EVERSPRING VC913 User manual

VC913 OUTDOOR IP CAMERA
General Introduction
The VC913 is an outdoor bullet IP camera suitable for monitoring outdoor areas around the home.
Main features
Weather proof housing to withstand long hours of outdoor operation
Powered by POE (Power-Over-Ethernet) for easy installation with option for DV12 adaptor
IR LED for clear night vision
H.265 encryption for efficient image compression
The Homesys cloud platform is required for using this camera.
Product Overview
Cables and connectors:
*Note : these wires are not used.
Powering up the camera
Method 1: By POE
Connect the camera‟s Ethernet connector to a cable from a POE-compatible equipment such as hub or
switch. Ensure that this cable provides access to internet.
Method 2: By DC adaptor (not provided)
1. Connect a 12V DC adaptor to the camera‟s DC jack. Note theAmpere and polarity of the DC adaptor
fits the power requirement shown on the camera‟s rating label.
2. Connect the camera‟s Ethernet connector to a router with internet access.
Binding with Homesys
1. Log into the Homesys account from a web browser.
2. Select “System”, then “Add a device”.
3. Select “Camera”.
4. Enter the Access Code found on a label on the camera and click “Next step”
5. The screen below will appear if the process is successful.
Camera lens
IR LED
Bracket
*Reset (Orange)
*Ground (Black)

Mounting the Unit
The camera can be mounted on a wall or ceiling.
1. Using the wrench supplied in the package, loosen the screw as indicated below. This will loosen the
ball joint lock of the bracket.
Note: for lock, and for unlock.
2. Fasten the bracket to the ceiling or wall using the supplied screws and wall fixings.
3. Adjust the desired angle of the camera then tighten the screw to lock its angle firmly in place.
4. Power on the camera and check the viewing angle.
Operation
Live video
1. To watch live video of the camera, go to LIVE to see a snapshot preview.
2. Click the snapshot image to view live video stream from the camera.
Playback recorded videos
1. To display recorded videos, go to VIDEO page.All videos are displayed with recording date and
video duration.
2. Click on any image to play the video.
3. During playback, it is possible to move forward and back the video by dragging the time bar, change
volume level, and display in full screen.
4. To download a copy of the video onto your PC, just click “Download Video”.

Troubleshooting
The troubleshooting table lists some possible causes and solutions. Please contact your original retailer
or nearest service center if the solutions below cannot solve your problem.
Symptom Possible Cause Recommendation
How to tell if camera is
turned on N/A A soft „click‟ sound can be heard when the camera is powered on
Camera is unreachable Internet connection not
available Check the internet connection of the cable connected to the
camera
Live view not working Local internet upload
speed not enough. Each camera requires at least 512kbit upload speed.
(Upload speed is different from
Download speed which is a
number usually marketed by
broadband providers)
Specifications
Operating Temperature Range -40°C ~ +50°C
Maximum operating Humidity 90% RH
Max. Image resolution 1920 x 1080 (1080P)
Image Encryption H.265 / H.264
View angle 89°(H), 46°(V)
IR LED range Up to 25m
Power supply POE (IEEE 802.3af) or
DC adaptor, 12V@1A
IP rating IP66
Specifications are subject to change without notice
Federal Communication Commission Interference Statement
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant
to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment generates uses and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that interference will not occur in
a particular installation. If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the user is encouraged to try to
correct the interference by one of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
- Consult the dealer or an experienced radio/TV technician for help.
FCC Caution:Any changes or modifications not expressly approved by the party responsible for
compliance could void the user's authority to operate this equipment.
This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter.
Radiation Exposure Statement:
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment.
This equipment should be installed and operated with minimum distance 20cm between the radiator &
your body.
Industry Canada statement:
This device complies with ISED‟s license-exempt RSSs. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause undesired operation.
Le présent appareil est conforme aux CNR d‟ ISED applicables aux appareils radio exempts de licence.
L‟exploitation est autorisée aux deux conditions suivantes : (1) le dispositif ne doit pas produire de
brouillage préjudiciable, et (2) ce dispositif doit accepter tout brouillage reçu, y compris un brouillage
susceptible de provoquer un fonctionnement indésirable.
Radiation Exposure Statement:
This equipment complies with ISED radiation exposure limits set forth for an uncontrolled environment.
This equipment should be installed and operated with minimum distance 20cm between the radiator &
your body.
Déclaration d'exposition aux radiations:
Cet équipement est conforme aux limites d'exposition aux rayonnements ISED établies pour un
environnement non contrôlé. Cet équipement doit être installé et utilisé avec un minimum de 20 cm de
distance entre la source de rayonnement et votre corps.
WARNING:
Do not dispose of electrical appliances as unsorted municipal waste, use separate collection facilities.
Contact your local government for information regarding the collection systems available.
If electrical appliances are disposed of in landfills or dumps, hazardous substances can leak into the
groundwater and get into the food chain, damaging your health and well-being.
When replacing old appliances with new ones, the retailer is legally obligated to take back your old
appliance for disposal at least for free of charge.
