ETQ TG12L31 User manual

0
Owner’s Manual Model TG12L31
Customer support: 1-888-908-6200
www.easterntools.com

1
PREFACE
The following manual is only a guide to assist you and is not a complete or comprehensive
manual of all aspects of maintaining and repairing your generator. The equipment you have
purchased is a complex piece of machinery. We recommend that that you consult with a
dealer if you have doubts or concerns as to your experience or ability to properly maintain or
repair your equipment. You will save time and the inconvenience of having to go back to the
store if you choose to write or call us concerning missing parts, service questions, operating
advice, and/or assembly questions.
The ETQ air-cooled gasoline generators are widely used when electrical power is
scarce. Our generators provide a portable mobile solution in supplying power for field
operations during project construction.
This manual will explain how to operate and service your generator set. If you have
any questions or suggestions about this manual, please contact your local dealer or us
directly. Consumers should notice that this manual might differ slightly from the
actual product as more improvements are made to our products. Some of the
pictures in this manual may differ slightly from the actual product as well. Eastern
Tools and Equipment, Inc. reserves the right to make changes at any time without
notice and without incurring any obligation.
TABLE OF CONTENTS
Page
TECHNICAL SPECIFICATIONS AND DATA
2
EQUIPMENT DESCRIPTION & KNOWING YOUR GENERATOR
3
PACKAGE CONTENTS
4
SAFETY PRECAUTIONS
4
GROUNDING THE GENERATOR
5
STOPPING THE GENERATOR
6

2
RECEPTACLES
6
MAINTENANCE
6
TROUBLESHOOTING
9
Wiring Diagram
10
LIMITED WARRANTY
11
SPECIFICATIONS
TG12L31
Engine Type
4-stroke, Air-cooled, OHV
Displacement
98 cc, 6.01 cu in
Bore × Stroke
56×40 mm , 2.20×1.57 in
Fuel
Unleaded
Fuel Tank Capacity
5.0 L
1.32 Gal
Operation Hours
10Hrs @ 50% load
Engine Oil
SAE 10W-30 or equivalent motor oil
Engine Oil Capacity
0.35L (11.84 Ounces)
Engine Start Pattern
Manual start
Generator Type
Synchronous generator
Phase
Single
Power Factor
Cos θ = 1.0
AC Output Voltage
120V
AC Output Frequency
60Hz
AC Output Max Power
1800 ± 10% Watts
AC Output Rated
Power
1200 ± 8% Watts
Noise Level
65 dB @ 7m
Product Weight
29.0 kg63.87 lbs
Product Dimensions
46.0x36.0x42.0 cm, (18.1 x14.2 x 16.5 in)
EQUIPMENT DESCRIPTION & KNOWING YOUR GENERATOR
Please read this manual and follow the procedures covered in this manual. Become familiar
with the generators functions, applications, and limitations.
Below is a diagram of the locations of the various controls and functions of the generator
ILLUSTRATION OF CONTROLS

3
1
AC CIRCUIT BREAKER 13.5A
10
COCK ASSY.FUEL
2
GROUND TERMINAL
11
AIR CLEANER
3
120V GFCI RECEPTACLE 5-20R
12
LEVER COMP,CHOKE
4
OIL DRAIN PLUG ENGINE SWITCH
13
FRAME COMP
5
OIL INDICATOR LIGHT ASSY
14
ALTERNATOR
6
OIL FILLER CAP
15
TANK COMP,FUEL
7
TRANSPORT FIXED BLOCK
16
MUFFLER ASSY
8
BOTTOM RUBBER
17
CAP COMP,FUEL FILLER
9
RECOIL STARTER
18
FUEL SENSORASSY
WARNING: DO NOT exceed the generator’s wattage/amperage capacity. Our
products are continuously being changed and improved. Every effort has been made to
ensure that information in this manual is accurate and up to date. However, we reserve the
right to change, alter or otherwise improve the product and this manual at any time without
prior notice.
PACKAGE CONTENTS
Your generator comes with the items listed below. Please check to see that all of the
following items are included with your generator.
If you are missing components DO NOT RETURN TO STORE, please call
[phone] for customer service.
1
2
3
14
4
5
6
7
1
1
15
2
3
4
5
6
7
8
9
10
11
12
13
14
18
17
16

4
Order
No.
Name
Qty
1
Air-cooled generator set
1
2
Tool Kit:
Flat Head Screwdriver
Spark Plug Wrench
Wrench, 8×10
1
3
Owner’s manual
1
SAFETY PRECAUTIONS
In order to ensure safety for the
consumer, please carefully follow
instructions on being careful with the
generator
Operate the generator ONLY outdoors.
Never run the generator indoors as the
engine gives off poisonous carbon
monoxide, an odorless and colorless gas.
Inhaling carbon monoxide will cause
nausea, fainting or death.Also, keep the
generator at least 3 feet away from
flammable matter for adequate
ventilation.
DANGER
Always properly ground the generator.
Failing to do so can result in
electrocution, particularly if the generator
is equipped with a wheel kit.
ELECTRIC SHOCK AND SHORT
CIRCUIT
Be sure to notify the utility company
when using the generator for backup
power. Use approved transfer equipment
to isolate the generator from electric
utility. In highly conductive area such as
metal decking or steel work, use a
ground circuit fault interrupter. Never
touch the generator if the generator is
wet. Also, never touch the generator if
your hand is wet. Never operate your
generator if the weather conditions call
for any type of precipitation such as rain,
snow, or fog.
PREVENTION FROM ACCIDENTAL
BURNS
Never touch the muffler and its cover
when the engine is running. Never touch
the muffler and cover after the engine
has been used, as the muffler remains
hot for a good period of time.
REFUELING PRECAUTIONS
Gasoline and its vapors are extremely
flammable. Do not smoke near gasoline
and keep gasoline away from generator
while the generator is running. When
adding fuel, turn the generator off and let

5
it cool for at least 2 minutes before
removing the gas cap. Loosen the gas
cap slowly to relieve the pressure in the
tank.
Fill fuel tank outdoors and never overfill
the tank.
When storing gasoline or equipment with
fuel in the tank. Store the gasoline away
from appliances or equipment that have
a pilot light or other ignition sources
because it can ignite gasoline vapors
ENGINE SAFETY PRECAUTIONS
After the generator has been run, the
engine produces heat. The temperature
of the muffler and nearby areas can
reach or exceed 1600 F. Severe burns
will occur on contact with skin. Do not
modify the generator in any way. The
generator supplies the rated voltage and
rated frequency at its governed speed.
GENERATOR SAFETY
Never overload your generator as this
can damage your generator or the
electrical devices connected to it
Do not start generator with electrical
devices connected to it. Start the
generator first and after the speed of the
generator stabilizes, electrical loads can
be applied to it.
When connecting electrical loads, make
sure the devices are "OFF" first before
connecting them. Keep the same
concept when disconnecting electrical
devices; make sure all devices are in the
"OFF" position before disconnecting.
Operate the generator on level surfaces
only. Inclined surfaces reduce the
effective lubrication of the engine.
Do not expose the generator to
excessive moisture, dust, dirt, or
corrosive vapors.
GROUNDING THE GENERATOR
The National Electric Code requires that
the frame of generator and the external
electrically conductive parts of the
generator be connected to an approved
earth ground. Local codes may differ and
require other grounding specifications.
For this purpose, please use the ground
wire that attaches from the frame to the
generator unit.
Using a No. 12AWG (American Wire
Gauge) stranded copper wire to the
frame and to an earth-driven copper or
brass grounding rod provides sufficient
safety against shock. However, local
codes may differ. Contact a local
electrician to find out specifications for
grounding your generator.
Note: Grounding your generator is
highly recommended. It helps prevent
electrical shock if a ground fault
condition exists in the generator or in
faulty connected electrical devices. Also,
because the generator is rotating at high
speeds, static electricity tends to buildup
within the unit. Grounding helps
dissipate the static electricity buildup
often buildup in underground devices.
CONNECTING ELECTRICAL LOADS
AND ELECTRICAL CAPACITY
Before beginning your work, you must
verify that the rated (running) and surge
(starting) watts for the items you will
power at the same time are within the
generators operating capacity. Please
refer to the following Table 1 for wattage
/ amperage ratings.Also, to prolong the
life of your generator, sequentially add
loads and permit the generator to
stabilize before adding another load.
Never exceed the capacity of the

6
generator.
Estimate how many surge (starting)
watts you will need. Surge wattage is the
short burst of power needed to start
electric motor-driven tools or appliances
such as a circular saw or refrigerator.
STOPPING THE ENGINE
Unplug all the electrical loads from
the generator panel (Figure 1).
.
Let the engine run at no-load for
several minutes to stabilize the
internal temperatures of engine and
generator.
Turn the engine switch to the "OFF"
position (Figure 2).
Figure 2.
Turn the fuel valve to the "OFF"
position (Figure 3).
Figure 3.
RECEPTACLES
This generator is equipped with the
following Receptacles
Figure 1. 5-20R: 125 Volt, 20 Amp
Duplex Receptacle
Note: Please be sure to use electrical
cords that support the amount of
wattage being used.
The electrical cords should be able to
handle 10 Amps of current at 125 Volts.
MAINTENACE
Below is a routine maintenance
schedule
(1)These items should be serviced by a
dealer.
(2)Every 3 years
clogs. Note: Do not use a garden hose to
clean the generator. Water can enter the
fuel and intake system and cause
problems. In addition, if water and dirt
buildup on the generators internal
windings, the resistance of these
windings will decrease.
To clean the generator, use a damp cloth
to wipe the exterior surfaces.

7
Use a soft bristle brush to loosen
caked on dirt of oil.
Use a vacuum cleaner to pick up
loose dirt and debris.
Compressed air (not to exceed 25 psi)
may be used to blow away dirt.
SPARK PLUG
Remove the spark plug
Remove the carbon deposits
CLEANING THE GENERATOR
Generator maintenance consists of
keeping the unit clean and dry. Be sure
to store the unit in a clean and dry
environment, where it will not be
exposed to excessive dust, dirt, moisture
or any corrosive vapors. Cooling slots
should always be clean and free from
Check for discoloration. Standard is tan
in color.
Gap measurements
0.7~0.8 mm (.028~.031 inches)
NOTE: If spark plug needs to be
replaced, use
NGK(or Others) Brand: BPR4ES or
F6(R)TC STORAGE
The generator should be started at least
once every week. If this cannot be done
and you must store the unit more than
30 days, please follow the following
guidelines.
Close the fuel valve: drain the fuel from
the fuel tank Figure 1.
Drain the fuel from the carburetor
(Figure 2).
Figure 2.
Remove the oil filter cap and drain
plug to drain the oil
Figure 3.
Tighten the oil drain plug and fill the
engine with new oil to the filter neck
Figure 4.
Pull the starter grip carefully until
resistance is felt
Figure 5.
Store the generator in a clean area

1
TROUBLESHOOTING
IMPORTANT: If trouble persists please call our customer help line at [phone] M-F
8-5 Central Time.
Problem
Cause
Solution
Engine will not
start
Engine switch is
set to "off".
Set engine switch to "on" position.
Fuel valve is
turned to "closed".
Turn fuel valve to "open" position.
Choke is open.
Close the choke
Engine is out of
gas.
Add gas.
Engine is filled
with contaminated
or
old gas
Change the gas in the engine.
Spark plug is dirty.
Clean spark plug.
Spark plug is
broken.
Replace spark plug.
Generator is not
on level surface.
Move generator to a level surface to prevent low oil
shutdown from triggering.
Oil is low
Add or replace oil.
Engine runs but
there is no
electrical output
Circuit reset
button is off.
Wait for 2 minutes and push the circuit reset button to
the "on" position.
Bad connecting
wires/cables.
If you are using an extension cord, try a different one.
Bad electrical
device connected
to generator.
Try connecting a different device.
Generator runs,
but does not
support all
electrical
devices
Generator is
overloaded
Try connecting fewer electrical loads to the generator.
There is a short in
connected device.
Try disconnecting any faulty or short-circuited electrical
loads.
Air cleaner is dirty.
Clean or replace air cleaner.

2
WIRING DIAGRAM

3
LIMITED WARRANTY
Eastern Tools & Equipment, Inc. will repair or replace, free of charge, any part or parts of the
generator that are defective in material or workmanship or both. Transportation charges on
parts submitted for repair or replacement under this Warranty must be borne by purchaser.
This warranty is effective for the time period and subject to the conditions provided for in this
policy. For warranty service, find the nearest Authorized Service Dealer by contacting the
place of purchase or Eastern Tools & Equipment, Inc. THERE IS NO OTHER
EXPRESSED WARRANTY. IMPLIED WARRANTIES, INCLUDING THOSE OF
MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, ARE LIMITED TO
ONE YEAR FROM PURCHASE, OR TO THE EXTENT PERMITED BY LAW ANY AND ALL
IMPLIED WARRANTIES ARE EXCLUDED. LIABILITY FOR CONSEQUENTIAL DAMAGES
UNDER ANY AND ALLWARRANTIES ARE EXCLUDED TO THE EXTENT EXCLUSION IS
PERMITTED BY LAW. Some states do not allow limitations on how long an implied warranty
lasts, and some states do not allow the exclusion or limitation of incidental or consequential
damages, so the above limitation and exclusion may not apply to you. This warranty gives
you specific legal rights and you may also have other rights, which vary from state to state.
Eastern Tools & Equipment, Inc.
WARRANTY PERIOD***
ENGINES
WITHIN U.S.A AND CANADA
OUTSIDE U.S.A. AND CANADA
CONSUMER
USE
COMMERCIAL
USE
CONSUMER
USE
COMMERCIAL
USE
GASOLINE
GENERATOR
1 year
Or 600 hours
1 year
Or 600 hours
1 year
Or 600 hours
1 year
Or 600 hours
*The warranty period begins on the date of purchase by the first retail consumer or
commercial end user, and continues for the period of time stated in the table above.
“Consumer use” means personal residential household use by a retail consumer.
“Commercial use” means all other uses, including the commercial, income producing or
rental purpose. Once the engine has experienced commercial use, it shall thereafter be
considered as a commercial use engine for purpose of this warranty. Engines use in
competitive racing or commercial or rental tracks are not warranted.
***A two-year warranty applies to the emission control system on engines certified by EPA
and CARB.
IMPORTANT
“WARRANTY REGISTRATIONS IS NECESSARY TO OBTAIN LIMITED WARRANTY ON
EASTERN TOOLS & EQUIPMENT, INC., ENGINES. THE WARRANTY REGISTRATION
CARD MUST BE RETURNED WITHIN 15 DAYS OF PURCHASE FOR LIMITED
WARRANTY TO BE VALID”
About Your Product Warranty
Eastern Tools & Equipment, Inc. welcomes warranty repair and apologizes to you for being
inconvenienced. Any Authorized Service Dealer may perform warranty repairs. Most
warranty repairs are handled routinely, but sometimes warranty service may be
inappropriate. For example, warranty would not apply if an engine is damaged because of
misuse, lack of routine maintenance, shipping, handling, warehousing and improper
installation. Similarly, warranty is void if the serial number on the engine has been removed
or if the engine has been altered or modified. If a customer differs with the decision of the
Service Dealer, an investigation will be made to determine whether the warranty applies.
Ask the Service Dealer to submit all supporting facts to his Distributor or the factory for
review. If the distributor or the factory decides that the claim is justified, the customer will be
fully reimbursed for those items that are defective. To avoid misunderstanding, which

4
might occur between the customer and the dealer, listed below are some of the causes of
engine failure that the warranty does not cover.
Normal wear:
Engines and generators, like all mechanical devices, need periodic parts service and
replacement to perform well. Warranty will not cover repair when normal use has exhausted
the life of a part of an engine.
Improper maintenance:
The life of an engine or your equipment depends upon the conditions under which it
operates, and the care it receives. Some applications, such as tillers, pumps, and rotary
movers, are very often used in dusty or dirty conditions, which can cause what appears to
be premature, wear. Such wear, when caused by dirt, dust, spark pug cleaning grit, or other
abrasive material that has entered the engine because of improper maintenance is not
covered by warranty.
This warranty cover engine related defective material and/or workmanship only, and
not replacement or refund of the equipment to which the engine may be mounted. Nor
des the warranty extend to repairs required because of:
1. Problems caused by parts that are not original eastern tools & equipment, inc.,
parts.
2. Equipment controls or installations that prevent starting, cause unsatisfactory
engine performance, or shorten engine life. (Contact equipment manufacturer.)
3. Leaking carburetor, clogged fuel pipes, sticking valves, or other damage, caused
by using contaminated or stale fuel. (Use clean, fresh, lead-free gasoline.)
4. Parts which are scored or broken because an engine was operated with
insufficient or contaminated lubricating oil, or and incorrect grad of lubricating oil
(check oil level daily or after every 8 hours of operation. Refill when necessary
and change at recommended intervals.) Engine damage may occur if oil level is
not properly maintained. Read Operating & Maintenance Instructions.
5. Repair or adjustment of associated parts or assemblies such as clutches,
transmissions, remote controls, etc., which are not manufactured by Eastern
Tools & Equipment, Inc.
6. Damage or wear to parts caused by dirt, which entered the engine because of
improper air filter maintenance, re-assembly, or use of a non-original air filter
element or cartridge. Read Operating & Maintenance Instructions.
7. Parts damaged by over-speeding, or overheating caused by grass, debris, or dirt,
which plugs or clogs the cooling fins, or flywheel are, or damaged caused by
operating the engine in a confined area without sufficient ventilation.
8. Engine or equipment parts broken by excessive vibration caused by a loosen
cutter blades unbalanced blades or loose unbalanced impellers, improper
attachment of equipment to engine crankshaft, over speeding or other abuse in
operation.
9. A bent or broken crankshaft, caused by striking a solid object with the cutter blade
of a rotary lawn mower, or excessive v-belt tightness.
10. Routine tune-up or adjustment of the engine.
11. Engine or engine component failure, i.e., combustion chamber, valves, valve
seats, valve guides, or burned starter motor winding, caused by the alternated
fuels such as, liquefied petroleum, natural gas, altered gasoline’s etc.
Warranty is available only through service dealers, which have been authorized by
Eastern Tools & Equipment, Inc., please contact the place of purchase or Eastern
Tools & Equipment, Inc. for a Service Dealer near you.
CALIFORNIA & US EPA EMISSION CONTROL WARRANTY STATEMENT

5
The U.S. Environmental Protection Agency (EPA), the California Air Resources Board
(CARB) and Eastern Tools & Equipment, Inc. are pleased to explain the Federal and
California Emission Control System Warranty on your small nonroad engine. In California,
new small nonroad engines must be designed, built and equipped to meet the State’s
stringent and anti-smog standards. Eastern Tools & Equipment, Inc. must warrant the
emission control system on your small nonroad engine for the periods of time listed above
listed above provided there has been no abuse, neglect or improper maintenance of your
small nonroad engine.
Your emission control system may include parts such as the carburetor, or fuel-injection
system, the ignition system and catalytic converter. Also included may be hoses, belts,
connectors and other emission-related assemblies.
Where a warrantable condition exists, Eastern Tools & Equipment, Inc. will repair your small
nonroad engine at no cost to you including diagnosis, parts and labor.
OWNER’S WARRANTY RESPONSIBILITIES
As the small nonroad engine owner, you are responsible for the performance of the required
maintenance listed in your Owner’s Manual. Eastern Tools & Equipment, Inc. recommends
that you retain all receipts covering maintenance on your small nonroad engine, but Eastern
Tools & Equipment, Inc. cannot deny warranty solely for the lack of receipts or for your
failure to ensure the performance of all scheduled maintenance.
As the small nonroad engine owner, you should, however, be aware that Eastern Tools &
Equipment, Inc. may deny you warranty coverage if your; small nonroad or part thereof has
failed due to abuse, neglect, improper maintenance or unapproved modifications.
You are responsible for presenting your small nonroad engine to Eastern Tools & Equipment,
Inc. distribution center as soon as a problem exists. The warranty repairs should be
completed in a reasonable amount of time, not to exceed 30 days.
If you have any questions regarding your warranty rights and responsibilities or request
warranty service you should contact either the place of purchase or Eastern Tools &
Equipment, Inc., c/o Service Manager, Engine and Equipment Service Division.
IMPORTANT NOTE:
This warranty statement explains your rights and obligations under Emission Control system
Warranty (ECS Warranty), which is provided to our by Eastern Tools & Equipment, Inc.
pursuant to California law, Eastern Tools & Equipment, Inc. also provides to original
purchasers of new Eastern Tools & Equipment, Inc. engines. Eastern Tools & Equipment,
Inc. Limited Warranties for New engines & other Equipment associated with the engine
(Eastern Tools & Equipment, Inc. Products Warranty), which is enclosed with all New
Eastern Tools & Equipment, Inc. engines and products on a separate sheet. The ECS
Warranty applies only to the emission control system of your new engine. To the extent that
there is any conflict in terms between the ECS Warranty and the Eastern Tools & Equipment,
Inc., Warranty, the ECS Warranty shall apply except in any circumstances in which the
Eastern Tools & Equipment, Inc. Product Warranty may provide a longer warranty period.
Both the ECS Warranty and the Eastern Tools & Equipment, Inc. product Warranty describe
important right and obligations with respect to your new engine.
Eastern Tools & Equipment, Inc. at its location in Ontario, California can perform warranty
service or any authorized service dealer near you. At the time of requesting warranty service,
evidence must be presented of the date of sale to the original purchaser. The purchaser
shall pay any charges for transporting the product to and from the place when the inspection
and/or warranty preformed. The purchaser shall be responsible for any damage or loss
incurred in connection with the transportation of any engine or any part(s) thereof submitted
for inspection and/or warranty work.
If you have any questions regarding your warranty rights and responsibilities, you should
contact Eastern Tools & Equipment, Inc.

6
