Reason for visit Inspection result Inspector
Breakdown caused by following reasons are exceptions for guaranteed repair.
zWhen breakdown occurs by remodeling the scale with one's decision, without any approval from
this company or this company's acknowledged business pursuits.
zBreakdown caused by lack of user's care.
zInterior remodeling; when damage is made by a person, not affiliated with this company and this
company's sales department, trying to change the inner structure of the product.
zBreakdown and damage caused by not abiding the cautions during use.
zBreakdown or damage caused by natural disaster such as fire and flood.
zWhen the letter of warranty is not presented.
3. Other
Letter of warranty without official seal of approval is not valid.
Letter of Warranty
Serial No.
Name of company
Address
Date of delivery (yr/mo/dt)
Sales department Telephone
Address
Sales agent
