Evco C-PRO 3 CLIMA sistema+ User guide

Evco S.p.A. c-pro 3 CLIMA sistema | Installer manual ver.1.0 | Code 144CP3CSE104
page 1 of 92
C-PRO 3 CLIMA sistema
Climatic modules for the air conditioning
and heating of buildings
ENGLISH
INSTALLER MANUAL er. 1.0
CODICE 144CP3CSE104

Evco S.p.A. c-pro 3 CLIMA sistema | Installer manual ver.1.0 | Code 144CP3CSE104
page 2 of 92
Important
Important
ead this document thoroughly before installation and before use of the device and follow all recommendations; keep
this document with the device for future consultation.
The following symbols support reading of the document:
indicates a suggestion
indicates a warning.
The device must be disposed of in compliance with local Standards regarding the collection of electric and electronic
equipment.

Evco S.p.A. c-pro 3 CLIMA sistema | Installer manual ver.1.0 | Code 144CP3CSE104
page 3 of 92
Index
1 GENE ALITIES ........................................................................................................................................ 7
1.1 Description..................................................................................................................................... 7
2 APPLICATIONS ........................................................................................................................................ 8
2.1 Application layouts .......................................................................................................................... 9
3 INSTALLATION ...................................................................................................................................... 10
3.1 Dimensions .................................................................................................................................. 10
3.1.1 Thermal power plant module dimensional drawing (MCCT). ............................................................ 10
3.1.2 Zone modules (MCZN), dehumidifier (MCDE) and solar panels (MCPS) dimensional drawing. ............. 10
3.1.3 Graphical display dimensional drawing (Vroom). ........................................................................... 11
3.2 Assembly ..................................................................................................................................... 11
3.2.1 Assembly of thermal power plant modules (MCCT), Zone (MCZN), Dehumidifier (MCDE) and solar panels
(MCPS) ……………………………………………………………………………………………………………………………………………………………..11
3.2.2 Display Assembly (Vroom) ......................................................................................................... 12
3.3 Electric connections ....................................................................................................................... 13
3.3.1 Thermal power plant electric connections (MCCT). ........................................................................ 13
3.3.2 Thermal power plant electric connections (MCCT) hecto + ............................................................. 15
3.3.3 Zones electric connections (MCZN). ............................................................................................ 16
3.3.4 Dehumidifier electric connections (MCDE). ................................................................................... 17
3.3.5 Solar panels electric connections (MCPS). .................................................................................... 18
3.4 egulators network configuration .................................................................................................... 19
3.4.1 MCCT thermal power plant controller network configuration ........................................................... 20
3.4.2 MCZN zone controllers network configuration ............................................................................... 20
3.4.3 Network configuration of controllers for additional MCDE dehumidifiers ........................................... 21
3.4.4 MCPS solar panels controller network configuration ....................................................................... 22
3.5 Displays network configuration ....................................................................................................... 22
3.5.1 Public terminal ......................................................................................................................... 22
3.5.2 Module private terminal ............................................................................................................. 23
3.5.3 Zone private terminal ................................................................................................................ 24
4 USE INTE FACE .................................................................................................................................. 26
4.1 Display and keyboard .................................................................................................................... 26
4.1.1 Built-in interface ....................................................................................................................... 26
4.2 Navigation through the applications making up the system ................................................................ 27
4.2.1 Access a c-pro 3 hecto MCZN zone regulator ................................................................................ 27
4.2.2 Access a regulator for additional c-pro 3 hecto MCDE dehumidifiers ................................................ 27
4.2.3 Access the regulator for c-pro 3 hecto MCPS solar panels .............................................................. 27
5 c-pro 3 mega MCCT regulator ................................................................................................................. 28
5.1 List of pages ................................................................................................................................ 28
5.2 Alarms/log menu .......................................................................................................................... 29
5.2.1 Alarms log ............................................................................................................................... 29
5.2.2 eset active alarms ................................................................................................................... 29
5.2.3 eset alarms log ....................................................................................................................... 29
5.3 Clock menu .................................................................................................................................. 30
5.4 Maintenance menu ........................................................................................................................ 30
5.5 Installer menu .............................................................................................................................. 31
5.6 Main OFF page.............................................................................................................................. 31
5.7 Main ON page ............................................................................................................................... 32
5.8 State pages .................................................................................................................................. 32

Evco S.p.A. c-pro 3 CLIMA sistema | Installer manual ver.1.0 | Code 144CP3CSE104
page 4 of 92
5.8.1 Delivery line L1 and delivery line L2 state page ............................................................................ 33
5.8.2 State page and access to the MCPS solar panels module ................................................................ 33
5.8.3 State and access page of the MCZN zone regulators modules ......................................................... 34
5.9 Configuration parameters .............................................................................................................. 34
5.9.1 List of MAINTENANCE menu configuration parameters ................................................................... 34
5.9.2 List of INSTALLE menu configuration parameters ........................................................................ 38
5.10 State of the unit ........................................................................................................................... 39
5.10.1 OFF state due to alarm .......................................................................................................... 40
5.11 Summer/winter functioning mode ................................................................................................... 40
6 c-pro 3 hecto MCZN regulator ................................................................................................................. 41
6.1 List of pages ................................................................................................................................ 41
6.2 Main page .................................................................................................................................... 42
6.3 Zones status ................................................................................................................................ 43
6.4 Main menu ................................................................................................................................... 43
6.4.1 Alarms menu............................................................................................................................ 43
6.4.2 Setpoint menu ......................................................................................................................... 43
6.4.3 Maintenance menu .................................................................................................................... 44
6.4.4 Installer menu .......................................................................................................................... 44
6.5 On/Off pages ................................................................................................................................ 45
6.6 System Network page ................................................................................................................... 45
6.7 Configuration parameters .............................................................................................................. 46
6.7.1 List of MAINTENANCE menu configuration parameters ................................................................... 46
6.7.2 List of INSTALLE menu configuration parameters ........................................................................ 48
6.8 State of the unit ........................................................................................................................... 51
6.9 State of Zone A and Zone B ........................................................................................................... 51
7 c-pro 3 hecto MCDE regulator ................................................................................................................. 51
7.1 List of pages ................................................................................................................................ 51
7.2 Main page .................................................................................................................................... 52
7.3 Status ......................................................................................................................................... 52
7.4 Main menu ................................................................................................................................... 53
7.4.1 Alarms/log menu ...................................................................................................................... 53
7.4.2 Alarms log ............................................................................................................................... 53
7.4.3 eset active alarms ................................................................................................................... 53
7.4.4 eset alarms log ....................................................................................................................... 54
7.4.5 Maintenance menu .................................................................................................................... 54
7.4.6 Installer menu .......................................................................................................................... 54
7.5 On/Off pages ................................................................................................................................ 55
7.6 System Network page ................................................................................................................... 55
7.7 Configuration parameters .............................................................................................................. 56
7.7.1 List of MAINTENANCE menu configuration parameters ................................................................... 56
7.7.2 List of INSTALLE menu configuration parameters ........................................................................ 58
7.8 State of the unit ........................................................................................................................... 59
8 c-pro 3 hecto MCPS regulator ................................................................................................................. 59
8.1 List of pages ................................................................................................................................ 59
8.2 Main page .................................................................................................................................... 60
8.3 State pages .................................................................................................................................. 60
8.3.1 Functioning state of DHW circuit (boiler) ...................................................................................... 60
8.3.2 Functioning state of solar panels circuit 1 and 2 ............................................................................ 61
8.3.3 Functioning state of auxiliary circuit ............................................................................................ 61

Evco S.p.A. c-pro 3 CLIMA sistema | Installer manual ver.1.0 | Code 144CP3CSE104
page 5 of 92
8.4 Main menu ................................................................................................................................... 62
8.4.1 Alarms/log menu ...................................................................................................................... 62
8.4.2 Alarms log ............................................................................................................................... 62
8.4.3 eset active alarms ................................................................................................................... 62
8.4.4 eset alarms log ....................................................................................................................... 62
8.4.5 Set-point menu ........................................................................................................................ 63
8.4.6 Maintenance menu .................................................................................................................... 63
8.4.7 Installer menu .......................................................................................................................... 64
8.5 System Network page ................................................................................................................... 64
8.6 Configuration parameters .............................................................................................................. 65
8.6.1 List of MAINTENANCE menu configuration parameters ................................................................... 65
8.6.2 List of INSTALLE menu configuration parameters ........................................................................ 67
8.7 State of the unit ........................................................................................................................... 69
9 egulations .......................................................................................................................................... 69
9.1 egulation of the zone temperature (MCZN, MCCT modules) .............................................................. 70
9.1.1 egulation principle .................................................................................................................. 70
9.1.2 Management of the zone heating/cooling manifolds ...................................................................... 70
9.1.3 (MCZN module) ........................................................................................................................ 70
9.1.4 Zone work set-point (MCZN module) ........................................................................................... 71
9.1.5 Zone anti-freeze protection (MCZN module) ................................................................................. 73
9.1.6 "Heating/cooling integration" function (MCZN, MCDE modules) ....................................................... 73
9.2 egulation of the delivery temperature (MCZN, MCCT modules) ......................................................... 74
9.2.1 Management of the delivery circulation pumps (MCCT module) ...................................................... 74
9.2.2 Management of the utilities set-up for heating delivery water: boiler (and heat pump (MCCT module) . 75
9.2.3 Management of the utility set-up for cooling delivery water: the chiller (MCCT module) ..................... 76
9.2.4 Delivery work set-point (MCCT module) ....................................................................................... 76
9.2.5 Output of the delivery mixing valve (MCCT module) ...................................................................... 76
9.2.6 Mixing valve delivery work set-point (MCCT module) ..................................................................... 77
9.2.7 Dew point control (MCCT, MCZN modules) ................................................................................... 78
9.2.8 Control of the high and low delivery temperature (MCCT module) ................................................... 78
9.2.9 Delivery anti-freeze protection (MCDE module) ............................................................................ 79
9.3 egulation of the zone humidity (MCZN, MCCT, MCDE modules) ......................................................... 79
9.3.1 egulation principle .................................................................................................................. 79
9.3.2 Management of the dehumidification manifold/valve (MCZN module) .............................................. 79
9.3.3 Zone humidity work set-point (MCZN module) .............................................................................. 80
9.3.4 Management and configuration of the c-pro 3 hecto MCDE module for additional dehumidifiers (MCZN,
MCDE modules) .................................................................................................................................... 80
9.3.5 Management of the dehumidifiers on/off digital inputs ................................................................... 81
9.4 egulation of air quality (recirculation) (MCDE module) ..................................................................... 81
9.4.1 egulation principle .................................................................................................................. 81
9.4.2 Management the air circulation damper (MCDE module) ................................................................ 81
9.5 egulation of the DHW tank temperature for the DHW water (MCPS module) ....................................... 82
9.5.1 egulation principle .................................................................................................................. 82
9.5.2 Management of the DHW circuit circulation pump (MCPS module) ................................................... 82
9.5.3 DHW tank work set-point (MCPS module) With DHW setpoint mode ................................................ 83
9.5.4 Management of the AUX1 auxiliary circuit circulation pump (MCPS module) .................................... 84
9.5.5 Control of the high and low temperature of the auxiliary circuit AUX1 (MCPS module) ....................... 85
9.5.6 Management and setting of the periodic antilegionella cycle for the DHW tank (MCPS module) ........... 85
9.6 Management and configuration of the heating solar panel circuits (MCPS module) ................................ 86

Evco S.p.A. c-pro 3 CLIMA sistema | Installer manual ver.1.0 | Code 144CP3CSE104
page 6 of 92
9.6.1 With DHW setpoint.................................................................................................................... 86
9.6.2 con tipo setpoint pannelli ........................................................................................................... 87
9.6.3 Management of the solar panels circuits circulation ....................................................................... 87
9.6.4 (MCPS module) ........................................................................................................................ 87
9.6.5 Control of the high and low temperature of the solar panel circuits (MCPS module) ........................... 88
9.6.6 Management and setting the stagnation emergency for solar panels circuits (MCPS module) .............. 88
9.7 Other regulations .......................................................................................................................... 89
9.7.1 Management and setting of the periodic anti-grip cycle ................................................................. 89
9.7.2 (MCCT, MCPS modules) ............................................................................................................. 89
9.7.3 Management of the circulation pumps protection digital input ......................................................... 90
9.7.4 (MCCT, MCPS modules) ............................................................................................................. 90
9.7.5 Manual functioning mode ........................................................................................................... 90
9.7.6 (MCCT, MCZN, MCDE, MCPS modules) ......................................................................................... 90

Evco S.p.A. c-pro 3 CLIMA sistema | Installer manual ver.1.0 | Code 144CP3CSE104
page 7 of 92
1GENERALITIES
1.1 Description
The climatic modules of the c-pro 3 CLIMA sistema series are devices studied for the air conditioning and the heating
of buildings.
They make use of the programmable controllers belonging to the c-pro 3 series and of the user interfaces belonging
to the same series.
They are available in built-in and in blind version with remote user interface (according to the kind of module).
They can be powered both in alternating and in direct current (24 VAC/20... 40 VDC).
The modules allow realizing an expandable and modular control device network distributed in the main rooms of the
building reducing the wiring work to a minimum: the modules c-pro 3 hecto MCCT and c-pro 3 mega MCCT can
manage the thermal power plant, the c-pro 3 hecto MCZN ones the air conditioning and the heating of two zones
instead, the c-pro 3 hecto MCDE ones the dehumidifiers and the c-pro 3 hecto MCPS ones finally the thermal solar
panels.
Through the user interfaces it is possible to operate (with different modalities to access to the functions) on the
modules c-pro 3 hecto MCZN.
Some of them incorporate a temperature sensor or a temperature and humidity sensor (according to the model).
The user interfaces can easily be integrated in residential and commercial rooms (at the front of the interfaces it is
possible to apply the plates CPVP or the plates belonging to the series “Living” and to the series “Light” Bticino).
All the modules have communication ports (programming, CAN, S-485, with MODBUS communication protocol, etc.).
Through the programming port it is possible to make the upload and the download of the configuration parameters
(using the programming key EVKEY10); through the S-485 one, with MODBUS communication protocol, it is possible
to connect the devices to the set-up software system Parameters Manager or to the plants monitoring and supervision
one ICS (through a serial interface) instead.
Through the CAN communication port it is possible to connect the devices among them; through the use of the module
c-pro 3 mega MCCT it is finally possible to integrate the devices in systems using the BACnet MS/TP communication
protocol.

Evco S.p.A. c-pro 3 CLIMA sistema | Installer manual ver.1.0 | Code 144CP3CSE104
page 8 of 92
2APPLICATIONS

Evco S.p.A. c-pro 3 CLIMA sistema | Installer manual ver.1.0 | Code 144CP3CSE104
page 9 of 92
2.1 Application layouts
Below find the application layouts:

Evco S.p.A. c-pro 3 CLIMA sistema | Installer manual ver.1.0 | Code 144CP3CSE104
page 10 of 92
3INSTALLATION
Below we will show the dimensions, assembly and electric connections of the c-pro 3 CLIMA sistema, made up from
thermal power plant modules (MCCT), Zones (MCZN), Dehumidifiers (MCDE), solar panels (MCPS) and graphical
displays (Vroom).
3.1 Dimensions
3.1.1 Thermal power plant module dimensional drawing (MCCT).
3.1.2 Zone modules (MCZN), dehumidifier (MCDE) and solar panels
(MCPS) dimensional drawing.

Evco S.p.A. c-pro 3 CLIMA sistema | Installer manual ver.1.0 | Code 144CP3CSE104
page 11 of 92
3.1.3 Graphical display dimensional drawing (Vroom).
3.2 Assembly
3.2.1 Assembly of thermal power plant modules (MCCT), Zone
(MCZN), Dehumidifier (MCDE) and solar panels (MCPS)
To install the thermal power plant, zone, Dehumidifier and solar panels module, operate as indicated in the diagrams
(points 1 and 2).
To remove thermal power plant, zone, dehumidifier and solar panels module, use a screwdriver and operate as
indicated in the diagrams (points 3 and 4).

Evco S.p.A. c-pro 3 CLIMA sistema | Installer manual ver.1.0 | Code 144CP3CSE104
page 12 of 92
3.2.2 Display Assembly (Vroom)
There are three possibilities for assembly of the Vroom graphical display:
3.2.2.1 Wall recessed in 506E box
3.2.2.2 Wall-installation, on E co CPVW00 support
3.2.2.3 Panel installation

Evco S.p.A. c-pro 3 CLIMA sistema | Installer manual ver.1.0 | Code 144CP3CSE104
page 13 of 92
3.3 Electric connections
3.3.1 Thermal power plant electric connections (MCCT).

Evco S.p.A. c-pro 3 CLIMA sistema | Installer manual ver.1.0 | Code 144CP3CSE104
page 14 of 92
c-pro 3 mega Thermal power plant controller
I/O Description
Analogue inputs (NTC / 0-5V / 4-20mA)
A/I 1 CT External air temperature – NTC
A/I 2 CT Delivery temperature 1 – NTC
A/I 3 CT Delivery temperature 2 – NTC
A/I 4 CT Not used
A/I 5 CT Not used
Serial ports
Rs485 s485 modbus TU ( J45)
CANbus At the c-pro 3 CLIMA sistema
Digital inputs (ON-OFF poco erial-free contact)
D/I 1 CT Alarm (block) Boiler
D/I 2 CT Chiller – Heat pump alarm
D/I 3 CT Delivery pump 1 flow switch (and/or thermal switch)
D/I 4 CT Delivery pump 2 flow switch (and/or thermal switch)
D/I 5 CT Not used
D/I 6 CT ON-OFF remote
D/I 7 CT Summer/Winter
Analogue outputs (PWM / 0-10 V / 4-20mA)
A/O 2 CT Delivery 2 modulating valve control (0-10 V)
A/O 3 CT Delivery 1 modulating valve control (0-10 V)
Digital outputs (Relay)
D/O 1 CT Delivery 1 circulation pump
D/O 2 CT Delivery 2 circulation pump
D/O 3 CT Boiler
D/O 4 CT Chiller/Heat pump
D/O 5 CT Summer/winter
D/O 6 CT Alarm that can be configured

Evco S.p.A. c-pro 3 CLIMA sistema | Installer manual ver.1.0 | Code 144CP3CSE104
page 15 of 92
3.3.2 Thermal power plant electric connections (MCCT) hecto +
c-pro 3 hecto+ controllore centrale termica
I/O Description
Ingressi analogici (NTC / 0-5V / 4-20mA)
A/I 1 CT External air temperature – NTC
A/I 2 CT Delivery temperature 1 – NTC
A/I 3 CT Delivery temperature 2 – NTC
A/I 4 CT non utilizzato
Porte seriali
Rs485 S485 modbus TU (su J45)
CANbus Ai moduli c-pro 3 CLIMA sistema
Ingressi digitali (ON-OFF 24V)
D/I 1 CT Alarm (block) Boiler
Chiller – Heat pump alarm
D/I 2 CT Delivery pump 1 flow switch (and/or thermal switch)
D/I 3 CT Delivery pump 2 flow switch (and/or thermal switch)
D/I 4 CT ON-OFF remote
D/I 5 CT Summer/Winter
Uscite analogiche (PWM / 0-10 V / 4-20mA)
A/O 2 CT Delivery 2 modulating valve control (0-10 V)
A/O 3 CT Delivery 1 modulating valve control (0-10 V)
Uscite digitali (Relè)
D/O 1 CT Delivery 1 circulation pump
D/O 2 CT Delivery 2 circulation pump
D/O 3 CT Boiler
D/O 4 CT Chiller/Heat pump
D/O 5 CT Summer/winter
D/O 6 CT Alarm that can be configured

Evco S.p.A. c-pro 3 CLIMA sistema | Installer manual ver.1.0 | Code 144CP3CSE104
page 16 of 92
3.3.3 Zones electric connections (MCZN).
c-pro 3 hecto+ zones controller
I/O Description
Analogue inputs (NTC / 0-5V / 4-20mA)
A/I 1 ZN oom humidity Zone A (0-5 V or 4-20 mA)
Zone A remote setpoint (10 KOhm)
A/I 2 ZN oom humidity Zone B (0-5 V or 4-20 mA)
Zone B remote setpoint (10 KOhm)
A/I 3 ZN Temperature Zone A
A/I 4 ZN Temperature Zone B
Zone B remote setpoint (10KOhm)
Serial ports
TTL (485) s485 modbus TU ( J45)
CANbus At the c-pro 3 CLIMA sistema
Digital inputs (ON-OFF poco erial-free contact)
D/I 1 ZN Zone A dehumidifier alarm
D/I 2 ZN Zone B dehumidifier alarm
D/I 3 ZN Zone A ON-OFF
D/I 4 ZN Zone B ON-OFF
D/I 5 ZN Aux. thermostat
Digital outputs (Relay)
D/O 1 ZN Zone A Heating/Cooling manifolds
D/O 2 ZN Zone A dehumidifier manifold
D/O 3 ZN Zone A alarm
D/O 4 ZN Zone B Heating/Cooling manifolds
D/O 5 ZN Zone B dehumidifier manifold
D/O 6 ZN Zone B alarm

Evco S.p.A. c-pro 3 CLIMA sistema | Installer manual ver.1.0 | Code 144CP3CSE104
page 17 of 92
3.3.4 Dehumidifier electric connections (MCDE).
c-pro 3 hecto+ dehumidifier controller
I/O Description
Analogue inputs (NTC / 0-5V / 4-20mA)
A/I 1 DE Zone A dehumidifier input temperature
A/I 2 DE Zone B dehumidifier input temperatures
A/I 3 DE CO2 transducer (0-5 V or 4-20 mA)
A/I 4 DE Not used
Serial ports
TTL (485) s485 modbus TU ( J45)
CANbus At the c-pro 3 CLIMA sistema
Digital inputs (ON-OFF poco erial-free contact)
D/I 1 DE Zone A dehumidifier alarm
D/I 2 DE Zone B dehumidifier alarm
D/I 3 DE Zone A dehumidifier ON-OFF
D/I 4 DE Zone B dehumidifier ON-OFF
D/I 5 DE Not used
Digital outputs (Relay)
D/O 1 DE Dehumidifier (Type 1)
Zone A dehumidifier (Type 2)
D/O 2 DE Heating integration (Type 1)
Zone A heating/cooling integration (Type 2)
D/O 3 DE Cooling integration (Type 1)
Zone B dehumidifier (Type 2)
D/O 4 DE enew damper
Zone B heating/cooling integration (Type 2)
D/O 5 DE Zone A dehumidifier alarm
D/O 6 DE Zone B dehumidifier alarm

Evco S.p.A. c-pro 3 CLIMA sistema | Installer manual ver.1.0 | Code 144CP3CSE104
page 18 of 92
3.3.5 Solar panels electric connections (MCPS).
c-pro 3 hecto+ solar panels controller
I/O Description
Analogue inputs (NTC / 0-5V / 4-20mA)
A/I 1 PS DHW tank temperature (upper) (NTC)
A/I 2 PS DHW tank lower temperature (NTC)
A/I 3 PS Auxiliary temperature 1 (NTC)
Solar panel 2 temperature (4-20 mA).
A/I 4 PS Solar panel 1 temperature (4-20 mA).
Serial ports
TTL (485) s485 modbus TU ( J45)
CANbus At the c-pro 3 CLIMA sistema
Digital inputs (ON-OFF poco erial-free contact)
D/I 1 PS Solar panels 1 circuit pump (thermal) flow switch
D/I 2 PS Solar panels 2 circuit pump (thermal) flow switch
D/I 3 PS DHW circuit pump (thermal) flow switch
D/I 4 PS Auxiliary system circuit pump (thermal) flow switch
D/I 5 PS Not used
Digital outputs (Relay)
D/O 1 PS Solar panels 1 circuit pump
D/O 2 PS Solar panels 2 circuit pump
D/O 3 PS DHW circuit pump
D/O 4 PS Alarm (that can be configured)
D/O 5 PS Auxiliary 1 circuit pump
Anti-stagnation emergency (cover opening)
D/O 6 PS Anti-stagnation emergency (heat disposal/cover opening)
Anti-stagnation emergency (cover closing)

Evco S.p.A. c-pro 3 CLIMA sistema | Installer manual ver.1.0 | Code 144CP3CSE104
page 19 of 92
3.4 Regulators network configuration
The c-pro 3 CLIMA sistema is based on the CANbus communication between the various control modules present in
the network, with the following maximum configuration:
•N° 1 c-pro 3 mega MCCT thermal power plant regulator
•N° 8 c-pro 3 hecto MCZN zone regulators
•N° 8 regulators for additional c-pro 3 hecto MCDE dehumidifiers
•N° 1 regulator for c-pro 3 hecto MCPS solar panels
Every controller present in the network must be assigned with a different and specific CANbus address, according to
the logic position of the controller inside the c-pro 3 CLIMA sistema, following the layout given below:
Type of controller Controller code CANbus
address
Thermal power plant regulator c-pro 3 mega MCCT 1 (default)
Zone 1 regulator (zones 1-2) c-pro 3 hecto MCZN 2 (default)
Zone 2 regulator (zones 3-4) c-pro 3 hecto MCZN 3
Zone 3 regulator (zones 5-6) c-pro 3 hecto MCZN 4
Zone 4 regulator (zones 7-8) c-pro 3 hecto MCZN 5
Zone 5 regulator (zones 9-10) c-pro 3 hecto MCZN 6
Zone 6 regulator (zones 11-12) c-pro 3 hecto MCZN 7
Zone 7 regulator (zones 13-14) c-pro 3 hecto MCZN 8
Zone 8 regulator (zones 15-16) c-pro 3 hecto MCZN 9
egulator for dehumidif. associated to zone 1 regulator c-pro 3 hecto MCDE 22 (default)
egulator for dehumidif. associated to zone 2 regulator c-pro 3 hecto MCDE 23
egulator for dehumidif. associated to zone 3 regulator c-pro 3 hecto MCDE 24
egulator for dehumidif. associated to zone 4 regulator c-pro 3 hecto MCDE 25
egulator for dehumidif. associated to zone 5 regulator c-pro 3 hecto MCDE 26
egulator for dehumidif. associated to zone 6 regulator c-pro 3 hecto MCDE 27
egulator for dehumidif. associated to zone 7 regulator c-pro 3 hecto MCDE 28
egulator for dehumidif. associated to zone 8 regulator c-pro 3 hecto MCDE 29
egulator for solar panels c-pro 3 hecto MCPS 17 (default)
As highlighted in the previous table, the controllers are set by default to be automatically recognised in network as:
•thermal power plant regulator CANbus 1 address
•zone 1 regulator CANbus 2 address
•regulator for dehumidifiers
added, associated to zone 1 regulator CANbus 22 address
•regulator for solar panels CANbus 17 address

Evco S.p.A. c-pro 3 CLIMA sistema | Installer manual ver.1.0 | Code 144CP3CSE104
page 20 of 92
3.4.1 MCCT thermal power plant controller network configuration
As the thermal power plant controller is the logical centre of the system controlled, it is first necessary to set how
many MCZN zone regulators will be present in the system, following the procedure given below:
1. Enter the Installer  General parameters menu of the MCCT regulator
2. Set the total number of zones controlled and the number of MCZN zone regulators present in the system
3. To set the communication speed (125k suggested) go to the menu
Installer -> general parameters and modify the baud rate parameter.
3.4.2 MCZN zone controllers network configuration
The zone regulator leaves the factory configured as zone 1 regulator (therefore with CANbus 2 address).
Whenever it is necessary to install more than one zone controller in the system, it will be necessary to configure the
regulators present as zone regulators 2, 3, etc…up to a maximum of 8.
To change the network configuration of the MCZN zone controller network, follow the procedure below:
1. Connect a zone regulator to the CANbus network (leaving all of the other zone regulators disconnected from
the network);the controller connected will be recognised as zone 1 controller
2. Access the MCZN zone regulator application as shown in chapter 5.2.1
3. Enter the Installer  General parameters menu
4. Set the number of local zones managed by the MCZN regulator (1 or 2 local zones)
5. Set the number of the last zone regulator that is to be inserted in the system managed (e.g. zone 4 regulator).
6. The controller will automatically assume the appropriate CANbus address (address 25 for the regulator of zone
4)
7. epeat the operation, connecting the next to last zone controller to the CANbus network and so on, until the
first zone regulator is connected (zone 1 regulator).
Total number of zones controlled
Number of MCZN zone regulators
Number of local zones managed
Number of zone regulators in the
