Everlast EV7000 Owner's manual

09/28/11
Important – Please read these instructions fully before assembly or using
These instructions contain important information which will help you get the best from your equipment and ensure
safe and correct assembly, use and maintenance.
If you need help or have damaged or missing parts, call the Customer Helpline: 0845 6000 464
335/8704
EV7000 Treadmill
Assembly & User Instructions - Please keep for future reference

2
Contents
Safety Information 3
Components - Parts 4
Components - Fixings 5
Assembly Instructiions 7-12
Computer Operation 13-15
Incline Adjustment 16
Folding Instructions 17
Care and Maintenance 18-19
Belt adjustment 18
Cleaning 19
Deck lubrication 19
Exercising Information 20-23
Before starting to exercise 20
Muscle chart 21
Warming up and cooling down exercises 22
Exploded Parts Diagram 24-30
Console 24
Upright Frame and Handle Bar 25
Motor Cover 26
Motor Cover Frame and Upright Cover 27
Walking Belt 28
Main Frame 29
Upright Cover and Handle Bar Cover 30
Exploded Diagram Parts List 31

3
Safety Information
To reduce the risk of serious injury, read the entire manual before you assemble or operate the Everlast Treadmill.
In particular, note the following safety precautions:
Important – Please read fully before assembly or using
Assembly
Using
• Check you have all the components and tools listed,
bearing in mind that, for ease of assembly, some
components are pre-assembled.
• Keep children and animals away from the work area,
small parts could choke if swallowed.
• Make sure you have enough space to layout the
parts before starting.
• Assemble the item as close to its final position (in
the same room) as possible.
• Position the equipment on a clear, level surface.
• Dispose of all packaging carefully and responsibly.
• Only one person at a time should use the
equipment.
• Keep hands away from all moving parts.
• Always wear appropriate workout clothing when
exercising. Do not wear loose or baggy clothing,
since it may get caught in the equipment. Wear
athletic shoes to protect your feet while exercising.
• Do not place any sharp objects around the
equipment.
• Disabled persons should not use the equipment
without a qualified person or doctor in attendance.
• This product is suitable for user’s weight of: 100kgs.
• This product conforms to: (BS EN957) - PARTS 1 &
6 class (H) - Home Use - Class (B).
• This exercise product has been designed and
manufactured to comply with the latest (BS EN 957)
British and European Safety Standards.
• It is the responsibility of the owner to ensure that all
users of this product are properly informed as to how
to use this product safely.
• This product is intended for domestic use only. Do
not use in any commercial, rental, or institutional
setting.
• Before using the equipment to exercise, always do
stretching exercises to properly warm up.
• If the user experiences dizziness, nausea, chest
pain, or other abnormal symptoms stop the workout
and seek immediate medical attention.
• Ensure that there is space behind your treadmill, 2
metres is recommended.
Warning: Before beginning any exercise program, consult your Doctor. This is especially important for
persons over the age of 35 or persons with pre-existing health problems. You MUST read all instructions before
using any fitness equipment. Argos and its associates assumes no responsibility for personal injury or property
damage sustained by or through the use of this product.

4
Main Frame Assembly x 1
507
Upright Cover - LL x 1
508
Upright Cover - LR x 1
509
Upright Cover - RL x 1
510
Upright Cover - RR x 1
214
Handle Bar Cover - Left 1 x 1
215
Handle Bar Cover - Left 2 x 1
217
Handle Bar Cover - Right 2 x 1
216
Handle Bar Cover - Right 1 x 1
103
Water Bottle Holder x 2
Components - Parts
Note: Some of the smaller components may be pre-fitted to larger components. Please check carefully before
contacting Argos regarding any missing components.
Please check you have all the parts listed below
If you have damaged or missing components,
call the Customer Helpline: 0845 6000 464

5
728
M8 x 45mm Bolt x 2
705
M8 x 42mm Bolt x 2
704
M8 x 18mm Bolt x 2
721
ø8 Washer x 4
701
M4 x 15mm Screw x 14
A
Allen Wrench x 1
B
Screwdriver x 1
E
Power Cord x 1
F
Safety Key x 1
G
Deck Lube x 1
Components - Fixings
Note: Some of the fixings are pre-fitted to the larger components. Please check carefully before contacting Argos
regarding any missing fixings.
Please check you have all the fixings listed below
Ruler - Use this ruler to help correctly identify the hardware
Note: Cut out this page to help fixing identification during assembly.

6

705
704
721
721
705
704
721
721
202
203
7
Assembly Instructions
a: Remove treadmill from carton and
place it on the oor in an open area.
Step 1
b: Attach the Upright-Left (202) and
Upright-Right (203) to the Base Frame
and secure in place using one M8 Bolt
(705) and two ø8 Washers (721), one
M8 Bolt (704).
Repeat this procedure on the Upright
- Right.
b:
b:

8
Assembly Instructions
Rotate the console upwards until it
stops, as shown in the drawing. Fix to
handlebar using 2 x Bolts (728).
Step 2

9
Assembly Instructions
Step 3
Attach the Upright Cover (507)
(508) (509) (510) onto the bottom of
upright by ø4 x 15mm Bolt (701) as
shown in the drawing.

10
Assembly Instructions
Attach Handlebar Covers (214, 215,
216,217) to top of uprights using 2 x
Screws (701) per cover.
Step 4

11
Assembly Instructions
Insert bottle holders (103) into the
computer housing.
Step 5

ON/OFF SWITCH
12
Assembly Instructions
Connecting to mains.
Step 6

13
Computer Operation
Functions and operations
BUTTON FUNCTIONS - This describes the button functions and should be read in
conjunction with computer operation.
START : Press to start exercise (initial speed 0.8 km/0.5 ml).
ENTER (MULTI FUNCTION)
1. Press to confirm program and preset function values under setting mode.
2. Press to quit preset program and function value after complete single program.
3. Setting procedure: returns to beginning of setting mode before pressing the START key.
STOP
Press to stop exercise during workout time.
SPEED UP / DOWN (MULTI FUNCTION)
1. Press to increase/decrease exercise speed by 0.1km/ml.
2. Hold the button to increase/decrease rapid speed by 0.5km/ml per second and release the button to stop the
function.
3. Press to select programs.
IMPORTANT
• The console display will turn itself off automatically after five minutes after the belt has stopped moving.
• The pulse function is for reference only, and not to be used for medical purposes.
SAFETY KEY
The safety key must be inserted into the slot on the console in order to operate the treadmill. Always insert the
safety key and attach the clip to your clothing waist before beginning your workout.
If you should encounter problems and need to stop the motor quickly, simply pull on the cord the disengage the
safety key from the console.

14
Computer Operation
Computer operation
QUICK START
After “power on” press start key to start exercise, use SPEED UP/DOWN keys to control belt speed.
PROGAM MODE
After “power on” P1 will ash in display, press SPEED UP/DOWN keys to select desired program, press ENTER key
to confirm selected program.
PROGARAM 1 – MANUAL
1. Press ENTER/MODE to confirm the program and press START key to start exercise.
2. Press ENTER/MODE before starting exercise to run presetting procedure, with P1 blinking.
TIME : Accumulates and displays workout time from start of exercise.
DISTANCE : Accumulates and displays workout distance from start of exercise.
CALORIES : Accumulates and displays calories consumed during workout time.
SPEED : Displays current speed.
PROGRAM 2 – TIME
1. Press ENTER/MODE to confirm the program.
2. Press ENTER/MODE before starting exercise to run presetting procedure, with P2 blinking.
3. Press SPEED UP/DOWN keys to preset the distance target values and press START
DISTANCE : Count down from preset target value automatically slows at end of program.
TIME : Accumulates and displays workout time from start of exercise.
CALORIES : Accumulates and displays calories consume during workout time.
SPEED : Displays current speed.
PROGRAM 3 – DISTANCE
1. Press ENTER/MODE to confirm the program and press START key to start exercise.
2. Press ENTER/MODE before starting exercise to run presetting procedure, with P3 blinking.
3. Press SPEED UP/DOWN keys to run preset time target value and press START.
TIME : Count down from preset target value automatically slows at end of program.
DISTANCE : Accumulates and displays workout distance from start of exercise.
CALORIES : Accumulates and displays calories consume during workout time.
SPEED : Displays current speed.
PROGRAM 4 – CALORIES
1. Press ENTER/MODE to confirm the program and press START key to start exercise.
2. Press ENTER/MODE before starting exercise to run presetting procedure, with P4 blinking.
3. Press SPEED UP/DOWN keys to run preset calories target value and press START.
CALORIES : Count down from preset target value automatically slows at end of program.
TIME : Accumulates and displays workout time from start of exercise.
DISTANCE : Accumulates and displays workout distance from start of exercise.
SPEED : Displays current speed.

15
Computer operation
PROGRAM 5 – 15 MINUTES PRESET SPEED
1. Press ENTER/MODE to confirm the program.
2. Press START key to start the exercise, or press ENTER/MODE before starting exercise to run preset procedure
with P5 blinking.
TIME : Accumulates and displays workout time from start of exercise.
DISTANCE : Accumulates and displays workout distance from start of exercise.
PULSE : Detects and displays current heart rate.
CALORIES : Accumulates and displays calories consume during workout time.
SPEED : Displays current speed.
PROGRAM 6 – 30MINUTES PRESET SPEED
1. Press ENTER/MODE to confirm the program.
2. Press START key to start exercise or press ENTER/MODE before starting exercise to run preset procedure with
P6 blinking.
TIME : Accumulates and displays workout time from start of exercise.
DISTANCE : Accumulates and displays workout distance from start of exercise.
PULSE : Detect and displays current heart rate.
CALORIES : Accumulates and displays calories consume during workout time.
SPEED : Displays current speed.
PROGRAM 7 – 45 MINUTES PRESET SPEED
Press ENTER/MODE to confirm the program. Press START key to start exercise or press ENTER/MODE before
starting exercise to run preset procedure with P7 blinking.
TIME : Accumulates and displays workout time from start of exercise.
DISTANCE : Accumulates and displays workout distance from start of exercise.
CALORIES : Accumulates and displays calories consume during workout time.
SPEED : Displays current speed.
SWITCHING BETWEEN PROGRAMS 5, 6, 7
If you want to switch program after you confirmed the program, press STOP key and re-initiate program selection
procedure.
Computer Operation

16
Incline level operation
The treadmill is designed with two level incline adjustment. To adjust the incline simply lift up the rear of the
treadmill, then rotate the elevation stabiliser to the desired level.
Incline Adjustment
Position for maximum incline level
Position for minimum incline level.

17
Folding and Unfolding Instructions
How to fold up the treadmill:
Your treadmill can be folded up for space saving storage. To do this follow the instructions here:
How to unfold the treadmill:
To unfold the treadmill for use follow the instructions here:
Folding Instructions
STEP FOOT RELEASE

18
How to maintain the momentum EV7000 treadmill:
Proper maintenance is very important to ensure your treadmill is always in top working condition. Improper
maintenance could cause damage or shorten the life of your treadmill and void the WARRANTY.
Important: Never use abrasives or solvents to clean the treadmill. To prevent damage to the computer, keep liquids
away and keep it out of direct sunlight.
Inspect and tighten all parts of the treadmill regularly. Replace any worn parts immediately.
BELT ADJUSTMENT:
Belt adjustment and tension performs two functions: adjustment for tension and centering. The running belt has
been adjusted properly at the factory. However transportation, uneven ooring or other unpredicted reasons could
cause the belt to shift off center resulting in the belt rubbing with the plastic side rail or end caps and possibly
causing damage. To adjust the belt back to it’s proper position please follow the directions below:
Belt has shifted to the left: First unplug the power cord from the surge protector. Using the hex key provided,
turn the left rear roller adjustment bolt 1/4 turn in the clockwise direction. Plug the power cord back into the surge
protector and run the treadmill at 2.5 mph. You should see the belt start to correct itself, moving back towards the
center. Repeat the above procedure until the walking belt is centered. It may be necessary to set walking belt
tension once you have completed this procedure if the belt feels like it is slipping while walking. Refer below to the
“Walking belt slipping” instructions.
Belt has shifted to the right: First unplug the power cord from the surge protector. Using the hex key provided,
turn the right rear roller adjustment bolt 1/4 turn in the clockwise direction. Plug the power cord back into the surge
protector and run the treadmill at 2.5 mph. You should see the belt start to correct itself, moving back towards the
center. Repeat the above procedure until the belt is centered. It may be necessary to set belt tension once you
have completed this procedure if the belt feels like it is slipping while walking. Refer below to the “Belt slipping”
instructions.
Belt is slipping: First unplug the power cord from the surge protector. Using the hex key provided, turn both the
left and right rear roller adjustment bolts the same distance, usually a 1/4 turn in the clockwise direction. Plug the
power cord back into the surge protector and run the treadmill at 2.5 mph. You should now walk on the belt to
determine if the belt is still slipping. Repeat the above procedure until the belt is not slipping. The tension should
be just tight enough not to slip.
WARNING! Do not over tighten rollers! This will cause premature roller bearing failure!
Right and left tension bolts are located at the rear of the treadmill.
Care and Maintainence

19
CLEANING:
Routine cleaning of your treadmill will extend the product’s life.
Warning : To prevent electrical shock, be sure the power to the treadmill is OFF and the power cord is
unplugged from the wall electrical outlet before attempting any cleaning or maintenance.
Important : Never use abrasives or solvents to clean the treadmill. To prevent damage to the computer,
keep liquids away and keep it out of direct sunlight.
After each workout : Wipe off the console and other treadmill surfaces with a clean, water dampened soft cloth to
remove excess perspiration.
Weekly : Vacuum underneath treadmill once a week as dirt from your shoes eventually makes it way
underneath the treadmill. Use of a treadmill mat is recommended.
DECK LUBRICATION:
The treadmill deck has been pre-lubricated at the factory. However, it is recommended that it is checked
periodically for lubrication to ensure optimal treadmill performance. Your treadmill should not have to be lubricated
usually within the first 400 hours of use.
Every 2 months of operation lift the sides of the walking belt and feel the top surface of the deck as far as you
can reach. If you feel signs of silicone, no further lubrication is required. If it feels dry to the touch, follow the
instructions below.
Please use a non-petroleum based silicone.
To apply lubricant to the deck:
1. Position the deck so that the seam is located on top and in center of the deck.
2. Insert the spray lube nozzle into the spray head of the lubricant bottle.
3. While lifting the side of the belt, position the spray nozzle between the belt and the board approximately 6” from
the front of the treadmill. Apply the silicone spray to the deck, moving from the front of the treadmill to the rear.
Repeat this on the other side of the belt.
Care and Maintainence
Spray lubricant from front to back.

20
Exercising Information
How you begin your exercise program depends on your physical condition. If you have been inactive for several
years, or are severely overweight, you must start slowly and increase your time on the equipment; a few minutes
per workout.
Initially, you may be able to exercise only for a few minutes in your target zone, however, your aerobic fitness will
improve over the next six to eight weeks. Don’t be discouraged if it takes longer. It’s important to work at your own
pace. Ultimately, you’ll be able to exercise continuously for 30 minutes. The better your aerobic fitness, the harder
you will have to work to stay in your target zone.
Please remember these essentials:
• Have your doctor review your training and diet programs to advise you of a workout routine you should adopt.
• Begin your training program slowly with realistic goals that have been set by you and your doctor.
• Monitor your pulse frequently. Establish your target heart rate based on your age and condition.
• Set up your equipment on a at even surface at least 3 feet from walls and furniture.
Exercise intensity
To maximize the benefits of exercising, it is important to exercise with the proper intensity. The proper intensity
level can be found by using your heart rate as a guide. For effective aerobic exercise, your heart rate should be
maintained at a level between 65% and 85% of your maximum heart rate as you exercise. This is known as your
target zone. You can find your target zone in the table below.
During the first few months of your exercise program, keep your heart rate near the low end of your target zone
as you exercise. After a few months, your heart rate can be increased gradually until it is near the middle of your
target zone as you exercise.
To measure your heart rate, stop exercising but continue moving your legs
or walking around and place two fingers on your wrist. Take a six-second
heartbeat count and multiply the results by 10 to find your heart rate. For
example, if your six-second heartbeat count is 14, your head rate is 140
beats per minute. (A six-seconds count is used because your heart rate will
drop rapidly when you stop exercising.) Adjust the intensity of your exercise
until your heart rate is at the proper level.
Before starting to exercise
80
100
120
140
160
180
200
Beats per minute (bpm)
25
Age
30 35 40 45 50 55 60 70
Cardiovascular
performance
Intermediate aerobic
Effective fat burning
Up to 55%
55% to 65%
65% to 85%
85% to Max
