Introduction
The R-1 Transfer Station archives R-1 recordings in the non-proprietary AES 31 format.
The recordings can then be used in any AES 31-compliant recorder, stored on a server,
and backed up like other types of critical data.
The Transfer Station has many of the same features found in the R-1, such as editing
and moving audio clips, but does not play or record audio. Review the following pages
in the R-1 Operation Manual to learn about file management, editing, and features of
the R-1 that are present in the Transfer Station:
13–14, 31–36, 48–66, 121–156, 168–192, 227–237, and 244–249
Review chapters 2–5 in the R-1 3.0 Addendum.
CAUTION:The Transfer Station software cannot be installed on the same computer
that runs the R-1 software. Do not install the Transfer Station software on
an R-1 Pilot PC. The Transfer Station software runs only on the Windows
2000 operating system.
New Features
The Transfer Station can convert any Sheet from an R-1 Title to an AES Edit Decision
List (EDL), named with an .adl suffix, and an AES 31 Broadcast Wave File (BWF),
named with a .wav suffix. The process can also be reversed: AES 31 content can be con-
verted back into an R-1 Title or Sheet for playback and editing on an R-1.
NOTE: The R-1 title does not get converted to an AES 31 Title in the Export process,
but that a Sheet from an R-1 Title becomes an AES 31 Title.
Setting Default Export and Import Folders
Before Exporting from or Importing into the Transfer Station, set up the Default Folders
Location. This is the location the Transfer Station uses to access exported titles and
place imported titles. These settings are found in the AES31 import and export dialogs.

Euphonix R-1 Transfer Station Operation Manual
6
Export to AES 31
To export a Sheet as an AES 31 EDL:
1. Right-click on the Track name in the Navigation Bar and select Export to
AES 31.
The Export dialog appears.
2. Select the desired Export options:
Export Title file only (when selected, the next two options are inactive)
Export R-1 Title (Puts a version of the R-1 title file with the ADL file and
Audio files for later use on an R-1)
Overwrite existing audio files
Export all audio files in Title’s library
Export all tracks (toggles with next option)
Export selected tracks (toggles with previous option)
Set export path (sets default export folder)
Browse (specify a folder other than default export folder)
File name (change exported file name)
3. Click Export.
Tips for Export Operation
When exporting titles with multiple sheets, all audio associated with the entire title can
be exported with the first Sheet. This allows the R-1 to be left unattended while you do
other tasks. When exporting the first title, select the Export all audio files in Title’s
library option.
When all audio has exported, export all other sheets belonging to that title. It is a good
idea to leave the Export all audio files in Title’s library option selected when export-
ing the other sheets, just in case material from one of the other sheets belongs to a dif-
ferent library. You should also make sure that each sheet is exported to the same
Windows folder to avoid duplicate copies of the material. In this case, do not select the
Overwrite existing audio files so each time you export a sheet belonging to the same
Library, you would not export audio previously exported.

Euphonix R-1 Transfer Station Operation Manual
7
AES Title Import
To Import an AES 31 Title into the R-1:
1. Left-click on the Track name in the Navigation Bar and select Import AES 31.
The Import dialog appears.
2. Configure the Import options:
Import Audio Files (Allows or disallows import of associated audio. If the
audio does not exist on the target drives where you are importing your title,
select this option.)
Overwrite existing audio file content (overwrites audio with same Global
Unique ID (GUID) on Transfer Station disks)
Import new audio files to library
Use same name as R-1 Title (puts audio that does not exist on R-1 disks into
same library as Title file)
Use another name (create a separate folder to store the audio)
Import R-1 Title (copies the R-1 Title previously exported with the AES
files back onto the R-1)
Set export path (sets default import folder)
Browse (specify a folder other than default import folder)
3. Click the Browse button to navigate to and select the .adl file to Import.
4. Click Import.
The AES file is imported with its audio to the R-1 format.
Audio in a Windows folder not associated with the adl file you are importing will not
be imported to the R-1. When importing adl files to an R-1, the system will only import
audio that is expected to be associated with the adl title. To import audio to the R-1 that
is not associated with an adl or R-1 title, see section 3.2 on page 26 in the R-1 3.0 Ad-
dendum.
AES Title Import as Sheet
Left-click on the Sheet in the Navigation Bar and select Import AES Title. Follow the
same instructions as Import AES Title but a new Sheet is created within the current
Title instead of a new Title.
This feature could be used to put all takes of a particular song into the same R-1 Title,
or merge all songs of an album into the same Title.

Euphonix R-1 Transfer Station Operation Manual
8
Import R-1 Title
When Importing an R-1 Title, be careful that the Title is not already present in the
Transfer Station; this could overwrite the first Title. Each R-1 Title is identified within
the R-1 and Transfer Station by a Globally Unique ID (GUID). The systems each track
and manage the Title’s versions as it is changed using the GUID. The system does not,
however, discriminate between multiple copies of an R-1 Title made outside of the
system. This requires great care as you manage Title files outside the R-1 or Transfer
Station applications.
To import an R-1 title:
1. Left-click on the Track name in the Navigation Bar and select Import AES 31.
The Import dialog appears.
2. Click the Browse button.
3. In the lower portion of the Browse dialog you will see a drop-down menu
named Files of Type. Open it and select R-1 Titles (.ttl).
4. Navigate to and select the folder where the file to import resides.
5. Select your R-1 .ttl file.
6. Click Import.
Track Views
The Transfer Station has several new track viewing options that are not found in the R-1.
The number of tracks viewed can be 2, 4, 8, 12, 24, and 48, which can be set in the
Zoom dialog or in the Deck settings on the Navigation Bar.
Several hot keys permit quick zoom operations:
• f7 = Zoom In
• f8 = Zoom Out
• f9 = Fewer Channels
• f10 = More Channels
Features exclusive to the Deck are available by right-clicking on the Deck button.

Euphonix R-1 Transfer Station Operation Manual
9
R1 Tape Backup/Restore (Version 2.0 only)
The backup and restore features on the Transfer Station work like an R-1 except for the
following differences:
• Only one Exabyte drive can be connected.
• When backing up or restoring the entire system, the Transfer Station begins to
backup or restore from Deck 1 and moves up to Deck 4.
• The Transfer Station can backup and restore all decks from one tape if the tape
is large enough to contain all the data.
• Multiple tapes cannot be used during one backup process. Backup and restore
processes cannot be canceled during their operation.

Euphonix R-1 Transfer Station Operation Manual
10
Features Changed from the R-1
Audio Browser, Media and Libraries, and Titles Browser
The Audio Browser and Titles Browser in the Transfer Station are now where the
Meters are located on an R-1. Tab between the Audio Browser and Titles Browser using
the Media/Browser button in the left side of the Navigation Bar.
Changing Drives and Drive Bay Positions
You cannot unload a drive and change hard drives while the Pilot PC is on. To change
drives shut down both the application and PC, change the drives, and then restart the
computer and application.
The drive positions in the nine-bay Kingston chassis equate to R-1 drive bays as follows:
Deck 1: drives 1 and 2 = Kingston 1 and a
Deck 2: drives 1 and 2 = Kingston 2 and b
Deck 3: drives 1 and 2 = Kingston 3 and c
Deck 4: drives 1 and 2 = Kingston 4 and d
Settings Saved in the .adl File
The following R-1 Title settings are saved when exporting to the AES 31 .adl file:
Track names, audio clips, audio file timecode and track positions, the disk the file orig-
inated from, sample rate, bit rate, default cross fade length, Sheet name, and exported
audio file names.
Settings Saved in the Broadcast Wave File
The following settings are saved when exporting to the Broadcast Wave File:
File name, timecode position, sample rate, bit rate.
Features Present in the R-1 but not in the Transfer Station
Rollback, Jog, Input mapping, All audible features (i.e., Play, record etc.), All Safe,
Track Status /input /Repro, Track Memories, Meters, Varispeed, Machine Control, and
Slaving.
