EverFocus ENDEAVOR User manual

2
3
4
7
6
5
8
9
1
13
15
10
11 JOG/SHUTTLE: Shuttle (outer wheel): In playback mode, use the SHUTTLE for fast
forward / fast reverse playback.
JOG (inner wheel): In PAUSE mode, use the jog to move frame by frame. Within
menu functions, use the jog to adjust the values / parameters. Use Jog to highlight
individual cameras. Use either Shuttle or Jog to switch between MENU parameters.
ENDEAVOR SD+HD DVR Quick Reference Guide
Menu/ESC: Press this key to enter/exit MAIN SETUP MENU
Operating elements
System LED
POWER: LED indicating power on
HDD: LED indicating HDD active
Alarm: LED indicating Alarm active
Network: LED for network traffic
Record: LED indicating Record active
12
14
Copy: Press this key to enter Copy Menu
Channel keys 1~16 (1~8): Press channel key (CH1~CH16) to display that channel in
full screen view.
DVD Eject: Press this button to eject the DVD.
View: Press this key to switch between 4x, PiP (Picture In Picture),full screen, 6x, 7x,
8x, 9x, 10x, 13x and 16x.
SEQ: Press this key to enter the auto sequential switching mode. The sequence dwell
time can be set in “Display Setting” tab of the Menu.
Menu Navigation Keys: Instead of or in combination with a mouse, you can use these
keys to change the Menu settings.
Monitor: Switch between Main monitor and Call monitor (Function reserved).
Display: Press this key to switch display of channels and status bar.
Search: Press this key to enter Search Menu
DVD burner: DVD+RW burner
2
3
4
7
6
5
8
9
1
10
Express menu (manual chapter 4.2)
Camera menu (manual chapter 4.3)
Record & Play menu (manual chapter 4.4)
Alarm & event menu (manual chapter 4.5)
Schedule menu (manual chapter 4.6)
Network menu (manual chapter 4.7)
Disk menu (manual chapter 4.8)
Display menu (manual chapter 4.9)
System menu (manual chapter 4.10)
Information menu (manual chapter 4.11)
123456 7 8 9 10
Description of on-screen main menu (control bar)
Remote Control Receiver: Receiver for IR remote control
Zoom: In full screen mode, 2x and 4x electronic zoom. Zoom screen can be moved
through arrow keys. Pressing the zoom key again switches the electronic zoom off.
16 ►►/I►: Fast Forward playback or step forward playback depending on playback mode
17 ►/ I I: Forward playback or pause
18 ■
: Stop playback
P/N:4605XCHD16002AR
19
20
I I / ◄: Reverse playback or pause
◄I /◄◄: Fast reverse playback or step reverse playback depending on playback mode
21 USB ports: Use one port for connecting USB-Flash-Drive to copy/archive video or for
firmware upgrades. Use the other port for connecting the mouse.

ENDEAVOR SD+HD DVR Quick Reference GuideOperation
1. Analog & HD-CCTV Video input
DVR will auto detect system format (NTSC/PAL) based on CH1 analog camera input.
However, the resolution displayed from HD-CCTV is auto-detected by the HD-CCTV
camera being connected. To change the resolution of HD-CCTV camera, please reboot
the DVR to start a new auto detection.
2. Monitor display formats
The monitor allows full screen, picture-in-picture, 6x, 7x, 8x, 9x, 10x, 13x and 16x
multiscreen display (PiP in live mode only) as well as sequence view.
Display format switching
Repeated VIEW key actuation switches between the display formats mentioned above.
Full screen:
Select one of the channel keys 1 ~ 16 (1~8).
Sequence (automatic switch, available in live mode only)
Press the SEQ key to start / stop the automatic switching mode.
3. Menu start
Press the MENU key to access the main menu bar (front key no. 14). Control the menu
either through mouse or through the menu navigation keys (front keys no. 9) or through
the Jog/Shuttle (front keys no. 11).
4. Brightness – contrast – color
Brightness, contrast and color can individually be set for each video channel. Select the
camera menu (2nd icon) and enter the option “Video adjust“. Define the values by using
either the mouse, the arrow keys located around the ENTER key or the Jog/Shuttle. After
adjusting the values, exit the menu by either pressing the MENU key 3 times or
mouseclick on the cross in the menu bar (top right corner). (Not applicable to HDCCTV
Video)
5. Recording
Recording starts directly after the recorder has booted; there is no separate LED or
display.
6. Playback
Start the playback at the latest HDD playback position by pressing the PLAY key (Quick
Play function deactivated!).
Fast forward / reverse:
Use the „Fast Forward“ key to play video images forward / reverse with up to 32x speed
(1x,2x,4x,8x,16x,32x and >>> “minute steps“)
Pause:
Actuate ◄/ II or ►/IIto freeze the current playback position.
7. Playback search
Press the SEARCH key to enter the playback search menu.
From the menu on the left, choose the search method:
- Time search
Enter time and date of the requested recording position and click PLAY.
Upon successful search, the monitor automatically switches to playback mode and
playback starts at the requested position.
- Event search
Select time and date as well as the relevant camera(s). In the “Event“ row, select
the requested event type (alarm, motion, video loss and text) and confirm
your selection by clicking SEARCH. After the search, a list of available events is
displayed. Select the relevant event from the list and click PLAY.
The monitor automatically switches to playback mode and playback starts at the
selected position.
-Smart search
Select time and date as well as the relevant camera(s). Click “Grid Setting“ key to
edit motion grid setup. Confirm your selection by clicking SEARCH. After the search,
a list of available motion is displayed. Select the relevent motions from the list and
click PLAY. The monitor automatically switches to playback mode and playback starts
at the selected position.
-Snapshot search
Select among thumbnail images extracted from the recorded video at a user defined
interval, at a specific date and time, in response to various types of events. Confirm
your selection by clicking SEARCH. After the search, all the snapshots will be
displayed. The result gives user an efficient review of significant activities.
8. Archiving video data
To archive to USB, insert a USB stick into the USB socket at the front. To archive to
CD/DVD, insert the CD/DVD into the DVD+RW burner at the front . Press the COPY key
in live mode to display the context menu.
Enter start and end time of the video export as well as the camera number and press
COPY to start the video data export.
If requested, the player software can also be exported to the USB stick or CD/DVD by
activating the checkbox “Player“.
Exit the menu by either pressing the MENU key several times or mouseclick on the cross
in the menu bar (top right corner).
9. Everfocus Central Management Software
ENDEAVOR SD+HD DVR is supported by Everfocus Central Management Software.
Please visit Everfocus website at: http://www.everfocus.com to download the software.
