eufy Security T8203 User manual

QUICK
START GUIDE
eufy Video Doorbell Dual (Wired)
Anker Innovations Limited. All rights reserved. eufy Security and eufy Security Logo are
trademarks of Anker Innovations Limited, registered in the United States and other
countries. All other trademarks are the property of their respective owners.
51005002970 V01

1 2
What You Need:
• Phillips-Head Screwdriver
• Power Drill with 1/4" (6.35mm) Drill Bit
1
PRODUCT
OVERVIEW
eufy Video Doorbell
Dual (Wired)
Model: T8203
Doorbell Chime
Model: T8742
Jumper for Existing
Chime (The second one is
optional)
Extension Wires and Wire
Nuts (Optional)
Quick Start Guide
Mounting Bracket
(Attached to 15°
Mounting Wedge)
Doorbell Chime
Power connector
(The pin type may vary in
different regions.)
15° Mounting Wedge
(Optional)
Screw Hole
Positioning-Card
Screw Packs (Spare screws
and anchors are included.)
Doorbell Detaching
Pin
The Video Doorbell system includes 2 parts. One is the video doorbell at your porch.
The other is the electronic chime plugged on indoor power socket. The video doorbell is
powered by existing doorbell wires. In order to get sufficient power from the doorbell
circuit, user needs to bypass the existing doorbell chime on the circuit.
2
HOW THE
SYSTEM WORKS

3 4
1. Download and install the eufy Security app, then sign up for an account.
2. Add video doorbell and scan the QR code for later installation process. The QR code can
be found on the back of the video doorbell.
3APP INSTALLATION
Note: Make sure you have installed the eufy Security App and scan the QR code before
handling the doorbell installation.
Step 1
Ring the existing doorbell, make sure it’s working and locate the place of your existing
chimes in the house.
Step 2
Shut off the doorbell power supply. If you're not sure, shut off the main power supply in
your house. Turn the lights in your home on / off to make sure the electricity in your house
is properly shut off.
Note: Always be careful when handling electricity wiring. If you’re not comfortable to do it
yourself, do consult a qualified electrician.
4
VIDEO DOORBELL
INSTALLATION

5 6
Step 3
Find the doorbell chime in your house, then remove the cover and find the screw terminals
with TRANS and FRONT markings. Use the provided jumper for existing chime to connect
the two terminals. This is to bypass the doorbell chime and will not affect the normal
operation of the circuit.
Note:
• The video doorbell requires user to bypass the existing chime first to get sufficient power.
Without this step, the video doorbell will still be able to power on but will operate unstably.
• In most cases, the existing doorbell circuit looks like below chart. Find the existing
doorbell chime in your house, remove the cover and take a photo of the wire connection in
case you need to reconnect it.
• Use the provided jumper to connect FRONT and TRANS terminals to bypass the chime on
the circuit. Do not remove the original wire connecting to the chime. If your doorbell chime
has different markings or you have multiple chimes, refer to the help session in the App for
the custom wiring instructions or consult a qualified electrician.
• When the jumper is in place, the existing chime will not sound anymore.
What are required: Jumper for existing chime / Phillips-Head Screwdriver
Step 4
Remove the existing doorbell button at the front door. Pull the two wires out carefully
when removing the old doorbell. Straighten the wire ends if necessary.
What's required: Phillips-Head Screwdriver

7 8
Step 5
Determine the mounting position of the doorbell. Consider the below factors:
1. Check if you can reuse the existing holes and anchors on the wall or door frame.
2. If you are drilling the mounting holes for the first time the recommended mounting
height is 48" from the ground.
If you are mounting the doorbell on a wooden wall or board, do NOT drill holes. Skip to
Step7 and use screws directly to mount the Mounting Bracket.
If your wall is stucco, brick or concrete, you need to drill holes. Use the Screw Hole
Positioning-Card to mark the position and drill holes with 1/4" (6.35mm) drill bit.
What are required: Power Drill with 1/4" (6.35mm) Drill Bit / Screw Hole Positioning-Card
Optional: Use the 15° mounting wedge as a supplementary mounting bracket if you wish
to see more on a specific side.
Step 6
Use the anchors provided when installing in materials such as stucco, brick, or concrete.
There is no need to use anchor If you were installing on wooden doorframe.
What's required: Anchors

9 10
Step 7
Lead the two doorbell wires through the central square hole on the bracket before start
mounting.
Insert the two screws provided through the screw holes or through the 15° mounting
wedge(Install the mounting bracket to the 15° mounting wedge in prior), and fasten the
screws tightly.
What are required: Mounting Bracket / Screw Packs / 15° Mounting Wedge(Optional) /
Phillips-Head Screwdriver
Step 8
Connect the wires to the two terminals at the back of the doorbell, then tighten the
terminal screws. Wire can connect to any terminal as the electric current is alternating
current.
Note: To prevent short-circuit, make sure the wires are not touching each other after
connecting them to the terminals. If the wires are too short, use the extension wires and
wire nuts provided to make them longer. Use electrical wiring tape to secure the connection
if the wall doesn't have space for wire nuts.
What are required: Extension Wires and Wire Nuts (Optional) / Video doorbell / Philips-
Head Screwdriver
eufy Video Doorbell Dual (Wired)
Model: T8203

11 12
Step 9
There are 2 thermal conductive pads on the mounting bracket. They're used to conduct
heat from video doorbell to the metal bracket. Remove the films on the thermal conductive
pads before you mount the doorbell.
Align the doorbell on the bottom, and then move it into place on top. Press the doorbell
down until it clicks.
Use the doorbell detaching pin provided if you wish to detach the doorbell from the
mounting bracket.
The detaching pin has magnet pad on the black-color side. Stick it on iron surface where
you can find it easily.
Note: The oval holes are speaker holes. Only press the round hole to detach the doorbell.
What's required: Doorbell detaching pin

13 14
Step 10
Switch the doorbell or master circuit breaker to ON.
Step 11
Wait until the doorbell ring flashes blue. Then follow the on-screen instructions in eufy
Security App to connect the video doorbell to your home Wi-Fi.
I
I
I
I
I
I
I
I
I
I
I
I
I
I
I
I
I
I
I
Step 12
Follow the on-screen instructions in eufy Security App. Install the doorbell power connector
to the doorbell chime and then pair it to your video doorbell.
Note: One video doorbell can link up to 4 electronic chimes. Use the volume and music
buttons on the side of the electronic chime to adjust the volume and ringtone.
What are required: Doorbell chime / Doorbell chime power connector
Doorbell Chime
Model: T8742

15 16
5NOTICE
NOTICE (Canada)
This device complies with Industry Canada licence-exempt RSS standard(s). Operation is
subject to the following two conditions:
(1)this device may not cause interference, and
(2)this device must accept any interference, including interference that may cause
undesired operation of the device."
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils
radio exempts de licence. L'exploitation est autorisée aux deux conditions suivantes:
(1)l'appareil nedoit pas produire de brouillage, et
(2)l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le
brouillage est susceptible d'en compromettre le fonctionnement."
This Class B digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada.
IC RF Statement:
When using the product, maintain a distance of 20cm from the body to ensure compliance
with RF exposure requirements.
Lors de l'utilisation du produit, maintenez une distance de 20 cm du corps afin de vous
conformer aux exigences en matière d'exposition RF.
NOTICE (United States Of America)
FCC Statement
This device complies with Part 15 of the FCC Rules. Operation is subject to the following
two conditions: (1) this device may not cause harmful interference, and (2) this device
must accept any interference received, including interference that may cause undesired
operation.
Warning: Changes or modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate the equipment.
Note: This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation.
This equipment generates uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not occur
in a particular installation. If this equipment does cause harmful interference to radio
or television reception, which can be determined by turning the equipment off and on,
the user is encouraged to try to correct the interference by one or more of the following
measures: (1) Reorient or relocate the receiving antenna. (2) Increase the separation
between the equipment and receiver. (3) Connect the equipment into an outlet on a
circuit different from that to which the receiver is connected. (4) Consult the dealer or an
experienced radio/TV technician for help.
FCC Radio Frequency Exposure Statement
The device has been evaluated to meet general RF exposure requirements. The device can
be used in fixed/mobile exposure condition. The min separation distance is 20cm.
Notice: Shielded cables
All connections to other computing devices must be made using shielded cables to
maintain compliance with FCC regulations.
The following importer is the responsible party
Company Name: POWER MOBILE LIFE, LLC
Address: 10900 NE 8th St, Ste 501, Bellevue WA 98004
Telephone:[phone]
