Operating Instructions
Transponder-Coded Safety Switch With Guard Locking
CTP-AR Unicode/Multicode

Operating Instructions
Transponder-Coded Safety Switch CTP-AR
2(translation of the original operating instructions) 2123041-08-01/21
Contents
1. About this document............................................................................................. 4
1.1. Scope............................................................................................................................................4
1.2. Target group ..................................................................................................................................4
1.3. Key to symbols...............................................................................................................................4
1.4. Supplementary documents ..............................................................................................................4
2. Correct use .......................................................................................................... 5
3. Description of the safety function .......................................................................... 6
4. Exclusion of liability and warranty ......................................................................... 8
5. General safety precautions ................................................................................... 8
6. Function............................................................................................................... 9
6.1. Guard lock monitoring.....................................................................................................................9
6.2. Door position monitoring output (OD)................................................................................................9
6.3. Diagnostic monitoring output (OI) .....................................................................................................9
6.4. Guard lock monitoring output (OL)....................................................................................................9
6.5. Version CTP Extended.....................................................................................................................9
6.6. Guard locking on version CTP-L1......................................................................................................9
6.7. Guard locking on version CTP-L2....................................................................................................10
6.8. Switching states ...........................................................................................................................10
7. Manual release................................................................................................... 11
7.1. Auxiliary release and auxiliary key release.......................................................................................11
7.1.1. Actuating auxiliary release .............................................................................................11
7.1.2. Actuating auxiliary key release .......................................................................................11
7.2. Emergency release .......................................................................................................................12
7.2.1. Actuating emergency release.........................................................................................12
7.3. Escape release (optional) ..............................................................................................................12
7.3.1. Actuating escape release...............................................................................................12
7.4. Wire front release (bowden) ...........................................................................................................13
7.4.1. Laying wire front release................................................................................................13
8. Changing the approach direction ........................................................................ 14
9. Mounting............................................................................................................ 15
10. Electrical connection .......................................................................................... 16
10.1. Notes about .........................................................................................................................17
10.2. Safety in case of faults..................................................................................................................17
10.3. Fuse protection for power supply...................................................................................................17
10.4. Requirements for connecting cables...............................................................................................18

3
2123041-08-01/21 (translation of the original operating instructions)
Operating Instructions
Transponder-Coded Safety Switch CTP-AR
EN
10.5. Maximum cable lengths.................................................................................................................19
10.5.1. Determining cable lengths using the example table..........................................................20
10.6. Connector assignment of safety switch CTP-…-AR-…-SAB-… with plug connectors 2 x M12 ...............21
10.7. Connector assignment of safety switch CTP-…-AR-…-SH-… with plug connector M23 (RC18) .............21
10.8. Connector assignment of Y-distributor............................................................................................22
10.9. Connection of a single CTP-AR .......................................................................................................23
10.10. Connection of several CTP-AR in a switch chain ................................................................................. 24
10.11. Information on operation on an AR evaluation unit ...........................................................................26
10.12. Notes on operation with safe control systems.................................................................................26
10.13. Connection of guard locking control ...............................................................................................28
10.13.1. Guard locking control for variants with IMM connection ....................................................28
10.13.2. Guard locking control for variants without IMM connection................................................28
11. Setup ................................................................................................................. 29
11.1. LED displays ................................................................................................................................29
11.2. Teach-in function for actuator (only for unicode evaluation) ...............................................................29
11.2.1. Actuator teach-in...........................................................................................................30
11.2.2. Teach-in function with series connection, replacing and teaching in device .........................30
11.3. Functional check...........................................................................................................................31
11.3.1. Mechanical function test ................................................................................................31
11.3.2. Electrical function test...................................................................................................31
12. System status table ............................................................................................ 32
13. Technical data .................................................................................................... 34
13.1. Technical data for safety switch CTP-AR..........................................................................................34
13.1.1. Typical system times.....................................................................................................35
13.2. Radio frequency approvals.............................................................................................................36
13.3. Dimension drawing for safety switch CTP… ....................................................................................37
13.4. Technical data for actuator CTP-... .................................................................................................39
13.4.1. Dimension drawing for actuator CTP-..............................................................................39
14. Ordering information and accessories................................................................. 42
15. Inspection and service ........................................................................................ 42
16. Service .............................................................................................................. 42
17. Declaration of conformity ................................................................................... 43

Operating Instructions
Transponder-Coded Safety Switch CTP-AR
4(translation of the original operating instructions) 2123041-08-01/21
1. About this document
1.1. Scope
These operating instructions are valid for all CTP-L.-AR… from version V1.0.0. These operating instructions, the document
Safety information and any enclosed data sheet form the complete user information for your device.
1.2. Target group
Design engineers and installation planners for safety devices on machines, as well as setup and servicing staff possessing
special expertise in handling safety components.
1.3. Key to symbols
Symbol/depiction Meaning
Printed document
Internet
www Document is available for download at www.euchner.com
DANGER
WARNING
CAUTION
Safety precautions
Danger of death or severe injuries
Warning about possible injuries
Caution slight injuries possible
NOTICE
Important!
Notice about possible device damage
Important information
Tip Useful information
1.4. Supplementary documents
The overall documentation for this device consists of the following documents:
Document title
(document number) Contents
Safety information
(2525460) Basic safety information
Operating instructions
(2123041) (this document)
Internet
www
Possibly enclosed data
sheet Item-specic information about deviations or additions
Important!
Always read all documents to gain a complete overview of safe installation, setup and use of the
device. The documents can be downloaded from www.euchner.com. For this purpose enter the doc.
no. in the search box.

5
2123041-08-01/21 (translation of the original operating instructions)
Operating Instructions
Transponder-Coded Safety Switch CTP-AR
EN
2. Correct use
Safety switches series CTP-L.-… are interlocking devices with guard locking solenoid (type4). Devices with unicode evaluation
possess a high coding level, devices with multicode evaluation possess a low coding level.
In combination with a movable guard and the machine control, this safety component prevents the guard from being opened
while a dangerous machine function is being performed.
This means:
ÌStarting commands that cause a dangerous machine function must become active only when the guard is closed and
locked.
ÌThe guard locking must not be released until the dangerous machine function has ended.
ÌClosing and locking a guard must not cause automatic starting of a dangerous machine function. A separate start com-
mand must be issued. For exceptions, refer to ENISO12100 or relevant C-standards.
Devices from this series are also suitable for process protection.
Before the device is used, a risk assessment must be performed on the machine, e.g. in accordance with the following
standards:
ÌENISO13849-1
ÌENISO12100
ÌIEC62061
Correct use includes observing the relevant requirements for installation and operation, particularly based on the following
standards:
ÌENISO13849-1
ÌENISO14119
ÌEN60204-1
The safety switch is allowed to be operated only in conjunction with the intended EUCHNER actuator and the related connec-
tion components from EUCHNER. On the use of different actuators or other connection components, EUCHNER provides
no warranty for safe function.
Connection of several devices in an AR switch chain is permitted only using devices intended for series connection in an AR
switch chain. Check this in the instructions of the device in question.
A maximum of 20 safety switches are allowed to be operated in a switch chain.
Important!
ÌThe user is responsible for the proper integration of the device into a safe overall system. For this
purpose, the overall system must be validated, e.g. in accordance with ENISO13849-2.
ÌIt is only allowed to use components that are permissible in accordance with the table below.
Table 1: Possible combinations for CTP components
Safety switch
Actuator
A-C-H-...
CTP-… Unicode/Multicode
Key to symbols Combination possible

Operating Instructions
Transponder-Coded Safety Switch CTP-AR
6(translation of the original operating instructions) 2123041-08-01/21
NOTICE
For information about combination with an AR evaluation unit, please refer to chapter 10.10. Connection
of several CTP‑AR in a switch chain on page 24.
3. Description of the safety function
Devices from this series feature the following safety functions:
Monitoring of guard locking and the position of the guard
(interlocking device with guard locking according to ENISO14119)
ÌSafety function (see chapter 6.8. Switching states on page 10):
- The safety outputs are switched off when guard locking is released (monitoring of the locking element).
- The safety outputs are switched off when the guard is open (monitoring of the door position).
- Guard locking can be activated only when the actuator is located in the switch head (prevention of inadvertent locking
position (faulty closure protection)).
- The following additionally applies in an AR series connection: the safety outputs are switched on only when the device
receives a corresponding signal from its predecessor in the chain.
ÌSafety characteristics: category, Performance Level, PFHD(see chapter 13. Technical data on page 34).
NOTICE
You can regard the complete AR device chain as one subsystem during calculation. The following
calculation method applies to the PFHDvalue:
#1
PFHD,1 PFHD,ext
AR-Device #1 ... n External Evaluation
(e.g. PLC)
PFHDges =∑ PFHD,k + PFHD,ext
n
k=1
#2
PFHD,2
#n
PFHD,n
Alternatively, the simplied method according to section 6.3 of EN 13849-1:2015 can be used for
calculation.

7
2123041-08-01/21 (translation of the original operating instructions)
Operating Instructions
Transponder-Coded Safety Switch CTP-AR
EN
Control of guard locking
If the device is used as guard locking for personnel protection, the control of the guard locking must be regarded as a
safety function.
The device does not feature a safety characteristic for the control of the guard locking, because the guard locking solenoid
is completely disconnected from outside the device (no control function within the device). It therefore does not contribute
to the failure probability.
The safety level for the control of the guard locking is dened only by the external control (e.g. PFHD, ext. for the standstill
monitor).
Guardlocking Device
PFHDext.
(e.g. standstill
monitor)
(locking mean)

Operating Instructions
Transponder-Coded Safety Switch CTP-AR
8(translation of the original operating instructions) 2123041-08-01/21
4. Exclusion of liability and warranty
In case of failure to comply with the conditions for correct use stated above, or if the safety regulations are not followed,
or if any servicing is not performed as required, liability will be excluded and the warranty void.
5. General safety precautions
Safety switches fulll personnel protection functions. Incorrect installation or tampering can lead to fatal injuries to personnel.
Check the safe function of the safeguard particularly
Ìafter any setup work
Ìafter the replacement of a system component
Ìafter an extended period without use
Ìafter every fault
Independent of these checks, the safe function of the safeguard should be checked at suitable intervals as part of the
maintenance schedule.
WARNING
Danger to life due to improper installation or due to bypassing (tampering). Safety components fulll
personnel protection functions.
ÌSafety components must not be bypassed, turned away, removed or otherwise rendered ineffec-
tive. On this topic pay attention in particular to the measures for reducing the possibility of bypass-
ing according to ENISO14119:2013, section 7.
ÌThe switching operation must be triggered only by actuators designated for this purpose.
ÌPrevent bypassing by means of replacement actuators (only for multicode evaluation). For this
purpose, restrict access to actuators and to keys for releases, for example.
ÌMounting, electrical connection and setup only by authorized personnel possessing the following
knowledge:
- specialist knowledge in handling safety components
- knowledge about the applicable EMC regulations
- knowledge about the applicable regulations on operational safety and accident prevention.
Important!
Prior to use, read the operating instructions and keep these in a safe place. Ensure the operating
instructions are always available during mounting, setup and servicing. For this reason you should
archive a printed copy of the operating instructions. You can download the operating instructions from
www.euchner.com.

9
2123041-08-01/21 (translation of the original operating instructions)
Operating Instructions
Transponder-Coded Safety Switch CTP-AR
EN
6. Function
The device permits the locking of movable guards.
The system consists of the following components: coded actuator (transponder)
and switch.
Whether the device learns the complete actuator code (unicode) or not (multi-
code) depends on the respective version.
ÌDevices with unicode evaluation: The actuator must be assigned to the
safety switch by a teach-in operation so that it is detected by the system.
This unambiguous assignment ensures a particularly high level of protection
against tampering. The system thus possesses a high coding level.
ÌDevices with multicode evaluation: Unlike systems with unicode evalu-
ation, on multicode devices a specic code is not requested but instead it is only checked whether the actuator is of a
type that can be detected by the system (multicode evaluation). There is no exact comparison of the actuator code with
the taught-in code in the safety switch (unicode evaluation). The system possesses a low coding level.
When the guard is closed, the actuator is moved into the safety switch. When the operating distance is reached, power is
supplied to the actuator by the switch and data are transferred.
If a permissible code is detected, the safety outputs are switched on.
The safety outputs and the monitoring output (OL) are switched off when the guard is unlocked.
In the event of a fault in the safety switch, the safety outputs are switched off and the DIA LED illuminates red. The oc-
currence of faults is detected at the latest on the next demand to close the safety outputs (e.g. on starting).
6.1. Guard lock monitoring
All versions feature two safe outputs for monitoring guard locking. The safety outputs (FO1A and FO1B) are switched
off when guard locking is released.
6.2. Door position monitoring output (OD)
The door position monitoring output is switched on as soon as the actuator is inserted into the switch head (state: guard
closed and not locked). The door position monitoring output also remains switched on when guard locking is active.
6.3. Diagnostic monitoring output (OI)
The diagnostic monitoring output is switched on in the event of a fault (switch-on condition as for DIA LED).
6.4. Guard lock monitoring output (OL)
The guard lock monitoring output is switched on when guard locking is active.
6.5. Version CTP Extended
Devices in the Extended version contain additional controls/indicators in the housing cover. Please refer to the enclosed
data sheet for further information.
6.6. Guard locking on version CTP-L1
(guard locking actuated by spring force and released by power-ON)
Activating guard locking: close guard; no voltage at the solenoid.
Releasing guard locking: apply voltage to the solenoid.
The spring-operated guard locking functions in accordance with the closed-circuit current principle. If the voltage is interrupted
at the solenoid, the guard locking remains active and the guard cannot be opened directly.
Important!
If the guard is open when the power supply is interrupted and is then closed, guard locking is activated.
This can lead to persons being locked in unintentionally.
Transponder-coded
actuator
Guard locking pin

Operating Instructions
Transponder-Coded Safety Switch CTP-AR
10 (translation of the original operating instructions) 2123041-08-01/21
The actuator cannot be pulled out of the switch and the guard is locked as long as the guard locking pin is extended.
If a voltage is applied to the guard locking solenoid, the guard locking pin is retracted and the actuator is released. The
guard can be opened.
6.7. Guard locking on version CTP-L2
(guard locking actuated by power-ON and released by spring force)
Important!
Use as guard locking for personnel protection is possible only in special cases, after strict assessment
of the accident risk (see ENISO14119:2013, section 5.7.1)!
Activating guard locking: apply voltage to the solenoid.
Releasing guard locking: disconnect voltage from the solenoid.
The magnetically actuated guard locking operates in accordance with the open-circuit current principle. If the voltage is
interrupted at the solenoid, the guard locking is released and the guard can be opened directly.
The guard can be opened as long as no voltage is applied to the guard locking solenoid.
If a voltage is applied to the guard locking solenoid, the guard locking pin is held in the extended position and the guard is
locked.
6.8. Switching states
The detailed switching states for your switch can be found in the system status table. All safety outputs, monitoring outputs
and display LEDs are described there.
Guard closed and locked
IMP
IMM
Guard closed and not locked
IMP
IMM
Guard open
IM
P
IM
M
Voltage on guard locking solenoid
CTP-L1
off on (irrelevant)
Voltage on guard locking solenoid
CTP-L2
on off (irrelevant)
Safety outputs FO1A and FO1B on off off
Guard lock monitoring output OL on off off
Door position monitoring output OD on on off

11
2123041-08-01/21 (translation of the original operating instructions)
Operating Instructions
Transponder-Coded Safety Switch CTP-AR
EN
7. Manual release
Important!
S1
S2
S3
No further release functions can be retrotted on Extended variants with control elements in position
1 (S1) and position 2 (S2).
Some situations require the guard locking to be released manually (e.g. malfunctions or an emergency). A function test
should be performed after release.
More information on this topic can be found in the standard ENISO14119:2013, section 5.7.5.1. The device can feature
the following release functions:
7.1. Auxiliary release and auxiliary key release
In the event of malfunctions, the guard locking can be released with the auxiliary release or the auxiliary key release irre-
spective of the state of the solenoid.
The safety outputs are switched off when the auxiliary release is actuated. Use the safety outputs to generate a stop
command.
The monitoring output OL is switched off; OD can assume an undened state. Open the guard and close it again after re-
setting the auxiliary release or auxiliary key release. The device will then operate normally again.
Important!
ÌThe actuator must not be under tensile stress during manual release.
ÌAfter use, reset the auxiliary release and screw in and seal the locking
screw (e.g. with sealing lacquer).
ÌThe auxiliary key release must not be used to lock the switch during
servicing to prevent activation of guard locking, for example.
ÌLoss of the release function due to mounting errors or damage during
mounting.
ÌCheck the release function every time after mounting.
ÌPlease observe the notes on any enclosed data sheets.
7.1.1. Actuating auxiliary release
1. Unscrew locking screw.
2. Using a screwdriver, turn the auxiliary release to in the direction of the arrow.
¨Guard locking is released.
7.1.2. Actuating auxiliary key release
On devices with auxiliary key release (can be retrotted), simply turn the key to release. Function as for auxiliary release.
For mounting, see the auxiliary key release supplement.
Auxiliary
release
Locking screw

Operating Instructions
Transponder-Coded Safety Switch CTP-AR
12 (translation of the original operating instructions) 2123041-08-01/21
7.2. Emergency release
Permits opening of a locked guard from outside the danger zone without tools. For mounting, see the mounting supplement.
Important!
ÌIt must be possible to operate the emergency release manually from outside the protected area
without tools.
ÌThe emergency release must possess a marking indicating that it may be used only in an emergen-
cy.
ÌThe actuator must not be under tensile stress during manual release.
ÌThe emergency release must be sealed or the misuse of the release function must be prevented in
the control system.
ÌThe release function meets all other requirements from ENISO14119.
ÌThe emergency release meets the requirements of Category B according to
ENISO13849-1:2015.
ÌLoss of the release function due to mounting errors or damage during mounting.
ÌCheck the release function every time after mounting.
ÌPlease observe the notes on any enclosed data sheets.
7.2.1. Actuating emergency release
ÌTurn the emergency release clockwise until it clicks into place.
¨Guard locking is released.
To reset, press the snap-in bolt inward using a small screwdriver or similar tool and turn the
emergency release back.
The safety outputs are switched off when the emergency release is actuated. Use the safety
outputs to generate a stop command.
The monitoring output OL is switched off; OD can assume an undened state. Open the guard and
close it again after resetting the emergency release. The device will then operate normally again.
7.3. Escape release (optional)
Permits opening of a locked guard from the danger zone without tools (see chapter 13.3.
Dimension drawing for safety switch CTP… on page 37).
Important!
ÌIt must be possible to actuate the escape release manually from in-
side the protected area without tools.
ÌIt must not be possible to reach the escape release from the outside.
ÌThe actuator must not be under tensile stress during manual release.
ÌThe escape release meets the requirements of Category B according
to ENISO13849-1:2015.
7.3.1. Actuating escape release
ÌPress the red release knob to the end stop
¨Guard locking is released.
Pull the knob out again to reset.
The safety outputs are switched off when the escape release is actuated. Use the safety outputs to generate a stop
command.
The monitoring output OL is switched off; OD can assume an undened state. Open the guard and close it again after re-
setting the escape release. The device will then operate normally again.
Snap-in bolt

13
2123041-08-01/21 (translation of the original operating instructions)
Operating Instructions
Transponder-Coded Safety Switch CTP-AR
EN
7.4. Wire front release (bowden)
Release via a pull wire. Depending on the type of attachment, the wire front release can be
used as an emergency release or escape release.
The following applies to non-latching wire front releases:
If the release is to be used as an emergency release, one of the following measures must be
taken (see EN ISO 14119:2013, section 5.7.5.3):
ÌInstall the release so that it can be reset only with the aid of a tool.
ÌAlternatively, resetting can be realized at the control-system level by means of a plausibility
check (status of the safety outputs does not match the guard locking control signal), for
example.
The emergency-release specications in chapter 7.2 on Page 12 apply irrespective of this
information.
Important!
ÌThe wire front release meets the requirements of Category B accord-
ing to ENISO13849-1:2015.
ÌThe correct function depends on the laying of the pull wire and the
attachment of the pull handle, and this is the responsibility of the plant
manufacturer.
ÌThe actuator must not be under tensile stress during manual release.
7.4.1. Laying wire front release
Important!
ÌLoss of the release function due to mounting errors, damage or wear.
ÌCheck the release function every time after mounting.
ÌWhen routing the wire front release, ensure that it operates smoothly.
ÌObserve the min. bending radius (100mm) and minimize the number of bends.
ÌThe switch is not allowed to be opened.
ÌObserve the notes on the enclosed data sheets.

Operating Instructions
Transponder-Coded Safety Switch CTP-AR
14 (translation of the original operating instructions) 2123041-08-01/21
8. Changing the approach direction
The approach direction needs to be changed only if the switch is to be approached from the rear.
Proceed as follows:
1. Remove the screws from the safety switch
2. Set the required direction
3. Tighten the screws with a torque of 1.2Nm
C
B
D
A
Figure 1: Changing the approach direction

15
2123041-08-01/21 (translation of the original operating instructions)
Operating Instructions
Transponder-Coded Safety Switch CTP-AR
EN
9. Mounting
CAUTION
Safety switches must not be bypassed (bridging of contacts), turned away, removed or otherwise
rendered ineffective.
ÌObserve ENISO14119:2013, section 7, for information about reducing the possibilities for by-
passing an interlocking device.
CAUTION
Risk of damage to equipment and malfunctions as a result of incorrect installation.
ÌSafety switches and actuators must not be used as an end stop.
ÌObserve ENISO14119:2014, sections 5.2 and 5.3, for information about mounting the safety
switch and the actuator. The following specications must be observed:
- Mounting with screws of property class 8.8 or higher.
- The minimum screw diameter is 4mm.
- Secure the xing material against loosening (e.g. by means of medium-strength positive screw
locking).
ÌProtect the switch head against damage, as well as penetrating foreign objects such as swarf,
sand and blasting shot, etc.
ÌObserve the min. door radii (see chapter 13.4.1. Dimension drawing for actuator CTP‑... on page
39).
ÌObserve the tightening torque for mounting the switch (max.1.4Nm).
Device damage or malfunctions caused by material changes due to the environment.
ÌIn accordance with section 6.3 of ENISO14119:2014, the environmental inuences (e.g. direct
UV radiation or corrosion) must be checked before a guard locking device is used.
ÌContact EUCHNER if you have any questions about environmental inuences or about use in ag-
gressive environments.
A clearance of 12mm must be maintained around the actuator head (see Figure 2).
min. 12 min. 12
Figure 2: Actuator head clearance

Operating Instructions
Transponder-Coded Safety Switch CTP-AR
16 (translation of the original operating instructions) 2123041-08-01/21
10. Electrical connection
The following connection options are available:
ÌSeparate operation
ÌSeries connection with Y-distributors from EUCHNER (only with M12 plug connector)
ÌSeries connection, e.g. with wiring in the control cabinet
ÌOperation on an AR evaluation unit (only for CTP Extended).
WARNING
In the event of a fault, loss of the safety function due to incorrect connection.
ÌTo ensure safety, both safety outputs (FO1A and FO1B) must always be evaluated.
ÌMonitoring outputs must not be used as safety outputs.
ÌLay the connecting cables with protection to prevent the risk of short circuits.
CAUTION
Risk of damage to equipment or malfunctions as a result of incorrect connection.
ÌThe power supply for the evaluation electronics is electrically isolated from the power supply for
the guard locking solenoid.
ÌDo not use a control system with pulsing or switch off the pulsing function in your control system.
The device generates its own test pulses on the output lines FO1A/FO1B. A downstream control
system must tolerate these test pulses, which may be up to 1ms long on AR devices.
The test pulses on AR devices are also output when the safety outputs are switched off.
Depending on the inertia of the downstream device (control system, relay, etc.), this can lead to
short switching processes.
ÌThe inputs on an evaluation unit connected must be positive-switching, as the two outputs on the
safety switch deliver a level of +24V in the switched-on state.
ÌAll the electrical connections must either be isolated from the mains supply by a safety transformer
according to IEC 61558-2-6 with limited output voltage in the event of a fault, or by other equivalent
isolation measures (PELV).
ÌAll electrical outputs must have an adequate protective circuit for inductive loads. The outputs
must be protected with a free-wheeling diode for this purpose. RC interference suppression units
must not be used.
ÌPower devices which are a powerful source of interference must be installed in a separate location
away from the input and output circuits for signal processing. The cable routing for safety circuits
should be as far away as possible from the cables of the power circuits.
ÌTo avoid EMC interference, the physical environmental and operating conditions at the in-
stallation site of the device must comply with the requirements according to the standard
EN60204-1:2006, section 4.4.2 (EMC).
CAUTION
Pay attention to any interference elds from devices such as frequency converters or induction heating
systems. Observe the EMC instructions in the manuals from the respective manufacturer.
Important!
If the device does not appear to function when operating voltage is applied (e.g. green STATE LED
does not ash), the safety switch must be returned unopened to the manufacturer.

17
2123041-08-01/21 (translation of the original operating instructions)
Operating Instructions
Transponder-Coded Safety Switch CTP-AR
EN
10.1. Notes about
Important!
ÌThis device is intended to be used with a Class 2 power source in accordance with UL1310.
As an alternative an LV/C (Limited Voltage/Current) power source with the following properties can
be used:
This device shall be used with a suitable isolating source in conjunction with a fuse in accordance
with UL248. The fuse shall be rated max. 3.3A and be installed in the max. 30VDC power supply
to the device in order to limit the available current to comply with the UL requirements. Please note
possibly lower connection ratings for your device (refer to the technical data).
ÌFor use and application as per the requirements of UL 1) a connecting cable listed under the UL
category code CYJV/7 must be used.
1) Note on the scope of the UL approval: the devices have been tested as per the requirements of UL508 and CSA/ C22.2 no. 14 (protection against electric shock
and re).
10.2. Safety in case of faults
ÌThe operating voltage UB and the solenoid voltage IMP are reverse polarity protected.
ÌThe safety outputs FO1A/FO1B are short circuit-proof.
ÌA short circuit between FO1A and FO1B is detected by the switch.
ÌA short circuit in the cable can be excluded by laying the cable with protection.
10.3. Fuse protection for power supply
The power supply must be provided with fuse protection depending on the number of switches and the current required for
the outputs. The following rules apply:
Max. current consumption of an individual switch Imax
Imax = IUB + IFO1A+FO1B + IOL + IOD
IUB = Switch operating current (40mA)
IOL/IOD = Load current of monitoring outputs (max. 50mA per monitoring output)
IFO1A+FO1B = Load current of safety outputs FO1A + FO1B (2 x max. 150mA)
Max. current consumption of a switch chain ΣImax
ΣImax = IFO1A+FO1B + nx(IUB + IOL + IOD)
n = Number of connected switches

Operating Instructions
Transponder-Coded Safety Switch CTP-AR
18 (translation of the original operating instructions) 2123041-08-01/21
10.4. Requirements for connecting cables
CAUTION
Risk of damage to equipment or malfunctions as a result of incorrect connecting cables.
ÌUse connection components and connecting cables from EUCHNER.
ÌOn the use of other connection components, the requirements in the following table apply.
EUCHNER provides no warranty for safe function in case of failure to comply with these require-
ments.
Observe the following requirements with respect to the connecting cables:
For safety switch CTP-…-AR-…-SAB-… with plug connectors 2 x M12
Parameter Value Unit
Conductor cross-section, min. 0.25 mm²
R max. 60 W/km
C max. 120 nF/km
L max. 0.65 mH/km
Recommended cable type LIYY 8 x 0.25mm² or 5 x 0.34mm²
For safety switch CTP-…-AR-…-SH-… with plug connector M23 (RC18)
Parameter Value Unit
Conductor cross-section, min. 0.25 mm²
R max. 60 W/km
C max. 120 nF/km
L max. 0.65 mH/km
Recommended cable type LIFY11Y min. 19-core

19
2123041-08-01/21 (translation of the original operating instructions)
Operating Instructions
Transponder-Coded Safety Switch CTP-AR
EN
10.5. Maximum cable lengths
Switch chains are permitted up to a maximum overall cable length of 200m taking into account the voltage drop as a result
of the cable resistance (see table below with example data and case example).
SPS
PLC
l1
l2
l
max
=200 m
ln
umin = 24 V -10%un= 24 V -20%
5 x 0,34 mm2
CTP-AR # n
CES-AR # n-1
CES-AR #
1
iout
n
Max. number of switches
IFO1A/FO1B (mA)
Possible output current per channel FO1A/FO1B
l1(m)
Max. cable length from the last switch to the
control system
5
10 150
25 100
50 80
100 50
150 25
6
10 120
25 90
50 70
100 50
150 25
10
10 70
25 60
50 50
100 40
150 25

Operating Instructions
Transponder-Coded Safety Switch CTP-AR
20 (translation of the original operating instructions) 2123041-08-01/21
10.5.1. Determining cable lengths using the example table
Example: 6 switches are to be used in series. Cabling with a length of 40m is routed from a safety relay in the control
cabinet to the last switch (#6). Cables with a length of 20m each are connected between the individual CES-AR/CTP-L1-…
safety switches.
CTP-AR # 6
Sicherheits-
relais
Safety Relay
CES-AR # 5CES-AR # 3
CES-AR # 2
CES-AR #
1
CTP-AR # 4
l1 = 40 ml2 = 5 x 20 m
l
= 140 m
ln = 20 m
un= min. 19,2 V
iOA/OB = 75 mA
Figure 3: Circuit example with six CES-AR/CTP-L1-…
A safety relay is connected downstream that consumes 75mA at each of the two safety inputs. This operates over the
whole temperature range with a voltage of 19.2V (corresponds to 24V -20%).
All the relevant values can now be determined using the example table:
1. Select the corresponding section in the column n (max. number of switches). In this case: 6 switches.
2. In the column IFO1A/FO1B (possible output current per channel FO1A/FO1B), nd a current greater than or equal to 75mA.
In this case: 100mA.
¨It is then possible to determine the maximum cable length from the last switch (#6) to the control system from column
l1. In this case, a length of 50m is permitted.
Result: The desired cable length l1of 40m is below the permitted value from the table. The overall length of the switch
chain lmax of 140m is less than the maximum value of 200m.
¨The planned application is therefore functional in this form.
