Etac Molift Quick Raiser 205 User manual

Molift Quick Raiser 205
Contents
User manual - English - 3
Gebrauchsanweisung - Deutsch - 23
Brukermanual - Norsk - 43
Bruksanvisning - Svenska - 63
Käyttöohje - Suomi - 83
Manual utente - Italiano - 103
Manual d`utilisation - Francais - 123
Manual de usuarioo - Español - 143
Handleiding - Nederlands - 163
Brugsvejledning - Dansk - 183
BM13099 Rev. B 2021-06-09

Molift Quick Raiser 205
EN - User manual
BM13001 Rev. E 2021-06-09
User manual - English

Important
This user manual contains important safety
instructions and information regarding the use of
the lifter and accessories.
In this manual the user is the person being lifted.
The assistant is the person operating the lifter.
Warning!
This symbol indicates important
information related to safety.
Follow these instructions carefully.
Read User Manual before use!
It is important to fully understand
the content of the user manual
before attempting to use the
equipment.
Download documentation at www.etac.com to
ensure you have the latest version.
Manufacturer’s Declaration can be found in the
Molift Quick Raiser Technical Manual (TM13001)
English Manual
4
Molift QuickRaiser 205 / www.etac.com

Molift Quick Raiser 205
Molift Quick Raiser 205 is a sit-to-stand mobile
lifter intended for raising and transferring a
person from/to a chair, wheelchair or toilet with
a sling. Molift Quick Raiser 205 is intended for
users who can follow instructions, have good
stability in upper body and can support weight
on at least one leg, but needs assistance when
standing. The shape of the lifter and geometry of
the lifting movement imitates the natural pattern
of movement of a person. The lifter is made of
light-weight materials, has castors, and an electric
motor powered by a battery. The hoist is operated
by using the hand control or the control panel on
the hoist. It has electrically adjustable legs and
with a lifting capacity of 205 kg (451lbs).
It is ideal for institutional care settings but can also
be used in privates homes and nursing homes. The
lifter should only be used for transfers across short
distances, such as between a chair and a bed or
into bathroom / rest room, and is not a replace-
ment for wheelchair or similar.
About Molift Quick Raiser 205
Components:
Lifting arm
Steering
handles
Emergency
stop
Leg support
Legs
Chassis
Trolley
Battery
Lifting
column Hand
control
Wheel / Castor
(Rear with break)
Footplate
Mains cable
Mains cable holder
Assembly tools:
6mm allen key
17mm spanner
5
Molift QuickRaiser 205 / www.etac.com
ENNO DEFR ITES FI SVNLDA

Product label / GS1-128
The barcode label contain EAN number,
serial number and production date.
Warning labels and Symbols
Symbols used on the product, explained in more
detail:
Product identification
General
CE declaration
The product, and its related accessories, described in this instruction for use (IFU),
is in compliance with the regulation (EU) 2017/745 of 5. April 2017 – as a medical
device, risk class I.
The product has been tested and approved by a third party according to standards
IEC 60601-1, IEC 60601-1-2 and EN/ISO 10535:2006.
Any serious incident that occurs in relation to the device should be reported to
the manufacturer and the competent authority of the Member State in which the
user and/or patient is established.
Conditions for Use
Lift and transfer of a person will always pose a certain risk and only trained personnel are allowed to use
the equipment and accessories covered by this user manual.
Modifications and use of components made by other manufacturers.
We recommend only using Etac Molift components and spare parts. Declaration of conformity is not
valid and Etac is not responsible for warranty if any modifications are made to the product. Etac shall not
be liable for faults or accidents that can occur when using components made by other manufacturers.
Only certified personnel are allowed to open lifter or accessories to perform service
or repair. Risk of injury from rotating parts and electric shock.
The lifter shall not be operated by the person being lifted.
Warranty notice
Two-year warranty against defects in workmanship and materials of our products.
One-year warranty for batteries.
Please refer to www.etac.com for terms and conditions.
Type BF applied part Charging indicator
CE marked Double isolation symbol
Refer to user manual Manufacturer
Indoor Use only
YYYY-MM-DD
Date of manufacture
Do not dispose in
general waste Catalogue number
Emergency lowering Serial number
Service indicator Medical Device
Battery indicator
6
Molift QuickRaiser 205 / www.etac.com

Safe Working Load (SWL):
205 kg (451 lbs)
Weight of unit:
Total weight of unit: 44,5 kg/98 lbs
Chassis: 17 kg/37,5 lbs
Lifting column: 19 kg/41,9 lbs
Leg support: 3,5 kg/7,7 lbs
4-point lifting arm: 5 kg/11 lbs
Battery:
SLA 24V 2.9 Ah
LiFePO4 25.6V 2.4 Ah
Battery charger:
Input: 100-240 VAC, 50-60 Hz, max 0.35 A
Output: 29.4 VDC, 0,5 A
Battery charge time:
5 hours
Rated performance:
100 hoists at: 75 kg and 500mm
Lifting speed:
35mm/second (1,4 inches/second)
with 75kg (165 lbs) load
Protection class:
IP24 (Complete lifter).
The ocject, probe sphere of 12.5mm Ø shall
not fully penetrate. Water splashing against
the enclosure from any direction shall have
no harmful effect.
Operating forces button:
Buttons on control panel: < 5 N
Buttons on handset: < 5 N
Material:
Aluminum, Plastic, steel
Motor:
Lifting motor: 24 V DC
Leg spreading motor: 24 V DC
Turning diameter:
1144mm / 1300 mm (453/64in) / (513/16in)
Expected Lifetime:
The lifter and accessories has an expected
lifetime of 30 000 cycles or 10 years.
Applied parts:
Sling
Foot rest
Rocker arm handles
Technical Data Quick Raiser 205
922 mm
(36/in)
808 mm
(31/in)
574 mm
(22/in)
530 mm
(20/in)
1068 mm
(42/in)
1320 mm
(51/in)
1730 mm (68/in)
1140mm (44/in)
1020 mm (40/in)
657 mm (25/in)
710 mm (27/in)
273 mm (10/in)
1
2
1
2
Highest position CSP
Lowest position CSP
1160 mm
(45/in)
630 mm (24/in)
590 mm (23/in)
220 mm (8/in)
350 mm (13/in)
1080 mm (42/in)
1210 mm (47/in)
795mm (31/in)
Ø = 1144 mm
(45/in)
Ø = 1300 mm
(51/in)
922 mm
(36/in)
808 mm
(31/in)
574 mm
(22/in)
530 mm
(20/in)
1068 mm
(42/in)
1320 mm
(51/in)
1730 mm (68/in)
1140mm (44/in)
1020 mm (40/in)
657 mm (25/in)
710 mm (27/in)
273 mm (10/in)
1
2
1
2
Highest position CSP
Lowest position CSP
1160 mm
(45/in)
630 mm (24/in)
590 mm (23/in)
220 mm (8/in)
350 mm (13/in)
1080 mm (42/in)
1210 mm (47/in)
795mm (31/in)
Ø = 1144 mm
(45/in)
Ø = 1300 mm
(51/in)
Rev.
1740 mm (68/in)
745 mm (29/in)
300 mm
(11/in)
675 mm
(26/in)
915 mm
(36/in)
1165 mm
(45/in)
1030 mm (40/in)
350 mm
(13/in) 220 mm (8/in)
Measurements, QuickRaiser 205 with fixed legs:
Rev.
1740 mm (68/in)
745 mm (29/in)
300 mm
(11/in)
675 mm
(26/in)
915 mm
(36/in)
1165 mm
(45/in)
1030 mm (40/in)
350 mm (13/in) 220 mm (8/in)
Measurements, QuickRaiser 205 with fixed legs:
7
Molift QuickRaiser 205 / www.etac.com
ENNO DEFR ITES FI SVNLDA

Assembly Instructions
Before assembly
Locate assembly tools (5mm allen key, and 17mm
spanner)
1
5
34x 3x
6
4
2
1. Battery
2. Leg Support
3. Column in chassis
4. Lifting Arm
5. Mains cable
6. Hand control
Only trained personell shall assem-
ble the lifter
All screws with pre applied
threadlock should only be used
once. Spare part art.no 2920075
1 - Battery
Push in the emergency stop button before
assembly
Place the column on a horizontal surface.
Make sure the emergency stop is pushed in.
Connect wire from control panel to battery box.
Slide the batterybox in place.
Use the allen key and tighten screw clockwise.
NB! make sure to use the washer.
Make sure the battery is properly
fastened before mounting the
column in the chassis
8
Molift QuickRaiser 205 / www.etac.com

2 - Leg support
Mount the leg support bracket.
3 - Lifting column and chassis
Place the cover on to the lifting column. Twist the
cover sideways to make it stay on column. Insert
the lifting column into the chassis.
Mount the screw with washer on column. Slide
the screw down to chassis, and tighten the screw.
Turn the lifter over on the side. Insert screw and
washer in the top hole and tighten the screw.
Connect cable between column and chassis.
(NB! The cable is NOT applicable with the Molift
Quick Raiser 205 FL version)
The screws will ensure that the column
cannot be pulled upwards. Do not use
lifter unless both screws are securely
fastened.
9
Molift QuickRaiser 205 / www.etac.com
ENNO DEFR ITES FI SVNLDA

4 - Lifting Arm
Place the cover onto the lifting arm. Place lifting
arm in trolley, and insert the bolt.
Insert the bolt and tighten the screw using the
17mm spanner and an 6mm allen key.
Make sure the lifting arm is properly fastened to
the trolley on the column.
Fit the cover onto the trolley
5 - Mains cable
Connect the mains cable to the bottom of the
battery box.
Fit the cover on to the chassis. Remember to put
the tools back in place.
10
Molift QuickRaiser 205 / www.etac.com
