Evco EVX012 User manual

EVCO S.p.A. • Code 104X012E104 • page 1/2
EVX012 Alarm module version 1.0
3 USER INTERFACE
3.1 Preliminary signals
The user interface consists of a custom 4-digit display (with decimal
points and function icons) and six keys (SET, UP, DOWN, MUTE, TEST
and ON/STAND-BY).
Operating Statuses:
• “on” status (the instrument is powered and on
• “stand-by” status (the instrument is powered but is switched off via
software)
• “off” status (the instrument is not powered).
Hereafter, with the word “start-up” means the passage from stand-by
status to on status; the word “shutdown” means the passage from on
status to stand-by status.
When th e power is switched back on, the instrument displays the
status that it was in at the time it was disconnected.
3.2 Switching on/off of the instrument
• make sure that the keyboard is not locked and that no other opera-
tion is in progress
• press and hold down the ON/STAND-BY key for 2 sec: the on/
stand-by LED will switch off/on.
3.3 The display
If the instrument is switched on, during normal operation, the display
will show the cell temperature.
If the instrument is switched off, the display will be switched off.
3.4 Activating/deactivating function “test”
• make sure that the keyboard is not locked and that no other opera-
tion is in progress
• press and release the TEST key : the LED will switch on/off.
Pressure of TEST key provokes the closure of the test relay in the alarm
module EVX012 and the lack of power supply in the backup module
EVC99P00X7XXX00; during the lack of power supply, the alarm mod-
ule is powered by the backup battery.
EN ENGLISH
1 IMPORTANT
1.1 Important
Carefully read these instructions before installing and using the product. Pay close attention to the notes on installation and electrical wiring
connections; save these instructions together with the instrument for future reference.
The instrument must be disposed of in accordance with local laws on the collection of electrical and electronic equipment.
2 DIMENSIONS AND INSTALLATION
2.1 Dimensions
The dimensions are expressed in mm (in).
• press and release the SET key while changing the hour: the display
will show “nn” followed by the two minute numbers
• press and release the UP and DOWN keys within 15 sec
• press and release the SET key or do not operate for 15 sec: the clock
LED will switch off.
To exit the procedure:
• press and release the UP or DOWN key until the diplay shows the
cell temperature and then do not operate for 60 sec.
Alternatively:
• press and release the ON/STAND-BY key.
4.2 Setting the upper alarm set
• ensure that the keyboard is not locked and that no other procedure
is in progress.
• press and release the SET key
• press and release the UP or DOWN key within 15 sec
• press and release the SET key or do not operate for 15 sec: the
instrument will exit the procedure.
To exit the procedure before the operation is complete:
• do not operate for 15 sec (any changes will be saved).
The upper alarm set can also be set via parameter SP.
4.3 Setting the configuration parameters
To begin the procedure:
• ensure that no other procedure is in progress
• hold down the UP and DOWN keys for 4 sec: the display will show
“PA”
• press and release the SET key
• press and release the UP or DOWN key within 15 sec to set “-19”
• press and release the SET key or do not operate for 15 sec
• hold down the UP and DOWN keys for 4 sec: the display will show
“SP”.
To select a parameter:
• press and release the UP or DOWN key.
To change a parameter:
• press and release the SET key.
• press and release the UP or DOWN key within 15 sec.
• press and release the SET key or do not operate for 15 sec.
To exit the procedure:
• hold down the UP and DOWN keys for 4 sec and do not operate
for 60 sec (any changes will be saved).
After changing the parameters, suspend power supply flow
to the instrument.
4.4 Restoring the Manufacturer’s Settings
To begin the procedure:
• make sure that no other procedure is in progress.
• hold down the UP and DOWN key for 4 sec: the display will show
“PA”
• press and release the SET key
• press and release the UP or DOWN key within 15 sec to set “149”
• press and release the SET key or do not operate for 15 sec
• hold down the UP and DOWN keys for 4 sec: the display will show
“dEF”
• press and release the SET key
• press and release the UP or DOWN key within 15 sec to set “1”
• press and release the SET key or do not operate for 15 sec: the
display will show “dEF” flashing for 4 sec, after which the instru-
ment will exit the procedure.
• suspend the power supply to the instrument.
To exit the procedure before the operation is complete:
• hold down the UP and DOWN keys for 4 sec during the procedure
(that is, before setting “1”: the settings wil not be restored).
Make sure that the manufacturer’s settings are appropriate
(see chapter 10).
5 HACCP FUNCTION
5.1 Preliminary notes
The instrument is able to store up to 9 HACCP alarms, after which the
most recent alarm will substitute the oldest.
The instrument provides the following information:
• critical value
• the date and time the alarm was signaled
• the duration of the alarm (from 1 min to 99 hours and 59 min, partial
if the alarm is in progress).
CODE ALARM TYPE (CRITICAL VALUE)
AL minimum temperature alarm (the minimum temperature
of the cell during the alarm)
AH maximum temperature alarm (the maximum temperature
of the cell during the alarm)
id door microswitch input alarm (the maximum tempera-
ture of the cell during the alarm); see also parameter i4
PF power supply interruption alarm (cell temperature when
power is restored); see also parameters A10 and A12
Notes:
•to avoid repeatedly storing alarms due to interruptions
in the power supply, disconnect the power when the
instrument is switched off
•if the duration of the power supply interruption alarm is
long enough to cause a clock error (code “rtc”), the instru-
ment will not provide any information about the alarm
duration
•if the instrument is switched off no alarms will be stored
When the problem that caused the alarm disappears, the display is
restored to normal operation, with the exception of the power supply
2.2 Installation
Back panel installation using M3 studs.
2.3 Installation notes
• make sure that the working conditions (operating tempera-
ture, humidity, etc.) fall within the limits inidcated in the tech-
nical specifications
• do not install the device near heat sources (resistors, hot air
ducts, ect.), near devices with strong magneti (large diffu-
sors etc.) and places subject to direct sunlight, rain, humidity,
excessive dust, mechanical vibrations or shaking
• in accordance with laws on safety, protection against possi-
ble contact with electrical parts must be ensured via the cor-
rect installation of the instrument; all the parts that ensure
such protection must be secured in such a way that they
cannot be removed without the using a special tool.
Contact 19-21 of the backup module EVC99P00X7XXX00 will be closed
provoking the activation of the power supply presence digital input
in the alarm module EVX012; the display of the module will show “iA”
flashing and the alarm output will be activated.
3.5 Locking/unlocking the keyboard
To lock the keyboard:
• make sure that no other procedure is in progress
• press and hold down the TEST and ON/STAND-BY keys for 1 sec:
the display will show the message “Loc” for 1 sec.
If the keyboard is locked, the following are not permitted:
• switch on/off of the instrument
• activating/deactivating function “test”
• changing the upper alarm set (with the procedure described in 4.2)
The operations cause the display of the label “Loc” per
1 sec.
To unlock the keyboard:
• press and hold down the TEST and ON/STAND-BY keys for 1 sec:
the display will show the message “UnL” for 1 sec.
3.6 Silencing the Buzzer
• ensure that no other procedure in is progress
• press a key.
4 SETTINGS
4.1 Setting the day and real time
• ensure that the keyboard is not locked and that no other procedures
are in progress
• press and hold down the DOWN key for 1 sec: the display will show
the first label available
• press and release the UP or DOWN key to select “rtc”.
To change the year:
• press and release the SET key: the display will show “yy” followed
by the last two numbers in the year and the clock LED will flash
• press and release the UP or DOWN key within 15 sec.
To change the month:
• press and release the SET key while changing the year: the display
will show “nn” followed by the two numbers of the month
• press and release the UP or DOWN key within 15 sec.
To change the day of the month:
• press and release the SET key while changing the month: the dis-
play will show “dd” followed by the two numbers of the day
• press and release the UP or DOWN key within 15 sec.
To change the hour:
• press and release the SET key while changing the day of the month:
the display will show “hh” followed by the two numbers of the
hour
• press and release the UP or DOWN key within 15 sec.
The hour is displayed using the 24 hour system.
To change the minutes:

EVCO S.p.A. • Code 104X012E104 • page 2/2
interruption alarm (code “PF”) which requires manual restoration of
the normal display.
To manually restore the normal display:
• press a key.
The HACCP LED provides information regarding the storage status of
the alarms; see paragraph 8.1.
5.2 Display of HACCP alarm information
To start the procedure:
• ensure that the keyboard is not locked and that no other operation
is in progress
• hold down the DOWN key for 1 sec: the display will show the first
label available
• press and release the UP or DOWN key to select “LS”
• press and release the SET key: the display will show the most recent
alarm code (or rather, one of the codes shown in the table in para-
graph 5.1) followed by the number “1”; the larger the number is that
follows the alarm code, the older the alarm is).
To select an alarm:
• press and release the UP or DOWN key (to select, for example, “AH3”).
To see information regarding the alarm:
• press and release the SET key: the HACCP LED will stop flashing and
will remain permanently on and the display will show the following
sequence of information (for example):
INFO. MEANING
8.0 the critical value is 8.0 °C/8 °F
StA the display is about to show the date and hour in which
the alarm was signaled
y09 the alarm was signaled in 2009 (data continues ...)
n03 the alarm was signaled in March (data continues ...)
d26 the alarm was signaled on the 26th of March 2009
h16 the alarm was signaled at 16:00 (other data continues)
n30 the alarm was signaled at 16:30
dur the display is about to show the alarm duration
h01 the alarm lasted for 1 hour (other data continues)
n15 the alarm lasted 1 hour and 15 min
AH3 the alarm selected
The display will show each message for 1 sec.
To exit the information sequence:
• press and release the ON/STAND-BY key: the display will show the
selected alarm (“AH3” in the example).
To exit the procedure:
• exit the information sequence
• press and release the UP or DOWN key until the display shows the
cell temperature or do not operate for 60 sec.
Alternatively:
• exit the information sequence
• press and release the ON/STAND-BY key.
If the instrument does not have any alarms stored, the label “LS” will
not be displayed.
5.3 Cancelling the HACCP alarm list
• ensure that the keyboard is not locked and that no other operation
is in progress
• hold down the DOWN key for 1 sec: the display will show the first
available label
• press and release the UP or DOWN key to select “rLS”
• press and release the SET key
• press and release the UP or DOWN key within 15 sec to set “149”
• press and release the SET key or do not operate for 15 sec: the
display will show a flashing “- - - -” for 4 sec and the HACCP LED will
switch off and then the instrument will exit the procedure.
If the instrument does not have any alarms stored, the label “rLS” will
not be displayed.
6 WARNING LIGHTS AND DIRECTIONS
6.1 Warning lights
LED MEANING
Multifunction LED light
If it is on:
• function “test” will be running
Clock LED
if flashing, the day and real time are in the process of being
changed
HACCP HACCP LED
if it is on, all information regarding HACCP alarms has not
been displayed
if it is flashing, the instrument has stored at least one new
HACCP alarm
if it is off, all information regarding the HACCP alarms has
been displayed or the list of HACCP alarms has been can-
celled
Alarms LED
if on, an alarm or error is in progress
°CCelsius grade LED
if on, the temperatures will be displayed using the Celsius
grade unit of measurement:
- parameter P2
°FFahrenheit grade LED
if on, the temperatures will be displayed using the Fahren-
heit grade unit of measurement:
- parameter P2
on/stand-by LED
if on, the instrument is in stand-by mode
7 ALARMS
7.1 Alarms
CODE MEANING
AL Minimum alarm temperatures
Solutions:
• check the cell temperature
• refer to:
- parameter A1
Main consequences:
• the alarm output will be activated
AH Maximum temperature alarm
Solutions:
• check the cell temperature
• refer to:
- parameter SP
Main consequences:
• the alarm output will be activated
id Door microswitch input alarm
Solutions:
• verify the cause of the input activation
• see parameters i1 and i4
Main consequences:
• if parameter is set to 1, the instrument will store the alarm,
provided parameter i2 is not set to -1
• the alarm output will be activated
PF Power supply interruption alarm
Solutions:
• verify the cause of the interruption in power supply
• parameters A10 and A12 are seen
• press a key to restore normal display
Main consequnces:
• if the power supply interruption lasts longer than the
time established with parameter A10, the instrument will
store the alarm
• the alarm output will be activated
iA Multifunction input alarm
Solutions:
• verify the cause of input activation
Main consequences:
• the alarm output will be activated
When the problem that caused the alarm disappears, the instrument
returns to normal function.
8 ERRORS
8.1 Errors
CODE MEANING
Pr1 Cell probe error
Solutions:
• verify that the probe is a type NTC
• verify that the probe is intact
• verify the instrument-probe connection
• check the cell temperature
Main consequences:
• the alarm output will be activated
rtc Clock error
Solutions:
• re-set the day and real time
Main consequences:
• the alarm output will be activated
When the problem that caused the alarm disappears, the instrument
returns to normal operation, with the exception of the clock error
(code “rtc”) which requires that the date and hour be set.
9 TECHNICAL DATA
9.1 Technical data
Case: without cover.
Frontal protection grade: IP 00.
Connections: 6.3 mm faston connectors (0.248 in, power and
outputs), screw terminal board (inputs), 6-outlet connector (serial port).
Operating temperature: from 0 to 55 °C (from 32 to 131 °F, 10 ...
90% relative humidity without condensaton).
Power: 12 VAC/DC, 50/60 Hz.
Preservation of clock data in the absence of power: 24 hr
fully-charged battery.
Battery recharge time: 2 min without interruption (the battery is
recharged by the instrument’s power supply).
Alarm buzzers: incorporated.
Measure inputs: 1 (cell probe) for NTC probe.
Digital inputs: 2 (door switch and power supply presence) for
normally open/normally closed contact (free contact, 5 V 1 mA).
Measurement field: from -40 to 105 °C (from -40 to 220 °F).
Resolution: 0.1 °C/1 °C/1 °F.
Digital outputs: 2 relays:
•test relay: 8 A res. @ 250 VCA (nor-
mally open contact)
•alarm relay: from 5 A res. @ 250 VCA
(normally open contact).
The maximum load current allowed is 16 A.
Serial port: port for communicating with the monitoring system (via
serial interface, via TTL, with a MODBUS communications protocol) or
via programming key.
PT • 03/14

EVCO S.p.A. • Code 104X012E104 • page 3/2
UPPE ALARM SET
upper alarm set
UPPE ALARM SET
upper alarm set
MEASUREMENT INPUTS
offset cell probe
Celsius degree decimal point (for size displayed during normal operation)
1 = YES
temperature unit of measurement (2)
0=°C
1=°F
delay in display of variations in temperature detected by the probes
MAIN REGULATOR
minimum alarm set
maximum alarm set
TEMPERATURE ALARMS
temperature (relative to upper alarm set, that is “SP - A1”; consider A1 without sign) below that at which the minimum temperature alarm
is activated (code “AL”); see also A11
delay in maximum temperature alarm (code “AH”) after the instrument is switched on (3)
temperature alarm delay (code “AL” and code “AH”)
delay in maximum temperature alarm (code “AH”) following the disactivation of the door microswitch input (4)
duration of interruption in the power supply that occurs when the instrument has been running for long enough to cause the storage of
the power interruption alarm when the power supply is restored. (code “PF”)
differential of parameter A1
kind of signal for power interruption alarm (code “PF”); also look at A10
0 = the alarm will not be signalled
1 = the display will show the code “PF” flashing and the buzzer will be activated
2 = the display will show the code “PF” flashing and the buzzer will be activated (this last on condition that the power interruption duration
is higher than time A10)
time between the buzzer is silenced and its re-activation (because of the persistence of the cause that has provoked the activation)
0 = the buzzer is never re-activated
enabling LED HACCP
1 = YES
DIGITAL INPUTS
type of door microswitch input contact
0 = normally open (active input with closed contact)
1 = normally closed (active input with open contact)
delay in signaling of door microswitch input alarm (code “id”)
-1= the alarm will not be signaled
storage of door microswitch input alarm (code “id”) (5)
1 = YES
type of mutlifunction input contact
0 = normally open (active input with closed contact)
1 = normally closed (active input with open contact)
multifunction input alarm delay (code “iA”)
DIGITAL OUTPUTS
enabling of alarm output disactivation with the silencing of the buzzer
1 = YES
SERIAL NETWORK (MODBUS)
instrument address
baud rate (0 = 2,400 baud, 1 = 4,800 baud, 2 = 9,600 baud, 3 = 19,200 baud)
parity (0 = none, 1 = odd, 2 = even)
10 WORKING SETPOINT AND CONFIGURATION PARAMETERS
10.1 Working setpoint
MIN. MAX. UM RESERV. RESERV. RESERV. DEF.
r1 r2 °C/°F (1) 2.0 -2.0 -18.0 10.0
10.2 Configuration parameters
PAR. MIN. MAX. UM RESERV. RESERV. RESERV. DEF.
SP r1 r2 °C/°F (1) 2.0 -2.0 -18.0 10.0
PAR. MIN. MAX. UM RESERV. RESERV. RESERV. DEF.
CA1 -25.0 25.0 °C/°F (1) 0.0 0.0 0.0 0.0
P101---- 1111
P201---- 0000
P80250ds 5555
PAR. MIN. MAX. UM RESERV. RESERV. RESERV. DEF.
r1 -99.0 r2 °C/°F (1) -50.0 -50.0 -50.0 -50.0
r2 r1 99.0 °C/°F (1) 50.0 50.0 50.0 50.0
PAR. MIN. MAX. UM RESERV. RESERV. RESERV. DEF.
A1 -99.0 99.0 °C/°F (1) -10.0 -10.0 -10.0 -10.0
A6 0 240 min 240 240 240 240
A7 0 240 min 15 15 15 15
A9 0 240 min 15 15 15 15
A100240min 1111
A11 0.1 15.0 °C/°F (1) 2.0 2.0 2.0 2.0
A1202---- 0000
A13 0 99 min 10 10 10 10
A1401---- 1111
PAR. MIN. MAX. UM RESERV. RESERV. RESERV. DEF.
i101---- 0000
i2 -1 120 min 30 30 30 30
i401---- 0000
i601---- 0000
i70120min 0000
PAR. MIN. MAX. UM RESERV. RESERV. RESERV. DEF.
u401---- 0010
PAR. MIN. MAX. UM RESERV. RESERV. RESERV. DEF.
LA 1 247 - - - - 247 247 247 247
Lb03---- 2222
LP02---- 2222
(1) the unit of measurement depends on P2
(2) properly set the parameters corresponding to the regulators after modifying parameter P2
(3) the parameter has effect even after an interruption in the power supply that occurs while the instrument is switched on
(4) during activation of the door microswitch input, the maximum temperature alarm is absent, provided the alarm was signaled after the activation of the input
(5) the instrument stores the alarm once the time established in parameter i2 has expired; if parameter i2 is set to -1, the instrument will not store the alarm.

EVCO S.p.A. This document belongs to EVCO; unless you are authorized by EVCO, you can not publish this document.
Via Feltre 81, 32036 Sedico Belluno ITALY EVCO does not take any responsibility about features, technical data and possible mistakes related in this document.
Phone [phone] • Fax [phone] EVCO does not take any responsibility about damages coming by the non-observance of additional information.
[email protected] • www.evco.it EVCO reserves the right to make any change without prior notice and at any time without prejudice the basic safety and operating featuRESERV.
EVCO S.p.A. • Code 104X012E104 • page 4/2
11 ELECTRIC CONNECTION
11.1 Preliminary notes
With reference to the electrical wiring diagrams:
• the serial port is the port for communicating with the monitoring system (via serial interface, via TTL, MODBUS communications protocol), with the programming key or with the data recording device EVUSBREC01;
the port must not be used for these three different purposes simultaneously.
11.2 Electrical wiring
