evertz 570REM-RX8-10GE User manual

570REM-RX8-10GE
8x J2K Decoders Driving 2x UHD or
8x 3G SDI Inputs, 4x 10GbE SFP Cages
User Manual
© Copyright 2018
EVERTZ MICROSYSTEMS LTD.
5292 John Lucas Drive
Burlington, Ontario
Canada L7L 5Z9
Phone: [phone]
Sales: [e-mail] Fax: [phone]
Tech Support: [e-mail] Fax: [phone]
Web Page: http://www.evertz.com Twitter: @EvertzTV
Version 1.0, December 2018
The material contained in this manual consists of information that is the property of Evertz Microsystems and is intended solely for the use of
purchasers of the 570REM-RX8-10GE. Evertz Microsystems expressly prohibits the use of this manual for any purpose other than the operation of
the 570REM-RX8-10GE.
All rights reserved. No part of this publication may be reproduced without the express written permission of Evertz Microsystems Ltd. Copies of
this manual can be ordered from your Evertz dealer or from Evertz Microsystems.

This page left intentionally blank

IMPORTANT SAFETY INSTRUCTIONS
The lightning flash with arrowhead symbol within an
equilateral triangle is
intended to alert the user to the presence of uninsulated “Dangerous voltage”
within the product’s enclosure that may be of sufficient magnitude to constitute a
risk of electric shock to persons.
The exclamation point within an equilateral triangle is intended to alert the user
to the presence of important operating and maintenance (Servicing) instructions
in the literature accompanying the product.
•Read this information
•Keep these instructions.
•Heed all warnings.
•Follow all instructions.
•Do not use this apparatus near water
•Clean only with dry cloth.
•Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.
•Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus
(including amplifiers) that produce heat.
•Do not defeat the safety purpose of the polarized or grounding type plug. A polarized plug has two
blades with one wider than other. A grounding type plug has two blades and a third grounding prong.
The wide blade or the third prong is provided for your safety. If the provided plug does not fit into your
outlet, consult an electrician for replacement of the obsolete outlet.
•Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles
and the point where they exit from the apparatus.
•Only use attachments/accessories specified by the manufacturer
•Unplug this apparatus during lightning storms or when unused for long periods of time.
•Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been
damaged in any way, such as power-supply cord or plug is damaged, liquid has been spilled or objects
have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate
normally, or has been dropped.
WARNING
TO REDUCE THE RISK OF FIRE OR ELECTRIC –
SHOCK, DO NOT EXPOSE THIS APPARATUS
TO RAIN OR MOISTURE
WARNING
DO NOT EXPOSE THIS EQUIPMENT TO DRIPPING OR SPLASHING AND ENSURE THAT NO
OBJECTS FILLED WITH LIQUIDS ARE PLACED ON THE EQUIPMENT
WARNING
TO COMPLETELY DISCONNECT THIS EQUIPMENT FROM THE AC MAINS, DISCONNECT THE
POWER SUPPLY CORD PLUG FROM THE AC RECEPTACLE
WARNING
THE MAINS PLUG OF THE POWER SUPPLY CORD SHALL REMAIN READILY OPERABLE

INFORMATION TO USERS IN EUROPE
NOTE
This equipment with the CE marking complies with both the EMC Directive (89/336/EEC) and the Low
Voltage Directive (73/23/EEC) issued by the Commission of the European Community.
Compliance with these directives implies conformity to the following European standards:
•EN60065 Product Safety
•EN55103-1 Electromagnetic Interference Class A (Emission)
•EN55103-2 Electromagnetic Susceptibility (Immunity)
This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant
to the European Union EMC directive. These limits are designed to provide reasonable protection against
harmful interference when the equipment is operated in a commercial environment. This equipment
generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with
the instruction manual, may cause harmful interference to radio communications. Operation of this
equipment in a residential area is likely to cause harmful interference in which case the user will be
required to correct the interference at his own expense.
INFORMATION TO USERS IN THE U.S.A.
NOTE
FCC CLASS A DIGITAL DEVICE OR PERIPHERAL
This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant
to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference when the equipment is operated in a commercial environment. This equipment generates,
uses, and can radiate radio frequency energy and, if not installed and used in accordance with the
instruction manual, may cause harmful interference to radio communications. Operation of this equipment
in a residential area is likely to cause harmful interference in which case the user will be required to correct
the interference at his own expense.
WARNING
Changes or modifications not expressly approved by Evertz Microsystems Ltd. could void the user’s
authority to operate the equipment.
Use of unshielded plugs or cables may cause radiation interference. Properly shielded interface cables
with the shield connected to the chassis ground of the device must be used.

570REM-RX8-10GE
User manual
Revision 1.0
REVISION HISTORY
REVISION DESCRIPTION DATE
1.0
First Release
Dec 2018
Information contained in this manual is believed to be accurate and reliable. However, Evertz assumes no responsibility for the use thereof or
for the rights of third parties, which may be affected in any way by the use thereof. Any representations in this document concerning
performance of Evertz products are for informational use only and are not warranties of future performance, either expressed or implied. The
only warranty offered by Evertz in relation to this product is the Evertz standard limited warranty, stated in the sales contract or order
confirmation form.
Although every attempt has been made to accurately describe the features, installation and operation of this product in this manual, no
warranty is granted nor liability assumed in relation to any errors or omissions unless specifically undertaken in the Evertz sales contract or
order confirmation. Information contained in this manual is periodically updated and changes will be incorporated into subsequent editions. If
you encounter an error, please notify Evertz Customer Service department. Evertz reserves the right, without notice or liability, to make
changes in equipment design or specifications.

570REM-RX8-10GE
User Manual
Revision 1.0
This page left intentionally blank

570REM-RX8-10GE
User manual
Revision 1.0 Page i
TABLE OF CONTENTS
1. OVERVIEW...................................................................................................................................1
2. GETTIMG STARTED ....................................................................................................................3
2.1. REAR AND FRONT PLATE.................................................................................................3
2.2. CARE AND HANDELING OF OPTICAL FIBER...................................................................4
2.3. HARDWARE INSTALLATION .............................................................................................4
3. SPECIFICATIONS ........................................................................................................................5
3.1. SERIAL DIGITAL VIDEO.....................................................................................................5
3.2. SERIAL VIEDO INPUTS ......................................................................................................5
3.3. SERIAL VIDEO OUTPUT.....................................................................................................5
3.4. IP INPUT ..............................................................................................................................5
3.5. EMBEDDING OF HANC & VANC ........................................................................................5
3.6. ELECTRICAL.......................................................................................................................5
3.7. PHYSICAL (NUMBER OF SLOTS)......................................................................................5
3.8. ENCLOSURES.....................................................................................................................6
4. WEB INTERFACE.........................................................................................................................7
4.1. SYSTEM...............................................................................................................................9
4.1.1. Control Port Configuration.........................................................................................9
4.1.2. Data Port Configuration.............................................................................................9
4.1.3. Data Port Monitor ....................................................................................................10
4.1.4. SFP Monitor ............................................................................................................11
4.1.5. Temperature Monitor...............................................................................................11
4.1.6. Configuration Management .....................................................................................11
4.1.7. Time Management...................................................................................................12
4.1.8. Genlock...................................................................................................................12
4.1.9. Card Control............................................................................................................12
4.2. PRODUCT FEATURES......................................................................................................13
4.2.1. License Control .......................................................................................................13
4.2.2. Product Features Supported....................................................................................13
4.3. DIN OUTPUT CONTROL ...................................................................................................14
4.3.1. Output Control.........................................................................................................14
4.3.2. Synchronization Control ..........................................................................................14
4.3.3. Phase Adjustment ...................................................................................................14
4.3.4. Frame Sync Status..................................................................................................15
4.4. IP OUTPUT CONTROL......................................................................................................15
4.4.1. Configuration...........................................................................................................15
4.4.2. IP Output Control.....................................................................................................16
4.4.3. Audio Group 1-4 / ANC............................................................................................16
4.4.4. SMPTE 2110 RTP Payload Type ............................................................................16

570REM-RX8-10GE
User manual
Page ii Revision 1.0
4.5. IP INPUT CONTROL..........................................................................................................17
4.5.1. MPPM Control.........................................................................................................17
4.5.2. Input SFP Port Selection.........................................................................................18
4.5.3. Input Port Control....................................................................................................18
4.5.4. ARP Control............................................................................................................18
4.6. BREAKWAY AUDIO INPUT CONTROL............................................................................19
4.6.1. Breakaway Audio Control........................................................................................19
4.7. DECODER CONTROL.......................................................................................................20
4.7.1. Rx Input Monitor......................................................................................................21
4.7.2. Decoder Input program Control...............................................................................21
4.7.3. Manual PID Control.................................................................................................21
4.7.4. Jitter Tolerance........................................................................................................22
4.7.5. Codec Latency ........................................................................................................22
4.7.6. Decoder Reference PCR Control ............................................................................22
4.7.7. Decoder Lip Sync Control........................................................................................22
4.7.8. Decoder Control......................................................................................................22
4.8. RTP AND MASTER PCR CONTROL.................................................................................23
4.8.1. PTP and Master PCR Control..................................................................................23
4.8.2. PTP Control.............................................................................................................23
4.8.3. Master PCR Control ................................................................................................24
4.9. IP INPUT MONITOR...........................................................................................................25
4.9.1. Input Stream............................................................................................................25
4.9.2. Input IP Packet Monitor...........................................................................................26
4.9.3. IP Packet Drop Counter Clear.................................................................................26
4.9.4. Jitter Measurement..................................................................................................26
4.10. DECODER PROGRAM MONITOR ....................................................................................26
4.10.1. Internal Decoder Core.............................................................................................27
4.10.2. Program Video Monitor............................................................................................27
4.10.3. Program Descriptor Monitor.....................................................................................27
4.11. SYSTEM NOTIFY...............................................................................................................28
4.11.1. System Monitoring Control ......................................................................................28
4.11.2. System Notify..........................................................................................................28
4.12. DECODER NOTIFY............................................................................................................29
4.12.1. Decoder Notification................................................................................................29
5. FIRMWARE UPGRADE..............................................................................................................31

570REM-RX8-10GE
User manual
Revision 1.0 Page iii
FIGURES
Figure 1-1 : 570REM-RX8-10GE Block Diagram...........................................................................1
Figure 2-1 : 570REM Rear Plate....................................................................................................3
Figure 4-1 : WebEASY® - Login Menu ...........................................................................................7
Figure 4-2 : WebEASY® - 570REM-RX8-10GE Main Menu............................................................8
Figure 4-3 : WebEASY® - System (Part 1) .....................................................................................9
Figure 4-4 : WebEASY® - System (Part 2) ...................................................................................11
Figure 4-5 : WebEASY® - Product Features.................................................................................13
Figure 4-6 : WebEASY® - DIN Output Control..............................................................................14
Figure 4-7 : WebEASY® - IP Output Control.................................................................................15
Figure 4-8 : WebEASY® - IP Input Control ...................................................................................17
Figure 4-9 : WebEASY® - Breakaway Audio Input Control ...........................................................19
Figure 4-10 : WebEASY® - Decoder Control................................................................................20
Figure 4-11 : WebEASY® - RTP and Master PCR Control ...........................................................23
Figure 4-12 : WebEASY® - IP Input Monitor.................................................................................25
Figure 4-13 : WebEASY® - Decoder Program Monitor .................................................................26
Figure 4-14 : WebEASY® - System Notify....................................................................................28
Figure 4-15 : WebEASY® - Decoder Notify...................................................................................29
Figure 5-1 : WebEASY® - Upgrade Button on Top Menu Bar.......................................................31
Figure 5-2 : WebEASY® - Firmware Upgrade Menu.....................................................................31
Figure 5-3 : WebEASY® - Firmware Upgrade Menu\Selecting Firmware File...............................32

570REM-RX8-10GE
User manual
Page iv Revision 1.0
This page left intentionally blank

570REM-RX8-10GE
User manual
Revision 1.0 Page 1
1. OVERVIEW
The 570REM-RX8-10GE is a high performance multi-channel JPEG2000 decoding platform. The
exceptional density of the 570REM-RX8-10GE enables up to 8x channels of 3G, HD/SDI, SD/SDI or up
to 2x channels of UHD JPEG2000 decoding. The 570REM-RX8-10GE provides 2x SDI outputs for
every JPEG2000 decode.
The 570REM-RX8-10GE incorporates patent-pending multi-path, multi-flow packet merge base network
bit error resilience for 100% QoS.
The 570REM-RX8-10GE can be managed via integrated HTTP web interface as well as SNMP
management via Frame Controller.
Features & Benefits
•8x 3G/HD/SD or 2x UHD JPEG2000 decodes with 2xSDI decoded outputs per JPEG2000
decode
•Standards supported: 3840x2160p/59.94/50 (Quad Division or 2SI), 1080p/59.94/50 Level A,
1080i/59.94/50, 720p/59.94/50, 625i/50 and 525i/59.94
•Support VSF TR-01 v2
•4x groups of audio on SDI output
•Full VANC de-encapsulation and embedding on SDI outputs
•Modules support control over frame controller or direct Ethernet interface. SNMP control from
VISTALINK PRO or MAGNUM Unified Control
•Built-in frame sync to lock output video to Genlock
Figure 1-1 : 570REM-RX8-10GE Block Diagram

570REM-RX8-10GE
User manual
Page 2 Revision 1.0
This page left intentionally blank

570REM-RX8-10GE
User manual
Revision 1.0 Page 3
2. GETTING STARTED
The 570REM-RX8-10GE modules come with a companion rear plate and occupy two slots in 570FR.
2.1. REAR AND FRONT PLATE
The rear plate of 570REM-RX8-10GE is equipped with 20 Mini-Din connectors.
Figure 2-1 : 570REM Rear Plate
The front plate of 570REM-RX8-10GE has 12 available SFP slots. These SFP slots can be populated
with SFP10G-TR13-A.

570REM-RX8-10GE
User manual
Page 4 Revision 1.0
2.2. CARE AND HANDELING OF OPTICAL FIBER
The transmission characteristics of the fiber are dependent on the shape of the optical core and
therefore care must be taken to prevent fiber damage due to heavy objects or abrupt fiber bending.
Evertz recommends that the user maintains a minimum bending radius of 5 cm to avoid fiber-bending
loss that will decrease the maximum attainable distance of the fiber cable. The Evertz fiber optic
modules come with cable lockout devices, to prevent the user from damaging the fiber by installing a
module into a slot in the frame that does not have a suitable I/O module.

NOTE: Never touch the end face of an optical fiber. Always keep dust caps on optical
fiber connectors when not connected and always remember to properly clean the optical
end face of a connector before making a connection.
2.3. HARDWARE INSTALLATION
To successfully install the 570REM-RX8-10GE, the following is required:
1. 570 Series Frame
2. 570 Frame Controller
3. WebEASY® using the 570FC frame controller with 570REM-RX8-10GE installed in frame.
Before handling the card it is important to minimize the potential effects of static electricity. It is
therefore recommended that an ESD strap be worn.
Locate on the chassis 2 adjacent vacant slots. Unpack the 570REM-RX8-10GE and separate the rear
panel from the main card. Locate on the rear of the rack the two slots and remove the blanking panels.
Insert the rear panel into the back of the chassis and secure using the four screws provided.
Now insert the 570REM-RX8-10GE card into the corresponding front slots ensuring the card lines up
with the slot runners on the bottom and the top of the chassis. Push the card firmly into the slot
ensuring that when it mates with the rear card it has been firmly pushed into a seated position. Do not
connect any cables to the rear card (failure to do this could cause unwanted network issues) until the
initial configuration has been completed.
This procedure can be completed to all the other modules and is hot swappable allowing for the frame
to be powered on while installing.

570REM-RX8-10GE
User manual
Revision 1.0 Page 5
3. SPECIFICATIONS
3.1. SERIAL DIGITAL VIDEO
Standards:
•SMPTE 424M (3Gb/s)
•SMPTE 292M (1.5Gb/s)
•SMPTE 259M (270Mb/s)
3.2. SERIAL VIEDO INPUTS
Number of Inputs Not Applicable
Input Equalization NA
Return Loss NA
3.3. SERIAL VIDEO OUTPUT
Number of Outputs 16x SDI
Connector DIN
Rise and Fall Time Per SMPTE spec
3.4. IP INPUT
Ethernet Interface 4 x 10GE SFP/SFP+
Ethernet/IP Signaling Multicast IGMP V2/V3 (SSM Support)
3.5. EMBEDDING OF HANC & VANC
•4x Groups Audio Pass-through per encoder
•All type of VANC data pass-through
3.6. ELECTRICAL
Power 90W
Voltage 12VDC
EMI/RFI Complies with FCC Part 15, Class A, EU EMC directive
3.7. PHYSICAL (NUMBER OF SLOTS)
570FR 2
S570FR 2

570REM-RX8-10GE
User manual
Page 6 Revision 1.0
3.8. ENCLOSURES
570FR 3RU Chassis
S570FR 1RU Chassis
Ordering Information
570REM-RX8-10GE: 8x J2K Decoders driving 2x UHD or 8x 3G/HD/SD SDI output, 4x 10GbE SFP
Cages (SFP+ sold separately)
SFP Modules:
•SFP10G-TR13-A 10GbE Optical SFP+
•SFP10G-TR85-A SFP+ Optical Transceiver, 10Gbs, 850nm, MMF

570REM-RX8-10GE
User manual
Revision 1.0 Page 7
4. WEB INTERFACE
The 570REM-RX8-10GE series of products are controlled using Web Interface. WebEasy operates
using Ethernet and SNMP control protocols.
Login
After the card has been installed and configured with the required network addresses, it can be
completely configured using the web interface. For doing this, simply type the IP address of the control
port of the 570REM-RX8-10GE module in the web browser.
Note: Computer must be on the same Subnet in order to have communication with the module.
Figure 4-1 : WebEASY® - Login Menu
Login and password is “root” and “evertz” respectively.
On the web interface there are several different types of menus highlighted in Figure 4-2.

570REM-RX8-10GE
User manual
Page 8 Revision 1.0
Figure 4-2 : WebEASY® - 570REM-RX8-10GE Main Menu

570REM-RX8-10GE
User manual
Revision 1.0 Page 9
4.1. SYSTEM
Figure 4-3 : WebEASY® - System (Part 1)
Card Alias: This parameter indicates the card alias string.
4.1.1. Control Port Configuration
IP Address: This parameter allows the user to set IP address for control port.
Netmask: This parameter allows the user to set Netmask for control port.
Gateway: This parameter allows the user to set Gateway for control port.
4.1.2. Data Port Configuration
For SFPP 1-6:
IP Address: This parameter allows the user to set the IP address for Data port.
Netmask: This parameter allows the user to set the Netmask for Data Port.
Gateway: This parameter allows the user to set the Gateway for Data Port.

570REM-RX8-10GE
User manual
Page 10 Revision 1.0
Mac Address: This parameter reflects the Mac address for Data Port.
4.1.3. Data Port Monitor
Port Link Status: This parameter indicates the link status for Data port.
Received Data Ethernet Total Bitrate: This parameter indicates bitrate which is received on this
Ethernet port, unit is kbps.
Transmitted Data Ethernet Total Bitrate: This field indicates bitrate transmitted on this output
Ethernet port, unit is kbps.
Rx Frame Count: This parameter indicates received Rx frames on this Ethernet port.
Rx CRC Error Frame Count: This field indicates received Rx frames with CRC errors on this Ethernet
port.
Rx Undersized Frame Count: This field indicates received Rx undersized frames on this Ethernet
port.
Tx Frame Count: This parameter indicates received Tx frames on this Ethernet port.
Tx Oversized Frame Count: This field indicates received Tx oversized frames on this Ethernet port.
Clear Status: This button allows the user to clear all the status of Data Port monitor.
