Pittway NOTIFIER UZC-256 Installation manual

Document 15976
07/30/97 Revision:B1
P/N15976:B1 ECN97-304
UZC-256
Universal Zone Coder
Programming Instructions
12 Clintonville Road
Northford, CT 06472
Phone: [phone]
Fax: [phone]

2UZC-256Programming 15976:B1 07/30/97

UZC-256Programming 15976:B1 07/30/97 3
Table of Contents
Chapter 1: Introduction
Overview ..........................................................................................5
What's in the Manual ........................................................................5
Key Terms and Icons........................................................................5
Before you Begin..............................................................................5
For Further Reference ......................................................................6
The UZC-256 Programming Kit ........................................................6
How to Connect the UZC-256 to a PC .............................................6
Installing the UZC-256 Application ..................................................7
Chapter 2: Getting Started
Overview ..........................................................................................8
Tasks required to program the UZC ................................................8
A Map of the UZC Application..........................................................9
UZC-256 Application Screens...........................................................9
Starting the UZC-256 Application ..................................................10
Opening Screen..............................................................................10
Main Menu .....................................................................................11
Chapter 3: Programming the UZC
Overview ................................................................................. 12
Program Modes –Counting and Coding ...................................12
Starting a Program File..............................................................12
Entering Output Codes.............................................................13
Formatting Output Codes.........................................................13
Sample Output Codes...............................................................14
Programming in Counting Mode................................................14
Terms used in Counting Mode .................................................14
How to Complete the Counting Screen....................................15
Storing the Program File ...........................................................15
Sample Counting Screen...........................................................15
Programming in Coding Mode .................................................16
Overview ...................................................................................16
Entering Variable Codes in a Coding Screen ............................16
All Call and Receive Only ..........................................................17
Variable Codes Timing Diagram ...............................................17
Programming an S5000/S500 .....................................................18
Overview ...................................................................................18
Sample Coding Screen..............................................................18
How to Create a Program File...................................................18
Annunciator Options ...............................................................19
Programming an S5000/AIM-200 ...............................................20
Overview ...................................................................................20
Sample Coding Screens ............................................................20
How to Create a Program File..................................................21

4UZC-256Programming 15976:B1 07/30/97
Table of Contents
Programming an AM2020/AFP1010 ...........................................22
Overview ...................................................................................22
Sample Coding Screens ............................................................22
How to Create a Program File..................................................23
Programming an AFP-400 ...........................................................24
Overview ...................................................................................24
AFP-400 Coding Guidelines ......................................................24
Coding AFP-400 Software Zones...............................................24
Zone Code Sample Programming Screens................................25
Coding AFP-400 Modules and Detectors ..................................26
Module Sample Programming Screens .....................................26
Programming a General Alarm..................................................28
Sample Coding Screen..............................................................28
How to Create a Program File...................................................28
Examples of General Code .......................................................29
Working with a Program File......................................................30
Overview ...................................................................................30
Modifying a Program File ..........................................................30
Chapter 4: Transferring Program Files
Copying Program Files (PC to a UZC )...........................................31
Copying Program Files ...................................................................32
Copying a Program File (UZC to PC ) ............................................32
Appendix A: Troubleshooting
Overview ........................................................................................33
Troubleshooting the UZC ..............................................................33
Null Modem Cable Pinouts ............................................................33

UZC-256Programming 15976:B1 07/30/97 5
Before you
Begin • Instructions in this manual assume you are familiar with using a
personal computer (PC) and a disk operating system (such as
MS-DOS®). Refer to your DOS manual if needed.
• The UZC-256 does not function with the following: a) indicating
devices that do not produce a steady periodic or non-periodic
sound; and b) appliances that produce their own code (such as
appliances with electronic sounds).
Chapter 1: Introduction
Overview
What's in the
Manual
Key Terms
and Icons
The UZC-256 Universal Zone Coder is a one-board module that
stores and communicates customer-specified codes for up to 256
initiating zones in a fire alarm system. You can create a program file,
containing coded information on a PC and store the file on the UZC-
256. Fire alarm systems that operate with the UZC-256 include the
following:
• S5000/S500
• S5000/AIM-200
• AM2020/AFP1010
• AFP-400
Key Terms and icons in this manual include the following:
Coded Output – Coded information from the UZC-256 Application
that controls the three relay outputs on the UZC-256 module.
Control Relay – One of three relays on the UZC-256 module,
controlled by the UZC-256 Application, that supplies coded informa-
tion to designated circuits.
Output Code – Four-digit code in the UZC-256 Application to specify
an addressable or intelligent module, device, or annunciator.
Program file – A PC file containing coded information for the
UZC-256.
UZC-256 Application – The menu-driven program used to create a
program file.
UZC-256 – used throughout the manual to refer to the UZC-256
module.
This manual contains information on the following:
• How to install and configure the UZC-256 for programming.
• How screens and menus work, including a map of the UZC-256
application.
• How to use the UZC-256 application and transfer files.
Warning or caution condition that can cause damage or loss
of data.
!
General information about the UZC-256 and programming.

6UZC-256Programming 15976:B1 07/30/97
The UZC-256 Programming Kit consists of a software kit and a
hardware kit. Table 1 lists the contents and part numbers for each
kit.
Kit Contents Part Number
UZC-SI
Programming Two low density floppy disks: • 5.25"
• 3.5"
Both disks contain the same files.
75238
75239
UZC-HI Hardware • Null modem cable, 9-pin socket
to 9-pin socket
• Adapter, 9-pin connector to
25-pin
socket
• AC Power Adapter
46028
46029
46027
Introduction
The UZC-256
Programming
Kit
References to other manuals and chapters are listed under topics
where further documentation could provide assistance. For instance,
programming sections contain references to other control panel
programming guides.
Connect the UZC-256 to the PC to load or download a program file
on the UZC-256. Figure 1 shows a block diagram of the UZC-256
module connected to a PC. Figure 1 contains instructions for
connecting a PC to the UZC-256 module.
Connecting a
UZC-256
to a PC
Figure 1: Connecting a PC to a UZC-256 Module
Continued on the next page…
For Further
Reference
Table 1: Contents of the UZC-256 Programming Kit
Null modem cable
(46028)
PC Serial Port
(COM1orCOM2)
9-pin plug

UZC-256Programming 15976:B1 07/30/97 7
!
WARNING: Never connect a PC to a UZC-256 module
that is installed in a fire alarm system with an earth
ground fault condition. Doing so can damage the PC
and cause loss of data.
You can install and use the UZC-256 Application on a stand-alone
PC. You only need to connect the PC to the UZC-256 when transfer-
ring files.
Step Action
1Configure the PC for a serial port at COM1 or COM2.
Note: If the PC does not have a 9-pin serial port, use the supplied
9-pin to 25-pin adapter.
2Turn off power to the UZC module and the PC.
3Plug one end of the null modem cable into the 9-pin connector on
the UZC module.
4Plug the other end of the null modem cable into the serial port on
the PC.
5Set DIP Switch 1 on the UZC module to "Program" mode by putting
the switch in the down position (Figure 1).
Connecting a
UZC-256 to a
PC, continued
Introduction
The two disks (5.25" and 3.5") in the UZC-256 software kit contain
identical files. Use one of the disks to install the UZC-256 applica-
tion.
Installing the
UZC-256
Application
Step Action
1Put the program disk in a disk drive.
2If installing on a hard drive:
a. Create a directory named “UZC.”
b. Copy the contents of the disk to the directory.
3Type the pathname or the letter of the disk drive.
4Type: “UZC” to start the program.
Table 3: Installing the UZC-256 Application
Before running the UZC-256 application, review the contents of the
“Readme.txt” file, included in the installation files.
Table 2: Connecting a PC to the UZC-256
To connect the UZC-256 to the PC, follow these steps.

8UZC-256Programming 15976:B1 07/30/97
Chapter 2: Getting Started
This chapter covers topics that prepare you for programming the UZC-
256, including how to start the UZC-256 application. This section
contains the following topics:
Overview
Figure 2 contains a diagram that outlines the order of tasks required
to program the UZC-256. References to this manual are listed to the
right of the each box.
Steps for
Creating a
Program File
Step 6: Connect the PC to
the UZC.
Step 5: Save the program
file.
Step 4: Select the General
Alarm screen enter code.
Step 3: Enter program
variables and Code.
Step 2: Load a UZC program
file.
Step 1: Select the
Programming Mode:
Counting
or Coding
Step 7: Download the
program file to the UZC.
Step 8: Run and test the
UZC program with the FACP.
“Programming Modes”
“Starting a Program File”
“Programming”
“Programming the
General Alarm”
“Working with
Program Files”
“Connecting the UZC
to a PC”
“Transferring Files”
FACP Manual
Figure 2: Creating a Program File
Continued on the next page…
…nonoitamrofnIroF…gniwollofehtotoG
noitacilppaehtfoweivrevonAnoitacilppAehtfapaMA
ehtmargorpotodotdeenuoytahW CZU sksaTgnimmargorP
sneercSCZUfoweivrevonAsneercSCZU
noitacilppaehttratsotwoHnoitacilppAehtgnitratS
tcelesotuneMniaMehtgnisU snoitpo niaM:snoitpOgnitceleS uneM
Table 4: Getting Started

UZC-256Programming 15976:B1 07/30/97 9
Getting Started
The UZC Application is a menu-driven application. Figure 3 contains a
map of the menus in the UZC application.
A Map of the
UZC-256
Application
UZC-256
Application
Screens
Table 5 lists the types of screens offered by the UZC-256 application.
Figure 3: A System Map of the UZC-256 Application
ehtesU …gniwollof …oT
neercSgninepOehtretnednanoitacilppaCZUehttratS neewtebdetcennoctroplairesehtforebmun .CPruoydnaCZUeht
uneMniaMelif,snoitpomargorptcelesdnayalpsiD CZUehttixedna,snoitporefsnart .noitacilppa
neercSgnitnuoCrofsnoitidnocdnasecivedyficepS .edomgnitnuoCniCZUehtgnimmargorp
neercSgnidoCCZUehtgnimmargorprofnoitamrofniretnE .edomgnidoCni
Table 5: UZC Screens

10 UZC-256Programming 15976:B1 07/30/97
Figure4: OpeningScreen
Getting Started
Starting the application includes two tasks:
1. Opening the application and completing the Opening screen.
2. Displaying the Main Menu where you select programming and
file transfer options.
Starting
the UZC-256
Application
Opening
Screen Start the application by typing the “UZC” at the DOS prompt. The
Opening screen displays.
The Opening screen serves as the first screen—as well as the “top”
screen—of the UZC-256 application. The screen also prompts for
the number of the serial port connected between the PC and the
UZC-256.
Purpose of the
Screen
You can program the UZC-256 without connecting the PC, but the
UZC-256 application requires an entry for the serial port to con-
tinue to the next screen. If transferring files between the UZC-256
and the PC, refer to “Connecting the UZC-256” in Chapter 1.
You can get to the Opening screen in one of two ways:
• Start the application; or
• Select option “A” from the Main Menu.
How to get the
Screen
The Opening screen prompts for the number of the serial port
connecting the UZC-256 to your PC. Complete the screen as
follows:
1. The screen lists two choices: COM1 or COM2.
2. Type a number (1 or 2) corresponding to the serial port con-
nected to the UZC-256. Refer to the note below.
Continued on the next page…
How to Use
the Screen

UZC-256Programming 15976:B1 07/30/97 11
Getting Started
The Main Menu displays after you successfully enter a number for the
serial port. The following subsections explain how to use the Main
Menu.
Main Menu
The Main Menu provides options that let you get program options,
load files, leave the application, or start over with the Opening Screen.
Function
The UZC application automatically displays the Main Menu after you
complete the Opening screen. Program screens also provide an
option to get back to the Main Menu at any time.
Figure 5 contains a display of the Main Menu with option 3 selected.
Figure 5: Main Menu
How to Use
the Screen Table 6 contains a function table that shows how to use the Main Menu.
Selecting Option... Lets you...
1) Display from Diskfile: Load a program file stored on disk.
2) Display from UZC Load a program file stored in the UZC.
3) Display Sample File Load a sample program file that you
can modify.
4) Copy Codes from Diskfile to UZC Load a UZC program file created on a
PC into UZC memory.
5) Copy Codes from UZC to Diskfile Load a program file stored in UZC
memory into PC memory.
6) Exit to DOS Leave the application and return to
the DOS prompt.
A) Change Serial Port Return to the Opening Screen to select
the COM port.
Table 6: Selecting Main Menu Options
Getting the
Main Menu

12 UZC-256Programming 15976:B1 07/30/97
Chapter 3: Programming the UZC
This chapter explains how to create and modify a program file,
organized into the following topics:
• Program modes
• Starting a program file
• Entering Output Codes
• Program the UZC as a Counter
• Program the UZC as a Coder
• Program the General Alarm
• Modifying a program file
Overview
The UZC application provides two programming modes, listed in
Table 7.
Program Mode… Allows you to…
Counting Program the UZC output relays to activate after a specific
number of alarms occur within pre-defined range of
annunciators.
Coding Program up to 256 addressable devices or zones,
depending on the capacity of the fire alarm system. When
the FACP senses an active coded device or circuit, the UZC
sends a pulse to the notification appliance via the UZC
control relays.
Table 7: Program Modes
Program
Modes:
Counting
and Coding
Figure 6: Starting a Program File
Access the Main Menu to display a sample program file as shown in
Figure 6.
Starting a
Program File
Continued on the next page…

UZC-256Programming 15976:B1 07/30/97 13
Display a sample program file by following the instructions in
Table 8.
Programming the UZC
Starting a
Program File,
continued
Table 8: Getting a Sample Program File
Programming involves filling in data fields on program screens. Data
fields vary according to the program mode and the system. The
programming sections contain details of filling in system-specific or
programming-specific data fields.
Filling in output codes, however, is common to all programming
modes and systems. You enter a unique four-digit output code to
program the following:
• Installed circuits for the S5000/S500 and S5000/AIM-200.
• Annunciator points representing software zones or initiating
devices in the AM2020/AFP1010.
Output codes consist of four digits, using a combination of decimal
and hexadecimal numbers.
Formatting
Output Codes
Entering
Output Codes
Continued on the next page…
petSnoitcA
1wodniwA”.eliFelpmaSyalpsiD“,3noitpotceleS gnimmargorpowtfoeciohcehtgnivigsyalpsid .gnidoCdnagnitnuoC:sedom
2.noitporuoyforebmunehtepyT
margorpelpmasa,gnitnuoC,1noitpotcelesuoyfI wena,gnidoC,2noitpotcelesuoyfI.syalpsidneercs .syalpsidwodniwnoitpo
3ottnawuoymetsysehtforebmunehtepyT .margorp .syalpsidneercsmargorpelpmasA

14 UZC-256Programming 15976:B1 07/30/97
Programming the UZC
Table 9 contains a conversion of decimal to hexadecimal numbers.
Number Hexadecimal Equivalent
10 A
11 B
12 C
13 D
14 E
15 F
Formatting
Output
Codes,
continued
Sample
Output Codes
Table 9: Hexadecimal Conversion
Table 10 contains sample entries for output codes. Column 1
contains sample output codes; column 2 contains the numbers as
typed from the keyboard.
To get output code… Type…
4-5 45
2-3-4 234
0-2-13-5 02D5
0-10-4-0 0A40
No Code 0000 or XXXX (see note)
Table 10: Sample Output Codes
Counting mode lets you program the UZC control relays to activate
after a specific number of devices alarm occur within a defined
“window” of annunciator addresses. The UZC monitors the control
relays within the window. When the specified number of devices
activate, the UZC sends a pulse through a control relay to the
notification appliance.
Programming
in Counting
Mode
Count – the number of devices set to activate a UZC control relay.
control relay – a relay on the UZC module wired to a notification
appliance.
window – a range of annunciator addresses defined by start and stop
address.
Terms used
in Counting
Mode
“0000” does not sound a zone code, but does count for General
Alarm use. “xxxx” does not sound a zone code and does not count
for General Alarm use.
AM2020/AFP1010 and AFP-400 systems can support up to 32
annunciator addresses, each consisting of 64 points. S5000, S500,
and S5000/AIM-200 systems support a lesser number of annuncia-
tors, depending on the number of installed modules.
Continued on the next page…

UZC-256Programming 15976:B1 07/30/97 15
Programming the UZC
Figure 7 shows a display of a sample counting program screen.
Sample
Counting
Screen
Table 11 explains how to complete the Counting screen.
Figure 7: Sample Counting Screen
How to
Complete
the Counting
Screen
Entry Field Description Complete as
follows…
Start Counting
From: The address (AA) and the point (PP) of an annunciator that defines the
beginning point of the counting
window.
AA (1-32) and
PP (1-64)
Stop Counting At: The address (AA) and the point (PP)
of an annunciator that defines the
end point of the counting window.
AA (1-32) and
PP (1-64)
Receive Only
(Y/N?) Receive Only = Y sets annunciators in the counting window to only
receive data from the FACP.
Specifying “Y” allows other
annunciators to use addressed points
in the count window.
Receive Only = N sets annunciators
in the counting window to receive
data from the FACP and transmit
data to the FACP.
Type: “Y” or “N”
Relay 1 activates…
Relay 2 activates…
Relay 3 activates…
Program a UZC control relay to
pulse a notification appliance after a
specified number of annunciators in
the Count window activate.
Number of counts
(1-10) for each UZC
control relay
Table 11: Completing a Counting Program Screen
➍
➌
➋
➊
Relays 1, 2, and 3
programmed to
activate after 3, 5,
and 9 devices go off
respectively.
Defines all devices between
0201 and 0256.
When finished completing the screen:
1. Press ESC to save the file and return to the main menu. If the
following message displays:
One or more of the input fields contains out-of-range data. Review
all fields, modify as needed, and press <ESC>.
2. From the Main Menu, download the file to the UZC or exit the
application.
Storingthe
Program
File

16 UZC-256Programming 15976:B1 07/30/97
Coding mode allows you to program up to 256 separate and distinct
codes. A code consists of the device address and the assigned number of
a point. The UZC can use up to four annunciator addresses. Each
annunciator point contains up to 64 points.
The UZC monitors each programmed point. When a device at one of the
points activates, the UZC sends a pulse through one of the control relays
to a notification appliance.
This section covers the following topics:
• How to enter output codes and variable codes.
• Sample coding screens.
• How to create program files from the sample screens.
Entering
Variable
Codes in a
Coding
Screen 1
25
Figure 8: Code Variables
When programming in coding mode, a sample General Alarm
coding screen appears as the last screen.
Programming in Coding Mode
Table 12: Variable Codes
Continued on the next page…
➊
➋
Each coding screen contains a set of six variable fields that define the
zone codes assigned to each circuit or annunciator point. Before pro-
gramming zone codes, complete these fields as shown below.
➍➏
➎➌
Variable Code You can specify the... By entering a value
between…
No. Rounds Number of times a code
sounds. 1-99 (typical value: 4)
Delay Time Time period from alarm to
start of a specified code. 1-99 seconds (recommended: 5 sec.
for S5000; 5 sec. for
AM2020)
Pulse Time Duration of one pulse. 0.0-1 second (0.01sec.
increments)
Pulse Pause Time period between pulses
within a digit of a specified
code.
0.0-1sec. (0.01 sec.
increments)
Digit Pause Pause between digits of a
specified code. 0.0-9.9 sec. (0.1sec. increments).
Round Pause Pause between sounding of
each round of code. 0.0-99 sec.
Overview

UZC-256Programming 15976:B1 07/30/97 17
Coding screens also contain the “All Call” and “Receive Only” options.
Enter values for these fields according to the following:
Do not select All Call and Receive Only at the same time.
Receive Only
Receive Only means that a device can only receive information from the
FACP. You can select this option if other Receive/Transmit devices
share an EIA-485 address.
All Call and
Receive
Only
All Call
All Call is an option that allows the UZC to activate all indicating circuits
(Indicating, speaker, and releasing) at the start of the General Alarm
code. Table 13 lists the systems supporting the All Call option and the
values to enter in the “All Call” field.
Table 13: All Call Options
CAUTION: The All Call option will activate Time Control Modules
TCM-2 and TCM-4. To disable the All Call option, program circuits on
the modules for Switch Inhibit. Refer to the TCM-2 or TCM-4 Manual.
!
Figures 9 and 10 show a sample timing diagram that results from the
variables and output code (0121) shown in Figure 8.
Variable
Codes
Timing
Diagram
Programming in Coding Mode, Continued
Figure 10: Timing Diagram – Two Rounds of Output Code
Figure 9: Timing Diagram – One Round of Output Code “1-2-1”
System Support All Call? Enter…
S5000 Yes, but only with CPU part numbers
73210
or greater Y or N
S500 No N
AM2020/AFP1010 No N

18 UZC-256Programming 15976:B1 07/30/97
Programming an S5000/S500
S5000/
S500
Overview
This section contains a sample S5000/S500 coding screen (Figure 11)
and instructions for completing the screen to create a program file.
For further information on S5000/S500 programming, refer to the
following:
For Information on… Go to the following…
How to enter output codes Chapter 3, “Entering Output Codes”
How to enter all other fields on the
screen Chapter 3, “Entering Program Variables”
S5000/S500 devices and modules S5000 Operating Guide (PN 15581)
Sample
Coding
Screen
Annunciator Mode
Window Display
Figure 11: Sample S5000/S500 Coding Screen
Follow the instructions in Table 14 to create a program file from the
coding screen.
How to
Create a
Program File Step Action
1Type: “E” to modify values on the screen.
2Enter the address size and the starting annunciator point (1).
3Enter the values for variable codes.
4Enter codes for annunciators 1 and 2.
5If programming annunciators 3 and 4, press PgDn to get the second
screen. Enter codes for the annunciators.
6When finished programming the AM2020/AFP1010, press PgDn to get
the General Alarm screen (refer to “Programming the General Alarm”).
7When finished press ESC. The following window dispays:
8Type: “S” to save as a program file.
Table 14: S5000 Annunciator Modes
Continued on the next page…
Figure 11 contains a sample S5000/S500 coding screen.

UZC-256Programming 15976:B1 07/30/97 19
Programming an S5000/S500
Table 15 contains a list of the S5000/S500 annunciator options,
along with address and point information.
Annunciator
Options
Annunciator
Option Size Address
asssigned to
UZC-256 Max. number
of points Refer to...
1) 1-64 points 1 1 64
2) 65-128 points 21 and 2 128
3) Dual 1-64 1 2 64 Notes 1, 2
4) Quad 1-64 1 4 64 Notes 1, 3
5) Dual -128 23 and 4 128 Notes 1, 4
Table 15: S5000 Annunciator Modes
Notes:
1) System 5000 only.
2) Assume one 64-point Receive/Transmit annunciator at address 1.
3) Assume three 64-point Receive/Transmit annunciators at ad-
dresses 1, 2, and 3.
4) Assume one 64-point Receive/Transmit annunciator at addresses
1 and 2.

20 UZC-256Programming 15976:B1 07/30/97
Programming an S5000/AIM-200
This section contains sample S5000/AIM-200 coding screens and
instructions for completing the screens to create a program file. For
further information on S5000/AIM-200 programming, refer to the
following:
Overview
For Information on… Go to the following…
How to enter output codes for devices
and annunciators. Chapter 3, “Entering Output Codes”
How to enter all other fields on the
screen. Chapter 3, “Entering Program Variables”
S5000/S500 devices and modules. S5000 Operating Guide (PN 15581)
AIM-200 modules and devices. AIM-200 Operating Guide
Figure 12 contains a sample of the first S5000/AIM-200 coding screen;
Figure 13 contains a sample of the second coding screen.
2
Figure 13: Sample S5000/AIM-200 Coding Screen (Page 2)
Figure 12: Sample S5000/AIM-200 Coding Screen (Page 1)
Continued on the next page…
Sample
Coding
Screens
➊
➋
➌
