Espressione EM-1040 Installation manual

Espressio
ne EM-
1040
Start Up
Instructions

Using Drip
Coffee
Side
•Note: that you can only use one
side of this unit at a time.
•To use the drip coffee side press
the top lid (G)on the front and back
on the left side to release to top lid
and open. Fill the glass carafe (B)
with water and pour it in the left side
(E). Then you can press the lid
back down and lock the lid by
pressing front and back.
•Use a paper filter and fill with coffee
and place in the filter cone (D).
Make sure not to get any coffee
grinds in the water tank area as this
can cause a blockage in the unit.

Using Drip
Coffee
Side
•Make sure (h7) bottom switch is OFF (to the left). To turn on
the drip coffee side, you slide the switch at the top (h2) to the
right. This will start the coffee brewing process. The light (h1)
will start to blink as the coffee is being made. The water will
start to heat and brew the pot of coffee. When done, you can
leave the glass on the warmer to keep the coffee warm.

Using the
Espresso Side
•Make sure the top switch (h2) is to
the LEFT and off. Make sure h5
switch is to the LEFT.
•Pull the water tank forward and fill
with water to the max line and push
firmly back into place.
•First time using the machine you will
want to prime the unit. You may
also have to do this from time to
time if air gets into the unit and you
are not getting water /espresso to
flow.

Using the
Espresso Side
•Turn (h7) switch to the
right and the blue light will
flash slowly. Once it is
solid, place a cup under
the frother nozzle and
rotate the knob on the
right side of the unit away
from you toward d2/d3.
Once you do this you will
hear the pump come on
and water should start to
come out. You will also
get some steam but wait
until you see a steam of
water and fill ½ a cup and
then rotate the knob
forward back to pending
d1.

Using the
Espresso
Side
•Now your unit is ready to make espresso.
•Take the filter holder (O) and place one of the baskets
for 1 or 2 cups (q / r) into the handle. Then fill with
espresso grinds with the spoon (s) for 1 or 2 scoops and
use the tamper end of (t) to press down on the grinds.
•Place the filter holder onto the unit and rotate to the right
until tight. It is ok if it is pulled off center to the right to
make sure it is tight.

Using the
Espresso Side
•Now you have the option of making 1
or 2 cups. Please note that these 2
switches are programmable. They are
factory set but you can change. To
start the espresso making, simply
press and release your finger on either
switch. You will hear the pump come
on and then go off for pre-wetting and
then a few seconds the pump will
come on again and espresso will start
to flow into your cup. It will
automatically shut off when the level is
reached.
•Note that you can also raise and lower
the cup holder by pressing the 2 circles
on the drip tray to raise or press down
to lower.

Using the
Espresso
Side
•If you want to change the amount of espresso being
made, you would simply set up the holder with coffee
and put on the unit and press and HOLD the switch
(either 1 or 2 cup) over to the right. Keep holding until it
fills the cup to the level you like and then release your
finger. This is now memorized. You can change at any
time doing the same process.

Frothing Milk
•If you would like to steam milk for your
espresso drink please do the following.
•Make sure the filter holder with the
espresso is off the unit when you do this.
•Turn the switch (h5) to the right. The blue
light will flash. Once solid you can place
your milk pitcher under the frother nozzle
and rotate the knob away from you to d3.
Use a circular and up and down motion to
froth your milk. When done, rotate the
knob back to d1 pending position.
•After you are done, remove the frother
cover and clean any milk away with damp
cloth. Also good to run hot water out of
the frother so it does not dry and clog the
nozzle.

Making hot water
•If you want to make hot water. With h5 switch to the left, rotate the knob
to d3 away from you and water will flow out of the frother. Turn back to
d1 pending to stop the process.
