ETC Desire series Configuration guide

ETC®
1 of 8
GENERAL INFORMATION
ETC’s Desire Series D40 fixture puts the seven-color x7 system into
a round theatrical wash light. Highly efficient primary lenses and
careful color choices make the D40 fixture ideal for stage, studio
and anywhere strong color and high-intensity are requirements. The
Selador®x7 Color System™produces the widest range of spectrally-
balanced saturated and tinted color choices available. D40’s rugged
die-cast enclosure, noiseless fan-free operation, multiple lens options
and advanced user interface make it ideal for multiple applications.
D40 LED ARRAY OPTIONS
D40 fixtures are based on the x7 Color System that uses seven
different LED colors to achieve true, usable broad-spectrum color.
The D40 luminaire is available with any one of the following x7 color
arrays (not interchangeable) to best suit the intended application.
• D40 Vivid™– the x7 Color System array balanced for best
all-around use as a color-changing wash fixture
• D40 Lustr®+™– optimized array with six colors plus high-
intensity white LEDs to create an ideal front light wash fixture
for full range color, with an emphasis on lighter colors
and white
• D40 Ice™– uses the cool colors of the x7 System to provide
extra-high brightness color in the blue end of the spectrum
• D40 Fire™– uses the warm colors of the x7 System to provide
extra-high brightness color in the red end of the spectrum
ORDERING INFORMATION
Selador D40
MODEL DESCRIPTION
SELD40VI D40 Vivid wash fixture – for high-intensity color
mixing across the spectrum for widest color
wash use
SELD40LI D40 Lustr+ front light wash fixture – optimized
for skin tones and light tints for use as a
theatrical front light
Note: D40 luminaires ship with hanging yoke, 25° secondary lens and input lead
with connector of choice. See page 2 for connector options. C-clamps are
not included.
Other D40 Versions
SELD40FI D40 Fire special wash fixture –limited palette, high
brightness in the red (warm) end of the spectrum
SELD40II D40 Ice special wash fixture –limited palette, high
brightness in the blue (cool) end of the spectrum
Desire™Series
D40™
0 = Black (standard)
1 = White
5 = Silver or other
custom color
(Contact factory)
X = Bare end
A = Parallel blade, U-ground (Edison)
Note – all IP-20 rated fixtures ship
standard with either bare-end power lead
or Edison connector-equipped power lead.
Other power lead options are shown in
the “Power Lead Options” table.
–
V = Vivid 7-color standard wash
L = Lustr+ front light
wash variant
F = Fire variant
I = Ice variant
I = IP20 (interior)
O = IP66 (exterior)
D40 Model Prefix
Color Mix
Usage Rating
Finish Options
Connector Options
SELD40 VI 0X
D40 D60D40XT
Vivid™
Lustr®+
Fire™
Ice™
This datasheet covers D40 fixtures as shown.
See other datasheets for other versions.

2 of 8
SPECIFICATIONS
GENERAL
• 40 LED color mixing wash fixture
• ETL listed to UL1573 – the standard for stage and studio
lighting units
• IP20-rated for indoor use
• Power and DMX in/thru connections for easy setup
• User-friendly control interface with multiple modes and
fixture settings
PHYSICAL
• Rugged die-cast all-metal housing
• Easy access slots for secondary lenses and standard 7.5”
PAR accessories
• Available in black (standard), white or silver (optional) or
custom colors (contact factory)
• Hanging yoke standard. Optional yoke/floor stand available
ELECTRICAL
• 100VAC to 240VAC 50/60 Hz universal power input
• Neutrik power in and thru connections
• Up to 10 fixtures (15A max) may be linked via power thru
connector
• Requires power from a non-dim source
LED*
• 50,000 hour LED life (50,000 hours to 70% intensity)
• 40 Luxeon®Rebel LED emitters
*See additional LED notes on page three
COLOR
• Exclusive x7 Color System™seven-color LED array
• Beautifully illuminates skin tones and other objects for
natural appearance and high color rendering
• Broad-spectrum color interacts seamlessly with
conventional sources
• Exclusive optional red-shift option emulates tungsten
dimming performance
OPTICAL
• Primary field angle of 17° and beam angle of 8°
• Secondary lenses available for multiple beam spread options
• Each fixture ships with a 25° lens; additional lenses must
be ordered separately
• Refer to accessories charts for lenses available
CONTROL
• DMX512 in and thru via five-pin XLR connectors
• Multiple control options including RGB, strobe, and console-
free Master/Slave mode
• See DMX Control Table for additional information
• 15-bit virtual dimming engine provides smooth, high quality
theatrical fades and minimizes color shift during dimming
• RDM functionality for address and setting changes
THERMAL
• Ambient operating temperature of -4° to 104°F (-20° to 40°C)
• Active electronic thermal management for
droop-free operation
• Noiseless, fan-free convection cooling for acoustically
sensitive installations
• Fixture is designed for continuous operation up to 104°F
(40°C) ambient temperature and requires free flow of air
around fixture housing
ETC®
Desire™Series
D40™
ADDITIONAL ORDERING INFORMATION
Power Input Cables
Use information below to order 5’ power input leads with factory fitted connectors
MODEL DESCRIPTION
DPA-A 5’ PowerCon™to parallel blade U-ground
(Edison) connector
DPA-B 5’ PowerCon to 20A two pin and ground (stage pin)
connector
DPA-C 5’ PowerCon to grounded 20A twistlock connector
DPA-X 5’ PowerCon to bare-end power input lead
Power Thru Jumpers
Note: Power thru jumpers connect to fixture’s output (thru) connector to provide link
to successive fixtures
MODEL DESCRIPTION
DPJ-5 5’ PowerCon to PowerCon™ fixture to
fixture jumper
DPJ-10 10’ PowerCon to PowerCon fixture to
fixture jumper
Fixtures Accessories
MODEL DESCRIPTION
SELD40FSY Yoke with floor stand attachment
400BD Barn door (Use only as a flexible top hat to diminish
aperture glare. Not for beam shaping)
407CF Color Frame (use for round and oblong lenses)
400L Egg Crate Louver
400PTH3 Top Hat 3” Tube
400PTH6 Top Hat 6” Tube
400PHH Half Hat 6” Tube
400CC C-Clamp (does not ship with fixture)
400SC Safety Cable (32”)
DPSJ-25 25’ PowerCon to Edison input power cable with
inline switch

3 of 8
ADDITIONAL ORDERING INFORMATION
Secondary Lens Options
MODEL DESCRIPTION: The following lenses are cut for
D40 fixtures and create round, linear or oblong
field patterns as described below. These lenses
are not sized for use in Selador®Classic (Vivid™,
Lustr®, Paletta™, etc.) fixtures.
Narrow
Linear Field
Note: This is the same material as Selador Classic
lenses
SELL20-7.5 7.5” 20° lens (narrow linear field) Linear lenses
may be
combined
to create
desired field
size, i.e.
40° X 60°
SELL30-7.5 7.5” 30° lens (narrow linear field)
SELL40-7.5 7.5” 40° lens (narrow linear field)
SELL60-7.5 7.5” 60° lens (narrow linear field)
SELL80-7.5 7.5” 80° lens (narrow linear field)
Round Field
SELR25-7.5 7.5” 25° lens (round field)
SELR35-7.5 7.5” 35° lens (round field)
SELR45-7.5 7.5” 45° lens (round field)
SELR75-7.5 7.5” 75° lens (round field)
Oblong Field
SELO2040-7.5 7.5” 20° x 40° lens (oblong field)
SELO3070-7.5 7.5” 30° x 70° lens (oblong field)
SELO3580-7.5 7.5” 35° x 80° lens (oblong field)
Typical Lens Field Profiles
Power Consumption at Full Intensity
MODEL VOLTAGE
(V)
CURRENT
(A)
WATTS
D40 120 / 240 1 / .5 110
ETC®
Desire™Series
NOTES ABOUT LED LUMINAIRES
All LED sources experience some lessening of light output and some
color shift over time. LED output will vary with thermal conditions.
Thermal conditions can be effected by ambient temperatures
and orientation. See the D40 Ambient Temperature and Power
Budgeting Guide for more details. Based on the LED manufacturer’s
B50 L70 specification, a Selador luminaire will achieve ~70% of
its initial output after 50,000 hours of typical usage. In individual
situations, LEDs will be used for different durations and at different
levels. This can eventually lead to minor alterations in color
performance, necessitating slight adjustment to presets, cues or
programs.
CRI AND CQS RATINGS
Desire fixtures were evaluated for CRI and CQS performance using
measured output spectrum and optimized mix solutions for a best
spectral match to black body sources at 3200K and 5600K.
Fixture CRI CQS Color
Fidelity
Duv
D40 Vivid™ at 3200K 87 89 89 0.000
D40 Vivid at 5600K 90 92 92 0.000
D40 Lustr+™at 3200K 86 88 88 0.000
D40 Lustr+ at 5600K 93 92 90 0.000
D40 Studio -HD™at 3200K 89 90 91 0.000
D40 Studio HD at 5600K 92 94 94 0.000
D40 Studio Daylight™
at 5600K
71 70 69 0.001
D40 Studio Tungsten™
at 3000K
86 86 86 0.001
All D40 luminaire versions provide excellent color rendering to the
eye, particularly at higher color temperature settings such as 5600K.
In most cases the Duv is 0.000. A Duv rating of 0.000 indicates that
the color mix used is exactly on the black body line, with no green or
magenta tint.
D40™
Round OblongNarrow Linear

4 of 8
ETC®
Desire™Series
CONTROL OPTIONS
DMX Input Channel Profiles
DMX
Profile
DMX
Channels
Channel
Assignments
Notes
Direct 9 1 – Red
2 – Orange
(white if Lustr+)
3 – Amber
4 – Green
5 – Cyan
6 – Blue
7 – Indigo
8 – Intensity
9 – Strobe
Direct control of each individual
color with a separate master
intensity channel. Color
calibration of LEDs is not active
in this mode. The nine-channel
profile will produce the highest
quality color cross-fades.
HSI 5 1 – Hue (coarse)
2 – Hue (fine)
3 – Saturation
4 – Intensity
5 – Strobe
High resolution hue (two-
channels), saturation, and
intensity control. HSI mode will
produce arbitrary color cross-
fades around the color space.
HSIC 6 1 – Hue (coarse)
2 – Hue (fine)
3 – Saturation
4 – Intensity
5 – Strobe
6 – Color Point
(CCT)
High-resolution hue, saturation
and intensity control as above,
with the addition of a color
point channel to adjust the color
temperature of the fixture in both
white light and color. Color cross-
fade performance is the same
as HSI.
RGB 5
(Ch. 4
not used)
1 – Red
2 – Green
3 – Blue
4 – n/a
5 - Strobe
Effectively addresses all seven
colors via three channels of
control. RGB profile will produce
medium quality color cross-fades
Studio 3 1 – Intensity
2 – Color Point
(CCT)
3 – Tint
Controls fixture as a white light
unit. If no DMX, i.e. console
input, is present, fixture can
be adjusted for these three
parameters on the U/I at the back
of the unit.
Additional profile options
Plus 7 Seven additional color control channels are available
in RGB, HSI, HSIC, and Studio profile settings.
For example HSI with ‘Plus 7’ enabled becomes a
14-channel profile:
1 – Hue (coarse)
2 – Hue (fine)
3 – Saturation
4 – Intensity
5 – Strobe
6 – n/a
7 – Plus 7
Control on/off
8 – Red
9 – Orange
(white if Lustr+)
10 – Amber
11 – Green
12 – Cyan
13 – Blue
14 – Indigo
The desired color and intensity
is achieved by using the HSI or
RGB channels.
Placing channel seven at a value
over 51% gives the fixture a
14-channel profile.
Channels 8-14 represent the
native colors of the fixture and
allow the operator to adjust
individual color channels to fine
tune the color output.
Strobe Variable strobe control: 0% is no strobe. The fixture
output will strobe more rapidly as the strobe channel
value approaches 100%.
D40™
CONTROL OPTIONS
User settings on D40 fixtures allow multiple operational modes and
settings for either console operation via DMX protocol or stand-alone
operation. The expanded LCD display provides easy navigation to all
possible settings and options. Some of the setting options are:
• Multiple DMX choices ranging from a simple RGB
profile – which effectively controls all seven LED colors via
three channels – to nine-channel ‘direct’ color and
intensity control
• Multiple dimming curve options
• Preset colors and sequences for stand-alone (no console
required) operation
• White point selection – white light and color behavior based
on a specific color temperature white light, i.e. 3200K,
5600K, etc
• Loss of data behavior options – instant off, hold last look for
two minutes, etc
• Output modes – three output options that offer the user a
choice between maximum output and maximum consistency
See the user manual for a complete explanation of all of the control
settings and options for the D40.
Quick Setups
To assist in managing the numerous control and fixture behavior choices, five
combinations of operational settings are available to quickly get started. These
settings are specifically created for different applications and are easily accessible at
the fixture display. Each setting can then be modified as required to take advantage
of all of the possible control features.
Setting
Title Profile Description Typical Features*
General Direct Factory Default:
For general purpose
use including interior
architectural applications
•Standarddimmingcurve
•Regulatedoutputfor
color consistency
Stage HSI
Plus 7
Enabled
Theatrical lighting:
Duplicates the color and
dimming behavior of
tungsten stage lighting
fixtures.
•Incandescentdimming
curve
•Regulatedoutputfor
color consistency
•3250Kwhitepointsetting
XT Arch HSI Exterior Architectural lighting:
Provides a high degree
of color consistency in
high ambient temperature
environments.
•Standarddimmingcurve
•Protectedoutput
•3200Kwhitepointsetting
High
Impact
RGB Event lighting:
Enables quickest response,
simple RGB control and
strobe channel for maximum
effect usage
•Quickdimmingcurve
•Boostmodefor
maximum intensity
•5600Kwhitepointsetting
Studio Studio Studio Factory Default:
Enables three parameter
control of white light
(intensity, white point, and
tint) via DMX from console
or from fixture display – no
console required
•Lineardimmingcurve
•Regulatedoutputmode
for color consistency
*See user manual for complete list of features for each Quick Setup

5 of 8
PHOTOMETRICS
ETC®
Desire™Series
D40™
D40 Vivid™
Mode Degree Candela Field
Lumens
Beam
Lumens
Lumens
Per Watt
Boost - Cold 17˚115,088 2,705 1,208 26.7
Regulated 17˚96,152 2,234 996 26.5
Metric Conversions: For Meters multiply feet by .3048
For Lux multiply footcandles by 10.76
Throw Distance (d) 10’
3.0m
15’
4.6m
20’
6.1m
25’
7.6m
319’
97m
Field Diameter 3.1’
0.9m
4.6’
1.4m
6.2’
1.9m
7.7’
2.3m –
Illuminance (fc) 1,019 453 255 163 1
Illuminance (lux) 10,968 4,875 2,742 1,755 10.76
For field diameter at any distance, multiply distance by .308
For beam diameter at any distance, multiply by 0.145
8˚ 17˚
Beam Angle
Field Angle
X
Y
Iso-Illuminance Diagram
(Flat Surface Distribution)
.056 .111 .167
0
20000
40000
60000
80000
100000
120000
-15-10 -5 0510 15
Candela
Degrees
X
Y
Cosine Candela Plot
X
Y
Iso-Illuminance Diagram
(Flat Surface Distribution)
10%
50%
% illuminance
foot candle
or lux
.056 .111 .167
0
20000
40000
60000
80000
100000
120000
-15-10 -5 0510 15
Candela
Degrees
X
Y
Cosine Candela Plot
10%
50%
% illuminance
foot candle
or lux
D40 Lustr+™
Mode Degree Candela Field
Lumens
Beam
Lumens
Lumens
Per Watt
Boost - Cold 17˚144,207 3,102 1,488 30.3
Regulated 17˚129,832 2,788 1,333 29.8
Metric Conversions: For Meters multiply feet by .3048
For Lux multiply footcandles by 10.76
Throw Distance (d) 10’
3.0m
15’
4.6m
20’
6.1m
25’
7.6m
348’
106m
Field Diameter 3.0’
0.9m
4.5’
1.4m
6.0’
1.8m
7.5’
2.3m –
Illuminance (fc) 1,215 540 304 194 1
Illuminance (lux) 13,078 5,813 3,270 2,093 10.76
For field diameter at any distance, multiply distance by .301
For beam diameter at any distance, multiply by 0.145
8˚ 17˚
Beam Angle
Field Angle

6 of 8
PHOTOMETRICS
ETC®
Desire™Series
D40™
X
Y
Iso-Illuminance Diagram
(Flat Surface Distribution)
.056 .111 .167
0
10000
20000
30000
40000
50000
60000
70000
80000
90000
100000
-15-10 -5 0510 15
Candela
Degrees
X
Y
Cosine Candela Plot
10%
50%
% illuminance
foot candle
or lux
Y
Iso-Illuminance Diagram
(Flat Surface Distribution)
10%
50%
% illuminance
foot candle
or lux
.056 .167.111
0
10000
20000
30000
40000
50000
60000
70000
-15-10 -5 0510 15
Candela
Degrees
X
Y
Cosine Candela Plot
D40 Fire™
Mode Degree Candela Field
Lumens
Beam
Lumens
Lumens
Per Watt
Boost - Cold 17˚118,891 2,728 1,237 28.7
Regulated 17˚88,805 2,029 902 27.7
Metric Conversions: For Meters multiply feet by .3048
For Lux multiply footcandles by 10.76
Throw Distance (d) 10’
3.0m
15’
4.6m
20’
6.1m
25’
7.6m
308’
93m
Field Diameter 3.2’
1.0m
4.8’
1.5m
6.4’
1.9m
8.0’
2.4m –
Illuminance (fc) 949 422 237 152 1
Illuminance (lux) 10,215 4,540 2,554 1,634 10.76
For field diameter at any distance, multiply distance by .318
For beam diameter at any distance, multiply by 0.148
8˚ 17˚
Beam Angle
Field Angle
D40 Ice™
Mode Degree Candela Field
Lumens
Beam
Lumens
Lumens
Per Watt
Boost - Cold 17˚76,908 1,621 704 18.1
Regulated 17˚72,455 1,515 671 18.0
Metric Conversions: For Meters multiply feet by .3048
For Lux multiply footcandles by 10.76
Throw Distance (d) 10’
3.0m
15’
4.6m
20’
6.1m
30’
9.1m
266’
81m
Field Diameter 3.1’
.9m
4.6’
1.4m
6.2’
1.9m
9.3’
2.8m –
Illuminance (fc) 709 315 177 78.78 1
Illuminance (lux) 7,632 3,392 1,908 848 10.76
For field diameter at any distance, multiply distance by .310
For beam diameter at any distance, multiply by 0.147
Throw Distance Multiplier (TDM)
To determine the distance from the center of the beam (Origin) to a certain illuminance level at a particular
distance, multiply the desired throw distance by the TDM desired on the Iso-Illuminance diagram.
Throw Distance (TD) x Throw Distance Multiplier (TDM) = Distance from the Origin (DfO) (distance from the center
of the beam)
Example: 25 feet (TD) x 0.047 (TDM) = 1.175 feet from center of beam (DfO)
For illumination with any lamp, multiply the candlepower of a beam spread by the multiplying factor (mf) shown for that lamp.
To determine illumination in footcandles or lux at any throw distance, divide candlepower by distance squared.
8˚ 17˚
Beam Angle
Field Angle
X

7 of 8
PHYSICAL
Selador D40 Weights and Dimensions
WEIGHT* SHIPPING WEIGHT
lbs kgs lbs kgs
14 6.4 17 7.8
* Does not include mounting hardware
ETC®
Desire™Series
D40™
19.3”
490mm
14.8”
375mm
11.7”
300mm
5.7”
145mm
4.5”
115mm
6.4”
165mm
10.4”
265mm
4.2”
105mm
8.3”
210mm
13.3”
340mm
8.5”
215mm
9.2”
235mm
10.6”
270mm

8 of 8
Corporate Headquarters•3031PleasantViewRd,POBox620979,MiddletonWI535620979USA•Tel+16088314116•Fax+16088361736
London, UK•Unit26-28,VictoriaIndustrialEstate,VictoriaRoad,LondonW36UU,UK•Tel+44(0)2088961000•Fax+44(0)2088962000
Rome, IT•ViaPieveTorina,48,00156Rome,Italy•Tel+39(06)32111683•Fax+44(0)2087528486
Holzkirchen, DE•Ohmstrasse3,83607Holzkirchen,Germany•Tel+49(8024)4700-0•Fax+49(8024)4700-300
Hong Kong•Room1801,18/F,Tower1Phase1,EnterpriseSquare,9SheungYuetRoad,KowloonBay,Kowloon,HongKong•Tel+85227991220•Fax+85227999325
Web•www.etcconnect.com•Copyright©2013ETC.AllRightsReserved.Allproductinformationandspecicationssubjecttochange.7410L1001Rev.JUSA01/13
This product is protected by one or more of the following U.S. Patents: 6,016,038, 6,150,774, 6,788,011, 6,806,659, 6,683,423 and 7,023,543
ETC®
Desire™Series
D40™
