Eureka Forbes Euroclean Steem User manual

INSTANT DRY STEAM CLEANING
VARIO
STEAM CLEANING
SUPER DRY STEAM
ECO-FRIENDLY
CLEANING
INSTANT
STEAM GENERATOR

CONTENTS
Why Euroclean? 1
The Euroclean Range Advantage 2
Product Overview 3
Features 4
Safety Information 5-7
Using Euroclean Steem 8-9
Operating Eurolcean Steem 10-14
Storage 15
Maintenance 16-17
Troubleshooting 18
Technical Specifications 19
Warranty Terms & Conditions 20

1
WHY EUROCLEAN?
We, at Eureka Forbes, firmly believe that a quality life is the right of every individual. Which is why we endeavour to offer you
only the best of health and technology, with our diverse and innovative range of products – designed for your every need. Be it
safe drinking water, pollution-free air, spotless surroundings or secure homes, we have invested in it all – for your well-being.
Coming to you from the pioneers and leaders in vacuum cleaners, water and air purification systems, Euroclean is designed to
take care of your home cleaning needs.
Trusted by over 5 million satisfied customers
Developed by a state-of-the-art R & D facility, with high-end testing equipments
Offers a wide range of products & accessories, developed after extensive consumer research and usage
Highest selling vacuum cleaner in India, for over 34 years
Largest network of service technicians, ensuring 100% service within a 5 km radius
Thank you for choosing us as your partner in good health!
l
l
l
l
l
l

2
THE EUROCLEAN RANGE ADVANTAGE
Active Shield™: The Active Shield™ coating, on Euroclean dust bags builds an impenetrable wall of anti-
bacterial fighting agents and traps & deactivates the harmful minute microorganisms inside the bag. This
ensures 100% cleaning, as well as 100% safety, of the air expelled from the vacuum cleaner. (Available in
Euroclean Dynomite Vacuum Cleaners).
Ergonomics™: Euroclean vacuum cleaners & cleaning machines are designed with care, keeping the best
ergonomic principles in mind. They are created to achieve new standards of operation, along with ease of
handling. For example, the soft gripped conical-shaped hose handle comes loaded with a patented 360
degree technology which swivels both sides, ensuring convenient and efficient cleaning, every time.
Deep Cleaning+™: Euroclean efficiently cleans, disinfects and purifies your home from dirt, dust and dust
mites. It cleans not only on the surface but also reaches every difficult deep nook and corner, thereby
eliminating the fear of common dust-related allergies or recurrent illnesses. Optimised power suction, superior
airflow and its ability to effectively remove the dangerous microscopic dust mites make the Euroclean a
cleaning marvel.
Triple I : The intelligent ion inducer technology works on the ‘corona discharge’ method. A tiny current of
electrons flows down the needle to its point. The nearer the electrons come to the needlepoint, the closer they
are forced together. Since electrons naturally repel each other, when they reach the very tip of the needle they
are forced off into the nearest air molecule and become a negative ion. Negative ions repel each other as
well, so as more and more are produced they are emitted further out into the air. Negative ionizers are proven
to clear the air of dust, pollen, pet dander, mould spores and other potential allergens. Negative ions increase
your sense of well-being and mental clarity, by removing the debilitating effects of excessive positive ions in
your environment. (Available in Euroclean i-Clean Vacuum Cleaners).
™

3
PRODUCT OVERVIEW
1. Hanger strap
2. Variable steam setting
3. Control switches (see (27)/(28)/(29)/(30)
4. Power cord holder (with quick release)
5. Water tank filler cap
6. Power cord
7. Water tank
8. Lower handle
9. Fold-out power cord holder
10. Lock button
11. Floor head
12. 2x Floor cloth grips (set on either side)
13. Brush sliders
14. Steam release valve (located on rear)
15. Elasticated floor cloth (for hard floors)
16. Floor cloth (for carpets)
17. Elasticated utility cloth
18. Squeegee nozzle
19. Utility nozzle
20. Deflector nozzle
21. Spot brush (with 2x spare brushes)
22. Nozzle cleaning pin
23. Generator cleaning brush
24. Detachable steam comb attachment
25. Detachable carpet glide base attachment
26. Water filling funnel
ON/OFF switch
STEAM switch
Power ON light (red)
Steam ready light (green)

FEATURES
3 in 1 Steam Mop - Euroclean Steem is the best combination of canister, handheld and upright cleaner which let’s you
clean every type of surface around the house.
Instant Steam Generator - Euroclean Steem uses an instant steam generator to produce continuous dry steam in just
30 seconds, without pressurisation. Conventional boiler-based steam cleaners can take up to 15 minutes to
pressurise.
Super Dry Steam - Euroclean STEEM produces dry steam which restricts the deposition of moisture on surfaces
being cleaned, ensuring a 100% clean and hygienic home.
Multipurpose Steam Cleaner - Comes with a set, of 16 different accessories, which cleans and sanitizes every nook
and corner of your home.
Easy Maintenance - The non-pressurised boiler is the first and only system that allows “easy clean” generator
maintenance at home, as this technology reduces mineral build up.
Vario Steam Cleaning - The digitally controlled variable steam flow technology allows the user to choose the right
amount of steam power for varied cleaning requirements.
Quick water re-fill on the go - No boiler means no cooling time needed before you can top up the water chamber. This
allows the user continuous cleaning, without disruptions.
Eco Cleaning - Steam cleaning is the safe and easy way for effective deep cleaning, without the use of any chemicals
or detergents.
4
CreatedbyAlexMuravevCreatedbyAlexMuravev
fromtheNounProjectfromtheNounProject

FOR HOUSEHOLD USE ONLY.
WARNING: Disconnect from the mains supply before carrying out any routine maintenance.
When using Euroclean Steem, basic safety precautions should always be observed, including the following:
1. Never modify the product in any way.
2. Do not leave the product unattended while it is connected to the supply mains. Unplug it from the socket when not in
use.
3. To prevent electric shock do not use outdoors.
4. Not to be used as a toy. Close supervision is necessary when used near children or the infant.
5. Use the product as described in this manual.
6. Do not use with a damaged cord or plug. If the supply cord and/or plug is damaged, it/they must be replaced by the
manufacturer, an authorised service agent or similarly qualified persons, in order to avoid accidents.
7. Do not pull or carry by the cord, use the cord as a handle, allow the cord to come into contact with hot or sharp
surfaces or close a door on the cord.
8. Do not unplug by pulling on the cord.
9. Do not allow the mains cord to become taut.
10. Do not handle the plug or cleaner with wet hands.
11. Do not put any objects into openings or operate with openings blocked.
12. Do not use without the tank cap in place.
13. Turn off all controls before unplugging.
14. Do not use an extension cord.
15. Store indoors, put away after use to prevent tripping accidents.
16. Using improper voltage may result in damage to the steam cleaner and possible injury to the user. The correct voltage is
listed on the rating label.
17. Liquid or steam must not be directed towards equipment containing electrical components such as the interior of ovens.
SAFETY INFORMATION
5

SAFETY INFORMATION
6
18. An accident may occur if the steam cleaner runs over the power cord.
19. Never immerse the steam cleaner in water or other liquids.
20. Keep the steam cleaner away from the rain and moisture. The steam cleaner is not suitable for outdoor use.
21. Do not store the steam cleaner near hot surfaces eg. ovens or heating appliances.
22. Only use the steam cleaner in containers/pools that are not filled with water or other liquids.
23. Do not operate the steam cleaner without water in the in-built tank.Always top up with water.
24. Empty the water tank when the steam cleaner is not in use.
25. Never fill the tank with anything other than water. Never put additives (such as perfume, stain remover or products
containing alcohol) in the water, as they may damage the steam cleaner or make it dangerous to use.
26. Always remove the mains plug and handle the steam cleaner with care, when topping up with water.
27. Do not overfill the tank. Do not exceed the maximum prescribed water filling level. Please use the funnel included.
28. Press the centre button on the water tank cap, at every refill and ensure that the cap has been screwed down fully
before use.
29. Ensure that the water tank cap is not open during use.
30. Do not touch any hot areas on the steam cleaner. It is normal for the steam cleaner to heat up during operation.
31. Do not use the steam cleaner to treat any items of clothing that are still being worn on the body.
32. The force and heat of the steam may have an adverse effect on some materials. Always check whether a surface is
suitable for treatment with the steam cleaner, by carrying out a test beforehand on a concealed area.
33. Never aim the steam cleaner at people, animals or plants (risk of scalding!) Do not aim the steam cleaner at electrical
systems or wires.
34. Accessories become hot during use, allow them to cool down before handling.
35. Maintain and clean the steam cleaner only when the unit is not in use.
36. Cleaning and user maintenance shall not be undertaken by children without supervision.

SAFETY INFORMATION
37. Children should be supervised to ensure that they do not play with the appliance.
38. The appliance is not be used if it has been dropped, if it has visible signs of damage or if it is leaking.
39. Keep the applicance out of reach of children when it is energized or cooling down.
40. This product can be used by persons (including children) with reduced physical, sensory, mental capacities, or lack of
experience and knowledge, if they have been given supervision or instruction concerning use of the appliance in a safe
way and understand the hazards involved.
41. Repairs to electrical appliances are only to be undertaken by authorized service agents or trained personel.
Unprofessional repairs can be dangerous to users.
42. Use only genuine spare parts and accessories.
STEAM RELEASE SAFETY FEATURE
IMPORTANT:
This steam cleaner is equipped with a steam release valve mechanism, located at the rear of the steam generator. In
event of a steam flow blockage, the safety valve is designed to release the steam. Regular cleaning of the steam chamber
and nozzle is therefore recommended to avoid such an occurrence. If the steam is released from the safety valve, stop
cleaning and unplug the steam cleaner from the electrical outlet. Allow the product to cool down thoroughly for at least one
hour. Then, clean the steam chamber and nozzle. If steam is still being released from the safety valve, after cleaning,
contact an authorized Service Centre immediately.
7

USING EUROCLEAN STEEM
IMPORTANT:
•Never open the water tank cap whilst the steam switch is on.
•Never fill the tank directly from a tap. Use a jug and the funnel provided.
•Do not operate a damaged appliance or damaged accessories.
•This steam cleaner is not intended for commercial use.
Remove the tank filler cap by unscrewing it and fit the funnel provided.
With the cleaner held at around 45°, pour the water into the funnel. The maximum
capacity of the tank is 0.8 litres of water, which will give you more than 25 minutes of
steaming. Use less water if required.
IMPORTANT: Do not overfill.
Rotate the upper cord storage hook to quickly release the power cord.
IMPORTANT: If the supply cord is damaged, it must be replaced by the
manufacturer, an authorised Service Agent or similarly qualified persons, to avoid
accidents.
Make sure the steam cleaner is switched OFF. Insert the power plug into an
electrical outlet.
WARNING: Before switching ON, ensure the floor head/accessories are kept
away from people or animals.
8
2929
2727
3030
2828

USING EUROCLEAN STEEM
Press the ON/OFF switch located on the handle to switch Euroclean Steem on. The red power ON light should now be
illuminated. The steam generator will start to heat but no steam will be emitted.
Press the steam switch to the ON position. After about 30 seconds, when the steam generator is up to the required
temperature, the water pump will start, the green steam ready light will illuminate and steam will be emitted.
To stop the steam, switch either switch to the OFF position. For quick breaks, we suggest just switching OFF the steam switch.
After switching the cleaner to OFF, steam will continue to be emitted for a few seconds until the steam generator is empty.
Turn the variable steam setting control to maximum and point the steam nozzle towards a
cloth or sink for approximately 30 seconds, to stabilise the flow and produce a continuous
steam.
9

OPERATING EUROLCEAN STEEM
• Press the ON/OFF switch located on the handle to switch the steam cleaner on. The
red power ON light should now be illuminated. The steam generator will start to heat
but no steam will be emitted.
• Press the steam switch to the ON position. After about 30 seconds, when the steam
generator is up to the required temperature, the water pump will start, the green steam
ready light will illuminate and steam will be emitted.
• To stop the steam, switch either switch to the OFF position. For quick breaks, we
suggest just switching OFF the steam switch.
• After switching the cleaner to OFF, steam will continue to be emitted for a few seconds
until the steam generator is empty.
• Turn the variable steam setting control to maximum and point the steam nozzle towards a cloth or sink for approximately
30 seconds, to stabilise the flow and produce a continuous steam.
DUAL FUNCTIONALITY
Your steam cleaner can easily be configured into two different cleaning modes:
• Upright steaming for floors and carpets.
• Attachment mode for vertical or hard to reach surfaces.
Important:Ensure the steam switch is turned off before connecting the floor head or any of the
other cleaning accessories.
UPRIGHT STEAMING: ASSEMBLY
Depending upon the task, connect the required floor cloth to the floor head by using the towel grips
as shown in this section.
To fit the nozzle to the main body, align the hole in the nozzle with the lock button on the main body.
Press the lock in and then twist and push the nozzle fully on until the lock button clicks into place.
10
Upright steaming Attachment mode

Important: Before use, hard floors should be throughly swept and carpets should be thoroughly dry vacuumed. However, we
recommend that Euroclean Steem is not used on:
• Bare wood floors or any surfaces where wood is exposed, as it will absorb moisture and may war pit.
• Damaged hard floors or hard floors with abnormal gaps present.
Also, do not keep the mop in one place for an extended period, where the continual heat may cause shrinkage or distortion on
carpets and laminate flooring.
Important: Please remember that Euroclean Steem operates by emitting steam at an increased temperature of 115°C.
Always test on an inconspicuos area first. Never use it on objects or surfaces which cannot resist this temperature, or on
delicate materials such as dralon, plastic, natural fur, etc.
If in doubt, check carefully on a part of the material where minor marks will not matter.
Important: When you have finished cleaning, ensure that both the power switch and steam switch are turned OFF and that
the plug is removed from the electrical outlet.
UPRIGHT STEAMING: OPERATION
Turn the steam switch ON.
Reduce the steam flow to a lower setting by turning the steam control regulator. Use
both forward and backward strokes across the floor area.
Note: The steam output can be regulated using the variable steam setting control on
the side of the handle.
UPRIGHT STEAMING: HARD FLOOR CLEANING AND STUBBORN STAINS
Connect the floor cloth (hard floor) to the floor head by stretching the elasticated skirt
around the floor head and secure it into place using cloth grips.
Important: When cleaning parquet, laminate and wood floors, set the steam regulator control to “minimum”.
Warning: The floor cloth becomes very hot during use. Please wait until the cloth is cool before removing, wringing, rinsing or
replacing the cloth.
When the cloth becomes wet, wring out the moisture, or replace with a clean, dry cloth.
OPERATING EUROLCEAN STEEM
11

12
OPERATING EUROLCEAN STEEM
If the cloth becomes too dirty, rinse out the dirt, or replace with a clean, dry cloth.
To remove stubborn stains or embedded grime on hard surfaces, fold and attach the floor
cloth (carpet) whilst leaving the brushes underneath the floor head visible.
Move the brush sliders so that the brushes appear underneath the floor head. Move
the brushes backwards and forwards over the selected area.
Important: Do not use the brushes for routine carpet and hard floor cleaning as
unnecessary scrubbing may cause damage. The brushes should only be used for
removing stubborn stains and grime.
UPRIGHT STEAMING: CARPET CLEANING AND PILE REJUVENATION
Carpets should be dry vacuumed before steam cleaning. For Best results use Euroclean range of Vacuum Cleaners.
For free movement of the steamer, over larger carpeted areas, the carpet glide
attachment can be used.
Detach and remove the steam comb section from the carpet glide attachment.
Fold the cloth and place inside the carpet glide base.
Secure the floor head inside the carpet glide base
and connect the cloth by using the floor cloth
grips.
To rejuvenate flattened carpet piles, remove the
cloth and connect the carpet glide base to the floor
head, with the steam comb section in place.
When cleaning carpets and rugs, set the steam regulator control to “maximum”. Use
slow forward and backward cleaning strokes over the desired area.
Using with other accessories (attachment mode)
Important: When the steam cleaner is used in a vertical or inclined position, shake the steam cleaner gently, to ensure that the
weighted tubing inside the tank is in the correct (immersed) position.

OPERATING EUROLCEAN STEEM
This function is ideal for a wide range of steam cleaning tasks and for cleaning hard to
reach places.
The accessories can be attached to the main body of Euroclean Steem by removing
the floor head.
Warning: The housing and accessories become hot during operation. Allow the steam
cleaner to cool down before replacing or removing the accessories.
To remove the floor head press the lock button in and then twist and pull the floor head
until it comes free from the handheld unit.
Important: Before connecting any of the
accessories (excluding the floor head), first connect the deflector nozzle to the end of
the steam outlet on the main body of the steam cleaner.
Fit the required accessory over the deflector nozzle by aligning with the lock button on
the main body of the steam cleaner. Press the lock button in and then twist and push
the accessory fully on until the lock button clicks.
ATTACHMENT: SQUEEGEE
For cleaning windows, patio doors, conservatory glass, tiles, shower screens and mirror panels. Use the Squeegee at a very low
steamflowbyadjustingthe variablesteamsetting. Use a clothtowipe the bladeandremove excess waterduringusage.
Warning: Do not use on very cold glass, as the sudden temperature change may crack the glass.
To clean windows, start at the top of the window, press the Squeegee to the surface and drag downwards. Move the Squeegee
in straight passes from top to bottom.
For small window panels, remove the squeegee tool and spray the steam directly onto the surface. Use the Squeegee
separately to wipe away the moisture.
13

14
OPERATING EUROLCEAN STEEM
ATTACHMENT: UTILITY NOZZLE
For cleaning tiled surfaces, cabinets and worktops in kitchens and bathrooms. Also use
this attachment for cleaning upholstery, curtains, pillows and mattresses.
Use on a low to medium steam flow by adjusting the variable steam setting.
Cover the utility tool with one or two of the elasticated utility cloths.
ATTACHMENT: SPOT BRUSH
For cleaning the grout between tiles or stubborn marks and stains on hard surfaces. Use
at medium or high steam flow by adjusting the variable steam setting.
Apply gentle pressure. Too much force may damage the bristles. Two sets of spare bristles are supplied. To change, loosen
the screw and pull out the bristle set.
ATTACHMENT: DEFLECTOR NOZZLE
For cleaning sanitaryware such as toilet bowls, taps or drain covers. Use this nozzle at maximum steam flow. Point it directly at
temporary/short-lined/momentary stains on carpets or upholstery whilst holding a clean cloth, near the stained area, to
capture any loosened dirt.
SANITISING BEDDING AND UPHOLSTERY
• To sanitise and remove dust mites and allergens from bedding and upholstery, fit the utility nozzle and pass the steam
slowly and evenly over the surface, ensuring all areas are treated. Repeat the process. Leave the mattress to dry
thoroughly before covering.
• Sanitising surfaces and hard floor
• To sanitize surfaces and hard floors, focus steam while cleaning or mopping for at least 15 seconds. Pass the steam
slowly and evenly over the surface, ensuring all areas are treated. Repeat the process.
Note: When the steam cleaner is used for cleaning in the overhead position, increase the steam flow to maximum and allow
approximately 30 seconds for the steam to be generated in full. Now the flow can be reduced to the level required for the
particular accessory being used.
Note: When using on hard/wooden floors, we recommend setting to minimum steam to prevent the floors from becoming too
wet. Use both forward and backward strokes across the floor area.

After Each Use
Switch Euroclean Steem OFF and unplug from the socket. Please keep Euroclean
Steem on a suitable surface (eg. Tiled floor) where the residual heat/moisture in the
floor nozzle/cloth will not affect the surface. Wait until the cleaner has cooled down
completely.
Empty any remaining water from the tank by unscrewing the water tank cap and turning
the steam cleaner upside down. This should be done over a sink or outdoors.
Wrap the cord around the two power cord holders, folding the lower holder out from its
location on the lower handle.
Store the product by using the hanger strap at the top of the handle if needed.
STORAGE
15

16
MAINTENANCE
CLEANING THE STEAM GENERATOR
1. Pull down the nozzle lock and hold,
2. Turn the steam outlet to release the hooks.
Important: Do not attempt to twist without releasing the lock.
3. Pull upwards/outwards. This will remove it
completely from the steam chamber along with an
attached spring.
4. Insert the boiler into the chamber. Rotate the brush
while pulling it in and out of the chamber to dislodge limescale. Repeat a few times and tip
out contents. Repeat until clear of limescale.
5. Remove the brush and insert the steam nozzle
back into the chamber and twist to lock back into
position.
Important: Only follow these instructions when the steam cleaner is completely cooled
down. Also ensure that the plug is removed from the electrical outlet.
Warning: Always unplug the steam cleaner from the mains supply before undertaking
maintenance procedures.
Note: Clean the steam chamber after every 10-15 uses, to ensure optimum performance.
1
23

• Unblocking the Steam Outlet
If steam flow appears reduced, the steam nozzle may be blocked. Insert the nozzle pin
into the centre of the steam nozzle. This will clear any blockage that may have formed.
• Cleaning the Mop Heads
The Mop Heads can all be washed in the washing machine (60°C max). For heavy
soiling, soak the cloths in warm water and detergent or a mild stain remover. Allow to
completely dry before storing.
• Maintaining the Attachments
Dirt and blockages should be regularly removed from the attachments, to help prolong their usage.
• Overall Maintenance
Your cleaner is manufactured to withstand normal day-to-day use, but an occasional wipe over with a damp cloth will help
maintain it. Abrasive cleaners should not be used.
MAINTENANCE
17

TROUBLESHOOTING
WARNING To reduce the risk of personal injury, always unplug Euroclean Steem from the mains supply before any
maintenance procedures or servicing.
PROBLEM Euroclean Steem has no power.
Cause Euroclean Steem is not properly plugged into an electrical outlet or is not switched on.
Solution Insert the plug into an electrical outlet and switch the Euroclean Steem on.
Cause The socket is faulty.
Solution Check the socket by unplugging the Euroclean Steem and plugging in a different appliance.
Cause The power cable is damaged.
Solution Have the cable replaced by an authorized ServiceAgent.
PROBLEM Very low or no steam is emitted when the Euroclean Steem is switched ON.
Cause The water tank is empty.
Solution Top up with water.
Cause The steam regulator is set to minimum.
Solution Turn the steam regulator to increase the steam flow.
Cause Despite the green light, the steam switch is not activated properly.
Solution Press down the steam switch fully.
Cause The weighted tubing inside the tank is not in the correct (immersed) position.
Solution Shake the steam cleaner gently.
PROBLEM The water tank appears deformed.
Cause Avacuum isbeingcreated inside,andthetank isimploding duetoblockage ofthe water cap’sair-inletvalve.
Solution Press in the centre button on the cap a few times to let the air in.
18
