Eurotops 37419 User manual

PTC FAN HEATER
USER MANUAL
Art. No.: 37419
230V~ 50Hz 1800W

IMPORTANT SAFEGUARDS
1.Please read these instructions carefully before using the appliance.
2.Check that your mains voltage corresponds to that stated on the rating plate of
the appliance.
3.Keep out of reach of children or incompetent persons.
4.From time to time check the cord for damages. Never use the appliance shows
any signs of damage but have if checked and repaired by a competent
qualified service. Should the cord be damaged, it must be replaced by a
competent qualified service.
5.Only use the appliance for domestic purposes and in the way indicated in
these instructions.
6.Never immerse the appliance in water or any other liquid for any reason
whatsoever. When cleaning the appliance, refer to the instructions in the
paragraph “Cleaning and care” because the water penetration through the
openings can be very dangerous for your appliance.
7.Never use the appliance near hot surfaces.
8.Before cleaning and when you do not use the appliance, always unplug the
appliance from the power supply .Do not attempt to remove the plug from the
wall socket with wet hands.
9.Never use the appliance outside and always place it in a dry environment.
10.Never use accessories that are not recommended by the producer. They
could constitute a danger to the user and risk to damage the appliance.
11.Never move the appliance by pulling the cord. Make sure the cord cannot get
caught in any way. Do not wind the cord around the appliance and do not bend
it.
12.Stand the appliance on a stable surface so that it cannot fall.
13.Do not place the appliance under a power socket. The power socket must not
be in the hot airflow of the appliance.
14.Always position the heater in such a way that inflammable materials (such as
curtains) cannot be ignited. Ensure at all times that the unit is placed solidly on
its base. Make sure that the air inlet and outlet openings are not blocked. To
avoid any risk of fire, do not cover the heater (ex. With clothes).

15.warning: Do not operate the heater near baths, showers, washbasins,
swimming pools or any other water container. It must be impossible to reach
the commands of your appliance when you are in contact with water.
16.The temperature of the grids may be very high when the appliance is in use.
Avoid contact with the skin.
17.Never use the appliance near inflammable or explosive materials.
18.Do not insert any objects through the grille or into the interior of the appliance.
19.This appliance is not intended for use by persons (including children) with
reduced physical, sensory or mental capabilities, or lack of experience and
knowledge,unless they have been given supervision or instruction concerning
use of the appliance by a person responsible for their safety.
20.Children should be supervised to ensure that they do not play with the
appliance.
(*) Competent qualified service: after sales department of the producer or
importer or any person who is qualified, approved and competent to perform this
kind of repairs in order to avoid all danger. In any case you should return the
appliance to this service.
Components name
1. Thermostat
2. Function selector
3. Osillation Control Button
4. Body
5. Guard
6. Tilt switch
1
2
3
4
5
6

USE
POSITIONING OF THE APPLIANCE
The heater should only be operated at a minimum distance of 50cm from any
wall or other object. Position the air flow in order to optimise the heating of the
room.Avoid corners, small volumes, floors and ceilings.
OPERATION
When the appliance is switched on for the first time, a slight smell may be
emitted. Please ensure sufficient ventilation. This smell will disappear very
quickly.
FUNCTION SELECTOR
0 OFF
Fan without heater
I 900W(low heat output)
II 1800W(full heat output)
Thermostat
Left (-) OFF
Right (+) Maximum
If you selected low or full output, choose the desired temperature with the
thermostat. With the thermostat, the temperature can be regulated steplessly.
When the desired temperature is reached ,the unit will automatically switch off.
Once the temperature has fallen below the per-set level ,the heater will switch on
again.
A pilot light will allow you to check the thermostatic regulation. When the
appliance is heating, this pilot light will be on. It will go out when the desired
temperature is reached.
Oscillation
This appliance also has an oscillation function. To switch the function on, press
the oscillation switch .To stop it ,press the oscillation switch again.
OVERHEAT PROTECTION
This heater is protected with an overheat protection that switches off the
appliance automatically in case of overheat, e.g. due to the total or partial
obstruction of the grids. In this case ,unplug the appliance ,wait about 30
minutes for it to cool and remove the object that is obstructing the grids. Then

switch it back on as described above .The appliance should operate normally.
Should the problem persist ,please contact the nearest customer service.
ANTI-TIPPING OVER SAFETY
Disconnects your appliance when it is tilted or tipped. If your appliance falls,
switch it off, replace it correctly and switch it on again.
CLEANING AND CARE
1. Before cleaning the appliance, ensure it is disconnected from the power
supply and has cooled down completely.
2. To avoid the risk of electric shock, do not clean the heater with water and do
not immerse it.
3. The housing may be wiped with a slightly damp ,lint-fee cloth.
4. If necessary, dust particles accumulated in the air outlet openings may be
removed with a vacuum cleaner.
Disposal:
The packaging material is reusable. Rid yourself of the packaging in an
environmentally friendly way and put it in the collection of recyclable materials.
Dispose of the product and the batteries in view of the
environment if you want to separate. The device and the
batteries should not be thrown into the household garbage. Bring
them to the recycling center for the used electrical and electronic
devices. You can consult to the local government for more
information. Remove the batteries first.
Eurotops Versand GmbH
Hardt 1-3
40764 Langenfeld
Germany
The manual only reflects the technical conditions available under printing. Any
changes in technology and equipment are reserved. @25.07.2011
