Esska RASB1200 User manual

>
Federzüge
Air-Schlauchfederzug RASB - Tragkraft 0,6-5 kg
Einsatzbereich
• FederzugidealfürVormontageplätze,beidenenz.B.Stabschrauberzum
Einsatzkommen
• IsolierteAufhängungmitdreh-undschwenkbaremSchraubkarabinerhaken
• formstabilesGehäusemitSicherungskette
• Traglastbereich-0,6kgbis5,0kg
• Seilauszug-1,5bis1,6m
Air-Schlauchfederzug
Art.-Nr.:952112000000
Beschreibung
Technische Daten / Gebrauchsanweisung
Sprache
.de
.de
Web: www.esska.de
Mail: [email protected]
ESSKA.deGmbH*Borstelmannsweg175*D-20537Hamburg*Tel.:+49(0)40-731036-0*Fax:+49(0)40-731036-50
ESSKA.seTeknikAB*Strandvägen2*S-67151Arvika*Tel.:[phone]*Fax:[phone]
Take load off before
adjusting.
Install into a
closed and solid xture.
This hole is used for
hanging, do not lock tightly
for wider operation direction.
The + means the turning
direction to increase capacity.
Only press the spring
1 to 3 cm to decrease capacity.
Loosen the screws and fasten
the ball in a position of rope.
Load the tool with the
closed hook.
Temperature: -10 ºC ~ 50 ºC
Prohibition of disassembly.
Don’t twist and rub the
cordage with cable during
travel.
Don’t load over its capacity.
Large angle using will
debase the wire rope’s
life.
Under 20º is better.
To increase capacity
of RASB5000, turn the
spindle clockwise using
the allen key.
Model Capacity
(kg)
Weight
(kg)
Travel
(m)
A
(mm)
B
(mm)
RASB1200 0.6~1.5 0.52 1.4 240 44
RASB2000 1.0~2.0 0.53 1.4 240 44
RASB3000 1.5~3.0 0.53 1.1 240 44
RASB5000 3.0~5.0 0.81 1.1 290 47
OPERATING MANUAL
RASB1200/RASB2000/
RASB3000/RASB5000
Read this manual before use
Loading
Travel
Only for
RASB5000
CAUTION
Prohitibion

>
Balancers
Balancer RASB / 0,6 - 5,0 kg
Application
Balanceridealforsub-assemblyworkusingbeam-powerscrewdriver
LoadRange-0.5kgupto5.0kg
CableExtension-1.5upto1.6m
Balancer
ItemNo.:952112000000
Technical Data
Instruction Manual
Languages
.de
.de
Web: www.esska.de
Mail: [email protected]
ESSKA.deGmbH*Borstelmannsweg175*D-20537Hamburg*Tel.:+49(0)40-731036-0*Fax:+49(0)40-731036-50
ESSKA.seTeknikAB*Strandvägen2*S-67151Arvika*Tel.:[phone]*Fax:[phone]
Take load off before
adjusting.
Install into a
closed and solid xture.
This hole is used for
hanging, do not lock tightly
for wider operation direction.
The + means the turning
direction to increase capacity.
Only press the spring
1 to 3 cm to decrease capacity.
Loosen the screws and fasten
the ball in a position of rope.
Load the tool with the
closed hook.
Temperature: -10 ºC ~ 50 ºC
Prohibition of disassembly.
Don’t twist and rub the
cordage with cable during
travel.
Don’t load over its capacity.
Large angle using will
debase the wire rope’s
life.
Under 20º is better.
To increase capacity
of RASB5000, turn the
spindle clockwise using
the allen key.
Model Capacity
(kg)
Weight
(kg)
Travel
(m)
A
(mm)
B
(mm)
RASB1200 0.6~1.5 0.52 1.4 240 44
RASB2000 1.0~2.0 0.53 1.4 240 44
RASB3000 1.5~3.0 0.53 1.1 240 44
RASB5000 3.0~5.0 0.81 1.1 290 47
OPERATING MANUAL
RASB1200/RASB2000/
RASB3000/RASB5000
Read this manual before use
Loading
Travel
Only for
RASB5000
CAUTION
Prohitibion
